OM600 ENGINE MECHANICAL  1B3-59

27. Replace the seal and then install the chain tensioner.

Tightening Torque

80 Nm

28. Remove the engine lock.

29. Insert the nozzle washer into the hole to face round part

downward.

30. Install the fuel injection nozzle.

Tightening Torque

40 Nm

31. Connect the fuel hose.

32. Install the cable channel and connect the cables to glow

plugs.

1B3-60  OM600 ENGINE MECHANICAL

35. Connect the wires to the coolant temperature sensor and

the glow plug sensor.

36. Replace the intake manifold gasket.

37. Install the intake manifold.

Tightening Torque

25 Nm

33. Replace the gasket and install the cylinder head cover.

Tightening Torque

10 Nm

34. Install the blow-by hose.

OM600 ENGINE MECHANICAL  1B3-61

38. Replace the O-ring of heater feed pipe and install it to the

cylinder head.

Notice

For installation, clean the hole.

39. Install the bracket of heater feed pipe to the oil filter.

40. Install the fuel pipe and the accelerator control linkage.

41. Connect the fuel lines to the injection nozzles and to the

injection pump.

Box Wrench Insert 000 589 77 03 00

Tightening Torque

18 Nm

1B3-62  OM600 ENGINE MECHANICAL

43. By inserting a rod into the tensioning lever upper hole and

pulling the rod, install the bolt and then tighten the nut.

44. Install the oil dipstick tube bracket.

Tightening Torque

10 Nm

45. Hold the cooling fan with the counter holder and tighten

the bolt.

42. Install the poly V-belt.

Notice

Be careful not to contaminate the belt.

Tightening Torque

23 Nm
