M162 ENGINE CONTROLS 1F1-39 Engine Connector Pin No. Abbreciation Decription 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 EV5 EV6 EV1 EV4 EV2 EV3 M+ M- TM.31 ZSC16 ZSA25 ZSB34 NWS - - - - MT GND LT Injector-cylinder 2 Injector-cylinder 4 Injector-cylinder 1 Injector-cylinder 6 Injector-cylinder 5 Injector-cylinder 3 E-GAS motor plus E-GAS motor minus Power ground TM.31 Ignition coil cylinder 1+6 Ignition coil cylinder 2+5 Ignition coil cylinder 3+4 Camshaft control - - - - Engine coolant temperature Temperature ground Intake air temperature |
