2D-10 REAR SUSPENSION
Removal & Installation Procedure
1. Disconnect actuator connector and unscrew bolt and remove
actuator assembly.
Notice
l
When installing the actuator to the mounting bracket,
the wiring should face outward of the frame.
l
Actuator wiring should be fixed 40 - 50mm away from
the wiring ends when fixing it with the frame open clip.
2. Unscrew the upper nut (6).
Notice
When screwing the nut, actuator contacting surface of the
mounting bracket and rod end should be 0.5 - 1.5mm.
3. Remove the mounting bracket (5).
Notice
When installing the bracket, it should be parallel to the frame
side member.
4. Remove the bush and check for damage and replace if
necessary.
5. Unscrew shock absorber lower bolt and nut and remove
the shock absorber.
Notice
Shock absorber is filled with gas, never attempt to cut or
heat.
6. Installation should follow the removal procedure in the
reverse order.
