DAF CF65, CF75, CF85 Series . Manual - part 1074

©

 200424

3-3

Removal and installation

09N044 LEADING REAR AXLE (FTP VEHICLE)

ΧΦ65/75/85 series

8

10

3.3 REMOVAL AND INSTALLATION, WHEEL BEARINGS

Removing wheel bearings
1.

Remove the hub (3) from the axle.

2.

Remove the hub seal (6).

3.

Remove the bearing cages (1) and (5).

4.

If the wheel bearings should be replaced, the

outer bearing races (2) and (4) can be

tapped from the hub (3) using a copper

driving tool.

Installing wheel bearings
1.

Clean the bearings and check them for signs

of damage.

2.

Use a driving tool and a hydraulic press to

install the new outer bearing races (2) and

(4) into the hub (3). Check that the outer

races (2) and (4) are pressed into the hub (3)

as far as the stop.

3.

Apply an ample quantity of new grease to the

outer races (2) and (4) and the bearing cages

(1) and (5).

4.

Lubricate the space between the wheel

bearings with new grease.

5.

Fit a new hub seal (6).

6.

Install the hub (3).

1

2

3

4

5

6

A8 00 431

09N044 LEADING REAR AXLE (FTP VEHICLE)

3-4

©

 200424

Removal and installation

10

ΧΦ65/75/85 series

8

STRUCTURE

©

 200448

DW23241902

0

1

2

3

4

5

6

7
