399

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

on the steering mounted button.

Using the telephone is not
recommended while driving.
Park the vehicle.
Make the call using the steering
mounted controls.

Making a call

Calling a new number

Press Telephone to display the
primary page.

Enter the phone number using the
digital keypad.

Press "Call

" to start the call.

Calling a contact

Press Telephone to display the
primary page.

Or make a long press

on the steering mounted TEL button.

Select "Contact

Select the desired contact from the list offered.

Select "Call

Calling a recently used number

Press Telephone to display the
primary page.

Make a long press

Select "Calls

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; as a safety
measure, first park the vehicle.

400

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

The access to "Messages" depends on
the compatibility of the smartphone and
the integral system.
Depending on the smartphone, access
to your messages or email may be
slow.

Managing messages

The "Email" function allows email
addresses to be entered for a contact,
but the system is not able to send
emails.

Managing contacts / entries

Press Telephone to display the
primary page.

Select "Contact

Select "Create

" to add a new contact.

In the "Telephone" tab, enter the
telephone numbers for the contact.

In the "Address" tab, enter the
addresses for the contact.

In the "Email" tab, enter the email
addresses for the contact.

Press "Answer

" to send a quick

message stored in the system.

Press Telephone to display the
primary page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Messages" to display the list
of messages.

Select the "All" or "Received" or
"Sent

" tab.

Select the detail of the message
chosen in one of the lists

Press "Call

" to start the call.

Press "Play

" to hear the message.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used.
Check in the manual for your telephone
and with your service provider for the
services available to you.

401

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Managing email

Press this button to "Modify" the new
quick message(s) created.

Press Telephone to display the
primary page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Email" to display the list of
messages.

Select the "Received" or "Sent" or
"Not read

" tab.

Select the email chosen in the list.

Press "Play

" to hear the email.

The "Modify" function does not apply
to quick messages already present in
the system.

Access to "Email" depends on the
compatibility of the smartphone and the
integral system.

Managing quick messages

Press Telephone to display the
primary page.

Press on the "OPTIONS" button to
go to the secondary page.

Select "Messages" to display the list
of messages.

Select the "Delayed" or "My arrival"
or "Not available" or "Other" tab
with the possibility of creating new
messages.

Select the message chosen in one of
the lists.

Press "Create" to write a new
message.

Press "Transfer" to select the
addressee(s).

Press "Play

" to play the message.

402

12:13

23 °C

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Audio settings

Level 1

Settings

Level 2

Audio settings

403

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Comments

Settings

Audio settings

Ambience

Select the sound ambience.

Distribution

Sound distribution by the Arkamys

system.

Sound

Adjust the volume or activate volume linked to
speed.

Voice

Adjust the voice volume.

Ringtone

Adjust the ringtone volume.

Confirm

Save the settings.

Settings

Turn off screen

Function allowing the display to be switched off.
Pressing the screen reactivates it.

Settings

Profile (1, 2, 3)

Activate the profile selected.

404

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Settings and tools

Screen configuration

System settings

Information

Languages

Screen configuration

405

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Comments

Settings

Secondary page

Screen

configuration

Animation

Activate or deactivate settings.

Brightness

Adjust the level of brightness.

Confirm

Save the settings.

Settings

Secondary page

System

settings

Units

Distance and fuel
consumption

Set the units used for distance, fuel consumption
and temperature.

Temperature

Factory settings

Reinitialize

Return to the factory settings.

System info

View

View the versions of the different modules
(system, mapping, risk areas) installed in the
system as well as the updates available.

Confirm

Save the settings.

Settings

Secondary page

Languages

All

Select the language then confirm.

Europe

Asia

America

Confirm

Having selected the language, save the setting.

406

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Settings and tools

Setting the time-date

Setting of the profiles

Level 3

407

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Level 1

Level 2

Level 3

Comments

Settings

Secondary page

Setting the

time-date

Date

Date

Enter the date and select the date format.

Date format:

Time

Time

Set the time.

Time Zone

Define the time zone.

Time format:

Select the time format: 12h / 24h.

Synchronisation with
GPS (UTC):

Activate or deactivate synchronisation with GPS.

Confirm

Save the settings.

Settings

Secondary page

Setting of the

profiles

Profile 1

Enter settings for the profiles.

Profile 2

Profile 3

Common profile

Confirm

Save the settings.

408

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Press Settings to display the primary
page.

Profile settings

Audio settings

Press Settings to display the primary
page.

Select "Audio settings

Select "Ambience

"Position"

"Sound"

"Voice"

"Ringtone

On-board audio: Arkamys

Sound

Staging optimises the distribution of
sound in the passenger compartment.

The settings for "Position" (All
passengers, Driver and Front only) are
common to all sources.

Activate or Deactivate "Touch tones",
"Volume linked to speed" and
"Auxiliary input

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.
Available only with the 6-speaker
configuration.

The audio Ambience

settings

(6 ambiences available) as well as the
Bass, Medium and Treble

settings

are different and independent for each
sound source.
Activate or Deactivate "Loudness

Press "Confirm

" to save the settings.

Press "Confirm

Press the "OPTIONS

" button to go to

the secondary page.

Select "Profile 1", "Profile 2",
"Profile 3" or "Common profile

Select "Setting of the profiles

Press this button to enter a name for
the profile using the virtual keypad

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the vehicle stationary

409

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Select a "Profile" (1 or 2 or 3) to
associate the "Audio settings" with
it.

Select "Audio settings

Select "Ambience

"Distribution

"Sound

"Voice

"Ringtone

The location for the photograph is
square; the system deforms the original
photograph if in another format.

Initialisation of the profile selected
activates the English language by default.

Press "Confirm

" to save the settings.

Press "Confirm" to accept the
transfer of the photograph.

Press "Confirm

" again to save the

settings.

Press this button to add a photograph
to the profile.

Insert a USB memory stick containing
the photograph in the USB port.
Select the photograph.

Press this button to initialise the
profile selected.

410

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Press Settings to display the primary
page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "System settings

Select "Screen configuration

Select "Units

" to change the units

for distance, fuel consumption and
temperature.

Select "Languages

" to change the

language.

Activate or deactivatre "Automatic
scrolling

Adjust the brightness of the screen.

Select "Factory settings" to return
to the initial settings.

Select "System info" to display the
versions of the different modules
installed in the system.

Modifying system settings

Returning the system to factory settings
activates the English language by
default.

Select "Animation

Select "Brightness

Select the language

Press Settings to display the primary
page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Setting the time-date

Setting the date

411

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Press Settings to display the primary
page.

Press the "OPTIONS

" button to go to

the secondary page.

Select "Date

Select "Time

Select "Setting the time-date

Adjustment of the time and date is only
available if synchronisation with GPS is
deactivated.
The change between winter and
summer time is done by changing the
time zone.

The system does not automatically
manage the change between winter
and summer time (depending on
country).

Setting the time

Press this button to define the date.

Press this button to adjust the time
using the virtual keypad.

Press "Confirm

Press this button to define the time
zone.

Select the display format of the date.

Select the display format for
the time (12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

412

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

The following table groups together the answers to the most frequently asked questions concerning your audio system.

QUESTION

ANSWER

SOLUTION

The route calculation is
not successful.

The route settings may conflict with the current location (exclusion
of toll roads on a toll motorway).

Check the route settings in the "Navigation"
menu.

The POIs do not appear.

The POIs have not been selected.

Select the POIs in the list of POIs.

The audible warning of
"Danger areas" does not
work.

The audible warning is not active.

Activate audible warnings (without the possibility
of adjusting the volume) in the "Navigation"
menu.

The system does not
suggest a detour around
an incident on the route.

The guidance criteria do not take account of TMC messages.

Select a setting for the "Traffic info" function
in the list of route settings (Without, Manual or
Automatic).

I receive a "Danger area"
alert which is not on my
route.

Other than guidance, the system announces all "Danger areas"
positioned in a cone located in front of the vehicle. It may provide
an alert for "Danger areas" located on nearby or parallel roads.

Zoom in on the map to view the exact position of the
"Danger areas". Select "On the route" to no longer
receive alerts other than navigation instructions or to
reduce the time for the announcement.

Frequently asked questions

Navigation

413

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

QUESTION

ANSWER

SOLUTION

Certain traffic jams along
the route are not indicated
in real time.

On starting, it is several minutes before the system starts to receive
traffic information.

Wait until the traffic information is being received
correctly (display of the traffic information icons
on the map).

In certain countries, only major routes (motorways...) are listed for
the traffic information.

This phenomenon is normal. The system is
dependent on the traffic information available.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly.

Wait until the system has started up completely
so that there is GPS coverage by at least
4 satellites.

Depending on the geographical environment (tunnel...) or the
weather, the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system
is dependent on the GPS signal reception
conditions.

414

Audio and Telematics

Spacetourer-VP_en_Chap10b_NAC-1_ed01-2016

Radio

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not
indicate a fault with the audio system.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a franchised dealer.

I cannot find some radio
stations in the list of
stations received.

The station is not received or its name has changed in the list.

Press on the "Update list" button in the "Radio
stations" secondary menu.

Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.

The name of the radio
station changes.

Content .. 24 25 26 27 ..
