• Routinely check www.driveuconnect.com (U.S. Resi-

dents) or www.driveuconnect.ca (Canadian Residents)
to learn about available Uconnect software updates.

• Only connect and use trusted media devices (e.g.

personal mobile phones, USBs, CDs).

Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Data Collection & Pri-
vacy” in your Uconnect Owner’s Manual Supplement or
“Onboard Diagnostic System (OBD II) Cybersecurity” in
“Getting To Know Your Instrument Panel”.

UCONNECT SETTINGS

The Uconnect system uses a combination of buttons on the
touchscreen and buttons on the faceplate located on the
center of the instrument panel that allows you to access
and change the customer programmable features.

CAUTION!

Do NOT attach any object to the touchscreen, doing so
can result in damage to the touchscreen.

Uconnect 4 Buttons On Touchscreen And Buttons On

Faceplate

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

MULTIMEDIA

445

NOTE:

Interior trims may vary. 6.4L vehicles will receive a

“SRT” switch rather than a “Sport” switch on the Instru-
ment Panel.

Customer Programmable Features — Uconnect 4
Settings

Press the “Settings” button on the bottom bar, or press the
“Apps

” button, then press the “Settings” button on

the touchscreen to display the menu setting screen.
In this mode the Uconnect system allows you to access
all of the available programmable features.

NOTE:

Depending on the vehicle’s options, feature set-

tings may vary.

When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting “option” until
a check-mark appears next to the setting, showing that
setting has been selected. Once the setting is complete,
press the “X” button on the touchscreen to close out of the
settings screen. Pressing the Up or Down Arrow button on
the right side of the screen will allow you to toggle up or
down through the available settings.

The following tables list the settings that may be found
within the Uconnect 4 radio, along with the selectable
options pertaining to each setting.

Uconnect 4C/4C NAV Buttons On Touchscreen And

Buttons On Faceplate

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

446

MULTIMEDIA

Display

After pressing the “Display” button on the touchscreen,
you may select from the available settings displayed in the
instrument cluster display, and navigation system (if
equipped). The following selectable units of measure are
listed below:

Setting Name

Selectable Options

Display Mode

Auto

Manual

Display Brightness With

Headlight ON

–

Display Brightness With

Headlights OFF

–

Set Language

English

Français

Español

NOTE:
When the “Set Language” feature is selected, you may select one of multiple languages (English/Français/Español)
for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the “Set
Language” button on the touchscreen, then press the desired language button on the touchscreen until a check-mark
appears next to the language, showing that setting has been selected.

Touchscreen Beep

Off

MULTIMEDIA

447

Units

After pressing the “Units” button on the touchscreen you
may select each unit of measure independently displayed
in the instrument cluster display, and navigation system
(if equipped). The following selectable units of measure are
listed below:

Setting Name

Selectable Options

Units

Metric

Custom

Speed

MPH

km/h

Distance

Fuel Consumption

MPG (US)

MPG (UK)

L/100 km

km/L

Pressure

psi

kPa

bar

Temperature

°F

°C

Voice

After pressing the “Voice” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Voice Response Length

Brief

Detailed

Show Command List

Always

With Help

Never

448

MULTIMEDIA

Clock & Date

After pressing the “Clock & Date” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Sync Time With GPS —

If Equipped

Off

NOTE:
The “Sync Time With GPS” feature will allow you to automatically have the radio set the time.

Set Time

–

Set Format

12 hour

24 hour

Set Date

Up Arrow

Down Arrow

NOTE:
When in this display, you may set the date manually. Press the “Set Date” button on the touchscreen then press the
corresponding arrows above and below the current date to adjust.

MULTIMEDIA

449

Safety/Assistance

After pressing the “Safety/Assistance” button on the
touchscreen, the following settings will be available:

Setting Name

Selectable Options

Forward Collision Warning

On/Off — If Equipped

Off

NOTE:
Changing the FCW status to “Off” prevents the system from warning you of a possible collision with the vehicle in
front of you.
The FCW system state is kept in memory from one ignition cycle to the next. If the system is turned off, it remains
off when the vehicle is restarted.

Forward Collision Warning

Sensitivity — If Equipped

Near

Far

NOTE:
The Forward Collision Warning (FCW) feature provides an audible and/or visual warning to potential forward colli-
sions. The feature can be set to Far, or set to Near. The default status of FCW is the Far setting. This means the sys-
tem warns you of a possible collision with the vehicle in front of you when you are farther away. This gives you the
most reaction time. To change the setting for more dynamic driving, select the Near setting. This warns you of a pos-
sible collision when you are much closer to the vehicle in front of you.

450

MULTIMEDIA

Setting Name

Selectable Options

Forward Collision Warning (FCW)

— Active Braking — If Equipped

Off

NOTE:
The FCW system includes Advanced Brake Assist (ABA). When this feature is selected, the ABA applies additional
brake pressure when the driver requests insufficient brake pressure to avoid a potential frontal collision. The ABA
system becomes active at 5 mph (8 km/h). To make your selection, press the “Forward Collision Warning Active
Braking” button on the touchscreen, until a check-mark appears next to setting, indicating that the setting had been
selected.

LaneSense Warning — If Equipped

Early

Medium

Late

NOTE:
When the “LanseSense Warning” feature is selected, it sets the distance at which the steering wheel provides feedback
for potential lane departures. The LDW sensitivity can be set to provide either an “Early,” “Medium,” or “Late”
warning zone start point.

LaneSense Strength — If Equipped

Low

Medium

High

NOTE:
When the “LaneSense Strength” feature is selected, it sets the strength of the steering wheel feedback for potential
lane departures.

MULTIMEDIA

451

Setting Name

Selectable Options

Electric Power Steering Default —

If Equipped

Normal

Sport

Comfort

NOTE:
When

⬙Electric Power Steering Default⬙ is selected, it allows you to change the default setting of your vehicle to either

normal, sport, or comfort.

ParkSense — If Equipped

Sound

Sound & Display

NOTE:
The ParkSense system scans for objects behind the vehicle when the transmission gear selector is in REVERSE and the
vehicle speed is less than 11 mph (18 km/h). It provides an alert (audible and/or visual) to indicate the proximity to
other objects. The system can be enabled with Sound, or Sound & Display.

Rear ParkSense Chime Volume —

If Equipped

Low

Med

High

ParkView Backup Camera Active

Guidelines

Off

NOTE:
Your vehicle may be equipped with the ParkView Rear Back Up Camera Active Guidelines that allows you to see
active guidelines over the ParkView Back up camera display whenever the gear selector is put into REVERSE.
The image will be displayed on the radio touchscreen display along with a caution note to “check entire surround-
ings” across the top of the screen. After five seconds, this note disappears.

452

MULTIMEDIA

Setting Name

Selectable Options

ParkView Backup Camera Delay

Off

NOTE:
When the vehicle is shifted out of REVERSE (with camera delay turned off), the rear camera mode is exited and the
navigation or audio screen appears again. When the vehicle is shifted out of REVERSE (with camera delay turned
on), the rear view image with dynamic grid lines will be displayed for up to ten seconds after shifting out of “RE-
VERSE” unless the forward vehicle speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK or the
ignition is switched to the off position. To set the ParkView Backup Camera Delay press the “Controls” button on the
touchscreen, the “settings” button on the touchscreen, then the “Safety & Assistance” button on the touchscreen.

Blind Spot Alert — If Equipped

Off

Lights

Lights & Chime

NOTE:

• When the feature “Blind Spot Alert” is selected, the Blind Spot Alert feature Provides alerts, visual and/or audible,

to indicate objects in your blind spot. The Blind Spot Alert feature can be activated in “Lights” mode. When this
mode is selected, the Blind Spot Monitor (BSM) system is activated and only shows a visual alert in the exterior
mirrors. When “Lights & Chime” mode is activated, the Blind Spot Monitor (BSM) shows a visual alert in the exte-
rior mirrors as well as an audible alert when the turn signal is on. When “Off” is selected, the Blind Spot Monitor
(BSM) system is deactivated.

• If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not

damaged, the sensor may have become misaligned. Take your vehicle to an authorized dealer to verify sensor
alignment. Having a sensor that is misaligned results in the BSM not operating to specification.

MULTIMEDIA

453

Setting Name

Selectable Options

Hill Start Assist — If Equipped

Off

NOTE:
When the “Hill Start Assist” feature is selected, the Hill Start Assist (HSA) system is active. To enable or disable,
press the “Hill Start Assist” button on the touchscreen, and select “On” or “Off.”

Lights

After pressing the “Lights” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Headlight Off Delay

NOTE:
When the “Headlight Off Delay” feature is selected, it allows the adjustment of the amount of time the headlights
remain on after the engine is shut off. To change the Headlight Off Delay setting, press the “Headlight Off Delay”
button on the touchscreen and choose either “0,” “30,” “60,” or “90” buttons on the touchscreen to select your desired
time interval.

454

MULTIMEDIA

Setting Name

Selectable Options

Headlight Illumination On

Approach

NOTE:
When the “Headlight Illumination On Approach” feature is selected, it allows the adjustment of the amount of time
the headlights remain on when the doors are unlocked with the key fob. To change the Illuminated Approach status,
press the “Illuminated Approach” button on the touchscreen and choose either “0,” “30,” “60,” or “90” buttons on the
touchscreen to select your desired time interval.

Headlights With Wipers —

If Equipped

Off

NOTE:
When the “Headlights With Wipers” feature is selected, and the headlight switch is in the AUTO position, the head-
lights will turn on approximately ten seconds after the wipers are turned on. The headlights will also turn off when
the wipers are turned off, if they were turned on by this feature.

Daytime Running Lights —

If Equipped

Off

NOTE:
When the “Daytime Running Lights” feature is selected, the headlights will turn on whenever the engine is running.

MULTIMEDIA

455

Setting Name

Selectable Options

Flash Lights With Lock

Off

NOTE:
When the “Flash Lights With Locks” feature is selected, the exterior lights will flash when the doors are locked or
unlocked with the key fob. This feature may be selected with or without the sound horn on lock feature selected.

Doors & Locks

After pressing the “Doors & Locks” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Auto Door Locks — If Equipped

Off

Auto Unlock On Exit

Off

Flash Lights With Lock

Off

NOTE:
When this feature is selected, the exterior lights flashes when the doors are locked or unlocked with the key fob.
This feature may be selected with or without the sound horn on lock feature selected.

Sound Horn With Lock

Off

1st Press

2nd Press

Sound Horn With Remote Start

Off

456

MULTIMEDIA

Setting Name

Selectable Options

1st Press of Key Fob Unlocks

All

Driver

NOTE:
This feature allows you to program your remote door locks to open “All doors” or only the “Driver door” with the
first push of the key fob or grabbing the Passive Entry door handle.

Passive Entry — If Equipped

Off

NOTE:
This feature allows you to lock and unlock the vehicle’s door(s) without having to push the key fob lock or unlock
buttons. It automatically unlocks the doors when the outside door handle is grabbed.

Personal Settings Linked To Key

Fob — If Equipped

Off

NOTE:

• This feature provides automatic recall of all settings stored to a memory location (driver’s seat, exterior mirrors,

steering column position and radio station pre-sets) to enhance driver mobility when entering and exiting the
vehicle.

• The seat returns to the memorized seat location (if Personal Settings Linked to Key Fob is set to on) when the key

fob is used to unlock the door.

MULTIMEDIA

457

Engine Off Options
After pressing the “Engine Off Options” button on the
touchscreen, the following settings will be available:

Setting Name

Selectable Options

Headlight Off Delay

Engine Off Power Delay

0 sec

5 mins

45 sec

10 mins

NOTE:
When this feature is selected, the power window switches, radio, Uconnect phone system (if equipped), DVD video
system (if equipped), power sunroof (if equipped), and power outlets remain active for up to ten minutes after the
ignition is cycled to OFF. Opening either front door cancels this feature.

Compass Settings — If Equipped
After pressing the “Compass Settings” button on the
touchscreen, the following settings will be available:

NOTE:

Before compass calibration is performed, the com-

pass variance zone should be set for best results.

Setting Name

Selectable Options

Compass Variance

NOTE:
When the “Compass Variance” feature is selected, it allows the compass variance to be set to any number from 1 to
15 per the compass variance zone map figure.

458

MULTIMEDIA

Setting Name

Selectable Options

Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differ-
ences, the variance should be set for the zone where the vehicle is being driven, illustrated in the zone map. Once
properly set, the compass will automatically compensate for the differences when calibrated, and provide the most
accurate compass headings.

Compass Variance Zone Map

MULTIMEDIA

459

Compass Calibration

Yes

NOTE:
Press “Compass Calibration” on the touchscreen to enter calibration. To start calibration of the compass, press the
“Yes” button on the touchscreen and complete one or more 360-degree turns (in an area free from large metal or
metallic objects). A message will appear on the touchscreen when the compass has been successfully calibrated.
Keep magnetic materials away from the rear view mirror, such as Mobile Phones, Laptops and Radar Detectors.
This is where the compass module is located, and it can cause interference with the compass sensor, and it may give
false readings.

Audio

After pressing the “Audio” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Equalizer

NOTE:
When in the “Equalizer” display you may adjust the Bass, Mid and Treble settings. Adjust the settings with the “+”
and “–” buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the
touchscreen.

460

MULTIMEDIA

Dodge Charger (2019 year). Manual - part 28
