• Carefully follow the instructions that come with the

restraint. If you install the restraint improperly, it may
not work when you need it.

• Buckle the child into the seat according to the child

restraint manufacturer’s directions.

• When your child restraint is not in use, secure it in the

vehicle with the seat belt or remove it from the vehicle.
Do not leave it loose in the vehicle. In a sudden stop or
collision, it could strike the occupants or seatbacks and
cause serious personal injury.

LATCH — Child Seat Anchorage System (Lower
Anchors and Tether for CHildren)
Your vehicle’s rear seat is equipped with the child
restraint anchorage system called LATCH. The LATCH
system provides for the installation of the child restraint
without using the vehicle’s seat belts, instead securing

the child restraint using lower anchorages and upper
tether straps from the child restraint to the vehicle
structure.

LATCH-compatible child restraint systems are now avail-
able. However, because the lower anchorages are to be
introduced over a period of years, child restraint systems
having attachments for those anchorages will continue to
have features for installation using the vehicle’s seat
belts. Child restraints having tether straps and hooks for
connection to the top tether anchorages, have been
available for some time. For some older child restraints,
many child restraint manufacturers offer add-on tether
strap kits or retrofit kits. You are urged to take advantage
of all the available attachments provided with your child
restraint in any vehicle.

All three rear-seating positions have lower anchorages
that are capable of accommodating LATCH-compatible

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

child seats. You should NEVER install LATCH-compat-
ible child seats so that two seats share a common lower
anchorage. If installing child seats in adjacent rear-
seating positions, or if your child restraints are not
LATCH-compatible, install the restraints using the vehi-
cle’s seat belts.

Installing the LATCH-Compatible Child Restraint
System
We urge you to follow the manufacturer’s directions
carefully when installing your child restraint. Not all
child restraint systems will be installed as described here.
Again, carefully follow the installation instructions that
are provided with the child restraint system.

The rear seat lower anchorages are round bars
located at the rear of the seat cushion where it
meets the seatback and are just visible when
you lean into the rear seat to install the child

restraint. You will easily feel them if you run your finger
along the intersection of the seatback and seat cushion
surfaces.

In addition, there are tether strap anchorages
behind each rear seating position located in the
panel between the rear seatback and the rear

LATCH Anchorages

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

window. These tether strap anchorages are under a
plastic cover with this symbol on it.

Many, but not all restraint systems will be equipped with
separate straps on each side, with each having a hook or
connector for attachment to the lower anchorage and a
means of adjusting the tension in the strap. Forward-
facing toddler restraints and some rear-facing infant
restraints will also be equipped with a tether strap, a
hook for attachment to the tether strap anchorage and a
means of adjusting the tension of the strap.

You will first loosen the adjusters on the lower straps and
on the tether strap so that you can more easily attach the
hooks or connectors to the vehicle anchorages. Next,
attach the lower hooks or connectors over the top of the
seatcover material. Then rotate the tether anchorage
cover directly behind the seat where you are placing the
child restraint and attach the tether strap to the anchor-
age, being careful to route the tether strap to provide the

most direct path between the anchor and the child
restraint. Finally, tighten all three straps as you push the
child restraint rearward and downward into the seat,
removing slack in the straps according to the child
restraint manufacturer’s instructions.

NOTE:

• Ensure that the tether strap does not slip into the

opening between the seatbacks as you remove slack in
the strap.

• When using the LATCH attaching system to install a

child restraint, please ensure that all seat belts not
being used for occupant restraints are stowed and out
of reach of children. It is recommended that before
installing the child restraint, buckle the seat belt so the
seat belt is tucked behind the child restraint and out of
reach. If the buckled seat belt interferes with the child
restraint installation, instead of tucking the seat belt
behind the child restraint, route the seat belt through

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

the child restraint belt path and then buckle it. This
should stow the seat belt out of the reach of an
inquisitive child. Remind all children in the vehicle
that the seat belts are not toys and should not be
played with, and never leave your child unattended in
the vehicle.

WARNING!

Improper installation of a child restraint to the
LATCH anchorages can lead to failure of an infant or
child restraint. The child could be badly injured or
killed. Follow the manufacturer’s directions exactly
when installing an infant or child restraint.

Installing Child Restraints Using the Vehicle Seat
Belt
The passenger seat belts are equipped with either cinch-
ing latch plates or automatic locking retractors, which are
designed to keep the lap portion tight around the child

restraint so that it is not necessary to use a locking clip.
Pulling up on the shoulder portion of the lap/shoulder
belt will tighten the belt. The cinching latch plate will
keep the belt tight; however, any seat belt system will
loosen with time, so check the belt occasionally and pull
it tight if necessary.

The seat belt must be in the Automatic Locking Mode in
order to enable a child restraint to be tightly installed.
Refer to “Automatic Locking Mode” in this section. A
locking clip should not be necessary once the automatic
locking feature is enabled. Position the shoulder and lap
belt on the child restraint. The automatic locking retractor
is activated by first attaching the child seat, then pulling
all of the webbing out of the retractor, then allowing the
webbing to retract back into the retractor. Tighten web-
bing. To release, simply unbuckle the seat belt by de-
pressing the button, allowing the webbing to retract into
the retractor.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

In the rear seat, you may have trouble tightening the
lap/shoulder belt on the child restraint because the
buckle or latch plate is too close to the belt path opening
on the restraint. Disconnect the latch plate from the
buckle and twist the short buckle end belt several times
to shorten it. Insert the latch plate into the buckle with the
release button facing out.

If the belt still cannot be tightened, or if pulling and
pushing on the restraint loosens the belt, you may need
to do something more. Disconnect the latch plate from
the buckle, turn the buckle around, and insert the latch
plate into the buckle again. If you still cannot make the
child restraint secure, try a different seating position.

To attach a child restraint tether strap:

1. Rotate the cover over the anchor directly behind the
seat where you are placing the child restraint.

2. Route the tether strap to provide the most direct path
for the strap between the anchor and the child seat.

3. Attach the tether strap hook (A) of the child restraint to
the anchor (B) and remove slack in the tether strap
according to the child restraint manufacturer’s instruc-
tions.

Tether Strap Mounting

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:

Ensure that the tether strap does not slip into the

opening between the seatbacks as you remove slack in
the strap.

WARNING!

An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchor positions directly behind
the child seat to secure a child restraint top tether
strap.

Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.

Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.

ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the drivetrain
(engine, transmission, and rear axle) in your new vehicle.

Drive moderately during the first 500 mi (800 km). After
the initial 60 mi (100 km), speeds up to 50 or 55 mph (80
or 90 km/h) are desirable.

While cruising, brief full-throttle acceleration within the
limits of local traffic laws contributes to a good break-in.
However, wide-open throttle acceleration in low gear can
be detrimental and should be avoided.

The engine oil, transmission fluid, and axle lubricant
installed at the factory is high-quality and energy-
conserving. Oil, fluid, and lubricant changes should be
consistent with anticipated climate and conditions under
which vehicle operations will occur. The recommended
viscosity and quality grades is shown in Section 7.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

CAUTION!

Never use Non-Detergent Oil or Straight Mineral Oil
in the engine or damage may result.

NOTE:

A new engine may consume some oil during its

first few thousand miles (kilometers) of operation. This
should be considered a normal part of the break-in and
not interpreted as an indication of difficulty.

SAFETY TIPS

Transporting Passengers
NEVER TRANSPORT PASSENGERS IN THE CARGO
AREA.

WARNING!

• It is extremely dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seri-
ously injured or killed.

• Do not allow people to ride in any area of your

vehicle that is not equipped with seats and seat
belts.

• Be sure everyone in your vehicle is in a seat and

using a seat belt properly.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Exhaust Gas

WARNING!

Exhaust gases can injure or kill. They contain carbon
monoxide (CO), which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow these safety tips:

Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in or
out of the area.

If it is necessary to sit in a parked vehicle with the engine
running, adjust your heating or cooling controls to force
outside air into the vehicle. Set the blower at high speed.

If you are required to drive with the trunk/liftgate open,
make sure that all windows are closed and the climate
control BLOWER switch is set at high speed. DO NOT
use the recirculation mode.

The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine exhaust
system.

Whenever a change is noticed in the sound of the exhaust
system, when exhaust fumes can be detected inside the
vehicle, or when the underside or rear of the vehicle is
damaged, have a competent mechanic inspect the com-
plete exhaust system and adjacent body areas for broken,
damaged, deteriorated, or mispositioned parts. Open
seams or loose connections could permit exhaust fumes
to seep into the passenger compartment. In addition,
inspect the exhaust system each time the vehicle is raised
for lubrication or oil change. Replace as required.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Safety Checks You Should Make Inside the
Vehicle

Seat Belts
Inspect the belt system periodically, checking for cuts,
frays, and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.

Front seat belt assemblies must be replaced after a
collision. Rear seat belt assemblies must be replaced after
a collision if they have been damaged (i.e., bent retractor,
torn webbing, etc.). If there is any question regarding belt
or retractor condition, replace the belt.

Airbag Warning Light
The light should come on and remain on for six to eight
seconds as a bulb check when the ignition switch is first
turned ON. If the light is not lit during starting, see your
authorized dealer. If the light stays on, flickers, or comes
on while driving, have the system checked by an autho-
rized dealer.

Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield. See your
authorized dealer for service if your defroster is
inoperable.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Periodic Safety Checks You Should Make Outside
the Vehicle

Tires
Examine tires for excessive tread wear and uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect the tread and sidewall for
cuts and cracks. Check the wheel nuts for tightness.
Check the tires (including spare) for proper pressure.

Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.

Door Latches
Check for positive closing, latching, and locking.

Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil, or other fluid leaks. Also, if gasoline
fumes are detected or if fuel, power steering fluid, or
brake fluid leaks are suspected, the cause should be
located and corrected immediately.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CONTENTS

䡵 Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

▫ Automatic Dimming Mirror . . . . . . . . . . . . . 75
▫ Outside Mirrors

. . . . . . . . . . . . . . . . . . . . . 76

▫ Outside Mirrors Folding Feature

. . . . . . . . . 76

▫ Power Mirrors

. . . . . . . . . . . . . . . . . . . . . . 77

▫ Heated Mirrors — If Equipped

. . . . . . . . . . 77

▫ Illuminated Vanity Mirrors

. . . . . . . . . . . . . 78

▫ Slide-On-Rod And Extender Features Of Sun

Visor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

䡵 uconnect威 phone — If Equipped . . . . . . . . . . . 79

▫ Operation

. . . . . . . . . . . . . . . . . . . . . . . . . 81

▫ Phone Call Features

. . . . . . . . . . . . . . . . . . 89

▫ uconnect威 phone Features . . . . . . . . . . . . . . 92
▫ Advanced Phone Connectivity . . . . . . . . . . . 97
▫ Things You Should Know About Your

uconnect

威 phone . . . . . . . . . . . . . . . . . . . . . . 99

▫ General Information

. . . . . . . . . . . . . . . . . 107

䡵 Voice Recognition (VR) System —

If Equipped . . . . . . . . . . . . . . . . . . . . . . . . . . 107

▫ Voice Recognition (VR) System Operation . . 107
▫ Commands

. . . . . . . . . . . . . . . . . . . . . . . 109

▫ Voice Training

. . . . . . . . . . . . . . . . . . . . . 112

䡵 Seats

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

▫ Easy Entry Seats . . . . . . . . . . . . . . . . . . . . 112
▫ Power Seats . . . . . . . . . . . . . . . . . . . . . . . 113
▫ Manual Front Seatback Recline

. . . . . . . . . 114

▫ Lumbar Support . . . . . . . . . . . . . . . . . . . . 115
▫ Head Restraints

. . . . . . . . . . . . . . . . . . . . 115

▫ Heated Seats

. . . . . . . . . . . . . . . . . . . . . . 116

▫ Folding Rear Seat . . . . . . . . . . . . . . . . . . . 117

䡵 To Open And Close The Hood

. . . . . . . . . . . 118

䡵 Lights

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

▫ Headlight Switch

. . . . . . . . . . . . . . . . . . . 120

▫ Automatic Headlights . . . . . . . . . . . . . . . . 120
▫ Headlights On With Wipers

(Available With Auto Headlights Only) . . . . . 121

▫ Headlight Time Delay . . . . . . . . . . . . . . . . 121
▫ Daytime Running Lights — If Equipped . . . 122
▫ Lights-On Reminder . . . . . . . . . . . . . . . . . 122
▫ Fog Lights . . . . . . . . . . . . . . . . . . . . . . . . 122
▫ Multifunction Lever

. . . . . . . . . . . . . . . . . 123

▫ Overhead Console Map/Reading Lights . . . 124
▫ Interior Lights

. . . . . . . . . . . . . . . . . . . . . 124

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

䡵 Windshield Wipers And Washers

. . . . . . . . . 125

▫ Intermittent Wiper System . . . . . . . . . . . . . 126
▫ Mist Feature . . . . . . . . . . . . . . . . . . . . . . . 127
▫ Windshield Washers

. . . . . . . . . . . . . . . . . 127

▫ Headlights On With Wipers

(Available With Auto Headlights Only) . . . . . 127

䡵 Tilt/Telescoping Steering Column . . . . . . . . . 128
䡵 Electronic Speed Control

. . . . . . . . . . . . . . . 129

▫ To Activate

. . . . . . . . . . . . . . . . . . . . . . . 130

▫ To Set A Desired Speed . . . . . . . . . . . . . . . 130
▫ To Deactivate . . . . . . . . . . . . . . . . . . . . . . 130
▫ To Resume Speed . . . . . . . . . . . . . . . . . . . 131
▫ To Vary The Speed Setting . . . . . . . . . . . . . 131

▫ To Accelerate For Passing

. . . . . . . . . . . . . 131

䡵 Overhead Console . . . . . . . . . . . . . . . . . . . . 132

▫ Courtesy/Reading Lights

. . . . . . . . . . . . . 133

▫ Sunglasses Storage

. . . . . . . . . . . . . . . . . . 133

䡵 Garage Door Opener

. . . . . . . . . . . . . . . . . . 133

▫ Programming HomeLink威 . . . . . . . . . . . . . 135
▫ Gate Operator/Canadian Programming

. . . 137

▫ Using HomeLink威

. . . . . . . . . . . . . . . . . . 138

▫ Reprogramming A Single

HomeLink

威 Button . . . . . . . . . . . . . . . . . . . 138

▫ Security . . . . . . . . . . . . . . . . . . . . . . . . . . 138
▫ Troubleshooting Tips . . . . . . . . . . . . . . . . . 139
▫ General Information

. . . . . . . . . . . . . . . . . 139

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

䡵 Power Sunroof — If Equipped

. . . . . . . . . . . 140

▫ Opening Sunroof — Partially . . . . . . . . . . . 141
▫ Opening Sunroof — Express

. . . . . . . . . . . 141

▫ Closing Sunroof — Partially

. . . . . . . . . . . 141

▫ Closing Sunroof — Express

. . . . . . . . . . . . 141

▫ Pinch Protect Feature

. . . . . . . . . . . . . . . . 141

▫ Pinch Protect Override

. . . . . . . . . . . . . . . 142

▫ Venting Sunroof — Express . . . . . . . . . . . . 142
▫ Sunshade Operation

. . . . . . . . . . . . . . . . . 142

▫ Wind Buffeting . . . . . . . . . . . . . . . . . . . . . 142
▫ Sunroof Maintenance

. . . . . . . . . . . . . . . . 142

▫ Ignition Off Operation

. . . . . . . . . . . . . . . 142

▫ Sunroof Fully Closed

. . . . . . . . . . . . . . . . 143

䡵 Electrical Power Outlets . . . . . . . . . . . . . . . . 143
䡵 Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . 145

▫ Front Cupholders . . . . . . . . . . . . . . . . . . . 145
▫ Rear Cupholders

. . . . . . . . . . . . . . . . . . . 146

䡵 Console Features . . . . . . . . . . . . . . . . . . . . . 146

▫ Sliding Center Console Armrest . . . . . . . . . 146
▫ Console Storage

. . . . . . . . . . . . . . . . . . . . 147

䡵 Rear Window Features . . . . . . . . . . . . . . . . . 148

▫ Rear Window Defroster . . . . . . . . . . . . . . . 148

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS

Automatic Dimming Mirror
This mirror automatically adjusts for headlight glare
from vehicles behind you. You can turn the feature on or
off by pressing the button at the base of the mirror. A light
next to the button will illuminate to indicate when the
dimming feature is activated.

CAUTION!

To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.

Automatic Dimming Mirror

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Dodge Challenger SRT8 (2009 year). Manual - part 4
