226

Technical data









Vehicle length

M (L1)

XL (L2)

A

Overall length

4,403

4,753

B

Overall height

Without roof bars

1,800 to 1,807

1,812 to 1,818

With roof bars

1,837 to 1,844

1,843 to 1,849

C

Wheelbase

2,785

2,975

D

Front overhang

892

E

Rear overhang

726

886

F

Width inc. mirrors

Folded

1,921

Unfolded

2,107

G

Front track width

1,553

H

Rear track width

1,567

227

Technical data

9

Engine technical data and

towed loads

Engines

The engine characteristics are given in the

vehicle's registration document, as well as in

sales brochures.

Only the values available at the time of

publication are presented in the tables.

Contact a CITROËN dealer or a qualified

workshop to obtain missing values.

The maximum power corresponds to the

value type-approved on a test bed, under

conditions defined by European legislation

(Directive 1999/99/EC).

For more information, contact a CITROËN dealer

or a qualified workshop.

Weights and towed loads

The weights and towed loads relating to

the vehicle are indicated on the registration

document, as well as in sales brochures.

These values are also indicated on the

manufacturer's plate or label.

For more information, contact a CITROËN dealer

or a qualified workshop.

The GTW (Gross Train Weight) and towed load

values indicated are valid up to a maximum

altitude of 1,000 metres. The towed load value

must be reduced by 10% for each additional

1,000 metres of altitude.

The maximum authorised nose weight

corresponds to the weight permitted on the

towball.

When exterior temperatures are high, the

vehicle performance may be limited in

order to protect the engine. When the exterior

temperature is higher than 37°C, reduce the

towed weight.

Towing even with a lightly loaded vehicle

can adversely affect its road holding.

Braking distances are increased when towing

a trailer.

When using a vehicle to tow, never exceed

a speed of 62 mph (100 km/h) (observe the

local legislation in force).

If the exterior temperature is high, it is

recommended that the engine is allowed

to idle for 1 to 2 minutes after the vehicle

comes to a stop, to facilitate its cooling.

Engines and towed loads - PETROL





Vehicles fitted with the

VTi 110 BVM5

 engine are not suitable for towing.

228

Technical data

Engines and towed loads - PETROL EURO 6.3





Engine

PureTech 110 S&S BVM6

PureTech 130 S&S EAT8

Gearbox

Manual 6-speed

Automatic 8-speed

Code

EB2ADT MB6 STTD

EB2ADTS ATN8 STTD

Length

M (L1)

XL (L2)

M (L1)

XL (L2)

Model Code

5 seats





ERHNP2-A

ERHNP2-C

ERHNS3-A

ERHNS3-C

7 seats





ERHNP2-B

ERHNP2-D

ERHNS3-B

ERHNS3-D

Cubic capacity (cc)

1,199

1,199

Max. power: EC standard (kW)

81

96

Fuel

Unleaded

Unleaded

Braked trailer (within

the GTW limit) on a 12%

slope (kg)

5 seats

1,150

1,100

1,200

1,150

7 seats

1,000

900/950

1,050

1,000/950

Unbraked trailer (kg)

5 seats

720/730

750

740/750

750

7 seats

750

750

750

750

Maximum authorised

nose/towball weight (kg)

5 seats

74

74

74

74

7 seats

50/70

50

70/50

50

229

Technical data

9

Engines and towed loads - DIESEL





Engine

HDi 92 S&S BVM5

Gearbox

Manual 5-speed

Code

DV6DR

Length

M (L1)

XL (L2)

Model Code

5 seats





EC___A-A

EC___A-C

7 seats





EC___A-B

EC___A-D

Cubic capacity (cc)

1,560

Max. power: EC standard (kW)

68

Fuel

Diesel

Braked trailer (within

the GTW limit) on a 12%

slope (kg)

5 seats

1,100

1,050

7 seats

950

900

Unbraked trailer (kg)

5 seats

720

750

7 seats

750

750

Maximum authorised

nose/towball weight (kg)

5 seats

74

74

7 seats

70 (Citroën)

50

230

Technical data

Engines and towed loads - DIESEL EURO 6.1





Engine

BlueHDi 100 BVM5

Gearbox

Manual 5-speed

Code

DV6FD BE

Length

M (L1)

XL (L2)

Model Code

5 seats





ECBHYB-A

ECBHYB-C

7 seats





ECBHYB-B

ECBHYB-D

Cubic capacity (cc)

1,560

Max. power: EC standard (kW)

73

Fuel

Diesel

Braked trailer (within the GTW limit) on a 12% slope (kg)

5 seats

1,100

1,050

7 seats

950

900

Unbraked trailer (kg)

5 seats

730

750

7 seats

750

Maximum authorised nose/towball weight (kg)

5 seats

74

74

7 seats

70 (Citroën)

50

231

Technical data

9

Engines and towed loads - DIESEL EURO 6.2





Engine

BlueHDi 100 S&S BVM5

BlueHDi 100 BVM5

BlueHDi 130 S&S EAT8

Gearbox

Manual 5-speed

Manual 5-speed

Automatic 8-speed

Code

DV5RD STTd BVM5

DV5RD BVM5

DV5RC STTd ATN8

Model Code

EFYHYC-L

EFYHYJ-L

EFYHZR-L

Cubic capacity (cc)

1,499

1,499

1,499

Max. power: EC standard (kW)

75

75

96

Fuel

Diesel

Diesel

Diesel

Braked trailer (within the GTW

limit) on a 12% slope (kg)

1,050

1,050

1,050

Unbraked trailer (kg)

750

750

750

Maximum authorised nose/

towball weight (kg)

74

74

74

232

Technical data





Engine

BlueHDi 100 S&S BVM5

BlueHDi 130 S&S EAT8

Gearbox

Manual 5-speed

Automatic 8-speed

Code

DV5RD BE STTD - TBC

DV5RC STTd ATN8

Length

M (L1)

XL (L2)

M (L1)

XL (L2)

Model Code

5 seats





ECYHYC-A

ECYHYC-C

ECYHZR-A

ECYHZR-C

7 seats





ECYHYC-B

ECYHYC-D

ECYHZR-B

ECYHZR-D

Cubic capacity (cc)

1,499

1,499

Max. power: EC standard (kW)

75

96

Fuel

Diesel

Diesel

Braked trailer (within the GTW

limit) on a 12% slope (kg)

5 seats

1,300

1,250

1,300

1,225/1,250

7 seats

1,150

1,050/1,100

1,100/1,150

1,050/1,100

Unbraked trailer (kg)

5 seats

740/750

750

750

750

7 seats

750

750

750

750

Maximum authorised nose/

towball weight (kg)

5 seats

74

74

52

74

7 seats

60 (Citroën)

50/60 (Citroën)

50

50

233

Technical data

9

Engines and towed loads - DIESEL EURO 6.3





Engine

BlueHDi 100 S&S

BVM6

BlueHDi 100 BVM6

BlueHDi 130 S&S

BVM6

BlueHDi 130 BVM6

BlueHDi 130 S&S

EAT8

Gearbox

Manual 6-speed

Manual 6-speed

Manual 6-speed

Manual 6-speed

Automatic 8-speed

Code

DV5RCf MB6 STTD

DV5RCf MB6

DV5RC ML6C STTD

DV5RC ML6C

DV5RC ATN8 STTD

Model Code

EFYHT2-L

EFYHT2-L

EFYHZ2-L

EFYHZ2-L

EFYHZ3-L

Cubic capacity (cc)

1,499

1,499

1,499

1,499

1,499

Max. power: EC standard

(kW)

75

75

96

96

96

Fuel

Diesel

Diesel

Diesel

Diesel

Diesel

Braked trailer (within

the GTW limit) on a 12%

slope (kg)

1,250

1,250

1,250

1,250

Unbraked trailer (kg)

750

750

750

750

Maximum authorised

nose/towball weight (kg)

74

74

74

74

234

Technical data





Engine

BlueHDi 100 S&S BVM6

BlueHDi 130 S&S BVM6

BlueHDi 130 S&S EAT8

Gearbox

Manual 6-speed

Manual 6-speed

Automatic 8-speed

Code

DV5RCf MB6 STTD

DV5RC ML6C STTD

DV5RC ATN8 STTD

Length

M (L1)

XL (L2)

M (L1)

XL (L2)

M (L1)

XL (L2)

Model Code

5 seats





ECYHT2-A

ECYHT2-C

ECYHZ2-A

ECYHZ2-C

ECYHZ3-A

ECYHZ3-C

7 seats





ECYHT2-B

ECYHT2-D

ECYHZ2-B

ECYHZ2-D

ECYHZ3-B

ECYHZ3-D

Cubic capacity (cc)

1,499

1,499

1,499

Max. power: EC standard (kW)

74

96

96

Fuel

Diesel

Diesel

Diesel

Braked trailer (within

the GTW limit) on a 12%

slope (kg)

5 seats

1,300

1,250

1,500

1,450

7 seats

1,150

1,050/1,100

1,350

1,250

Unbraked trailer (kg)

5 seats

740/750

750

750

750

7 seats

750

750

750

750

Maximum authorised

nose/towball weight (kg)

5 seats

74

74

74

74

7 seats

60 (Citroën)

50/60

(Citroën)

55/60

50

235

Technical data

9

Motor and towed loads - Electric

Electric motor

Electric motor

Technology

Synchronous with permanent magnets

Max. power : EC standard (kW)/(hp)

100

Traction battery

Technology

Lithium-Ion

Battery pack

18 modules

Installed capacity (kWh)

50

Domestic charging

Mode 2

Alternating current (AC) voltage

Rating (A)

230

8 or 16

Accelerated charging

Mode 3

Alternating current (AC) voltage

Rating (A)

230 (single-phase or three-phase)

16 or 32

Superfast charging

Mode 4

Direct current (DC) voltage

400

Towed loads

Model codes:

ZKX

Braked trailer (within the GTW limit) (kg)

on a 10% or 12% gradient

750

Unbraked trailer (kg)

750

Maximum authorised nose weight (kg)

50

236

Technical data

Identification markings

Various visible markings for vehicle identification

and vehicle search.





A.

Vehicle Identification Number (VIN), under

the bonnet.

Stamped on the chassis, near the right-hand

front wheel arch.

B. Vehicle Identification Number (VIN), on the

dashboard.

Printed on an adhesive label visible through the

windscreen.

C. Manufacturer's label.

Affixed to the centre pillar, left-hand side or right-

hand side.

Bears the following information:

–  Manufacturer’s name.

–  European whole vehicle type approval

number.

–  Vehicle Identification number (VIN).

–  Gross vehicle weight (GVW).

–  Gross train weight (GTW).

–  Maximum weight on the front axle.

–  Maximum weight on the rear axle.

D. Tyres/paint code label.





Affixed to the driver's door.

Bears the following information about the tyres:

–  Tyre pressures, unladen and laden.

–  Tyre specification, made up of the dimensions

and type as well as the load and speed indices.

–  Spare tyre inflation pressure.

Also indicates the paint colour code.

The vehicle may be originally equipped

with tyres with higher load and speed

indices than those indicated on the label,

without affecting tyre pressure (on cold tyres).

In the event of a change in the type of tyres,

contact a CITROËN dealer for the tyre fits

approved for the vehicle.

237

Touch screen BLUETOOTH audio system

10

Touch screen

BLUETOOTH audio

system





Multimedia audio system -

Bluetooth

®

 telephone

The functions and settings described

vary according to the vehicle version and

configuration.

For safety reasons and because they

require sustained attention by the driver,

the following operations must be carried out

with the

vehicle stationary

 and the ignition

on:

–  Pairing the smartphone with the system in

Bluetooth mode.

–  Using the smartphone.

–  Changing the system settings and

configuration.

The system is protected in such a way

that it will only operate in the vehicle.

The

Energy Economy Mode

 message is

displayed when the system is about to enter

the corresponding mode.

First steps

With the engine running, a press mutes

the sound.

With the ignition off, a press turns the system on.

Increase or decrease the volume using

the thumbwheel on the left-hand side.

To access the menus, press this button

on the touch screen.

Press the back arrow to go back a level.

To clean the screen, use a soft,

non-abrasive cloth (e.g. spectacles cloth)

with no additional product.

Do not use sharp objects on the screen.

Do not touch the screen with wet hands.

Certain information is displayed permanently in

the upper bar of the touch screen:

–  Air conditioning information (depending on

version).

–  Bluetooth connection.

–  Indication of location data sharing.

Selection of the audio source:

–  FM/AM/DAB radio stations (depending on

equipment).

–  Telephone connected via Bluetooth and

Bluetooth multimedia broadcast (streaming).

–  USB memory stick.

–  Media player connected via the auxiliary

socket (depending on equipment).

In very hot conditions, the volume may

be limited to protect the system. It may

go into standby (screen and sound off) for at

least 5 minutes.

The return to normal takes place when the

temperature in the passenger compartment

has dropped.

Steering mounted controls

Steering mounted controls -

Type 1





Radio:

Select the previous/next preset radio

station.

Select the previous/next item in a menu or a list.

Media:

Select the previous/next track.

Select the previous/next item in a menu or a list.

Radio:

238

Touch screen BLUETOOTH audio system

Short press: display the list of radio stations.

Long press: update the list.

Media:

Short press: display the list of folders.

Long press: display the available sorting options.

Short press: change audio source (radio;

USB; AUX if equipment connected; CD;

streaming).

Long press: display the call log.

Short press during an incoming call: accept the

call.

Short press during a call in progress: end the

call.

Confirm a selection.



Increase volume.

Decrease volume.

Mute/restore sound by simultaneously

pressing the increase and decrease

volume buttons.

Steering mounted controls -

Type 2





Voice commands

:

This control is located on the steering

wheel or at the end of the lighting control stalk

(depending on equipment).

Short press, smartphone voice commands via

the system.

Increase volume.

Decrease volume.

Mute by pressing the volume increase

and decrease buttons simultaneously

(depending on equipment).

Restore the sound by pressing one of the two

volume buttons.

Change the multimedia source.

Short press: display the calls log.

Short press during an incoming call:

accept the call.

Long press during an incoming call: reject the

call.

Short press during a call in progress: end the

call.

Radio

 (rotate): previous/next preset

station.

Media

 (rotate): previous/next track, move in a

list.

Short press

: confirm a selection; if nothing

selected, access to presets.

Radio

: display the list of stations.

Media

: display the list of tracks.

Menus

Radio





Select a radio station.

Media





Select an audio source.

239

Touch screen BLUETOOTH audio system

10

Telephone





Connect a mobile phone via Bluetooth

®

.

Driving





Activate, deactivate or configure certain

vehicle functions (depending on

equipment/version).

Settings





Adjust the sound settings (balance,

ambience, etc.), the display (language,

units, date, time, etc.) or configure the system

(privacy).

Air conditioning/Heating





Depending on equipment/Depending on version.

Manage various temperature and air flow

settings.

Radio

Choose the band

Press the "

Radio

" menu.

Press the "

SOURCE

" button.

Choose the band:

FM

,

AM

 or

DAB

, depending

on equipment.

Selecting a station

Press one of the buttons for an automatic

search for radio stations.

Or

Press on the displayed frequency.

Enter the FM and AM waveband values

using the virtual keypad.

Or

Press this button to display the list of

stations received and available on the

waveband.

Radio reception may be affected by the

use of electrical equipment not approved

by the Brand, such as a USB charger

connected to the 12 V socket.

The exterior environment (hills, buildings,

tunnels, basement car parks, etc.) may block

reception, including in RDS mode. This

behaviour is normal in propagation of radio

waves and does not indicate any failure of the

audio system.

240

Touch screen BLUETOOTH audio system

Presetting a station

Select a radio station or frequency.

Press the "

Presets

" button.

Make a long press on an empty line to preset the

station. An audible signal confirms the presetting

of the station.

It is possible to preset up to 16 stations.

To replace a preset station by the

currently playing station, make a long

press on the preset station.

Activating/Deactivating RDS

RDS, if activated, allows you to continue

listening to the same station by automatically

retuning to alternative frequencies.

In certain conditions, tracking may not be

assured throughout the entire country as

radio stations do not cover 100% of the

territory. This explains the loss of reception of

the station during a journey.

Press the "

Radio Settings

" button.

Activate/Deactivate "

RDS options

".

Playing TA messages

The TA (Traffic Announcement) function gives

priority to TA alert messages.

To operate, this function needs good reception

of a radio station that transmits this type of

message. While traffic information is being

broadcast, the current media is automatically

interrupted so that the TA message can be

heard. Normal play of the media previously

playing is resumed at the end of the message.

Press the "

Radio Settings

" button.

Activate/Deactivate "

Traffic

announcement (TA)

".

Audio settings

Press the "

Radio Settings

" button.

In the list, select "

Audio Settings

".

Activate/deactivate and configure the available

options (sound balance, ambiances, etc.).

The sound balance/distribution is audio

processing that allows the quality of the

sound to be adapted according to where the

passengers are sitting in the vehicle.

DAB (Digital Audio

Broadcasting) radio

Terrestrial Digital Radio

Choosing the DAB radio

Terrestrial digital radio (DAB) provides higher

quality reception.

The different "multiplexes/ensembles" offer a

choice of radio stations arranged in alphabetical

order.

Press the "

Radio

" menu.

Press the "

SOURCE

" button.

In the list of available sources, choose "

DAB

Radio

".

Activating FM-DAB Tracking

"DAB" does not cover 100% of the territory.

When the digital radio signal is poor, the

"FM-DAB tracking" allows you to continue

listening to the same station, by automatically

switching to the corresponding "FM" analogue

station (if there is one).

Press the "

Radio Settings

" button.

Activate "

DAB-FM

".

If "FM-DAB tracking" is activated, there

may be a difference of a few seconds

241

Touch screen BLUETOOTH audio system

10

when the system switches to "FM" analogue

radio with sometimes a variation in volume.

Once the digital signal quality is restored, the

system automatically changes back to "DAB".

If the "DAB" station being listened to is

not available on "FM", or if the "FM-DAB

tracking" is not activated, the sound will cut

out while the digital signal is too weak.

Media

Selecting the source

Press the "

Media

" menu.

Press the "

SOURCE

" button.

Select the source (USB, Bluetooth or AUX,

depending on equipment).

USB port

Insert the USB memory stick into the USB

port or connect the USB device to the

USB port using a suitable cable (not supplied).

To protect the system, do not use a USB

hub.

The system builds playlists (in temporary

memory); this operation can take from a

few seconds to several minutes at the first

connection.

Playlists are updated whenever a USB memory

stick is connected or the contents of a particular

USB memory stick are changed. The lists

are memorised: if they are not modified, the

subsequent loading time will be shorter.

Auxiliary (AUX) jack socket

Depending on equipment

Connect a portable device (MP3 player,

etc.) to the auxiliary jack socket using an

audio cable (not supplied).

This source is only available if "

Aux

Amplification

" has been selected in the audio

settings.

First adjust the volume on the portable device

(to a high level). Then adjust the volume of the

audio system.

Controls are managed via the portable device.

Bluetooth

®

streaming

Streaming allows you to listen to music from your

smartphone.

The Bluetooth profile must be activated, first

adjust the volume on the portable device (to a

high level).

Then adjust the volume of the system.

If play does not start automatically, it may be

necessary to start the audio playback from the

smartphone.

Control is from the portable device or by using

the system's touch buttons.

Once connected in Streaming mode, the

smartphone is considered to be a media

source.

Connecting Apple

®

 players

Connect the Apple

®

 player to the USB socket

using a suitable cable (not supplied).

Play starts automatically.

Control is via the audio system.

The classifications available are those of

the portable device connected (artists/

albums/genres/playlists/audio books/

podcasts). It is also possible to use a

classification structured in the form of a

library.

The default classification used is by artist. To

modify the classification used, return to the

first level of the menu then select the desired

classification (playlists for example) and

confirm to go down through the menu to the

desired track.

The version of software in the audio system may

not be compatible with the generation of the

Apple

®

 player.

Media settings

Press the "

Media Settings

" button.

Activate/deactivate track playback options and

access the audio settings.
