TECHNICAL SERVICE BULLETIN

TECHNICAL SERVICE BULLETIN

Description:

Reference:

Prod. Dates:

Bulletin No.:

Model(s):

Date:

VIN Range:

Group:

TSB-004-00

All

March 31, 2000

All

Wheel Nut/Bolt Torque

Publication Revisions

1999 Service Manuals

All

General Manager
Service Manager

Technician(s)
Service Advisor

Body Shop Manager
Parts Manager

Circulate To:

√

√
√

√
√

√

Daewoo Motor America has revised the Lanos, Nubira and Leganza Wheel Nut/Bolt Torque
Specification for both steel and alloy wheels.

i The Wheel Nut/Bolt Torque Specification for all Lanos and Nubira models has been

increased from 66 lb. ft. (90 N

im) to 88 lb. ft. (120 Nim).

i The Wheel Nut/Bolt Torque Specification for all Leganza models has been increased from

72 lb. ft. (100 N

im) to 81 lb. ft. (110 Nim).

All vehicles returning to the Store/Independent Dealer for normal service or repair should
have the wheels tightened to the new torque specification before returning the vehicle to the
customer.  Because tire rotation is included in every 6,000 mile service interval, no additional
labor time is required.

Service Manual Revision
To ensure that the revised Wheel Nut/Bolt Torque Specifications are available for future
reference in your 1999 Service Manuals, line out the existing printed specifications and write
in the revised Wheel Nut/Bolt Torque Specifications on the following Service Manual pages:

1999 Lanos Service Manual:

Pages 2E-2, 2E-3, 3A-7, 3B-7

Change from 66 lb. ft. (90 N

im) to 88 lb. ft. (120 Ni

im)

1999 Nubira Service Manual:

Pages 2E-2, 2E-3, 3A-7, 3B-8

Change from 66 lb. ft. (90 N

im) to 88 lb. ft. (120 Ni

im)

1999 Leganza Service Manual:

Pages 2E-2, 2E-4, 3A-7, 3B-7

Change from 72 lb. ft. (100 N

im) to 81 lb. ft. (110 Ni

im)

Questions regarding these specification changes should be referred to the Daewoo Technical
Assistance Center, which can be contacted toll-free at (877) 362-1234, selection 1.
