MODE 2 OVERCURRENT (DUAL-ZONE) (CONTINUED) 8. RUN THE ACTUATOR CIRCUIT TEST Reconnect the A/C Heater Control C1 harness connector. Turn the ignition on. With the DRBIII T in HVAC, select System Tests and then select Actuator Circuit Test. Allow the test to run to com- pletion before proceeding. Does the DRBIII T display any Actuator Circuit Test fault messages? Yes >> Diagnose and repair the fault(s). Refer to *ACTUATOR CIRCUIT TEST DIAGNOSTICS (DUAL-ZONE) in this section. No >> Replace the A/C Heater Control in accordance with the Service Information. Perform BODY VERIFICATION TEST - VER 1. (Refer to 8 - ELECTRICAL/ELECTRONIC CONTROL 24 - 88 HVAC - ELECTRICAL DIAGNOSTICS DR/DH |
