2B – 10

I

WHEEL ALIGNMENT

DAEWOO V–121 BL4

REAR CAMBER CHECK

The rear camber is not adjustable. Refer to ”Wheel Align-
ment Specifications” in this section. If the rear camber
deviates from the specification, locate the cause and cor-
rect it. If damaged, loose, bent, dented, or worn suspen-
sion parts are found, they should be repaired or replaced.
If the problem is body related, repair the body.

REAR TOE ADJUSTMENT

Adjustment Procedure

1.  Perform a preliminary inspection before any at-

tempt is made to change or correct the wheel align-
ment factors. Refer to ”Preliminary Inspection” in
this section.

2.  Loosen the nuts on the parallel link–to–crossmem-

ber bolts.

3.  Rotate the parallel link adjustment cams until the

preferred rear toe specification is obtained. Refer to
”Wheel Alignment Specifications” in this section for
preferred specifications.

4.  Hold the parallel link adjustment cams and tighten

the parallel link–to–crossmember nuts.

Tighten

Tighten the parallel link–to–crossmember bolts to 75
N

S

m (55 lb–ft).
