18

Instruments

Emergency brake malfunction (with

electric parking brake)

Fixed, accompanied by the

message "

Parking brake fault

".

Emergency braking does not deliver optimal

performance.

If automatic release is not available, use manual

release or carry out (3).

Active lane departure warning system

Fixed.

The system has been automatically

deactivated or placed on standby.

Flashing.

You are about to cross a broken

lane marking without operating the direction

indicators.

The system is activated, then corrects the

trajectory if it detects a risk of unintentionally

crossing a line or hard shoulder (depending on

version).

For more information, refer to the

Driving



section.

Fixed.

The system has a fault.

Carry out (3).

Overload indicator (Citroën Berlingo Van)

Fixed.

The load on board the vehicle exceeds

the maximum authorised load.

The load on board the vehicle must be

decreased.

Fixed, accompanied by the display

of a message.

The overload indicator system has a fault.

Carry out (2).

AdBlue

®

 (with 1.6 BlueHDi Euro 6.1)

Fixed, on switching on the ignition,

accompanied by an audible signal and a

message indicating the driving range.

The driving range is between 1,500 and 370

miles (2,400 and 600 km).

You must quickly top up the AdBlue

®

, or carry

out (3).

AdBlue

®

 warning lamp flashing and

Service warning lamp fixed,

accompanied by an audible signal and a

message indicating the driving range.

The driving range is less than 375 miles

(600 km).

You

must

 top up the AdBlue

®

 to

avoid a

breakdown

, or carry out (3).

AdBlue

®

 warning lamp flashing and

Service warning lamp fixed,

accompanied by an audible signal and a

message indicating that starting is prevented.

The AdBlue

®

 tank is empty: the legally required

engine immobiliser system prevents the engine

from starting.

To restart the engine, top up the AdBlue

®

, or

carry out (2).

You

must

 add at least 5 litres of AdBlue

®

 to its

tank.

AdBlue

®

 (with 1.5 BlueHDi Euro 6.2/6.3)

On for around 30 seconds when starting

the vehicle, accompanied by a message

indicating the driving range.

The driving range is between 1,500 and 500

miles (2,400 and 800 km).

Top up the AdBlue

®

.

Fixed, on switching on the ignition,

accompanied by an audible signal and a

message indicating the driving range.

The driving range is between 500 and 62 miles

(800 and 100 km).

Promptly

 top up the AdBlue

®

, or carry out (3).

Flashing, accompanied by an audible

signal and a message indicating the

driving range.

The driving range is less than 62 miles (100 km).

You

must

 top up the AdBlue

®

 to

avoid engine

starting being prevented

, or carry out (3).

Flashing, accompanied by an audible

signal and a message indicating that

starting is prevented.

The AdBlue

®

 tank is empty: the legally required

engine immobiliser system prevents the engine

from starting.

To restart the engine, top up the AdBlue

®

 or carry

out (2).

It is

essential

 to add at least 5 litres of AdBlue

®



to the tank.

19

Instruments

1

SCR emissions control system (BlueHDi)

Fixed when the ignition is

switched on, accompanied

by an audible signal and a message.

A malfunction of the SCR emissions control

system has been detected.

This alert disappears once the exhaust

emissions return to normal levels.

Flashing AdBlue

®

 warning

lamp on switching on the

ignition, with the Service and Engine self-

diagnostics warning lamps on fixed,

accompanied by an audible signal and a

message indicating the driving range.

Depending on the message displayed, it is

possible to drive for up to 685 miles (1,100 km)

before the engine immobiliser is triggered.

Carry out (3) without delay, to

avoid starting

being prevented

.

Flashing AdBlue

®

 warning

lamp on switching on the

ignition, with the Service and Engine self-

diagnostics warning lamps on fixed,

accompanied by an audible signal and a

message indicating that starting is prevented.

The engine immobiliser prevents the engine from

restarting (the permitted driving limit has been

exceeded after confirmation of a malfunction of

the emissions control system).

To start the engine, carry out (2).

Service

Temporarily on, accompanied by the

display of a message.

One or more minor faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel.

You may be able to deal with some faults

yourself, such as changing the battery in the

remote control.

For other faults, such as with the tyre under-

inflation detection system, carry out (3).

Fixed, accompanied by the display of a

message.

One or more major faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel, then carry

out (3).

Fixed, accompanied by the message

"

Parking brake fault

".

Automatic release of the electric parking brake is

unavailable.

Carry out (2).

Service warning lamp fixed and

service spanner flashing then

fixed.

The servicing interval has been exceeded.

The vehicle must be serviced as soon as

possible.

Only with BlueHDi Diesel engines.

Rear foglamp

Fixed.

The lamp is on.

Green warning/indicator lamps
Stop & Start

Fixed.

When the vehicle stops, the Stop & Start

puts the engine into STOP mode.

Flashing temporarily.

STOP mode is momentarily unavailable

or START mode is automatically triggered.

For more information, refer to the

Driving



section.

Vehicle ready to drive (Electric)

Fixed, accompanied by an audible signal

when it comes on.

The vehicle is ready to drive and the thermal

comfort systems are available.

The indicator lamp goes out upon reaching a

speed of approximately 3 mph (5 km/h) and

lights up again when the vehicle stops moving.

The lamp will go out when you turn off the

engine and exit the vehicle.

Hill Assist Descent Control

Fixed.

The system has been activated, but the

conditions for regulation are not met (gradient,

speed too high, gear engaged).

Flashing.

The function is regulating the speed of

the vehicle.

20

Instruments

The vehicle is being braked; the brake lamps

come on during the descent.

Eco mode (Petrol or Diesel)

Fixed.

ECO mode is active.

Some parameters are adjusted to reduce the fuel

consumption.

Automatic wiping

Fixed.

Automatic windscreen wiping is activated.

Front foglamps

Fixed.

The front foglamps are on.

Sidelamps

Fixed.

The lamps are on.

Direction indicators

Flashing with audible signal.

The direction indicators are on.

Dipped beam headlamps

Fixed.

The lamps are on.

Automatic headlamp dipping

Fixed.

The function has been activated

via the touch screen (

Driving

/

Vehicle

 menu).

The lighting control stalk is in the "AUTO"

position.

For more information, refer to the

Lighting and

visibility

 section.

Blue warning/indicator lamps
Main beam headlamps

Fixed.

The lamps are on.

Black/white warning lamps
Foot on the brake

Fixed.

Insufficient or no pressure on the brake

pedal.

With the automatic gearbox or the drive selector,

it may be necessary to depress the brake pedal

to unlock the gearbox from mode

N

.

Foot on the clutch

Fixed.

Stop & Start: the change to START mode

is rejected because the clutch pedal is not fully

depressed.

Fully depress the clutch pedal.

Automatic wiping

Fixed.

Automatic front wiping is activated.

Hill Assist Descent Control

Fixed.

(grey)

The function has been activated, but is currently

paused because the speed is too high.

Reduce the vehicle speed to below 19 mph

(30 km/h).

Indicators

Service indicator

The servicing information is expressed in terms

of distance (miles or kilometres) and time

(months or days).

The alert is given at whichever of these two

terms is reached first.

The servicing information is displayed in the

instrument panel. Depending on the version of

the vehicle:

–  The distance recorder display line indicates

the distance remaining before the next service

is due, or the distance travelled since it was due

preceded by the "-" sign.

–  An alert message indicates the distance

remaining, as well as the period before the next

service is due or how long it is overdue.

The value indicated is calculated

according to the distance covered and

the time elapsed since the last service.

The alert may also be triggered close to a

due date.

Service spanner

On temporarily when the ignition is

switched on.

Between 620 and 1,860 miles (1,000 and 3,000

km) remain before the next service is due.

Fixed, when the ignition is switched on.

The next service is due in less than 620

miles (1,000 km).

21

Instruments

1

Have your vehicle serviced very soon.

Service spanner flashing

Flashing then fixed, when the

ignition is switched on.

(With BlueHDi Diesel engines, associated with

the Service warning lamp.)

The servicing interval has been exceeded.

Have your vehicle serviced as soon as possible.

Resetting the service indicator

The service indicator must be reset after each

service.

►  Switch the ignition off.

With LCD symbols and LCD text or matrix

instrument panel









►  Press and hold this button.

►  Switch on the ignition; the distance recorder

display begins a countdown.

►  Release the button when

=0

 is displayed; the

spanner disappears.

With digital instrument panel

The service indicator is reset using the

"

Check

" button in the

Driving/Vehicle



touch screen menu.

If you have to disconnect the battery

following this operation, lock the vehicle

and wait at least 5 minutes for the reset to be

registered.

Reminder of the servicing information

You can access the servicing information at any

time.

With LCD symbols and LCD text or matrix

instrument panel

►  Press the trip distance recorder reset button.

With digital instrument panel

You can view the servicing information by

pressing the "

Check

" button in the

Driving/Vehicle

 touch screen menu.

The servicing information is displayed for a few

seconds, then disappears.

Instrument panel display screen

With LCD symbols and LCD text or matrix

instrument panel

















With the vehicle stationary

, use the left-hand

thumbwheel on the steering wheel or the "

SET

"

button on the instrument panel to move through

the menus to configure certain vehicle settings.

Thumbwheel operation:

–  Press: open the

Main menu

; confirm the

selection.

–  Rotate (other than in a menu): scroll through

the list of available active functions.

–  Rotate (in a menu): move up or down in the

menu.

With digital instrument panel

You can configure some of the vehicle's

settings by pressing the "

Check

" button in

the

Driving/Vehicle

 touch screen menu.

Distance recorders

The total and trip distances are displayed for

thirty seconds when the ignition is switched off,

when the driver's door is opened and when the

vehicle is locked or unlocked.

22

Instruments

Total distance recorder





This measures the total distance travelled by the

vehicle since its initial registration.

Trip distance recorder

This measures the distance travelled since it was

last reset by the driver.

Resetting the trip recorder

With LCD symbols and LCD text or matrix

instrument panel









►  With the ignition on, press the button until

zeros appear.

Coolant temperature indicator





With the engine running:

–  In zone

A

, the temperature is correct.

–  In zone

B

, the temperature is too high.

The associated warning lamp and the

STOP

 warning lamp light up in red on the

instrument panel, accompanied by the display of

a message and an audible signal.

You must stop the vehicle as soon as it is

safe to do so.

Wait a few minutes before switching off the

engine.

After switching off the ignition, carefully

open the bonnet and check the coolant

level.

For more information on

Checking

levels

, refer to the corresponding

section.

Checking

After driving for a few minutes, the temperature

and pressure in the cooling system increase.

To top up the level:

►  wait at least one hour for the engine to cool,

►  unscrew the cap by two turns to allow the

pressure to drop,

►  when the pressure has dropped, remove the

cap,

►  top up the level to the "MAX" mark.

For more information on

Checking levels

, refer

to the corresponding section.

Be aware of the risk of scalding when

topping up the coolant. Do not fill above

the maximum level (indicated on the

reservoir).

Engine oil level indicator

(Depending on version)

On versions fitted with an electric gauge, the

engine oil level status is displayed on the

instrument panel for a few seconds when the

ignition is switched on, at the same time as the

servicing information.

23

Instruments

1

The level read will only be correct if the

vehicle is on level ground and the engine

has been off for more than 30 minutes.

With digital instrument panel

The conformity of the engine oil level can

be monitored by pressing the "

Check

"

button in the

Driving/Vehicle

 touch screen

menu.

With LCD symbols and LCD text or matrix

instrument panel

Oil level correct





This is indicated by a message on the instrument

panel.

Low oil level





This is indicated by a message on the instrument

panel.

If a low oil level is confirmed by a check using

the dipstick, the level must be topped up to avoid

damage to the engine.

For more information on

Checking levels

, refer

to the corresponding section.

Oil gauge malfunction





This is indicated by the display of a message on

the instrument panel.

Contact a CITROËN dealer or a qualified

workshop.

In the event of a malfunction of the

electric gauge, the oil level is no longer

monitored.

If the system is faulty, you must check the

engine oil level using the manual dipstick

located in the engine compartment.

For more information on

Checking levels

,

refer to the corresponding section.

AdBlue

®

 range indicators (BlueHDi)

The Diesel BlueHDi engines are equipped with

a system that associates the SCR (Selective

Catalytic Reduction) emissions control system

and the Diesel particle filter (DPF) for the

treatment of exhaust gases. They cannot

function without AdBlue

®

 fluid.

When the level of AdBlue

®

 falls below the

reserve level (between 1,500 and 0 miles (2,400

and 0 km)), a warning lamp lights up when

the ignition is switched on and an estimate

of the distance that can be travelled before

engine starting is prevented is displayed in the

instrument panel.

The engine starting prevention system

required by regulations is activated

automatically once the AdBlue

®

 tank is empty.

It is then no longer possible to start the

engine until the minimum level of AdBlue

®

 has

been topped up.

Manual display of driving range

While the driving range is greater than

1,500 miles (2,400 km), it is not displayed

automatically.

With LCD symbols and LCD text/matrix

instrument panel









►  Press this button to temporarily display the

driving range.

With digital instrument panel

You can view the range information by

pressing the "

Check

" button in the

Driving/Vehicle

 touch screen menu.

24

Instruments

Actions required related to a lack of

AdBlue

®

The following warning lamps light up when the

quantity of AdBlue

®

 is below the reserve level:

driving range of 1,500 miles (2,400 km).

Together with the warning lamps, messages

regularly remind you of the need to top up to

avoid engine starting being prevented. Refer to

the

Warning and indicator lamps

 section for

details of the messages displayed.

For more information on

AdBlue

®



(BlueHDi)

 and in particular on topping

up, refer to the corresponding section.

With 1.6 BlueHDi (Euro 6.1) engines

Warning/

indicator

lamps on

Action

Remaining

range





Top up as

soon as

possible.

Between

1,500 miles

and 375

miles (2,400

km and 600

km)





A top-up is

vital

, there is

a risk that the

engine will

be prevented

from starting.

Between

375 miles

and 0 miles

(600 km and

0 km)

Warning/

indicator

lamps on

Action

Remaining

range





To be able

to restart the

engine, add at

least 5 litres of

AdBlue

®

 to the

tank.

0 miles (km)

With 1.5 BlueHDi (Euro 6.2/6.3) engines

Warning/

indicator

lamps on

Action

Remaining

range





Top up.

Between

1,500 miles

and 500

miles (2,400

km and 800

km)





Top up as

soon as

possible.

Between

500 miles

and 62

miles (800

km and

100 km)

Warning/

indicator

lamps on

Action

Remaining

range





A top-up is

vital

, there is

a risk that the

engine will

be prevented

from starting.

Between 62

miles and 0

miles (100

km and 0

km)





To be able

to restart the

engine, add at

least 5 litres of

AdBlue

®

 to the

tank.

0 miles (km)

Malfunction of the SCR emissions control

system

Malfunction detection





If a malfunction is detected,

these warning lamps come

on, accompanied by an

audible signal and the

display of an "

Emissions

control fault

" or "

NO START

IN

" message.

The alert is triggered while driving when the

fault is detected for the first time, and thereafter

when switching on the ignition for subsequent

25

Instruments

1

journeys, for as long as the cause of the fault

persists.

If the fault is temporary, the alert

disappears during the next journey, after

self-diagnostic checks of the SCR emissions

control system.

Malfunction confirmed during the

permitted driving phase (between 685

miles and 0 miles (1,100 km and 0 km))

If the fault indication is still displayed

permanently after 31 miles (50 km) of driving, the

fault in the SCR system is confirmed.

The AdBlue warning lamp flashes and

a message is displayed ("

Emissions

control fault: starting prevented in X miles

(kms)

" or "

NO START IN X miles (kms)

"),

indicating the driving range in miles or

kilometres.

While driving, the message is displayed every 30

seconds. The alert is repeated when switching

on the ignition.

You can continue driving for up to 685 miles

(1,100 km) before the

engine starting

prevention

 system is triggered.

Have it checked by a CITROËN dealer or

a qualified workshop.

Starting prevented

Every time the ignition is switched on, the

message "

Emissions control fault: Starting

prevented

" or "

NO START IN

" is displayed.

To restart the engine

Contact a CITROËN dealer or a qualified

workshop.

Power indicator (Electric)





CHARGE

Traction battery charging during deceleration

and braking.

ECO

Moderate energy consumption and optimised

driving range.

POWER

Energy consumption by the drive train during

acceleration.

NEUTRAL

When the ignition is switched on, the vehicle’s

electric drive train neither consumes nor

generates energy; after sweeping over the

indicator, the cursor returns to its "neutral"

position: between ECO and CHARGE.

With the ignition off, opening the driver's

door activates the indicator, which moves

to the "neutral" position: between ECO and

CHARGE.

Charge level indicator (Electric)





The traction battery's actual charge level and

the remaining range are displayed continuously

when the vehicle is started.

With the ignition off, opening the driver's

door activates the indicator.

26

Instruments

Associated warning lamps

Two successive alert levels indicate that the

energy available has dropped to a low level:

1st level: Reserve

The state of charge of the traction battery

is low.

Fixed and indicator in the red zone,

accompanied by an audible signal.

►  View the remaining range on the instrument

panel.

►  Put the vehicle on charge as soon as

possible.

2nd level: Critical

The state of charge of the traction battery

is critical.

Fixed, together with the reserve warning lamp,

accompanied by an audible signal.

►  You must put the vehicle on charge.

The remaining range is no longer

calculated. The drive train power

gradually decreases.

The heating and air conditioning are switched

off (even if the thermal comfort consumption

indicator is not at the "

ECO

" level).

Thermal comfort consumption

indicator (Electric)

(Depending on version)





The gauge shows the consumption of the

traction battery's electrical energy by the thermal

comfort devices in the passenger compartment.

The devices in question are the heating and air

conditioning systems.

This equipment can be used:

–  If the vehicle is not plugged in, when the

READY

 lamp is lit.

–  If the vehicle is plugged in, when the ignition is

switched on ("Lounge" mode).

Selecting

ECO

 mode limits the performance of

some of this equipment. The thermal comfort

consumption indicator then moves into the

"

ECO

" zone.

To quickly heat or cool the passenger

compartment, feel free to temporarily

select the maximum heating or cooling

setting.

When the heating is on maximum, the gauge

on the thermal comfort consumption indicator

is in the

MAX

 zone. When the air conditioning

is on maximum, it stays in the

ECO

 zone.

Excessive use of thermal comfort equipment,

particularly at low speed, can significantly

decrease the vehicle's range.

Remember to optimise equipment settings

upon achieving the desired level of comfort,

and adjust them if necessary whenever you

start the vehicle.

After an extended period without using the

heating, you may notice a slight odour during

the first few minutes of use.

Lighting dimmer

This control lets you manually adjust the

brightness of the instrument panel according to

the exterior light level.

With LCD symbols and LCD

text/matrix instrument panel









With the lamps on (not in the AUTO position) ,

press button

A

 to increase the brightness of the

lighting, or button

B

 to decrease it.

Release the button when the desired brightness

is reached.

27

Instruments

1

With digital instrument

panel

With BLUETOOTH touch screen audio

system

►  Press on the

Settings

 menu.

►  Select "

Display

".

►  Adjust the brightness by

pressing the buttons.

You can also switch off the screen:

►  Select "

Turn off screen

".

The screen goes off completely.

►  Press the screen again (anywhere on its

surface) to activate it.

With CITROËN Connect Radio

►  Press this button to select the

Settings

 menu.

►  Select "

Brightness

".

►  Adjust the brightness by pressing the

arrows or moving the slider.

The settings are applied immediately.

►  Press outside the settings window to exit.

You can also switch off the screen:

►  Press this button to select the

Settings

 menu.

►  Select "

Dark

".

The screen goes off completely.

►  Press the screen again (anywhere on its

surface) to turn it on.

With CITROËN Connect Nav

With the lamps switched on:

►  Press this button to select the

Settings

 menu.

►  Select "

OPTIONS

".

►  Select "

Screen configuration

".

►  Select the "

Brightness

” tab.

►  Adjust the instrument panel and

screen brightness by using the arrows or

moving the slider.

►  Press this button to save and exit.



You can also switch off the screen:

►  Press this button to select the

Settings

 menu.

►  Select "

Turn off screen

".

The screen goes off completely.

►  Press the screen again (anywhere on its

surface) to turn it on.

Trip computer

Displays information related to the current trip

(range, fuel consumption, average speed, etc.).

Information display

Details are displayed successively.

–  Trip mileage.

– Range.

–  Current fuel consumption.

–  Average speed.

–  Stop & Start time counter.

–  Information from the speed limit recognition

system.









►  Press the button located on the end of the

wiper control stalk

.









►  Or press the thumbwheel on the steering

wheel.

Trip reset

The reset is performed when the trip counter is

displayed.

28

Instruments

►  Press the button on the end of the

wiper

control stalk

 for more than two seconds.

►  Press the knob on the

steering wheel

 for

more than two seconds.









►  Press this button for more than 2 seconds.

Definitions

Range

(miles or km)

(Traction battery charge level percentage)

(Electric)

/

Distance that can still be travelled

with the fuel remaining in the tank

(based on the average fuel consumption over the

last few miles (kilometres) travelled) (Petrol or

Diesel).

Actual traction battery charge level and

remaining range (Electric).

This value may vary following a change in driving

style or terrain, leading to a significant change in

current fuel consumption.

Vehicle with Petrol or Diesel engine:

When the range falls below 19 miles (30 km),

dashes are displayed.

After filling with at least 5 litres of fuel, the range

is recalculated and is displayed if it exceeds 62

miles (100 km).

Dashes appearing permanently in place of

numbers while driving indicates a malfunction.

Contact a CITROËN dealer or a qualified

workshop.

Vehicle with Electric motor:

Two successive alert levels indicate that the

energy available has dropped to a low level.

For more information on the

Indicators

, and in

particular the

Charge level indicator (Electric)

,

refer to the corresponding section.

Current consumption

(mpg or l/100 km or km/l)

(miles/kWh or kWh/100 km or km/kWh) (Electric)

/

Calculated during the last few

seconds.

This function is only displayed at speeds above

19 mph (30 km/h) (Petrol).

Average consumption

(mpg or l/100 km or km/l)

(miles/kWh or kWh/100 km or km/kWh) (Electric)

/

Calculated since the last trip

computer reset.

Average speed

(mph or km/h)

Calculated since the last trip computer

reset.

Distance travelled

(miles or km)

Calculated since the last trip computer

reset.

Stop & Start time counter

(minutes/seconds or hours/minutes)

If your vehicle is fitted with the Stop & Start

function, a time counter calculates the time spent

in STOP mode during a journey.

The time counter is reset each time the ignition is

switched on.

Touch screen

BLUETOOTH audio

system





This system gives access to the following

elements:

–  Audio system and telephone controls and

display of related information.

–  Vehicle function and equipment setting menus.

29

Instruments

1

–  Air conditioning system controls (depending

on version).

For safety reasons, always stop the

vehicle before performing operations

that require sustained attention.

Some functions are not accessible while

driving.

Recommendations

Do not use pointed objects on the touch screen.

Do not touch the touch screen with wet hands.

Use a soft, clean cloth to clean the touch screen.

Main controls

With the ignition off: system start-up

With the engine running: mute

Left knob: volume adjustment (rotation)/

direct access to the

Media

 menu (press)

Right knob: air flow adjustment (rotation)/direct

access to the

Climate

 menu (press)

Access to menus

Return to the previous screen or confirm



After a few moments with no action on

the second page, the first page is

displayed automatically.

Menus

Radio



Media



Climate

Settings for temperature, air flow, etc.

For more information on

Manual air

conditioning

, refer to the corresponding section.

Telephone



Driving

Activation, deactivation and settings for

certain functions.

Settings

Main system settings.

For more information about the menus,

refer to the sections describing the audio

and telematics systems.

Touch screen

This system gives access to the following

elements:

–  Permanent display of the time and outside

temperature (a blue warning lamp appears if

there is a risk of ice).

–  Vehicle functions and equipment setting

menus.

–  Audio system and telephone controls and

display of related information.

–  Display of visual manoeuvring aid functions

–  Internet services and display of related

information.

–  Navigation system controls and

display of related information (depending on

version).

For safety reasons, always stop the

vehicle before performing operations

that require sustained attention.

Some functions are not accessible while

driving.

Recommendations

This screen uses capacitive sensing technology.

–  Do not use pointed objects on the touch

screen.

–  Do not touch the touch screen with wet hands.

–  Use a soft, clean cloth to clean the touch

screen.

Principles

►  Use the

buttons on each side of the touch

screen to access the menus, then press the

buttons that appear on the touch screen.

Some menus may display across two pages:

press the "

OPTIONS

" button to access the

second page.

After a few moments with no action on

the second page, the first page is

displayed automatically.

30

Instruments

To deactivate/activate a function, select "

OFF

"

or "

ON

".

Configuring a function



Access to additional information on the

function

Confirm



Return to the previous page or confirm



Menus

Press the touch

screen with three fingers

to show all of the menu buttons.

For more information about the menus,

refer to the sections describing the audio

and telematics systems.

Radio/Media



Navigation

 (Depending on equipment)

Driving or Vehicle

 (Depending on

equipment)

Activation, deactivation and settings for certain

functions.

The functions are organised in 2 tabs: "

Driving

functions

" and "

Vehicle settings

".

Telephone



Applications

Display of available connected services.

Energy

 (with CITROËN Connect Nav)

Access the specific Electric functions

(energy flow, consumption statistics, deferred

charge) organised in the corresponding 3 tabs.

or

Settings

Main settings for the audio system and

touch screen.

Audio system on/off

Volume adjustment/mute

Upper bar

Certain information is displayed permanently in

the upper bar of the touch screen:

–  Time and outside temperature (a blue warning

lamp appears if there is a risk of ice).

–  Reminder of information from the

RadioMedia

 and

Telephone

 menus and

navigation instructions (depending on

equipment).

–  Notifications.

–  Access to the

Settings

.

Energy menu

This menu is only available with CITROËN

Connect Nav.

Depending on version, this is accessible either:

–  directly, by pressing the button near the

touch screen.

–  via the

Applications

 menu.

Flow

The page displays a real-time representation of

the electric drive train’s operation.





1.

Active driving mode

2.

Electric motor

3.

Estimated traction battery charge level

4.

Energy flows

The energy flows have a specific colour for each

type of driving:

A.

Blue: energy consumption

B.

Green: energy recovery

Statistics

This page shows electrical energy consumption

statistics.





–  Blue bar chart: directly consumed energy

supplied by the traction battery.

31

Instruments

1

–  Green bar chart: energy recovered during

deceleration and braking, used to recharge the

battery.

The average result for the current trip is stated in

kWh/100 km.

►  You can change the displayed time scale by

pressing the

-

 or

+

 buttons.

A current trip is any trip of more than 20

minutes without switching off the ignition.

Charging

This page allows you to programme deferred

charging.

For more information on

Charging the traction

battery (Electric)

, refer to the corresponding

section.

Setting the date and time

Without audio system













Set the date and time via the instrument panel

display.

►  Press and hold this button.



►  Press one of these buttons to select

the setting to be changed.

►  Briefly press this button to confirm.



►  Press one of these buttons to change

the setting and confirm again to record

the change.

For more information on setting the date

and time with the

Touch screen

BLUETOOTH audio system

,

CITROËN

Connect Radio

 or

CITROËN Connect Nav

,

refer to the corresponding sections.

32

Access

Electronic key with

remote control function

and built-in key,

If one of the doors or the boot is still open

or if the electronic key for the Keyless

Entry and Start  system has been left inside

the vehicle, central locking will not take place.

However, if the vehicle is fitted with an alarm,

it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or

tailgate are not subsequently opened, the

vehicle will automatically lock itself again after

about 30 seconds. If the vehicle is fitted with

an alarm, it will be reactivated automatically.

Automatic door mirror folding and

unfolding can be deactivated by a

CITROËN dealer or a qualified workshop.

As a safety measure, never leave the

vehicle, even for a short time, without

taking the Keyless Entry and Start system’s

electronic key with you.

Be aware of the risk of theft of the vehicle if

the key is present in one of the defined areas

while the vehicle is unlocked.

To preserve the battery charge in the

electronic key and the vehicle's battery,

the "hands-free" functions are set to

hibernation mode after 21 days without use.

To restore these functions, press one of the

remote control buttons or start the engine with

the electronic key in the reader.

For more information on starting with the

Keyless Entry and Start system, refer to the

corresponding section.

Electrical interference

The electronic key may not work if it is

close to an electronic device (e.g. mobile

telephone (switched on or on standby), laptop

computer, strong magnetic fields). If this

occurs, move the electronic key away from

the electronic device.

Remote control key

This allows the central locking or unlocking of the

vehicle using the door lock or from a distance.

It also allows the vehicle to be located, the fuel

filler cap and charging flap to be opened and

closed and the engine to be started or switched

off, as well as providing protection against theft.

The remote control buttons are not active

with the ignition switched on.

Unfolding / Folding the key





►  Press this button to unfold or fold the key.

The remote control may be damaged if

you do not press the button.

Keyless Entry and Start

This allows the central locking or unlocking of the

vehicle from a distance.

It is also used to locate and start the vehicle, as

well as providing protection against theft.

Integral key

This is used to lock and unlock the vehicle when

the remote control cannot operate:

–  remote control battery discharged, vehicle

battery discharged or disconnected, etc.

–  vehicle located in an area subject to strong

electromagnetic interference.



33

Access

2



►  Keep this button

1

 pulled across to remove

the key

2

 from the device.

If the alarm is activated, the audible

signal triggered on opening a door with

the key (integral with the remote control) will

stop when the ignition is switched on.

Once the built-in key is ejected, always

keep it with you to be able to carry out

the corresponding back-up procedures.

"Keyless Entry and Start" on your

person





It allows the unlocking, locking and starting of the

vehicle, while carrying the remote control on your

person in the recognition zone "

A

".

In the ignition on (accessories) position,

with the "START/STOP" button, the

hands-free function is deactivated and it is

impossible to open the doors.

For more information on

Starting/switching

off the engine

 and in particular the "ignition

on" position, refer to the corresponding

section.

Locating the vehicle

This function helps you to spot your vehicle from

a distance, with the vehicle locked:

–  The direction indicators flash for approximately

10 seconds.

–  The courtesy lamps come on.

►  Press this button.



Remote operation of lighting

A short press on this button switches on

the lighting remotely (lighting of

sidelamps, dipped beam headlamps and number

plate lamps).

A second press on the button before the end of

the timed period cancels the remote lighting.

Advice

Remote control

The remote control is a sensitive, high-

frequency device; avoid handling it in your

pocket, due to the risk of unintentionally

unlocking the vehicle.

Avoid pressing the remote control buttons

while out of range of the vehicle, due to

the risk of rendering the remote control

inoperative. It would then be necessary to

reset it.

The remote control does not work when the

key is in the ignition switch, even when the

ignition is switched off.

Anti-theft protection

Do not modify the electronic vehicle

immobiliser, as this might result in

malfunctions.

For vehicles with a key ignition switch,

remember to remove the key and turn the

steering wheel to engage the steering lock.

Locking the vehicle

Driving with the doors locked could make

it more difficult for the emergency services

to enter the passenger compartment in an

emergency.

As a safety precaution, remove the key from

the ignition or take the electronic key with you

when leaving the vehicle, even for a short

time.
