TRANSFER CASE (PART TIME 4408) 5D1-35 Companion Flange 1. Install the 2 plugs to the cover. 2. Install the companion flange, oil seal and washer. 3. Holding the companion flange, tighten the nut. 1 Nut 2 Washer 3 Oil Seal 4 Companion Flange 5 Plug 25 Cover Notice Apply Loctite 262 to nut before installation. Tightening Torque 346 - 380 Nm |
