Citroen DS5 (2016 year). Instruction - part 25

Audio and Telematics

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth telephone
used. Check the telephone manual and
with your network provider for details of
the services available to you.

The ability of the system to connect
with only one profile depends on the
telephone. The three profiles may all
connect by default.

Visit www.citroen.co.uk for more information
(compatibility, additional help, ...).

The recognised telephone
appears in the list.

Depending on your telephone, you may be
asked to accept automatic connection every
time the ignition is switched on.

On return to the vehicle, if the last telephone
connected is present again, it is reconnected
automatically and within around 30 seconds
after switching on the ignition the pairing is
done without any action on your part, with
(Bluetooth activated).
To modify the automatic connection mode,
select the telephone in the list then select the
desired profile.

Depending on the type of telephone,
the system will ask you to accept or not
the transfer of your contacts.

If not, select " Update ".

Connecting a Bluetooth

peripheral device

Automatic reconnection

  On switching on the ignition, the telephone
connected when the ignition was last switched
off is automatically reconnected, if this
connection mode had been activated during the
pairing procedure.
  The connection is confirmed by the display of a
message and the name of the telephone.

Manual connection

Press on Telephone to display the
primary page.

Press on the secondary page.

Select " Bluetooth " to display the list
of paired peripherals.

Select the peripheral to connect.

Press on " Search for devices ".

The connection is confirmed by the display of a
message and the name of the telephone.

Managing paired

telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Using the telephone is not
recommended while driving.
Park the vehicle.
Make the call using the steering
mounted controls.

Press on Telephone to display the
primary page.

Press on the secondary page.

Select " Bluetooth " to display the list
of paired peripheral devices.

Select the peripheral in the list.

Select " Search for devices "

" Connect / Disconnect " to start or
end the Bluetooth connection with
the selected device.

" Delete " to delete the pairing.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

  Make a short press on the steering
mounted TEL  button to accept an
incoming call.

Make a long press

on the steering mounted TEL button
to reject the call.

Select " End call ".

Making a call

Calling a new number

Press on Telephone to display the
primary page.

Enter the phone number using the
digital keypad.
Press " Call " to start the call.

Calling a contact

Press on Telephone to display the
primary page.

Or make a long press

on the steering mounted TEL button.

Audio and Telematics

Select " Contacts ".

Select the desired contact from the list offered.

Select " Call ".

Calling a recently used number

Press on Telephone to display the
primary page.

Select " Call log ".

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; park the
vehicle first as a safety measure.

Managing contacts / entries

Press on Telephone to display the
primary page.

Select " Contacts ".

Select " View ".

Select " Create " to add a new contact.

" Modify " to edit the selected contact.

" Delete " to delete the selected
contact.

" Delete all " to delete all information
for the selected contact.

Select " By name " to view the list of
contacts.

The following table groups together the answers to the most frequently asked questions concerning your audio system.

QUESTION

ANSWER

SOLUTION

The route calculation is
not successful.

The route settings may conflict with the current location (exclusion
of toll roads on a toll motorway).

Check the route settings in the "Navigation"
menu.

The POIs do not appear.

The POIs have not been selected.

Select the POIs in the list of POIs.

The Risk areas audible
warning does not work.

The audible warning is not active.

Activate audible warnings in the "Navigation"
menu.

The system does not
suggest a detour around
an incident on the route.

The guidance criteria do not take account of TMC messages.

Select the "Information" function in the list of
route settings.

I receive a Risk areas alert
which is not on my route.

Other than guidance, the system announces all Risk areas
positioned in a cone located in front of the vehicle. It may provide
an alert for Risk areas located on nearby or parallel roads.

Zoom in on the map to view the exact position of
the Risk areas. Select "On the route" to no longer
receive alerts other than navigation instructions
or to reduce the time for the announcement.

Frequently asked questions

Navigation

Audio and Telematics

QUESTION

ANSWER

SOLUTION

Certain traffic jams along
the route are not indicated
in real time.

On starting, it is several minutes before the system begins to
receive the traffic information.

Wait until the traffic information is being received
correctly (display of the traffic information icons
on the map).

The filters are too restrictive.

Modify the settings.

In certain countries, only major routes (motorways...) are listed for
the traffic information.

This phenomenon is normal. The system is
dependent on the traffic information available.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly.

Wait until the system has started up completely
so that there is GPS coverage by at least
4 satellites.

Depending on the geographical environment (tunnel...) or the
weather, the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system
is dependent on the GPS signal reception
conditions.

Radio

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not
indicate a fault with the audio system.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a CITROËN dealer.

I cannot find some radio
stations in the list of
stations received.

The station is not received or its name has changed in the list.

Press and hold the "List" button at the steering
mounted controls to update the list of stations
received or press on the system update function:
"Update list".

Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.

The name of the radio
station changes.

Audio and Telematics

Media

QUESTION

ANSWER

SOLUTION

Playback of my USB
memory stick starts only
after a very long wait
(around 2 to 3 minutes).

Some files supplied with the memory stick may greatly slow down
access to reading the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

When I connect my iPhone
as a telephone and to
the USB port at the same
time, I am unable to play
the music files.

When the iPhone connects automatically as a telephone, it forces
the streaming function. The streaming function takes the place
of the USB function which is then not useable, there is a period
without sound of the track being played with Apple

players.

Disconnect and reconnect to the USB port (the
USB function takes priority over streaming).

The CD is ejected
automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.

Check that the CD is inserted in the player
the right way up.

Check the condition of the CD: the CD
cannot be played if it is too damaged.

Check the content in the case of a recorded
CD: refer to the advice in the "AUDIO" section.

The audio system's CD player does not play
DVDs.

Some recorded CDs will not be played by
the audio system because they are not of the
correct quality.

The CD has been recorded in a format that is not compatible with the player (udf, ...).

The CD is protected by an anti-pirating protection system which is
not recognised by the audio system.

There is a long waiting
period following the insertion
of a CD or connection of a
USB memory stick.

When a new medium is inserted, the system reads a certain
amount of data (directory, title, artist, etc.). This may take from a few
seconds to a few minutes.

This phenomenon is normal.

QUESTION

ANSWER

SOLUTION

The CD player sound is
poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio equipment settings (bass, treble, ambiences) are
unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

Some characters in the
media information are not
displayed correctly while
playing.

The audio system does not display some types of characters.

Use standard characters to name tracks and
folders.

Playing of streaming files
does not start.

The peripheral device connected does not support automatic play.

Start the playback from the device.

The names of tracks and
the track length are not
displayed on the screen
when streaming audio.

The Bluetooth profile does not allow the transfer of this information.

Audio and Telematics

QUESTION

ANSWER

SOLUTION

In changing the setting
of treble and bass the
equalizer setting is
deselected.

The selection of an equalizer setting imposes the balance settings.
Modifying one without the other is not possible.

Modify the balance or equalizer settings to obtain
the desired musical ambience.

In changing the equalizer
setting, treble and bass
return to zero.

When changing the
balance settings, the
distribution setting is
deselected.

The selection of a distribution setting imposes the balance settings.
Modifying one without the other is not possible.

Modify the balance or distribution settings to
obtain the desired musical ambience.

When changing an
distribution setting,
the balance setting is
deselected.

Settings

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources.

For optimum sound quality, the audio settings for Loudness,
Ambience, Treble, Bass, Volume can be adapted to the different
sound sources, which may result in audible differences when
changing source.

Check that the audio settings for Loudness,
Ambience, Treble, Bass, Volume) are adapted
to the sources listened to. Adjust Balance,
Treble, Bassto the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

With the engine off, the
system switches off after a
few minutes of use.

When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
The switch-off is normal: the system switches to economy mode
and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

Audio and Telematics

QUESTION

ANSWER

SOLUTION

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be switched off or the
telephone may not be visible.

Check that your telephone's Bluetooth
function is switched on.

Check in the telephone settings that it is
"visible to all".

The Bluetooth telephone is not compatible with the system.

You can check the compatibility of your
telephone at www.citroen.co.uk (services).

The volume of the
telephone connected
in Bluetooth mode is
inaudible.

The volume depends both on the system and on the telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.

The ambient noise level has an influence on the quality of
telephone communication.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).

Some contacts are
duplicated in the list.

The options for synchronizing contacts are synchronizing the
contacts on the SIM card, the contacts on the telephone, or both.
When both synchronizations are selected, some contacts may be
duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

Contacts are not shown in
alphabetical order.

Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order.

Modify the display setting in the telephone
directory.

The system does not
receive SMS text messages.

The Bluetooth mode does not permit sending SMS text messages
to the system.

Telephone

4Dconcept

Diadeis

Interak

08-15

Labels are applied at various points on your vehicle. They

carry safety warnings as well as vehicle identifi cation

information. Do not remove them : they form an integral

part of your vehicle.

Automobiles CITROËN declares, by application of the

provisions of the European legislation (Directive 2000/53)

relating to End of Life Vehicles, that it achieves the

objectives set by this legislation and that recycled materials

are used in the manufacture of the products that it sells.

Printed in the EU

Anglais

For any work on your vehicle, use a qualifi ed workshop

that has the technical information, skills and equipment

required, all of which a CITROËN dealer is able to provide.

Reproduction or translation of all or part of this document

is prohibited without written authorisation from Automobiles

CITROËN.

We draw your attention to the following points:
- The fi tting of electrical equipment or accessories not

listed by CITROËN may cause faults and failures
with the electrical system of your vehicle. Contact
a CITROËN dealer for information on the range of
recommended accessories.

- As a safety measure, access to the diagnostic socket,

used for the vehicle's electronic systems, is reserved
strictly for CITROËN dealers or qualifi ed workshops,
equipped with the special diagnostic tool required (risk
of malfunctions of the vehicle's electronic systems that
could cause breakdowns or serious accidents). The
manufacturer cannot be held responsible if this advice is
not followed.

- Any modifi cation or adaptation not intended or

authorised by Automobiles CITROËN or carried out
without meeting the technical requirements defi ned by
the manufacturer would lead to the suspension of the
legal and contractual warranties.

15DS5.A040

Anglais

Content .. 23 24 25 26 ..
