CAUTION: Do not use coolant additives that are claimed to improve engine cooling.
Do not remove the radiator cap to add coolant to the system. When adding coolant to maintain the correct level, do
so only at the reserve/overflow bottle. Remove the radiator cap only for testing or when refilling the system after
service. Removing the cap unnecessarily can cause loss of coolant and allow air to enter the system, which pro-
duces corrosion.
WARNING: DO NOT REMOVE OR LOOSEN THE RADIATOR CAP WITH THE COOLING SYSTEM HOT AND
UNDER PRESSURE. SERIOUS BURNS FROM THE COOLANT OR HIGH PRESSURE STEAM CAN OCCUR.
SPECIFICATIONS
TORQUE
DESCRIPTION
N·m
Ft. Lbs.
In. Lbs.
Bolt - Automatic Belt Tensioner to Block
41
30
-
Bolt - Automatic Belt Tensioner Pulley
61
45
-
Bolt - Automatic Belt Tensioner Pulley - Diesel
43
32
-
Engine Mounted Fan Shroud Brackets (Upper and Lower)
24
18
-
Fan Shroud Ring to Fan Shroud Brackets
24
18
-
Bolt - Block Heater
2
-
17
Bolts - Generator/Compressor Mounting Bracket
# 1 and 2
54
40
-
# 3
40
30
-
Bolts - Generator/Compressor Mounting Bracket - Diesel
24
18
-
Bolts - Fan Shroud to Radiator Mounting - All Except 5.9L
Diesel
6
-
55
5.9L Diesel
11.8
-
105
Bolts - Radiator to Support
8.5
-
75
Bolts - Fan Blade to Viscous Fan Drive
24
18
-
Fan Drive - All Except 8.0L/5.9L Diesel
50
37
-
8.0L/5.9L Diesel
115
85
-
Bolt - Idler Pulley
54
40
-
Bolt - Idler Pulley - Diesel
43
32
-
Bolts - Thermostat Housing - All Except 5.9L Diesel
13
-
112
Bolts - Thermostat Housing 5.9L
23
16
-
Bolts - Thermostat Housing - Diesel
10
-
89
Bolts - Power Steering Oil Cooler
8.4
-
75
Bolts - Transmission Auxiliary Oil Cooler
6
-
55
Nuts - Transmission Oil Cooler Tube
31.5
24
-
Bolts - Coolant Bottle
8.5
-
75
Tube Nuts - Transmission Oil Cooler to Transmission
5.9L/46RE
31.5
24
-
3.7L/4.7L/5.7L/45RFE
20
18
-
Bolts - Water Pump - Diesel
24
18
-
Bolts - Water Pump - 4.7L
58
43
-
Block Heater - Diesel
75
55
-
Transmission Oil Cooler - Diesel
M8
24
18
-
M12
77
57
-
7 - 22
COOLING
DR/DH
