TORQUE SPECIFICATIONS
DESCRIPTION
N·m
Ft. Lbs.
In. Lbs.
Fitting, cooler line at trans
17.5
-
155
Bolt, torque converter
31
23
-
Bolt, Torque Converter
Housing
68
50
-
Bolt/nut, crossmember
68
50
-
Bolt, driveplate to
crankshaft
75
55
-
Bolt, oil pan
11.8
-
105
Screw, primary fluid filter
4.5
-
40
Bolt, oil pump
28.2
-
250
Bolt, oil pump body to
cover
4.5
-
40
Screw, plate to oil pump
body
4.5
-
40
Bolt, valve body to case
11.8
-
105
Plug, pressure test port
5.1
-
45
Bolt, reaction shaft support
11.8
-
105
Screw, valve body to
transfer plate
5.6
-
50
Screw, solenoid module to
transfer plate
5.7
-
50
Screw, accumulator cover
7
-
60
Screw, detent spring
4.5
-
40
Bolt, input speed sensor
11.8
-
105
Bolt, output speed sensor
11.8
-
105
Bolt, line pressure sensor
11.8
-
105
Bolt, extension housing
54
40
-
Valve, cooler return filter
bypass
4.5
-
40
Screw, manual valve cam
retaining
4.5
-
40
Bolt, manual lever
28.2
-
250
21 - 740
AUTOMATIC TRANSMISSION 545RFE - SERVICE INFORMATION
ND
