Citroen Nemo Dag (2010 year). Instruction

Access

ELECTRONIC IMMOBILISER

All of the keys contain an electronic
immobiliser device.
This device locks the engine supply system.
It is activated automatically when the key is
removed from the ignition.
After the ignition is switched on, a dialogue
is established between the key and the
electronic immobiliser system.

This warning lamp is switched off
after the ignition is switched on
and the key has been recognised,
the engine can be started.

If the key is not recognised, the engine
cannot be started. Use another key and
have the faulty key checked by a CITROËN
dealer.

Good practice

Do not make any modifications to the
electronic immobiliser system.
Operating the remote control, even when it
is in your pocket, may result in involuntary
unlocking of the doors.
The simultaneous use of other high
frequency equipment (mobile telephones,
domestic alarms…), may interfere with the
operation of the remote control temporarily.

When purchasing a second-hand vehicle:
- ensure that you are given the confidential

card,

- have the keys memorised by a CITROËN

dealer to ensure that the keys in your
possession are the only ones which can
start the vehicle.

CONFIDENTIAL CARD

This is given to you on delivery of your
vehicle with the duplicate keys.
It contains the identification code necessary
for any work carried out by a CITROËN
dealer on the electronic immobiliser system.
This code is hidden by a film, which should
be removed only if necessary.
Keep your card in a safe place, never inside
the vehicle.
When undertaking a long trip or journey,
however, it is advisable to take it with you
along with your personal papers.

Driving with the doors locked may
make access to the passenger

compartment by the emergency services
more difficult in an emergency.
As a safety precaution (with children on
board), remove the key from the ignition when
leaving the vehicle, even for a short time.

Access

ALARM

This provides:
- exterior perimeter protection by means of

detectors on the doors and bonnet and
on the electrical supply,

- interior protection,

- anti-tilt protection,

- protection against the unauthorised

insertion of a key in the starter.

The equipment includes a siren.

Activation of the alarm

First ensure that all of the accesses are
closed correctly.

The alarm is activated by
pressing this control, the
protection is active after a few
seconds.

While the alarm is monitoring, any intrusion
triggers the siren for approximately
30 seconds, accompanied by illumination of
the direction indicators.
The alarm then returns to monitoring mode.
The alarm is also triggered following an
electrical supply cut-off, when the supply is
restored.

Deactivation using the remote control

Deactivation using the key

Unlock the doors using the key and enter
the vehicle. Switch on the ignition to the
RUNNING position, identification of the key
code will switch off the alarm.

Deactivation of the volumetric and
anti-tilt protection

Good practice

To quickly deactivate the siren following
unwanted triggering, unlock the vehicle
using the remote control.
To avoid setting the alarm, before washing
the vehicle for example, lock the vehicle
using the key.

When this button is pressed, the
alarm is deactivated when the
vehicle is unlocked.

Signalling of attempted intrusion

When you return to your vehicle,
flashing of the electronic engine
immobiliser warning lamp or
the appearance of a warning

message in the instrument panel display
indicates an attempted intrusion during your
absence.

To deactivate the volumetric
and anti-tilt protection, press the
button located in the vehicle's
courtesy lamp. To be effective,

this operation must be repeated every time
the ignition is switched off.

Access

OPENING FROM THE OUTSIDE
Driver's door

Use the remote control to unlock from the
outside.
Pull the handle towards you.
If the remote control does not work, insert
the metal part of the key in the lock on the
driver's side.

Sliding side door

Pull the handle towards you then towards
the rear.
Slide the door fully to pass the point of
resistance (Light van) or to engage the latch
which holds the door in the open position
(Combi).

When the fuel filler flap is open, a
safety system checks the sliding of the
side door.

Tailgate (Combi)

After unlocking the vehicle using the remote
control or the key, pull the central handle
and lift the tailgate.

If your vehicle is parked on a slope,
guide the side door as it slides. The

door could open or close more quickly due
to the incline of the ground, risking injury.
As a safety precaution and to guarantee
correct operation, do not drive with the
sliding side door open.

Access

OPENING FROM THE INSIDE

Driver's door

Pull the interior handle to unlock.
Active locking : when the vehicle
speed approaches 12 mph (20 km/h), a
characteristic locking noise indicates that
your vehicle has been locked automatically.
This "AUTOCLOSE" function is activated or
deactivated via the "MENU".
This function is deactivated when the vehicle
is delivered.

Opening to 180°

Press the catch while opening the door.

Side-hinged rear doors

The 60/40 type asymmetrical hinged rear
doors have four closing points, including a
central closing point.
Pull the handle towards you.
Start by opening the large hinged door, then
unlock by pulling the lever to release and
open the small hinged door.
The two hinged doors open to 90°.
Driving with the small hinged door open is
permitted to make the transportation of long
loads easier. Observe the customary safety
indications, to attract the attention of other
drivers.

Access

Good practice

When opening, take care not to obstruct the
guide space on the floor to allow the door to
slide correctly.
Do not block traffic.

Load space

Sliding side door (Combi)

Pull the handle A towards the rear, slide the
door fully to engage the latch which holds
the door in the open position (Combi).

Side-hinged rear doors

To open, slide the control B to the right.

If your vehicle is parked on a slope,
guide the side door as it slides. The

door could open or close more quickly due
to the incline of the ground, risking injury.
As a safety precaution and to guarantee
correct operation, do not drive with the
sliding side door open.

Press once to unlock the sliding
side doors and the rear doors
(Light van) from the driving
position.

Tailgate (Combi)

In the event of a battery or central
locking fault, the tailgate can be released
mechanically from inside the boot.
Open the sliding side door and fold the rear
seats fully.
From inside the boot, press the lever to
release the tailgate.

Access

CLOSING FROM INSIDE

Central locking

Push the interior handle to lock the entire
vehicle or the door concerned. However,
if one of the doors is open or is not closed
correctly, the central locking does not work.

Always remove the key from the
ignition when leaving the vehicle, even
for a short time.

Closing from 180°

The check strap will re-attach automatically
when the hinged doors are closed, the small
door being closed first.

Load space

Press to lock the sliding side
doors and the rear doors
(Light van) from the driving
position.

Protection against attack

When the vehicle is started, the system
locks the driving position and load space
doors automatically when you reach
approximately 12 mph (20 km/h).
This "AUTOCLOSE" function is activated or
deactivated via the "MENU".
If none of the doors are opened during the
journey, the locking remains active.
This function is deactivated when the vehicle
is delivered.

Access

Sliding side door (Combi)

Press the control to release the door and pull
the handle towards you to close the door.

Child safety

This prevents either of the rear doors being
opened from inside.


Turn the switch on each rear door a

quarter of a turn using the ignition key.

CLOSING FROM THE OUTSIDE

Sliding side door

Pull the handle towards you then towards
the front to pass the point of resistance
(Light van) or to release the door retaining
device (Combi).
Slide the door fully until it is closed.

Hinged rear doors

Start by closing the small hinged door, this is
secured automatically when closed.
Close the large door using its handle.

Tailgate (Combi)

Lower the tailgate using the interior grab
handle.

Access

OPENING FROM THE OUTSIDE
Driver's door

Use the remote control to unlock from the
outside.
Pull the handle towards you.
If the remote control does not work, insert
the metal part of the key in the lock on the
driver's side.

Sliding side door

Pull the handle towards you then towards
the rear.
Slide the door fully to pass the point of
resistance (Light van) or to engage the latch
which holds the door in the open position
(Combi).

When the fuel filler flap is open, a
safety system checks the sliding of the
side door.

Tailgate (Combi)

After unlocking the vehicle using the remote
control or the key, pull the central handle
and lift the tailgate.

If your vehicle is parked on a slope,
guide the side door as it slides. The

door could open or close more quickly due
to the incline of the ground, risking injury.
As a safety precaution and to guarantee
correct operation, do not drive with the
sliding side door open.

Access

OPENING FROM THE INSIDE

Driver's door

Opening to 180°

Press the catch while opening the door.

Side-hinged rear doors

Access

Good practice

When opening, take care not to obstruct the
guide space on the floor to allow the door to
slide correctly.
Do not block traffic.

Load space

Sliding side door (Combi)

Pull the handle A towards the rear, slide the
door fully to engage the latch which holds
the door in the open position (Combi).

Side-hinged rear doors

To open, slide the control B to the right.

If your vehicle is parked on a slope,
guide the side door as it slides. The

door could open or close more quickly due
to the incline of the ground, risking injury.
As a safety precaution and to guarantee
correct operation, do not drive with the
sliding side door open.

Press once to unlock the sliding
side doors and the rear doors
(Light van) from the driving
position.

Tailgate (Combi)

Access

CLOSING FROM INSIDE

Central locking

Push the interior handle to lock the entire
vehicle or the door concerned. However,
if one of the doors is open or is not closed
correctly, the central locking does not work.

Always remove the key from the
ignition when leaving the vehicle, even
for a short time.

Closing from 180°

The check strap will re-attach automatically
when the hinged doors are closed, the small
door being closed first.

Load space

Press to lock the sliding side
doors and the rear doors
(Light van) from the driving
position.

Protection against attack

Access

Sliding side door (Combi)

Press the control to release the door and pull
the handle towards you to close the door.

Child safety

This prevents either of the rear doors being
opened from inside.


Turn the switch on each rear door a

quarter of a turn using the ignition key.

CLOSING FROM THE OUTSIDE

Sliding side door

Pull the handle towards you then towards
the front to pass the point of resistance
(Light van) or to release the door retaining
device (Combi).
Slide the door fully until it is closed.

Hinged rear doors

Start by closing the small hinged door, this is
secured automatically when closed.
Close the large door using its handle.

Tailgate (Combi)

Lower the tailgate using the interior grab
handle.

Access

Sliding side door (Combi)

Press the control to release the door and pull
the handle towards you to close the door.

Child safety

This prevents either of the rear doors being
opened from inside.


Turn the switch on each rear door a

quarter of a turn using the ignition key.

CLOSING FROM THE OUTSIDE

Sliding side door

Pull the handle towards you then towards
the front to pass the point of resistance
(Light van) or to release the door retaining
device (Combi).
Slide the door fully until it is closed.

Hinged rear doors

Start by closing the small hinged door, this is
secured automatically when closed.
Close the large door using its handle.

Tailgate (Combi)

Lower the tailgate using the interior grab
handle.

Steering mounted controls

LIGHTING STALK

Selection is by rotation of the white mark
on the ring, when the ignition key is in the
RUNNING position.

All lamps off

Sidelamps on

This is indicated on the instrument
panel by lighting of the warning lamp.

Dipped headlamps/main beam
headlamps on

Dipped headlamps/main beam
headlamps change

Pull the lighting stalk fully towards you.

Headlamp flash

Direction indicators

"Motorway" function

System which indicates a change of lane on
high-speed roads.
Press the lighting stalk up or down once,
without passing the point of resistance; the
corresponding direction indicators will flash
three times.

Pull the lighting stalk towards you
gently, regardless of the position
of the ring.

Left: push downwards. The green
direction arrow warning lamp
flashes on the instrument panel.
Right: push upwards. The green

direction arrow warning lamp flashes on the
instrument panel.

Turn the ring into position.

Parking lamps

Side markers for the vehicle by illumination
of the sidelamps on the traffic side only.
Ignition key in the STOP position or removed
from the ignition switch:
 turn the ring to the "Lighting off" position,

then to the "Sidelamps" position,

 operate the lighting control stalk up

or down depending on the traffic side
(for example: when parking on the left;
lighting control stalk upwards; the right
hand sidelamps are on).

This is confirmed by illumination of the
sidelamps warning lamp in the instrument
panel.
To switch off the parking lamps, return the
lighting control stalk to the middle position
and the ring to the "Lighting off" position.

Steering mounted controls

Headlamp beam

You are advised to adjust the height of the
headlamp beams in accordance with the
load in your vehicle.
This function can only be accessed in
the main beam headlamps and dipped
headlamps position.

Press these controls, located
on the fascia panel, several
times in succession to adjust the
headlamps.

Fog lamps

The controls are located on the fascia panel
control pad.

Front and rear fog lamps

The fog lamps should only be used in
fog or when snow is falling.

In clear weather or in rain, both day and
night, lit rear fog lamps dazzle and are
prohibited.
Do not forget to switch them off when they
are no longer necessary.

Guide-me-home lighting

The temporary maintaining of the dipped
headlamps, after switching off the vehicle's
ignition, makes the driver's exit easier when
the light is poor and lights the space in front
of the vehicle.

Activation
With the ignition key in the STOP position
or removed, pull the lighting stalk towards
the steering wheel within 2 minutes after
switching off the engine.
Each time the control is operated, the
duration for which the lamps will remain
on is extended by 30 seconds, up to a
maximum of 210 seconds. Once this period
of time has elapsed, the lamps switch off
automatically.

Deactivation
Pull the lighting stalk towards the steering
wheel for more than 2 seconds.

The front fog lamps operate with
the side lights and the dipped
headlamps.

The rear fog lamps operate with
the dipped headlamps.

Press one of these controls to switch on the
lights.

The warning lamp comes on,
accompanied by a message
on the display, the first time
the control is operated and

remains on until the function is deactivated
automatically.

An indicator light on the display
indicates the adjustment position
selected (0, 1, 2, 3).

Steering mounted controls

Headlamp beam

You are advised to adjust the height of the
headlamp beams in accordance with the
load in your vehicle.
This function can only be accessed in
the main beam headlamps and dipped
headlamps position.

Press these controls, located
on the fascia panel, several
times in succession to adjust the
headlamps.

Fog lamps

The controls are located on the fascia panel
control pad.

Front and rear fog lamps

The fog lamps should only be used in
fog or when snow is falling.

In clear weather or in rain, both day and
night, lit rear fog lamps dazzle and are
prohibited.
Do not forget to switch them off when they
are no longer necessary.

Guide-me-home lighting

The temporary maintaining of the dipped
headlamps, after switching off the vehicle's
ignition, makes the driver's exit easier when
the light is poor and lights the space in front
of the vehicle.

Deactivation
Pull the lighting stalk towards the steering
wheel for more than 2 seconds.

The front fog lamps operate with
the side lights and the dipped
headlamps.

The rear fog lamps operate with
the dipped headlamps.

Press one of these controls to switch on the
lights.

The warning lamp comes on,
accompanied by a message
on the display, the first time
the control is operated and

remains on until the function is deactivated
automatically.

An indicator light on the display
indicates the adjustment position
selected (0, 1, 2, 3).

Citroen Nemo Dag (2010 year). Instruction - part 3
