OM600 ENGINE MECHANICAL 1B3-95 3. Remove the flywheel (3), if equipped with manual transmission. Installation Notice Correctly align the position of dowel pin (2). Tools Required 602 589 00 40 00 Engine Lock Removal & Installation Procedure 1. Install the engine lock. Engine Lock 602 589 02 40 00 2. Remove the 12-sided stretch bolts (4). Installation Notice Tightening Torque 45 Nm + 90° Notice If the length ‘L’ of bolts exceeds 22.5mm, replace the bolts. |
