Citroen SpaceTourer (2016 year). Instruction

415

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Media

QUESTION

ANSWER

SOLUTION

Playback of my USB
memory stick starts only
after a very long wait
(around 2 to 3 minutes).

Some files supplied with the memory stick may greatly slow down
access to reading the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

Some characters in the
media information are not
displayed correctly while
playing.

The audio system does not display some types of characters.

Use standard characters to name tracks and
folders.

Playing of streaming files
does not start.

The peripheral device connected does not support automatic play.

Start the playback from the device.

The names of tracks and
the track length are not
displayed on the screen
when streaming audio.

The Bluetooth profile does not allow the transfer of this information.

416

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be switched off or the
telephone may not be visible.

Check that your telephone's Bluetooth function is
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with the system.

You can check the compatibility of your
telephone at the brand's website (services).

The volume of the
telephone connected
in Bluetooth mode is
inaudible.

The volume depends both on the system and on the telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.

The ambient noise level has an influence on the quality of
telephone communication.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).

Some contacts are
duplicated in the list.

The options for synchronizing contacts are synchronizing the
contacts on the SIM card, the contacts on the telephone, or both.
When both synchronizations are selected, some contacts may be
duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

Contacts are not shown in
alphabetical order.

Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order.

Modify the display setting in the telephone
directory.

The system does not
receive SMS text messages.

The Bluetooth mode does not permit sending SMS text messages
to the system.

Telephone

417

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

In changing the setting
of treble and bass the
equalizer setting is
deselected.

The selection of an equalizer setting imposes the settings for treble
and bass and vice-versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

In changing the equalizer
setting, treble and bass
return to zero.

When changing the
balance settings, the
distribution setting is
deselected.

The selection of a distribution setting imposes the balance settings
and vice-versa.

Modify the balance or distribution settings to
obtain the desired musical ambience.

When changing a
distribution setting,
the balance setting is
deselected.

Settings

418

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources.

For optimum sound quality, the audio settings for Loudness,
Ambience, Treble, Bass and Volume can be adapted to the different
sound sources, which may result in audible differences when
changing source.

Check that the audio settings for Loudness,
Ambience, Treble, Bass and Volume are adapted
to the sources listened to. Adjust the Balance,
Treble and Bass to the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

With the engine off, the
system switches off after a
few minutes of use.

When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
The switch-off is normal: the system switches to economy mode
and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

419

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

CITROËN Connect Radio

Connectivity - Multimedia audio - Bluetooth

telephone

Contents

First steps

420

Steering mounted controls

422

Menus 423
Connectivity 424
Radio Media

434

Telephone 446
Settings

458

Frequently asked questions

468

The system is protected in such a way that it will only operate in
your vehicle.

The link below gives access to OSS (Open Source Software)
codes for the system.
http://www.psa-peugeot-citroen.com/oss

As a safety measure and because it requires sustained attention
by the driver, the pairing of a Bluetooth mobile telephone with
the Bluetooth hands-free system of your audio system must be
done with the vehicle stationary

and the ignition on.

The display of the energy economy mode message signals that
a change to standby is imminent. For more information on the
Energy economy mode

refer to the corresponding section.

420

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns the
system on.

Volume.

Use the buttons either side of the touch screen
for access to the menus, then press the virtual
buttons in the touch screen. All of the touch
areas of the screen are white.
Each menu is displayed in one or two pages
(primary page and secondary page).

Secondary page

Primary page

The touch screen is of the "capacitive"
type.
To clean the screen, use a soft,
non-abrasive cloth (spectacles cloth)
with no additional product.
Do not use sharp objects on the
screen.
Do not touch the screen with wet
hands.

421

12:13

23 °C

531 kHz

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Select the audio source (depending on version):
- FM / DAB* / AM* stations.
- Smartphone via MirrorLink

or CarPlay

- USB memory stick.
-

Media player connected to the auxiliary
socket (jack, cable not supplied).

Telephone connected by Bluetooth* and
using Bluetooth* audio streaming.

* Depending on equipment.

Short-cuts: using the virtual buttons in the
upper band of touch screen, it is possible to go
directly to the selection of audio source, the list
of stations (or titles, depending on the source),
message notifications and emails.

In very hot conditions, the volume may
be limited to protect the system. It may
go into standby (screen and sound off)
for at least 5 minutes
The return to normal takes place when
the temperature in the passenger
compartment drops.

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with the
possibility of entering a multitude of
settings (radio presets, audio settings,
contact favourites, ...); these settings
are taken into account automatically.

422

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Steering mounted controls

Media

(short press): change the

multimedia source.
Telephone

(short press): call.

Call in progress

(short press):

access to telephone menu.
Telephone

(long press): reject an

incoming call, end call, access to
telephone menu.

Decrease volume.

Voice commands

Long press, smartphone voice
commands via the system.

Mute/ Restore the sound.

Radio

(rotate): automatic search for

the previous / next station.
Media

(rotate): previous / next track,

move in a list.
Short press

: Confirm a selection.

Other than selection, access to
presets.

Radio

: display the list of stations.

Media

: display the list of tracks.

Radio, press and hold

: update the

list of stations received.

Increase volume.

423

12:13

23 °C

531 kHz

FM/87.5 MHz

87.5MHz

12:13

23 °C

87.5 MHz

12:13

23 °C

531 kHz

12:13

23 °C

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Menus

Settings

Radio Media

Driving

Connectivity

Telephone

Enter settings for a personal profile and/
or adjust the settings for sound (balance,
ambience, ...), and the display (language, units,
date, time, ...).

Select an audio source, a radio station, display
photographs.

Activate, deactivate, adjust the settings for
certain vehicle functions.

Operate certain applications on a smartphone
connected via MirrorLink

or CarPlay

Check the state of Bluetooth and Wi-Fi
connections.

Connect a telephone by Bluetooth

, read

messages and emails and send quick
messages.

424

12:13

23 °C

531 kHz

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Level 1

Level 2

Level 3

Bluetooth connection

Wi-Fi network connection

Networks

Share Wi-Fi connection

Connections and subscriptions to services

Functionalities available according to equipment.

Connectivity

425

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Level 2

Level 3

Comments

Connectivity

Secondary page

Bluetooth

connection

All

Display all telephones, connected or
disconnected.

Connected

Display all connected telephones.

Start a search for a device to connect.

Connectivity

Secondary page

Wi-Fi network

connection

Secured

Display secured Wi-Fi networks.

Not secured

Display non-secured Wi-Fi networks.

Stored

Display remembered Wi-Fi networks.

Connectivity

Secondary page

Manage connection

Display the state of the subscription to connected
services, the state of the network connection and
the connection mode.

Connectivity

Secondary page

Share Wi-Fi

connection

Activation

Activate or deactivating the sharing of the Wi-Fi
connection.

Settings

Select a Wi-Fi network found by the system and
connect to it.

Save settings.

Functionalities available according to equipment.

426

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Bluetooth

connection

Procedure from the system

Connection sharing

Press "Telephone" to display the
secondary page.

Press "Bluetooth connection

Select "Search

The list of detected telephones is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The system offers to connect the
telephone with 3 profiles:
- "Telephone

" (hands-free kit, telephone

only),

- "Streaming" (wireless play of audio files

on the telephone),

- "Mobile internet data

Select the name of the chosen
telephone in the list.

Press "Confirm

Select one or more profiles.

Press the "OPTIONS

" button to go to

the secondary page.

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the vehicle stationary
and the ignition on.

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Depending on the type of telephone,
you may be asked to accept or not the
transfer of your contacts and messages.

427

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

Wi-Fi connection

Sharing the Wi-Fi connection

Managing connections

To protect from any piracy and provide
maximum security for your systems,
it is recommended that you use a
security code or complex password.

The Wi-Fi connection and the sharing
of the Wi-Fi connection are exclusive.

Press "Confirm

Press "Confirm" to start the
connection.

Press "Connectivity" to display the
primary page.

Network connection by the smartphone Wi-Fi.

Creation of a local Wi-Fi network by the
system.

Press Connectivity to display the
primary page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Wi-Fi network connection

Select "Share Wi-Fi connection

Select "Manage connection

And / Or

Select the "Secured", "Not secured"
or "Stored

" tab.

Select the "Activation" tab to
activate or deactivate sharing of the
Wi-Fi connection.

Select the "Settings

" to change the

name of the system network and the
password.

With this function you can view the access
to connected services, the availability of
connected services and modify the connection
mode.

Using the virtual keypad, enter the
"Key

" for the Wi-Fi network and the

"Password

Select a network.

429

Audio and Telematics

Spacetourer-VP_en_Chap10c_RCC-1_ed01-2016

As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
MirrorLink

technology to be displayed

in the vehicle's screen.
The principles and standards
are constantly evolving. For the
communication process between
the smartphone and the system to
work correctly, the smartphone must
be unlocked; update the operating
system of your smartphone as
well as the date and time in the
smartphone and the system

For the list of eligible smartphones,
connect to the brand's internet website
in your country.

The "MirrorLink

" function requires

the use of a compatible smartphone
and applications.

There may be a wait for the availability
of applications, depending on the
quality of your network.

When connecting a smartphone to
the system, it is recommended that
Bluetooth

be started on the smartphone

Depending on the smartphone, it may be
necessary to activate the "MirrorLink

" function.

During the procedure, several screen
pages relating to certain functions
are displayed.
Accept to start and end the
connection.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press "MirrorLink

" to start the

application in the system.

Once connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons

From the system, press on
"Connectivity" to display the primary
page.

As a safety measure, applications
can only be viewed with the vehicle
stationary; display is interrupted once
the vehicle is moving.

Citroen SpaceTourer (2016 year). Instruction - part 27
