258

CITROËN Connect Radio

Press this button to set the time zone.

Select the display format for the time

(12h/24h).

Activate or deactivate summer time (+1

hour).

Activate or deactivate GPS

synchronisation (UTC).

Press the back arrow to save the settings.

The system may not automatically

manage the change between winter and

summer time (depending on the country of

sale).

Setting the date

Press

Settings

 to display the main page.

Press "

Configuration

" to access the

secondary page.

Press "

Date and time

".

Select "

Date

".

Press this button to set the date.

Press the back arrow to save the date.

Select the display format for the date.

Press the back arrow again to confirm.



Time and date setting is only available if

"GPS Synchronisation:" is deactivated.

Frequently asked

questions

The following information groups together the

answers to the most frequently asked questions

concerning the system.

Radio

The reception quality of the tuned radio

station gradually deteriorates or the station

presets are not working (no sound, 87.5 MHz

is displayed, etc.).

The vehicle is too far from the selected station’s

transmitter, or no transmitter is present in the

geographical area.

►  Activate the "RDS" function in the upper bar

to enable the system to check whether there is

a more powerful transmitter in the geographical

area.

The environment (hills, buildings, tunnels,

basement car parks, etc.) is blocking reception,

including in RDS mode.

This is a perfectly normal phenomenon, and is

not indicative of an audio system malfunction.

The aerial is missing or has been damaged

(for example while entering a car wash or

underground car park).

►  Have the aerial checked by a dealer.

I cannot find some radio stations in the list of

received stations.

The name of the radio station changes.

The station is no longer received or its name has

changed in the list.

►  Press the round arrow on the "List" tab on the

"Radio" page.

Some radio stations send other information

in place of their name (the title of the song for

example).

The system interprets these details as the station

name.

►  Press the round arrow on the "List" tab on the

"Radio" page.

Media

Playback of my USB memory stick starts only

after a very long wait (around 2 to 3 minutes).

Some files supplied with the memory stick may

greatly slow down access to reading the memory

stick (multiplication by 10 of the cataloguing

time).

►  Delete the files supplied with the memory

stick and limit the number of sub-folders in the

file structure on the memory stick.

Some characters in information about the

currently playing media are not displayed

correctly.

The audio system is unable to process certain

types of character.

►  Use standard characters to name tracks and

folders.

Playback of streaming files does not start.

259

CITROËN Connect Radio

11

The connected device does not automatically

launch playback.

►  Start playback from the device.

Track names and playing times are not

displayed on the audio streaming screen.

The Bluetooth profile does not allow the transfer

of this information.

Telephone

I cannot connect my Bluetooth telephone.

The telephone's Bluetooth function may be

switched off or the device may not be visible.

►  Check that the telephone has Bluetooth

switched on.

►  Check in the telephone settings that it is

"visible to all".

The Bluetooth telephone is not compatible with

the system.

►  Check the compatibility of the telephone on

the Brand's website (services).

Android Auto and/or CarPlay do not work.

Android Auto and CarPlay may not activate if the

USB cables are of poor quality.

►  Use genuine USB cables to ensure

compatibility.

Android Auto and/or CarPlay do not work.

Android Auto and CarPlay are not available in all

countries.

►  Check the Google Android Auto or Apple

website to see which countries are supported.

The volume of the telephone connected in

Bluetooth mode is inaudible.

The volume depends on both the system and the

telephone.

►  Increase the volume of the audio system, to

maximum if required, and increase the volume of

the telephone if necessary.

Ambient noise affects the quality of the

telephone call.

►  Reduce ambient noise (close windows, turn

down ventilation, slow down, etc.).

The contacts are not listed in alphabetical

order.

Some telephones offer display options.

Depending on the settings chosen, contacts can

be transferred in a specific order.

►  Modify the telephone directory display

settings.

Settings

When the treble and bass settings are

changed, the ambience is deselected.

When the ambience is changed, the treble

and bass settings are reset.

Selecting an ambience imposes the treble and

bass settings, and vice versa.

►  Modify the treble and bass or ambience

settings to obtain the desired musical ambience.

When the balance settings are changed, the

distribution is deselected.

When the distribution setting is changed, the

balance settings are deselected.

Selecting a distribution setting imposes the

balance settings, and vice versa.

►  Modify the balance setting or the distribution

setting to obtain the desired sound quality.

There is a difference in sound quality

between audio sources.

To allow for optimal listening quality, the sound

settings can be tailored to different audio

sources, which can generate audible differences

when changing source.

►  Check that the sound settings are appropriate

to the sources listened to. Adjust the sound

functions to the middle position.

When the engine is off, the system switches

off after several minutes of use.

When the engine is switched off, the system's

operating time depends on the state of charge of

the battery.

The switch-off is normal: the system

automatically goes into energy economy mode

and switches off to maintain an adequate charge

in the battery.

►  Start the vehicle’s engine to increase the

charge of the battery.

260

CITROËN Connect Nav

CITROËN Connect Nav

GPS navigation -

Applications - Multimedia

audio system - Bluetooth

®



telephone

The functions and settings described

vary according to the vehicle version and

configuration, as well as the country of sale.

For safety reasons and because they

require sustained attention by the driver,

the following operations must be carried out

with the

vehicle stationary

 and the ignition

on:

–  Pairing the smartphone with the system via

Bluetooth.

–  Using the smartphone.

–  Connecting to the CarPlay

®

 or Android

Auto applications (certain applications stop

displaying when the vehicle is moving).

–  Watching a video (the video stops when the

vehicle starts to move again).

–  Changing the system settings and

configuration.

AM and DAB radio are not available on

Hybrid vehicles.

The system is protected so that it only

operates in the vehicle.

The message

Energy economy mode

 is

displayed when the system is about to go into

standby.

System and map updates can be

downloaded from the Brand's website.

The update procedure is also available there.

The system’s Open Source Software

(OSS) source codes are available at the

following addresses:

https://www.groupe-psa.com/fr/oss/

https://www.groupe-psa.com/en/oss/

First steps

With the engine running, a press mutes

the sound.

With the ignition off, a press turns the system on.

Increase or decrease the volume using

the wheel or the "plus" or "minus" buttons

(depending on the equipment).

Use the menu buttons on either side of or below

the touch screen for access to the menus, then

press the virtual buttons in the touch screen.

Depending on the model, use the "Source" or

"Menu" buttons to access the rolling menus, then

press the virtual buttons in the touch screen.

Display the rolling menus at any time by pressing

the screen briefly with three fingers.

All of the touch areas of the screen are white.

Press the back arrow to go back a level.

Press "OK" to confirm.

The touch screen is of the "capacitive"

type.

To clean the screen, use a soft, non-abrasive

cloth (e.g. spectacles cloth) with no additional

product.

Do not use sharp objects on the screen.

Do not touch the screen with wet hands.

Certain information is displayed permanently

in the side bars or in the upper bar of the touch

screen (depending on equipment):

–  Air conditioning status information (depending

on version), and direct access to the

corresponding menu.

–  Go directly to the audio source selection

option, to view the list of radio stations (or list of

titles depending on the source).

–  Go to the "Notifications" of messages, emails,

map updates and, depending on the services,

the navigation notifications.

–  Go to the settings for the touch screen and the

digital instrument panel.

Audio source selection (depending on

equipment):

–  FM/DAB/AM radio stations (depending on

equipment).

–  Telephone connected via Bluetooth and

Bluetooth multimedia broadcast (streaming).

–  USB memory stick.

261

CITROËN Connect Nav

12

–  Media player connected via the auxiliary

socket (depending on equipment).

–  Video (depending on equipment).





In the "Settings" menu, it is possible to

create a profile for an individual or for a

group of people with shared interests, and

configure a wide range of settings (radio

presets, audio settings, navigation history,

favourite contacts, etc.). Settings are applied

automatically.

In very hot conditions, the volume may

be limited to protect the system. It may

enter standby mode (with the screen and

sound off) for 5 minutes or more.

The system will resume normal operation

when the temperature in the passenger

compartment has dropped.

Steering mounted controls

Voice control

:

This control is located on the steering

wheel or at the end of the lighting control stalk

(depending on equipment).

Short press, system voice control.

Long press, voice commands from smartphone

or CarPlay

®

, Android Auto via the system.

Increase volume.

Decrease volume.

Mute by pressing the volume increase

and decrease buttons simultaneously

(depending on equipment).

Restore the sound by pressing one of the two

volume buttons.

Media

 (short press): change the

multimedia source.

Telephone

 (short press): start telephone

call.

Call in progress

 (short press): access

telephone menu.

Telephone

 (long press): reject an incoming call,

end call; when no call is in progress, access

telephone menu.

Radio

 (rotate): automatic search for the

previous/next station.

Media

 (rotate): previous/next track, move

through a list.

Short press

: confirm a selection; if nothing

selected, access presets.

Radio

: display the list of stations.

Media

: display the list of tracks.

Radio

 (press and hold): update the list of

detected stations.

Menus

Connected navigation





Enter navigation settings and choose a

destination.

Use real-time services, depending on equipment.

262

CITROËN Connect Nav

Applications





Run certain applications from a

smartphone connected via CarPlay

®

 or

Android Auto.

Check the status of the Bluetooth

®

 and Wi-Fi

connections.

Radio Media



FM  87.5 MHz



Select an audio source or radio station, or

display photographs.

Telephone





Connect a telephone via Bluetooth

®

, read

messages and emails and send quick

messages.

Settings





Configure a personal profile and/or

configure the sound (balance, ambience,

etc.) and the display (language, units, date, time,

etc.).

Vehicle





Activate, deactivate or configure certain

vehicle functions.

Air conditioning



21,5

18,5



Manage various temperature and air flow

settings.

263

CITROËN Connect Nav

12

Voice commands

Steering wheel-mounted

controls

Voice commands

:

Voice commands can be issued from any

screen page after a short press on the "Voice

commands" button located on the steering

wheel or at the end of the lighting control stalk

(depending on equipment), as long as there is no

telephone call in progress.

To ensure that voice commands are

always recognised by the system, please

follow these recommendations:

–

use natural language in a normal tone

without breaking up words or raising your

voice.

–  always wait for the "beep" (audible signal)

before speaking.

–  for best results, closing the windows and

sunroof is recommended, to avoid extraneous

interference (depending on version).

–  before issuing a voice command, ask any

other passengers to refrain from speaking.

First steps

Example of a "voice command" for

navigation:

"Navigate to address 11 regent street,

London"

Example of a "voice command" for the radio and

media:

"Play artist Madonna"

Example of a "voice command" for the

telephone:

"Call David Miller"

The voice commands, with a choice of 17

languages (Arabic, Brazilian, Czech,

Danish, Dutch, English, Farsi, French,

German, Italian, Norwegian, Polish,

Portuguese, Russian, Spanish, Swedish,

Turkish), are made using the language

previously chosen and set in the system.

For some voice commands, there are

alternative synonyms.

Example: Guide to / Navigate to / Go to / ...

The voice commands in Arabic for: "Navigate

to address" and "Display POI in the city", are

not available.

Information - Using the

system

When voice commands are activated, by

briefly pressing the button, help is

displayed on the touch screen, offering various

menus and enabling voice-based interaction with

the system.





A number of commands are available when a

menu is selected.





Press the Push To Talk button and tell me

what you'd like after the tone. Remember

you can interrupt me at any time by pressing this

button. If you press it again while I'm waiting for

you to speak, it'll end the conversation. If you

need to start over, say "cancel". If you want to

undo something, say "undo". And to get

information and tips at any time, just say "help".

If you ask to me do something and there's some

information missing that I need, I'll give you

some examples or take you through it step by

264

CITROËN Connect Nav

step. There's more information available in

"novice" mode. You can set the dialogue mode to

"expert" when you feel comfortable.

Global voice commands

Voice commands



Set dialogue mode as novice - expert

Select user 1 / Select profile John

Increase temperature

Decrease temperature

Help messages



There are lots of topics I can help you with.

You can say: "help with phone", "help with

navigation", "help with media" or "help with

radio". For an overview on how to use voice

controls, you can say "help with voice controls".

Say "yes" if I got that right. Otherwise, say "no"

and we'll start that again.

"Navigation" voice

commands

Voice commands



Navigate home

Navigate to work

Navigate to preferred address, Tennis club

Navigate to contact, John Miller

Navigate to address 11 regent street, London

Help messages



To plan a route, say "navigate to" followed by the

address, the contact name or an intersection. For

example, "navigate to address 11 Regent Street,

London", "navigate to contact, John Miller",

or "navigate to intersection of Regent Street,

London". You can specify if it's a preferred

address, or a Point of Interest. For example, say

"navigate to preferred address, Tennis club", or

"navigate to POI Heathrow Airport in London".

Or, you can just say, "navigate home". To see

Points of Interest on a map, you can say things

like "show POI hotels in Banbury". For more

information say "help with points of interest" or

"help with route guidance".

To choose a destination, say something like

"navigate to line three" or "select line two". If you

can't find the destination but the street's right,

say for example "select the street in line three".

To move around a displayed list, you can say

"next page" or "previous page". You can undo

your last action and start over by saying "undo",

or say "cancel" to cancel the current action.

Voice commands



Tell me the remaining distance

Tell me the remaining time

Tell me the arrival time

Stop route guidance

Help messages



You can say "stop" or "resume route guidance".

To get information about your current route, you

can say "tell me the remaining time", "remaining

distance" or "arrival time". To learn more

commands, try saying "help with navigation".

Voice commands



Show POI ''hotel'' at the destination

Show nearby POI petrol station

Navigate to POI Heathrow Airport in London

Navigate to POI petrol station along the route

Help messages



To see points of interest on a map, you can

say things like "show hotels in Banbury", "show

nearby parking", "show hotel at the destination"

or "show petrol station along the route". If you

prefer to navigate directly to a point of interest,

you can say "navigate to nearby petrol station".

If you feel you are not being well understood,

try to say the word "POI" in front of the point

of interest. For example say "navigate to POI

restaurant at the destination".

To choose a POI, say something like "select

line 2". If you've searched for a Point of Interest

and don't see the one you're after, you can filter

further by saying something like "select POI in

line 2", or "select the city in line 3". You can also

scroll through the list by saying "next page" or

"previous page".

Depending on the country, give

destination (address) instructions in the

language configured for the system.

265

CITROËN Connect Nav

12

"Radio Media" voice

commands

Voice commands



Turn on source radio - Streaming Bluetooth

- …

Help messages



You can select an audio source by saying "turn

on source" followed by the device name. For

example, "turn on source, Streaming Bluetooth",

or "turn on source, radio". Use the command

"play" to specify the type of music you'd like to

hear. You can choose between "song", "artist",

or "album". Just say something like "play artist,

Madonna", "play song, Hey Jude", or "play

album, Thriller".

Voice commands



Tune to channel BBC Radio 2

Tune to 98.5 FM

Tune to preset number five

Help messages



You can pick a radio station by saying "tune to"

and the station name or frequency. For example

"tune to channel Talksport" or "tune to 98.5

FM". To listen to a preset radio station, say for

example "tune to preset number five".

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

Voice commands



What's playing?

Help messages



To choose what you'd like to play, start by saying

"play" and then the item. For example, say "play

song Hey Jude", "play line 3" or "select line 2".

You can undo your last action and start over

by saying "undo", or say "cancel" to cancel the

current action.

Voice commands



Play song Hey Jude

Play artist Madonna

Play album Thriller

Help messages



I'm not sure what you'd like to play. Please say

"play" and then a song title, an album title, or

an artist name. For example, say "play song

Hey Jude", "play artist Madonna" or "play

album Thriller". To select a line number from the

display, say "select line two". To move around

a displayed list, you can say "next page" or

"previous page". You can undo your last action

and start over by saying "undo", or say "cancel"

to cancel the current action.

Media voice commands are available

only with a USB connection.

"Telephone" voice

commands

If there is no telephone connected by

Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session is closed.

Voice commands



Call David Miller

*

Call voicemail

*

Display calls

*

Help messages



To make a phone call, say "call" followed by

the contact name, for example: "Call David

Miller". You can also include the phone type, for

example: "Call David Miller at home". To make

a call by number, say "dial" followed by the

phone number, for example, "Dial 107776 835

417". You can check your voicemail by saying

"call voicemail". To send a text, say "send quick

message to", followed by the contact, and then

the name of the quick message you'd like to

send. For example, "send quick message to

266

CITROËN Connect Nav

David Miller, I'll be late". To display the list of

calls, say "display calls". For more information on

SMS, you can say "help with texting".

To choose a contact, say something like "select

line three". To move around the list say "next

page" or "previous page". You can undo your last

action and start over by saying "undo", or say

"cancel" to cancel the current action.

"Text message" voice

commands

If there is no telephone connected by

Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session is closed.

The "Text messages" voice commands

function allows you to dictate and send

an SMS.

Dictate the text, taking care to pause briefly

between each word.

When you have finished, the voice recognition

system will automatically generate an SMS.

Voice commands



Send quick message to Bill Carter, I'll be late

Help messages



* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

From the list of quick messages, say the name of

the one you'd like to send. To move around the

list you can say "go to start", "go to end", "next

page" or "previous page". You can undo your last

action and start over by saying "undo", or say

"cancel" to cancel the current action.

Voice commands



Send SMS to John Miller, I'm just arriving

Send SMS to David Miller at the office, don't

wait for me

Help messages



Please say "call" or "send quick message to",

and then select a line from the list. To move

around a list shown on the display, you can

say "go to start", "go to end", "next page" or

"previous page". You can undo your last action

and start over by saying "undo", or say "cancel"

to cancel the current action.

Voice commands



Listen to most recent message

*

Help messages



To hear your last message, you can say "listen to

most recent message". When you want to send

a text, there's a set of quick messages ready for

you to use. Just use the quick message name

and say something like "send quick message to

Bill Carter, I'll be late". Check the phone menu

for the names of the supported messages.

The system only sends pre-recorded

"Quick messages".

Navigation

Choice of a destination

To a new destination

Intuitive method:

Press

Navigation

 to display the main

page.

Press "

Search…

".

Enter an address or the key words for the

destination.

Press "

OK

" to select the "

Guidance

criteria

".

Or

Guided method:

In order to be able to use the navigation,

you must enter the "

City

", the "

Street

"

(suggestions are displayed automatically

when you begin typing), then enter the

"

Number

" using the virtual keypad, or select

267

CITROËN Connect Nav

12

an address from the "

Contact

" list or the

address "

History

".

If you do not confirm the number, the

navigation system will show one end of

the street.

Press the "

MENU

" button to access the

secondary page.

Select "

Enter address

".

Then

Select the "

Country

".

Select the keyboard “language”.

Change the keyboard "type" according to

the selected "language": ABCDE;

AZERTY; QWERTY or QWERTZ.

Enter the "

City

", the "

Street

" and the

"

Number

", and confirm by pressing on

the displayed suggestions.

Press "

OK

" to select the "

Guidance

criteria

".

And/or

Select "

See on map

" to choose the

"

Guidance criteria

".

Press "

OK

" to start guided navigation.

Zoom in/out using the touch buttons or

with two fingers on the screen.

To a recent destination

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Recent

” tab.

Select the address chosen in the list to display

the "

Guidance criteria

”.

Press "

OK

" to start guided navigation.

Select "

Position

" to see the point of

arrival on the map.

To "Home" or "My work"

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Preferred

” tab.

Select "

Home

".

Or

Select "

My work

".

Or

Select a preset favourite destination.

To a contact

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Contact

” tab.

Select a contact in the list to start guided

navigation.

To points of interest (POI)

Guided method:

Points of interest (POI) are listed in different

categories.

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Points of interest

".

Select the "

Travel

", "

leisure

",

"

Commercial

", "

Public

" or "

Geographic

”

tab.

Or

Select "

Search

" to enter the name and

address of a POI.

Press "

OK

" to calculate the route.

Or

Intuitive method:

268

CITROËN Connect Nav

You can only select this method of

using the service if a network connection

is active; this may be either a "network

connection provided by the vehicle", if you

use the Citroën Connect Box solution, or else

a "network connection provided by the user"

via a smartphone,

In both cases, the system is automatically

connected to the Internet, if network coverage

permits.

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Search

".

Press on the mode shown in the bottom right of

the screen (On-Board or Connected) to change

the "Database".

Select the "Database" in "On-Board"

mode (integrated into the map), or in

"Connected" mode (connected to the Internet).

Press the back arrow to confirm.



Enter an address or the key words for the

destination (POI).

Press "

OK

" to start the search.

Select the "

On the route

", "

Around the

vehicle

" or "

At destination

" tab to refine

your search.

Select the desired address to calculate the route.

To a point on the map

Press

Navigation

 to display the main

page.

Explore the map by sliding a finger on the

screen.

Select the destination by pressing on the map.

Tap the screen to place a marker and

display the sub-menu.

Press this button to start guided

navigation.

Or

Press this button to save the displayed

address.

A long press on a point opens a list of

nearby POIs.

To GPS coordinates

Press

Navigation

 to display the main

page.

Explore the map by sliding a finger on the

screen.

Touch the screen with a finger to go to the next

image.

Press this button to display the world

map.

Using the grid, select the desired country or

region by zooming.

Press this button to display or enter the

GPS coordinates.

A marker is displayed in the middle of the

screen, with the "

Latitude

" and

"

Longitude

" coordinates.

Choose the type of coordinates:

DMS for: Degrees, Minutes, Seconds.

DD for: Degrees, Decimals.

Press this button to start guided

navigation.

Or

Press this button to save the displayed

address.

OR

Press this button to enter the "

Latitude

"

value using the virtual keypad.

And

Press this button to enter the "

Longitude

"

value using the virtual keypad.

TMC (Traffic Message

Channel)

Available in some countries.

TMC (Traffic Message Channel) messages

are based on a European standard for traffic

information broadcasting via the RDS system on

FM radio, sending traffic information in real time.

The TMC information is then displayed on a GPS

Navigation system map and taken into account

straight away when routes are calculated, to

avoid accidents, traffic jams and closed roads.

Danger zone alerts may or may not be

displayed, depending on the applicable

269

CITROËN Connect Nav

12

legislation and subscription to the

corresponding service.

Connected navigation

Connected navigation

connection

Depending on version, vehicle trim level and

subscription to online services and options.

Network connection provided by the

vehicle

With the Citroën Connect Box solution,

the system is automatically connected to

the Internet and connected services, and does

not require the user to provide a connection via

their smartphone.

OR

Network connection provided by the

user





For the list of compatible smartphones,

visit the Brand's website in your country.

Activate and enter settings for sharing the

smartphone connection.

As processes and standards are

constantly changing, we recommend you

update the smartphone operating system

as well as the date and time on the

smartphone and system

, to ensure that the

communication process between the

smartphone and the system functions

correctly.

USB connection

Connect the USB cable.

The smartphone charges when

connected by the USB cable.

Bluetooth connection

Activate the Bluetooth function on the

telephone and ensure that it is visible to

all (see the "Connect-App" section).

Wi-Fi connection

Select a Wi-Fi network detected by the

system and connect to it.

This function is only available if it has

been activated either via the

"Notifications" or via the "Applications" menu.

Press "

Notifications

".

Select Wi-Fi to activate it.

OR

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Wi-Fi network connection

".

Select the "

Secured

", "

Not secured

" or

"

Stored

” tab.

Select a network.

Using the virtual keypad, enter the "

Key

"

network Wi-Fi and the "

Password

".

Press "

OK

" to establish a connection

between the smartphone and the

vehicle’s system.

Usage restrictions:

With CarPlay

®

, connection sharing is only

available with a Wi-Fi connection.

The quality of services depends on the quality

of the network connection.

Authorize sending

information

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

System configuration

".

Select the "

Private mode

" tab.

OR

Press "

Notifications

".

Press "

Private mode

".

THEN

270

CITROËN Connect Nav

Activate or deactivate:

– "

No data sharing except for company

vehicles

".

– "

Only data sharing

"

– "

Sharing data and vehicle position

"

Settings specific to

connected navigation

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Settings

".

Select the "

Map

” tab.

Activate or deactivate:

– "

Allow declaration of danger zones

".

– "

Guidance to final destination on foot

".

These settings must be configured for each

profile.

Press “

OK”

 to confirm your selection.



Select the "

Alerts

” tab.

Activate or deactivate:

– "

Advise of car park nearby

".

– "

Filling station alert

".

– “

Risk areas alert

" then press the warning icon

(triangle) to configure the alerts.

– "

Give an audible warning

".

– "

Advise proximity of POI 1

".

– "

Advise proximity of POI 2

".

Press “

OK”

 to confirm your selection.



The "Notifications", located in the upper

bar, can be accessed at any time.

Danger zone alerts may or may not be

displayed, depending on the applicable

legislation and subscription to the

corresponding service.

When "TOMTOM TRAFFIC” appears, the

services are available.

The services offered with connected

navigation are as follows.

A Connected Services pack:

– Weather,

–  Filling stations,

–  Car park,

–  Traffic,

–  POI local search.

A Danger area pack (optional).

Declaration: "Risk areas

alert"

To send information about danger zones,

select the option:

Allow declaration of

danger zones

Press

Navigation

 to display the main

page.

Press the "

Declare a new danger zone

"

button located in the side bars or the

upper bar of the touch screen (depending on

equipment).

Select the "

Type

” option to select the type

of "Danger area".

Select the "

"Speed

" option and enter it

using the virtual keypad.

Press "

OK

" to save and send the

information.

Displaying fuel information

Press

Navigation

 to display the main

page.

Press this button to display the list of

services.

Press "

POI on map" to display the list

of points of interest.

Press one of the buttons to search for

"

Stations

".

Activate/deactivate "

Stations

".

Press this button to display a secondary

page.

Select the "

Settings

” tab.

Select the desired fuel.

Press "

OK

" to save.

271

CITROËN Connect Nav

12

Displaying charging station

details

Press

Navigation

 to display the main

page.

Press this button to display the list of

services.

Press "

POI on map" to display the list

of points of interest.

Press one of the buttons to search for

"

Stations

".

Activate/deactivate "

Stations

".

Press this button to display a secondary

page.

Select the "

Settings

" tab.

Select the desired connector type.

Press "

OK

" to save.

Displaying weather

information

Press

Navigation

 to display the main

page.

Press this button to display the list of

services.

Select "

View map

".

Select "

Weather

".

Press this button to display basic

information.

Press this button to display detailed

weather information.

The temperature displayed at 6 a.m. will

be the maximum temperature for the day.

The temperature displayed at 6 p.m. will be

the minimum temperature for the night.

Applications

USB sockets

Depending on equipment, for more information

on the USB sockets compatible with

CarPlay

®

 or

Android Auto

 applications, refer to the "Ease of

use and comfort" section.

For the list of compatible smartphones,

visit the Manufacturer's website in your

country.

Synchronising a smartphone enables

users to display applications that support

the smartphone’s CarPlay

®

 or Android Auto

technology on the vehicle’s screen. For

CarPlay

®

 technology, the CarPlay

®

 function

must first be activated on the smartphone.

Unlock the smartphone for the communication

process between the smartphone and the

system to work.

As principles and standards are constantly

changing,

we recommend keeping the

smartphone's operating system up-to-

date, together with the date and time on

the smartphone and the system

.

Connectivity

Press

Applications

 to display the main

page.

Press "

Connectivity

" to access the

CarPlay

®

 or

Android Auto

 functions.

CarPlay

®

 smartphone

connection

Depending on country.

On connecting the USB cable, the

CarPlay

®

 function deactivates the

system's Bluetooth

®

 mode.

The "

CarPlay

" function requires the use of

a compatible smartphone and compatible

applications.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

Press "

Telephone

" to display the

CarPlay

®

 interface.

Or

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

272

CITROËN Connect Nav

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "CarPlay

®

”

function.

Press "

CarPlay

" to display the CarPlay

®



interface.

When the USB cable is disconnected

and the ignition is switched off then back

on, the system will not automatically switch to

Radio Media mode; the source must be

changed manually.

Android Auto smartphone

connection

Depending on country.

Install the "

Android Auto

" application on

the smartphone via "Google Play".

The "

Android Auto

" function requires the use

of a compatible smartphone and compatible

applications.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "Android

Auto” function.

Press "

Android Auto

" to start the

application in the system.

During the procedure, several screen

pages relating to certain features are

displayed.

Accept to start and complete the connection.

Access to the different audio sources remains

available in the margin of the Android Auto

display, using the touch buttons located in the

upper bar.

Access to the menus for the system is possible

at any time using the dedicated buttons.

In Android Auto mode, the function that

displays rolling menus by briefly pressing

the screen with three fingers is disabled.

There may be a pause before

applications become available,

depending on the quality of the network.

Car Apps

Press

Applications

 to display the main

page.

Press "

Car Apps

" to display the applications

home page.

Internet Browser

Press

Applications

 to display the main

page.

Press "

Connectivity

" to access the "

Connected

Apps

” function.

Press "

Connected Apps

" to display the browser

home page.

Select the country of residence.

Press "

OK

" to save and start the browser.

Connection to the internet is via one of

the network connections provided by the

vehicle or the user.

Bluetooth connection

®

The services available depend on the

network, the SIM card and the

compatibility of the Bluetooth devices used.

Consult the smartphone user guide and the

service provider to check which services are

available.

The Bluetooth function must be activated

and the smartphone configured as

"Visible to all".

To complete the pairing, whichever procedure is

used (from the smartphone or from the system),

ensure that the code is the same in the system

and in the smartphone.

If the pairing procedure fails, we

recommend deactivating and then

reactivating the Bluetooth function on the

smartphone.

273

CITROËN Connect Nav

12

Procedure from the smartphone

Select the name of the system in the list

of detected devices.

In the system, accept the connection request

from the smartphone.

Procedure from the system

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Press "

Bluetooth connection

".

Select "

Search

".

The list of detected smartphones is

displayed.

Select the name of the chosen

smartphone in the list.

Depending on the type of smartphone,

you may by prompted to accept the

transfer of contacts and messages.

Connection sharing

The system offers to connect the smartphone

with 3 profiles:

– "

Telephone

" (hands-free kit, telephone only),

– “

Streaming

" (streaming: wireless playing of

audio files on the smartphone),

– "

Mobile internet data

".

The "

Mobile internet data

" profile must

be activated for connected navigation (if

the vehicle does not have "Emergency and

assistance call" services), after first activating

smartphone connection sharing.

Select one or more profiles.



Press "

OK

" to confirm.



Wi-Fi connection

Network connection via the smartphone's Wi-Fi.

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Wi-Fi network connection

".

Select the "

Secured

", "

Not secured

" or

"

Stored

” tab.

Select a network.

Using the virtual keypad , enter the Wi-Fi

network "

Key

" and "

Password

".

Press "

OK

" to establish the connection.

The Wi-Fi connection and Wi-Fi

connection sharing are exclusive.

Wi-Fi connection sharing

Depending on equipment.

Creation of a local Wi-Fi network by the system.

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Share Wi-Fi connection

".

Select the "

Activation

" tab to activate or

deactivate Wi-Fi connection sharing.

And/or

Select the "

Settings

" tab to change the system’s

network name and password.

Press "

OK

" to confirm.



To protect against unauthorised access

and to make all systems as secure as

possible, the use of a security code or a

complex password is recommended.

Managing connections

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Manage connection

".

With this function, you can view the access to

connected services, the availability of connected

services and modify the connection mode.
