RIGHT FRONT ISOLATION SOLENOID SHORTED - 43 (CONTINUED) For a complete wiring diagram Refer to Section 8W. • When Monitored: • Set Condition: Possible Causes INTERMITTENT BATTERY VOLTAGE LOW DTC FUSED RUN RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE FUSED B+ CIRCUIT OPEN OR HIGH RESISTANCE FUSED B+ CIRCUIT SHORTED TO FUSED IGNITION SWITCH OUTPUT CIRCUIT GROUND CIRCUIT OPEN OR HIGH RESISTANCE CONTROLLER ANTI-LOCK BRAKE Diagnostic Test 1. DTC IS ACTIVE Turn the ignition on. With the DRBIII T , erase DTCs. Turn the ignition off. Start the engine. With the DRBIII T read DTCs. Does the DTC reset? Yes >> Go To 2 No >> Go To 6 5 - 160 BRAKES - ABS - ELECTRICAL DIAGNOSTICS DR/DH |
