REAR DRIVE AXLE 3D-3
Checks
Worn or Damaged Tooth of Pinion or Side Gear
Worn Pinion Shaft
Excessive Backlash of Pinion Gear and Side Gear
Excessive End-play of Rear Axle Shaft
Incorrect Contact of Side Gear and Differential Case
Axle Housing Crack
Bent or Poor Installation of Drive Pinion Oil Seal
Damaged or Torn Drive Pinion Oil Seal
Loosened Bearing Collar
Worn or Damaged Universal Joint
Worn or Damaged Axle Shaft Bearing
Checks
Excessive Oil
Faulty Seal of Carrier Contact Surface
Axle Housing Crack
Worn or Damaged Oil Seal
Checks
Lack of Oil
Low Viscosity of Oil
Insufficient Oil
Excessive Backlash of Ring Gear
Worn or Damaged Tooth of Ring and Pinion Gear
Worn or Damaged Drive Pinion Bearing
Bent Axle Housing
Bent Differential Case
Worn Pinion Shaft
Incorrect Drive Pinion Preload
Incorrect Contact of Ring Gear and Pinion
DIAGNOSIS
NOISE (DURING STRAIGHT DRIVING)
Action
Replenish
Replace
Replace
Adjust
Replace
Replace
Replace
Replace
Replace
Adjust
Retightening
OIL LEAKAGE
Action
Adjust
Repair
Replace
Replace
NOISE (DURING TURNING)
Action
Replace
Replace
Replace
Adjust
Replace
Replace
Replace
Replace
Replace
Replace
Replace
HEATING
Checks
Lack of Oil
Insufficient Backlash of Gears
Excessive Preload of Bearing
Action
Replenish
Adjust
Adjust
