P2074-MAP/TPS CORRELLATION - HIGH AIRFLOW/VACUUM LEAK DETECTED (CONTINUED) 5. EXCESSIVE RESISTANCE IN THE (F855) 5-VOLT SUPPLY CIRCUIT Turn the ignition off. Disconnect the TP Sensor harness connector. Disconnect the C2 PCM harness connector. CAUTION: Do not probe the PCM harness connectors. Probing Is the resistance below 5.0 ohms? Yes >> Go To 6 No >> Repair the excessive resistance in the (F855) 5-volt Sup- ply circuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer 6. (F855) 5-VOLT SUPPLY CIRCUIT SHORTED TO GROUND Measure the resistance between ground and (F855) 5-volt Supply cir- Is the resistance below 100 ohms? Yes >> Repair the short to ground in the (F855) 5-volt Supply cir- cuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer No >> Go To 7 9 - 802 ENGINE - ELECTRICAL DIAGNOSTICS - 3.7L/4.7L/5.7L DR/DH |
