DAF 95XF. Manual - part 512

3

PTO

General

2-6

2.3 OVERVIEW DRAWING N71/1 AND N353/1 PTO, C-VERSION

V300218

2

6

4

3

9

7 8

3

5

1

1.

Lead screw/ring

2.

Studs

3.

Gasket

4.

PTO housing

5.

Selector block

6.

Selector sleeve

7.

Lock washer

8.

Nut

9.

Lead cover

ǹ 0002

11

3

General

PTO

2-7

2.4 OVERVIEW DRAWING N71/2 AND N353/2 PTO, B-VERSION

1

1

2

3

4

5

5

V300219

1.

Studs

2.

Needle bearing

3.

PTO housing

4.

Gasket

5.

Lock washer and nut

ǹ 0002

11

3

PTO

General

2-8

2.5 OVERVIEW DRAWING N71/2 AND N353/2 PTO, C-VERSION

1

1

2

6

7

3

8

4

5

5

V300220

1.

Studs

2.

Gasket

3.

Needle bearing

4.

PTO housing

5.

Lock washer and nut

6.

Circlip

7.

Gearwheel

8.

Gasket

11

ǹ 0002

3

General

PTO

2-9

2.6 OVERVIEW DRAWING N221/10 PTO ON GEARBOX WITHOUT INTARDER

1.

Side cover fixing bolts

2.

Side cover

3.

Gasket

4.

PTO housing

5.

Long fixing bolts

6.

Short fixing bolts

7.

O-ring

8.

Centring ring

9.

Gasket

10. Adjusting ring

1

10

9

2

3

4

5

7
8

6

V300221

2.7 OVERVIEW DRAWING N221/10 PTO ON GEARBOX WITH INTARDER

1.

Side cover fixing bolts

2.

Side cover

3.

Gasket

4.

PTO housing

5.

Short fixing bolts

6.

Long fixing bolts

7.

O-ring

8.

Gasket

9.

O-ring

10. Centring ring

1

1

2

3

4

7

8

9

10

6

6

5

5

V300222

11

ǹ 0002
