BRAKE WEAR SENSOR-LEFT FRONT

CAV

CIRCUIT

FUNCTION

1

16BR

GROUND

2

16BR/WT

BRAKE WEAR SENSOR SIGNAL

BRAKE WEAR SENSOR-LEFT REAR

CAV

CIRCUIT

FUNCTION

1

16BR

GROUND

2

16BR/WT

BRAKE WEAR SENSOR SIGNAL

BRAKE WEAR SENSOR-RIGHT FRONT

CAV

CIRCUIT

FUNCTION

1

16BR

GROUND

2

16BR/WT

BRAKE WEAR SENSOR SIGNAL

BRAKE WEAR SENSOR-RIGHT REAR

CAV

CIRCUIT

FUNCTION

1

16BR

GROUND

2

16BR/WT

BRAKE WEAR SENSOR SIGNAL

C100 - (MAIN BODY SIDE)

CAV

CIRCUIT

1

18BK/BL

2

18RD/DG

3

16WT/BL/RD

4

-

5

16RD

6

16BK

7

16BK/BL

8

14BK/VT

9

-

10

-

8W - 80 - 12

8W-80 CONNECTOR PIN-OUTS

VA

C100 - BLACK (MAIN BODY)

CAV

CIRCUIT

1

18BK/BL

2

18RD/DG

3

16WT/BL/RD

4

-

5

16RD

6

16BK

7

16BK/BL

8

14BK/VT

9

-

10

-

C101 - YELLOW (ENGINE SIDE)

CAV

CIRCUIT

1

16WT/BL

2

14BK/YL

3

16BL/DG

4

16BK/RD

C101 - YELLOW (MAIN BODY SIDE)

CAV

CIRCUIT

1

20BL

2

12BK/YL

3

16BL/DG

4

16BK/RD

C102 (EXCEPT OBD) - (ENGINE SIDE)

CAV

CIRCUIT

A

18WT/BL

B

-

VA

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 13

C102 (EXCEPT OBD) - (GENERATOR SIDE)

CAV

CIRCUIT

A

18WT/BL

B

-

C103 (OBD) - (GENERATOR SIDE)

CAV

CIRCUIT

1

18WT/BL

2

14BK/YL

3

-

4

-

5

-

6

16YL/RD

C103 (OBD) - (MAIN BODY)

CAV

CIRCUIT

1

20BL

2

12BK/YL

3

-

4

-

5

-

6

16YL/RD

C200 - BLACK (DASH SIDE)

CAV

CIRCUIT

1

16GY

2

16GY/DG

3

16BK/YL

4

16DG/BL/WT

5

16YL/BK

6

16BL/RD

7

16BK/RD

8

16WT/BK

9

16WT/DG

10

16WT/YL

11

16WT/RD

12

16BK/RD

13

16VT/YL

14

16BR/WT

15

16YL

16

16BR/WT

17

16GY/RD

18

16BK/YL/DG

19

16BK/YL

20

-

21

-

22

-

8W - 80 - 14

8W-80 CONNECTOR PIN-OUTS

VA

C200 - BLACK (MAIN BODY SIDE)

CAV

CIRCUIT

1

16GY

2

16GY/DG

3

16BK/YL

4

16DG/BL/WT

5

16YL/BL

6

16BL/RD

7

16BK/RD

8

16WT/BK

9

16WT/DG

10

16WT/YL

11

16WT/RD

12

16BK/RD

13

18VT/YL

14

16BR/BK

15

16YL

16

16BR/WT

17

16GY/RD

18

16BK/YL/DG

19

16BK/YL

20

-

21

-

22

-

C201 - (DASH SIDE)

CAV

CIRCUIT

1

-

2

16GY/DG/RD

3

16RD/BL

4

20BL/VT

4

16RD/YL/WT

5

16VT/WT

6

20BL/RD/WT

7

16BK/RD

8

16RD/YL

9

18BK/RD

10

18BK/BL

11

16YL

12

-

13

16RD

14

-

15

18RD/BK

16

-

17

-

18

-

VA

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 15
