18

Instruments

The alert is given at whichever of these two

terms is reached first.

The servicing information is displayed in the

instrument panel. Depending on the version of

the vehicle:

–  The distance recorder display line indicates

the distance remaining before the next service

is due, or the distance travelled since it was due

preceded by the "-" sign.

–  An alert message indicates the distance

remaining, as well as the period before the next

service is due or how long it is overdue.

The value indicated is calculated

according to the distance covered and

the time elapsed since the last service.

The alert may also be triggered close to a

due date.

Service spanner

On temporarily when the ignition is

switched on.

Between 620 and 1,860 miles (1,000 and 3,000

km) remain before the next service is due.

Fixed, when the ignition is switched on.

The next service is due in less than 620

miles (1,000 km).

Have your vehicle serviced very soon.

Service spanner flashing

Flashing then fixed, when the ignition is

switched on.

The servicing interval has been exceeded.

Have your vehicle serviced as soon as possible.

Resetting the service indicator

The service indicator must be reset after each

service.

If you have serviced your vehicle yourself:

►  Switch the ignition off.









►  Press and hold the button located on the end

of the lighting control stalk.

►  Without pressing the brake pedal, press the

START/STOP

 button once; a temporary display

window appears and a countdown begins.

►  When the display indicates =0, a confirmation

message appears; release the lighting control

stalk button and the spanner symbol disappears.

If you disconnect the battery following

this operation, lock the vehicle and wait

at least 5 minutes for the reset to be

registered.

Reminder of the servicing information

Servicing information is accessible using

the “

Check

” button in the

Settings>Vehicle

 touch screen application.

Engine oil level indicator

(Depending on version)

On versions fitted with an electric gauge, the

engine oil level status is displayed on the

instrument panel for a few seconds when

the ignition is switched on, after the servicing

information, in the form of messages.

The level read will only be correct if the

vehicle is on level ground and the engine

has been off for more than 30 minutes.

Low oil level

This is indicated by the message "

Oil

level incorrect

" on the instrument panel,

accompanied by the lighting of the Service

warning lamp and an audible signal.

If a low oil level is confirmed by a check using

the dipstick, the level must be topped up to avoid

damage to the engine.

For more information on

Checking levels

, refer

to the corresponding section.

Oil gauge malfunction

This is indicated by the message "

Oil level

measurement invalid

" on the instrument panel.

Contact a CITROËN dealer or a qualified

workshop.

19

Instruments

1

In the event of a malfunction of the

electric gauge, the oil level is no longer

monitored.

If the system is faulty, you must check the

engine oil level using the manual dipstick

located in the engine compartment.

For more information on

Checking levels

,

refer to the corresponding section.

Coolant temperature

indicator

This information is only available in the

instrument panel's customisable area.

For more information on the

Digital instrument

panel

, refer to the corresponding section.





With the engine running:

–  In zone

A

, the temperature is correct.

–  In zone

B

, the temperature is too high.

The associated warning lamp and the

STOP

 warning lamp light up in red on the

instrument panel, accompanied by the display of

a message and an audible signal.

You must stop the vehicle as soon as it is

safe to do so.

Wait a few minutes before switching off the

engine.

After switching off the ignition, carefully

open the bonnet and check the coolant

level.

For more information on

Checking

levels

, refer to the corresponding

section.

Power indicator

(Rechargeable hybrid)

The power indicator shows in real time the power

demanded from the vehicle.

There are 3 zones:





POWER High power demand, using the

combined capabilities of the petrol

engine and the electric motor.

The slider is located in this zone

during more dynamic driving phases

when high levels of performance are

being demanded.

ECO

Optimal use of energy (internal

combustion or electric).

The slider is located in this zone

when driving under electric power

and when optimal use is being made

of the petrol engine, both accessible

by adopting a suitable driving style.

A symbol indicates the threshold at

which the petrol engine will restart.

The driver can therefore moderate

their acceleration to remain in electric

driving mode.

CHARGE Energy recovery for partly

recharging the traction battery.

The slider is located in this zone

during deceleration: taking your foot

off the accelerator pedal or braking.

Partial recharging of the battery by

energy recovery has no effect on the

charge level indicator.

Charge level indicator

(Rechargeable hybrid)





The charge level of the traction battery and

the remaining range in electric driving mode

are permanently displayed when the vehicle is

switched on.

20

Instruments

The range displayed depends on the use

of the vehicle (type of driving and speed),

the outside temperature and the activated

comfort equipment.

Manual test

This function allows you to check certain

indicators and display the alerts log.

The test is launched in the

Settings>Vehicle

 touch screen

application.

►  Then select

Safety>Check

.

The following information is displayed on the

instrument panel:

–  Tyre pressures.

–  Engine oil level (depending on engine).

–  Next service due.

–  Current alerts.

This information is also displayed

automatically every time the ignition is

switched on.

Total distance recorder

The total distance recorder measures the total

distance travelled by the vehicle since its initial

registration.

With the ignition on, the total distance is

displayed at all times. It remains displayed for

30 seconds after switching off the ignition. It is

displayed when the driver's door is opened, and

when the vehicle is locked or unlocked.

When travelling abroad, it may be

necessary to change the distance units

(km or miles): the road speed must be

displayed in the local country’s official unit

(km/h or mph).

The unit is changed via the application of

screen settings, with the vehicle stationary.

Rechargeable hybrid vehicles

The total distance recorder is only

accessible from the trip computer.

For more information on the

Trip computer

,

refer to the corresponding section.

Lighting dimmer

Used to manually adjust the brightness of the

instruments and controls to suit the exterior light

level.

It is configured in the

Settings >

Brightness

 touch screen application.

►  In the “

Cockpit

” section, press or move the

slider to the desired setting.

Trip computer

Displays information related to the current trip

(range, fuel consumption, average speed, etc.).

Data displayed on the

instrument panel

Display of the different tabs









►  Pressing the button located on the end of the

wiper control stalk displays the following tabs in

turn:

–  Current information:

•  Total range.

•  Current consumption (Petrol).

•  Total odometer (Rechargeable hybrid).

•  Traction battery charge level percentage

(Rechargeable hybrid).

•  Autonomy (Petrol or Diesel, only on the

E-HUD).

•  Current consumption (Petrol or Diesel).

•  Stop & Start time counter (Petrol).

•  Percentage of the current journey travelled

in all-electric driving mode (Rechargeable

hybrid).

–  Trips "

1

" then "

2

":

•  Average speed.

•  Average fuel consumption.

•  Distance travelled.

Depending on the settings for the pages

displayed on the instrument panel and

the activation/deactivation of the extended

21

Instruments

1

head-up display, the trip computer appears in

one or the other, or both.

For more information on the

Digital

instrument panel

 and the

E-HUD

, refer to

the corresponding sections.

Trip reset

►  When the desired trip is displayed,

press the button on the end of the wiper

control stalk for more than 2 seconds.

Trips "

1

" and "

2

" are independent and are used

in the same way.

Definitions

Range

(miles or km)

Distance that can still be travelled with the

fuel remaining in the tank (based on the

average fuel consumption over the last few miles

(kilometres) travelled).

This value may vary following a change in driving

style or terrain, leading to a significant change in

current fuel consumption.

When the range falls below 19 miles (30 km),

dashes are displayed.

After filling with at least 5 litres of fuel, the range

is recalculated and is displayed if it exceeds 62

miles (100 km).

If dashes instead of figures continue to be

displayed while driving, contact a CITROËN

dealer or a qualified workshop.

Current consumption

(mpg or l/100 km or km/l)

Calculated during the last few seconds.

This function is only displayed at speeds above

19 mph (30 km/h).

Average consumption

(mpg or l/100 km or km/l)

Calculated since the last trip computer

reset.

Average speed

(mph or km/h)

Calculated since the last trip computer

reset.

Distance travelled

(miles or km)

Calculated since the last trip computer

reset.

Stop & Start time counter

(minutes/seconds or hours/minutes)

If your vehicle is fitted with Stop & Start, a time

counter calculates the time spent in STOP mode

during a journey.

The time counter is reset each time the ignition is

switched on.

Touch screen

This system gives access to the following

elements:

–  Time and exterior temperature.

–  Heating/air conditioning system controls and

reminders of settings.

–  Settings for driving aid functions, comfort and

safety functions, audio equipment and digital

instrument panel.

–  Settings of functions specific to rechargeable

hybrid vehicles.

–  Display of visual manoeuvring aid functions.

–  Interactive handbook.

–  Video tutorials (e.g. screen management,

driving aids, voice recognition).

–  Audio equipment and telephone controls with

display of associated information.

–  Connected services and display of associated

information.

–  Navigation system controls and display

of associated information (depending on

equipment).

–  Voice recognition (depending on equipment).

For safety reasons, always stop the

vehicle before performing operations

that require sustained attention.

Some functions are not accessible while

driving.

Recommendations

It is a capacitive touch screen.

22

Instruments

Do not use pointed objects on the touch screen.

Do not touch the touch screen with wet hands.

►  Use a soft, clean cloth to clean the touch

screen.

Main controls

Access to one of the

Home

 pages

Return to the first

Home

 page

Direct access to the

Shortcuts for

driving aids

►  Swipe down from the upper edge of the touch

screen to access a list of quick settings (e.g.

Brightness

,

Diagnostics

).

►  Depending on the pages displayed on the

screen, with or without the context menu, scroll

the text by swiping with your finger, as with a

smartphone.

Show/Hide context menu

Return to the previous page

►  To change the status of a function, press the

description for the corresponding line (change

confirmed by the slider moving to the right/left:

function activated/deactivated).

Access to additional information on the

function

Access to function parameters

Adding/Removing shortcuts

Short press, ignition off: system on/off.

Short press, ignition on: mute/restoration of

sound.

Long press, ignition on: launch of standby mode

(mute, screens off and clock display).

Rotation: volume adjustment.

Applications

Press this button to access the

applications wall.

From any page, press the touch screen

with three fingers to display the

applications wall.

To obtain information about the other

applications not listed here, refer to the sections

describing the audio and telematic systems.

ADAS

Activation/Deactivation and configuration

of the driving aid functions.

Climate

Settings for air flow, etc.

For more information on

Dual-zone automatic

air conditioning

, refer to the corresponding

section.

Seat Options

Activation/Deactivation and configuration

of the seat comfort functions (ventilation and

massages).

For more information on the

Ventilated seats



or on the

Multi-point massages

, refer to the

corresponding section.

Settings

Main settings for the audio system, touch screen

and digital instrument panel.

Activation/Deactivation and configuration of

the exterior lighting, vehicle access and safety

functions.

For more information on the other applications,

refer to the sections describing the Audio and

telematics systems.

Energy

Access to the rechargeable hybrid system

features (energy flow, consumption statistics,

deferred charging, e-SAVE function).

Energy application

Energy Flow

The page shows the operation of the

rechargeable hybrid system in real time.

1.

Active driving mode

2.

Petrol engine

3.

Electric motor

4.

Traction battery charge level

The energy flows have a specific colour for each

type of driving:

–  Blue: 100% electrical energy.

23

Instruments

1

–  Orange: energy from the petrol engine.

–  Green: energy recovery.

Statistics

This page shows electrical energy and fuel

consumption statistics.





1.

 Average electrical consumption for the current

trip (kWh/100 km) and historical values:

–  Blue graph: energy consumed directly from

the traction battery.

–  Green graph: energy regenerated during

deceleration and braking phases to recharge the

battery.

2.

 Average fuel consumption for the current trip

(l/100 km) and historical values (orange graph).

Charging

This page allows you to programme deferred

charging.

For more information on

Charging the traction

battery (Rechargeable hybrid)

, refer to the

corresponding section.

e-SAVE

The

e-SAVE

 function makes it possible to

reserve all or part of the electrical energy of the

traction battery to be used later during a journey

(e.g. passing through an urban area or an area

reserved for electric vehicles).

►  Activate the function by pressing

ON

, then

select the electric range to be reserved (

6 miles

(10 km)

,

12 miles (20 km)

 or the full range

MAX

).

Activation of the function is confirmed by

the lighting of this indicator lamp on the

instrument panel and the indication of the energy

reserve in miles or kms.

►  To use the energy reserve, choose the

Electric

 driving mode in the mode selector.

If the requested range exceeds the

available range (not recommended), the

internal combustion engine starts to recharge

the traction battery up to the requested

threshold. This leads to excessive fuel

consumption.

My shortcuts

(Depending on equipment)





From the edge of the audio system's screen,

swipe right to display the shortcuts.

By default, it suggests the main applications:

Media

,

Navigation

,

Phone

,

Mirror Screen

...

These shortcuts can be customised.

For more information, refer to the Audio

equipment and telematics systems.

Remote functions

(Rechargeable hybrid)





In addition to all the functions of

the

MyCitroën App

 application

that you can access from a

smartphone, you can access the

following functions:

–  Battery charge management (Deferred

charging).

–  Temperature pre-conditioning management.

–  Consultation of the state of charge and range

of the vehicle.

24

Instruments

Installation procedure

►  Download the

MyCitroën App

 app from the

appropriate online store for your smartphone.

►  Create an account.

►  Enter the vehicle’s V.I.N. (code beginning

with "VF" on the vehicle registration document).

For more information on

Identification

markings

, refer to the corresponding section.

Network coverage

In order to be able to use the various

remotely operable features, ensure that your

vehicle is located in an area covered by the

mobile network.

A lack of network coverage may prevent

communication with the vehicle (for example,

if it is in an underground car park). In such

cases, the application will display a message

indicating that the connection with the vehicle

could not be established.

25

Access

2

Electronic key with

remote control function

and built-in key

Remote control function





The remote control can be used for the following

remote functions, depending on version:

–  Unlocking/Locking/Deadlocking the vehicle.

–  Unlocking - Opening the boot.

–  Folding/Unfolding the door mirrors.

–  Activating/Deactivating the alarm.

–  Locating the vehicle.

–  Opening/Closing the windows.

–  Closing the sunroof.

–  Activating the vehicle’s electronic immobiliser.

Back-up procedures allow the vehicle to be

locked/unlocked in the event of a failure of the

remote control, the central locking, the battery,

etc. For more information on the

Back-up

procedures

, refer to the corresponding section.

Built-in key

The key built into the remote control can be

used for the following operations, depending on

version:

–  Activation/Deactivation of the manual child

lock.

–  Activation/Deactivation of the front passenger

airbag.

–  Back-up Unlocking/Locking of the doors.





►  To eject the key or put it back in place, pull

and hold the button.

Once the built-in key is ejected, always

keep it with you to be able to carry out

the corresponding back-up procedures.

Unlocking the vehicle





Selective unlocking (driver’s door, boot) is

configured in the

Settings > Vehicle



touch screen application.

Complete unlocking

►  If the selective unlocking is deactivated,

press the unlocking button.

Depending on version, the door mirrors unfold.

Selective unlocking

Driver’s door and fuel filler/charging flap

►  Press the unlocking button.

►  Press it

again

 to unlock the other doors and

the boot.

The charging nozzle can be unplugged on the

second press.

Complete or selective unlocking, and alarm

deactivation (depending on version), is confirmed

by the flashing of the direction indicators.

Depending on version, the door mirrors unfold.

Opening the windows

►  To open the windows, press the unlocking

button for more than 2 seconds (depending on

version).

►  Press again to stop the windows opening.

Selective unlocking and opening of

the tailgate

By default, selective unlocking of the tailgate

is deactivated and its motorised operation is

activated.

26

Access

►  Press and hold this button to unlock

the boot and trigger the motorised

opening of the tailgate.

When selective unlocking of the tailgate is

activated, the doors and the fuel filler flap remain

locked.

If selective unlocking of the tailgate is

deactivated, pressing the button unlocks the

whole vehicle.

If motorised operation of the tailgate is

deactivated, pressing the button partially

opens the tailgate.

To lock the vehicle, it is necessary to close

the tailgate again.

Locking the vehicle





Normal locking

►  Press the locking button.

The locking, and the activation of the alarm

depending on version, is confirmed by the

lighting of the direction indicators.

Depending on version, the door mirrors fold.

An access (door or boot) that is not

properly closed prevents locking of the

vehicle. However, if the vehicle is fitted with

an alarm, it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or boot

are not subsequently opened, the vehicle

will automatically lock itself again after about

30 seconds. If the vehicle is fitted with an

alarm, it will be reactivated automatically.

Closing the windows and sunroof

►  To completely close the windows and,

depending on version, the sunroof, press the

locking button for more than 2 seconds.

►  Press again to stop closing.

Ensure that no person or object could

prevent the correct closing of the

windows and sunroof.

If, on versions with alarm, you want to

leave the windows and/or sunroof partially

open, you must first deactivate the interior

volumetric alarm protection.

For more information on the

Alarm

, refer to

the corresponding section.

Deadlocking





Deadlocking renders the interior door

controls inoperative. It also disables the

central locking button.

The horn remains operational.

Never leave anyone inside the vehicle

when it is deadlocked.

►  Press the locking button.

►  Press the locking button again within 3

seconds to deadlock the vehicle (confirmed by

the temporary lighting of the direction indicators).

For vehicles equipped with the Keyless

Entry and Starting system, a double audible

signal indicates that the vehicle has not been

deadlocked.

Depending on version, activation/

deactivation of the audible signal is done

in the

Settings > Vehicle

 touch screen

application.

Locating the vehicle

Helps you to locate your vehicle from a distance,

with the vehicle locked:

–  The direction indicators flash for approximately

10 seconds.

–  The door mirror spotlamps come on.

–  The courtesy lamps come on.

►  Press this button.



Advice

Remote control

The remote control is a sensitive, high-

frequency device; avoid handling it in your

pocket, due to the risk of unintentionally

unlocking the vehicle.

Avoid pressing the remote control buttons

while out of range of the vehicle, due to

the risk of rendering the remote control

27

Access

2

inoperative. It would then be necessary to

reset it.

Anti-theft protection

Do not modify the electronic vehicle

immobiliser, as this might result in

malfunctions.

Locking the vehicle

Driving with the doors locked could make

it more difficult for the emergency services

to enter the passenger compartment in an

emergency.

As a safety precaution, take the electronic key

with you when leaving the vehicle, even for a

short time.

Purchasing a second-hand vehicle

Have the key codes memorised by a

CITROËN dealer, to ensure that the keys in

your possession are the only ones able to

start the vehicle.

Proximity Keyless Entry

and Start

This Keyless Entry and Starting system enables

automatic vehicle locking/unlocking simply by

detection of the electronic key.

As long as the driver has the electronic key

on their person, the vehicle unlocks as they

approach and locks when they walk away.

Key recognition zones:





Zone A

: welcome lighting on approaching

the vehicle (between 3 and 5 metres from the

vehicle).

Zone B

: automatic locking on leaving the vehicle

(about 2 metres from the vehicle).

Zone C

: automatic unlocking on approaching

the vehicle (between 1 and 2 metres from the

vehicle).

Automatic functions are configured in the

Settings > Vehicle

 touch screen

application.

Unlocking the vehicle





Selective unlocking (driver’s door, boot) is

configured in the

Settings > Vehicle



touch screen application.

Complete unlocking

The vehicle (doors and boot) unlocks:

►  either automatically when the driver is

approaching (zone

C

), if the automatic functions

are activated;

►  or by a light press on the driver's door handle.

The unlocking, and the deactivation of the alarm

depending on version, is confirmed by flashing of

the direction indicators.

Depending on version, the door mirrors unfold.

If the key remains around the vehicle

(zones

A

,

B

 or

C

) for more than 15

minutes without action, the automatic

functions are deactivated. To unlock or lock

the vehicle, use the remote control or press

on one of the door handles.

If using the door handle does not lock/unlock

the vehicle, bring the key closer and repeat

the desired action.

28

Access

Selective unlocking

Driver’s door and fuel filler/charging flap

They unlock:

►  either automatically when approaching the

driver’s door, if the automatic functions are

activated;

►  or by a light press on the handle.

►  Once inside the vehicle, to unlock all

accesses, press the central locking button or pull

the opening control of any door.

If the user is outside zone

A

 and presses

once on the unlocking button of their

electronic key, only the driver's door and the

fuel filler flap will unlock if selectivity is

activated. Pressing the button again unlocks

the rest of the vehicle.

Selective unlocking of the tailgate

The tailgate unlocks automatically as you

approach the rear of the vehicle.

►  Press the tailgate control to open the boot.

The doors remain locked.

Locking the vehicle

Normal locking





With the doors and boot closed, the vehicle

locks:

►  either automatically when leaving recognition

zone

B

, if the automatic functions are activated;

►  or by a light press on the driver's door handle.

The locking is confirmed by the illumination

of the direction indicators as well as a double

audible signal for the locking on moving away

from the vehicle.

The alarm does not activate when

locking automatically from a distance (the

direction indicators do not light up).

It is not possible to lock the vehicle if the

electronic key is left inside.

Deadlocking





Deadlocking renders the interior door

controls inoperative. It also deactivates

the central locking button.

The horn remains operational.

Never leave anyone inside the vehicle

when it is deadlocked.





►  Gently press the driver’s door handle to lock

the vehicle.

►  Press it again within 3 seconds to deadlock

the vehicle (confirmed by the temporary lighting

of the direction indicators).

A double audible signal indicates that the vehicle

has not been deadlocked.

Depending on version, activation/

deactivation of the audible signal is done

in the

Settings > Vehicle

 touch screen

application.

Advice

If one of the doors or the boot is still open

or if the electronic key for the Keyless

Entry and Starting system has been left inside

the vehicle, central locking will not take place.

If the vehicle is unlocked but the doors or

tailgate are not subsequently opened, the

vehicle will automatically lock itself again after

about 30 seconds. If the vehicle is so

equipped, the alarm is automatically

reactivated (if previously activated).

Automatic folding/unfolding of the door

mirrors is configured in the

Settings >

Vehicle

 touch screen application.

As a safety measure, never leave the

vehicle, even for a short time, without

29

Access

2

taking the Keyless Entry and Starting

system’s electronic key with you.

Be aware of the risk of theft of the vehicle if

the key is present in one of the defined areas

while the vehicle is unlocked.

In order to preserve the battery in the

electronic key and the vehicle's battery:

–  The unlock on approach function (zone

C

)

automatically switches to standby mode

after several days (approximately one week)

without being used. To unlock the vehicle, use

the remote control or press on one of the door

handles. The next time the vehicle is started,

the automatic unlocking and locking functions

will be reactivated.

–  If the welcome lighting is triggered

several times in succession without the

vehicle subsequently being started, it will be

deactivated.

–  All "hands-free" functions switch to

extended standby mode after 21 days of non-

use. To restore these functions, unlock the

vehicle using the remote control and start the

engine.

Electrical interference

The electronic key may not operate

if close to certain electronic devices (e.g.

telephones (switched on or on standby),

laptop computers, strong magnetic fields). If

this is the case, move the electronic key away

from the electronic device.

Central locking









Manual

►  Press this button to lock/unlock the vehicle

(doors and boot) from inside the vehicle.

The indicator lamp comes on to confirm the

central locking of the vehicle.

Central locking does not take place if any

of the doors are open.

When locking/deadlocking from the

outside

When the vehicle is locked or deadlocked

from the outside, the indicator lamp flashes

and the button is deactivated.

►  After normal locking, pull one of the

interior door controls to unlock the vehicle.

►  After deadlocking, you must use the

remote control, the "Keyless Entry and

Starting" system or the built-in key to unlock

the vehicle.

Automatic (anti-intrusion

security)

The doors and boot lock automatically while

driving (speed above 6 mph (10 km/h)).

To deactivate/reactivate this function (activated

by default):

►  Press the button until a confirmation

message appears.

Transporting long or voluminous

objects

Press the central locking control to drive

with the boot open and the doors locked.

Otherwise, every time the speed of the

vehicle exceeds 6 mph (10 km/h), the sound

of the locks rebounding will be heard and an

alert will be displayed.

Back-up procedures

Lost keys, remote control,

electronic key

Go to a CITROËN dealer with the vehicle's

registration certificate, your personal

identification documents and if possible, the label

bearing the key code.

30

Access

The CITROËN dealer will be able to retrieve the

key code and the transponder code, enabling a

new key to be ordered.

Complete unlocking/locking

of the vehicle with the key

Use this procedure in the following situations:

–  Remote control battery discharged.

–  Remote control malfunction.

–  Vehicle battery discharged.

–  Vehicle in an area subject to strong

electromagnetic interference.

In the first case, change the remote control

battery.

In the second case, reinitialise the remote

control.

Refer to the corresponding sections.





►  Insert the key in the notch of the lock cover

and remove the lock cover.

►  Insert the key in the door lock.

►  Turn the key towards the front or the rear to

unlock and lock the vehicle.

If the vehicle is fitted with an alarm, it will

not be activated when locking with the

key.

If the alarm is activated, the siren sounds

when the door is opened; switch on the

ignition to stop it.

Central locking not

functioning

Use these procedures in the following cases:

–  Central locking malfunction.

–  Battery disconnected or discharged.

In the event of a malfunction of the

central locking system, the battery must

be disconnected to ensure that the vehicle is

locked fully.

Front left-hand door

►  Insert the key in the lock and turn it to lock

the door.

Other doors

Unlocking

►  Pull the interior door opening control.

Locking





►  Open the doors.

►  For the rear doors, check that the child lock

is not on.

Refer to the corresponding section.

►  Gently insert the key into the latch located in

the door lock, then turn the latch an eighth of a

turn towards the outside of the door.

►  Close the doors and check from the outside

that the vehicle is locked.

Changing the battery

A message is displayed on the instrument panel

when the battery needs changing.

31

Access

2

Battery type: CR2032/3 volts.





►  Unclip the cover by inserting a small

screwdriver in the slot and lift the cover.

►  Remove the flat battery from its housing.

►  Put the new battery in place, respecting the

polarity. Start by inserting it into the contacts

located in the corner, then clip the cover onto

the unit.

►  Reinitialise the remote control.

For more information on

Reinitialising the

remote control

, refer to the corresponding

section.

Do not throw remote control batteries

away, as they contain metals that are

harmful to the environment. Take them to an

approved disposal point.

This product contains a coin / button cell

battery.

Do not ingest battery. Chemical Burn Hazard.

If the coin / button cell battery is swallowed,

it can cause severe internal burns in just 2

hours and can lead to death.

If you think coins / buttons cell battery might

have been swallowed or placed inside any

part of the body, seek immediate medical

attention.

Keep new and used batteries away from

children.

If the battery compartment does not close

securely, stop using the product and keep it

away from children.

Risk of explosion if the coin / button cell

battery is replaced by an incorrect type.

Replace the coin / button cell battery with the

same type.

Risk of explosion or the leakage of

flammable liquid or gas.

Do not use in /store in /bring into environment

of extremely high temperature or extremely

low pressure due to the very high altitude.

Do not attempt to burn, crush, or cut used

coin / button cell battery.

Reinitialising the remote

control

Following replacement of the battery or in

the event of a fault, it may be necessary to

reinitialise the remote control.





►  Insert the mechanical key (incorporated into

the remote control) into the lock to open the

vehicle.

►  Place the electronic key against the back-up

reader on the steering column and hold it there

until the ignition is switched on.

►

With an automatic gearbox,

 while in mode

P

, depress the brake pedal.

►  Switch on the ignition by pressing the

"

START/STOP

" button.

If the fault persists after reinitialisation, contact a

CITROËN dealer or a qualified workshop without

delay.

Doors

Opening

From outside

►  After unlocking the vehicle or with the

"Keyless Entry and Starting" system electronic

key in the recognition zone, pull the door handle.

32

Access

From inside

►  Pull the interior opening control of a door; this

unlocks the vehicle completely.

With selective unlocking activated:

–  Opening the driver's door unlocks

the driver's door only (if the vehicle has not

already been completely unlocked).

–  Opening one of the passenger doors

unlocks the rest of the vehicle.

Boot

Opening the tailgate

►   With the vehicle unlocked or with the

electronic key in the recognition zone, press the

central tailgate control.

►  Raise the tailgate.

When selective unlocking is activated,

the electronic key must be close to the

rear of the vehicle.

The tailgate is not designed to hold a

bicycle carrier.

Closing the tailgate

►  Lower the tailgate using the interior grips.

►  Release the grips and press down on the

outside of the tailgate to close it.

In the event of a malfunction or if you

experience difficulty opening or closing

the tailgate, have it checked by a CITROËN

dealer or a qualified workshop without delay,

to avoid the issue deteriorating and prevent

any risk of the tailgate dropping, potentially

causing serious injury.

Back-up release

To manually unlock the boot in the event of a

battery or central locking failure.

Unlocking

►  Fold the rear seats to gain access to the lock

from inside the boot.





►  Insert a small screwdriver into hole

A

 of the

lock to unlock the boot.

►  Move the latch to the left.

Locking after closing

If the fault persists after closing again, the boot

will remain locked.

Motorised tailgate

The motorised tailgate must only be operated

with the vehicle stationary.





Check that there is enough space to

allow for the movement of the motorised

tailgate.





Never insert a finger in the locking

system of the motorised tailgate - risk of

serious injury!

33

Access

2

To avoid the risk of injury through

pinching or trapping, before and during

operation of the motorised tailgate:

–  ensure that there is no-one close to the

rear of the vehicle.

–  monitor the activity of the rear passengers,

particularly any children.

Bicycle carrier/Towing device

The motorised tailgate is not designed to support

a bicycle carrier.

When installing a bicycle carrier on the towing

device with connection of the cable to the trailer

socket, the motorised operation of the tailgate

will be automatically deactivated.

If using a towing device or bicycle carrier

not recommended by CITROËN, it is

essential to deactivate the motorised

operation of the tailgate.

Motorised operation

The motorised operation of the tailgate is

configured in the

Settings > Vehicle



touch screen application.





There are several ways of operating the tailgate:

A.

Using the Keyless Entry and Starting

system’s electronic key

B.

Using the exterior tailgate control

C.

Using the interior tailgate control

D.

Using the control on the dashboard

Opening

►  A long press on the central button

A

 of the

electronic key.

or

►  A short press on the exterior tailgate control

B

, with the electronic key on your person.

or

►  Two consecutive presses on the control

D

 on

the dashboard.

The tailgate opens, either completely by

default, or to the position memorised

beforehand.

If motorised operation is not activated, these

actions release the tailgate (partially-open

position).

When the vehicle is locked, the request to

open the boot with one of the controls

A



or

B

 unlocks the vehicle, or only the boot if

selective unlocking is activated, prior to the

opening of the boot.

Closing

►  A short press on the interior tailgate control

C

.

It is possible to interrupt the operation of

the tailgate at any point.

Pressing one of these controls again

interrupts the movement that is underway.

Memorising an opening

position

To limit the opening angle of the motorised

tailgate:

►  move the tailgate to the desired position

manually or by pressing the button.

►  press button

C

 or the exterior control

B

 for

more than 3 seconds (memorisation is confirmed

by a brief audible signal).

A new memorisation operation cancels the

previous one.
