Citroen DS5 (2016 year). Instruction - part 23

Audio and Telematics

Select a radio station or frequency (refer to the
corresponding section).

Press on Radio Media to display the
primary page.

Press on the secondary page.

Select " Settings ".

Select " Radio ".

Activate/deactivate " RDS
options ".

Press on Radio Media to display the
primary page.

Press on the secondary page.

Press on " Save " (preset).

Select a number in the list to preset the
previously chosen radio station.
A long press on a number presets (memorises)
the station.

Press on Frequency .

Enter the frequency in full
(e.g.: 92.10 MHz) using the keypad
then " Confirm ".

Changing radio station
Pressing the name of the current radio station
brings up a list.
To change radio station press the name of the
desired station.

Press on Radio Media to display the
primary page.

Select " Save " (preset).

Preset a station

Activate/ Deactivate RDS

THEN

A press on this button presets all of
the stations one after the other.

Recall pre-set stations

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100 % of the
territory. This explains the loss of
reception of the station during a journey.

  Display of options:
if active but not available, the display will be greyed out,
if active and available, the display will be blank.

Display of "Radiotext" for
the current station.

Manage the Jukebox.
Display current action.

Select the audio source.
Display the "DAB" band.

Display of the name of the
current station.

Short-cut: access to the choice of audio
source and the list of stations (or titles,
depending on the source).

Select the radio station.

Any thumbnail broadcast by
the station.

Preset stations, buttons 1
to 15.
Short press: select the
preset radio station.
Long press: preset a radio
station.

Next "Multiplex".
Next radio station.

Secondary page.

Display the name and
number of the multiplex
service being used.

Previous "Multiplex".
Previous radio station.

DAB (Digital Audio Broadcasting) radio

If the "DAB" radio station being listened to is not
available on "FM", the "DAB FM" option is greyed out.

Journaline

is a text-based information service designed for digital radio systems.

It provides text-based information structured around topics and sub-topics.
This service is available from the "LIST OF DAB STATIONS" page.

Audio and Telematics

Select change of source.

Press on Radio Media to display the
primary page.

Select " DAB Radio ".

Select " List " in the primary page.

Select the radio station from the list offered.

Press on Radio Media to display the
primary page.

Press on the secondary page.

Select " Settings ".

Select " Radio ".

Select " Digital/FM auto
tracking " then " Confirm ".

DAB / FM auto tracking

Digital radio

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB/FM station tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

If "DAB/FM station tracking" is
activated, there is a difference of a few
seconds when the system switches to
"FM" analogue radio with sometimes a
variation in volume.
When the digital signal is restored, the
system automatically changes back to
"DAB".

Digital radio provides higher quality
reception and also the graphical display
of current information on the radio
station being listened to. Select "List" in
the primary page.
The range of multiplexes available is
displayed in alphabetical order.

If the "DAB" station being listened to
is not available on "FM" (" DAB/FM "
option greyed out), or "DAB/FM station
tracking" is not activated, the sound
will cut out while the digital signal is too
weak.

  or
  Select " Radio list " in the secondary
page.

Media

USB player

Selecting the source

The steering mounted SRC (source)
button can be used to go to the next
media source, available if the source
is active.

Press OK to confirm the selection.

Select change of source.

Press on Radio Media to display the
primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or connection of a USB
memory stick. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

Auxiliary (AUX) socket

CD player

Insert the CD in the player.

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

Choose the source.

Audio and Telematics

The audio equipment will only play audio
files with ".wma, .aac, .flac, .ogg and. mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, ...) can be played.
".wma" files must be of the standard wma 9 type.
The sampling rates supported are 32, 44 and
48 KHz.

In order to be able to play a recorded CDR or
CDRW, when recording it is preferable to select
the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it may
not be played correctly.
It is recommended that the same recording
standard is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g.: " " ? ; ù) to avoid any playing
and displaying problems.

Information and advice

Use only USB memory sticks formatted FAT32
(file allocation table).

The system supports USB mass
storage devices, BlackBerry

devices

or Apple

players via USB ports. The

adaptor cable not supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied).

It is recommended that the USB cable
for the portable device is used.

The system does not support the
simultaneous connection of two
identical devices (two memory sticks,
two Apple

players) but it is possible

to connect one memory stick and one
Apple

player at the same time.

Bluetooth

audio streaming

Streaming allows audio files on your telephone
to be played through the vehicle's speakers.

Connect the telephone: see the " Telephone "
section, then " Bluetooth ".
Choose the " Audio " or " All " profile.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the peripheral device or by
using the audio system buttons.

Once connected in streaming mode,
the telephone is considered to be a
media source.
It is recommended that you activate
" Repeat " on the Bluetooth peripheral.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts).
The default classification used is by
artist. To modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Audio and Telematics

Managing the Jukebox

Connect the device (MP3 player...) to the USB
port or auxiliary Jack socket using a suitable
audio cable.

When no audio file is copied to the
system, which has a capacity of 8 GB,
all of the Jukebox function symbols are
greyed and are not available.

Select " Media list ".

Select the magnifying glass to enter
the folder or album and select audio
file by audio file.

Select copy " Copy Jukebox ".

Select " Confirm " then " Copy ".

Select " Sort by folder ".

Select " New folder " to create a
folder structure in the Jukebox.

" Sort by album ".

Select " Keep structure " to retain the structure
from the device.

While copying the system returns to the
primary page; you can go back to the copy view
at any time by selecting this button.

Level 1

Settings

Level 2

Level 3

Audio settings

Choice of color scheme

Audio settings

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Settings

Audio settings

Ambience

Choose the sound ambience.

Balance

Sound distribution using the Arkamys

system.

Sound effects

Set the volume or activate the link to vehicle
speed.

Ringtones

Set the telephone ringtone and volume.

Voice

Set the volume and voice for speaking street
names

Confirm

Save your settings.

Settings

Turn off screen

Function that turns off the display.
Pressing the screen reactivates it.

Settings

Color schemes

Confirm

Choose the color scheme, then confirm to save
the setting.

Units

Display screen

Configuration

Adjust date and time

Factory settings

Level 1

Level 2

Audio and Telematics

Level 1

Level 2

Comments

Settings

Secondary page

System Settings

Units

Set the units used to display distance, fuel
consumption and temperature.

Delete data

Select the desired data in the list then press
Delete.

Factory settings

Return to factory settings.

Confirm

Save the settings.

Settings

Secondary page

Time/Date

Confirm

Set the date and time then confirm.

Settings

Secondary page

Screen settings

Activate automatic text scrolling

Activate or deactivate the setting then confirm.

Activate animations

Confirm

Choice of language

Calculator

Configuration

Calendar

Level 1

Level 2

Audio and Telematics

Level 1

Level 2

Comments

Settings

Secondary page

Languages

Confirm

Select the language then confirm.

Settings

Secondary page

Calculator

Select the calculator.

Settings

Secondary page

Calendar

Select the calendar.

Audio settings

Press Settings to display the primary
page.

Select " Audio settings ".

Select " Ambience "

" Balance "

" Sound effects "

" Ringtones "

" Voice ".

On-board audio: Arkamys

Sound

Staging optimises sound distribution in
the the passenger compartment.

The distribution (or spatialisation using
the Arkamys

system) of sound is an

audio process that allows the audio
quality to be adapted to the number of
passengers in the vehicle.
Available only with the 6-speaker
configuration.

  The audio settings ( Ambience , Bass: ,
Treble:  and Loudness ) are different
and independent for each sound
source.
The settings for Distribution  and
Balance  are common to all sources.

- "

Ambience " (choice of 6 musical

ambiences)

- "

Bass: "

- "

Treble: "

- "

Loudness " (Activate/Deactivate)

- "

Distribution " (" Driver ", " All

passengers ", " Front only " )

- "

Audible response from touch

screen "

- "

Volume linked to speed "

(Activate/Deactivate)

Color schemes

Press on Settings to display the
primary page.

Select " Color schemes ".

Select the color scheme in the list
then " Confirm ".

At each change of color scheme the
system restarts, showing a black
screen for a few moments.

As a safety measure, the procedure
for changing the color scheme is only
possible with the vehicle stationary.

Audio and Telematics

Press on Settings to display the
primary page.

Press on "Settings" to display the
primary page.

Press on Settings to display the
primary page.

Press on the secondary page.

Press on the secondary page

Press on the secondary page.

Select " System Settings ".

Select " Time/Date " to change the
time zone, synchronisation with GPS,
the time and its format, then the date.

Select " Screen settings ".

Select " Units " to change the units
of distance, fuel consumption and
temperature.

Select " Languages " to change
language.

) Select the " Settings " menu.

Activate or deactivate " Activate
automatic text scrolling " and
" Activate animations ".

Select " Delete data " to delete the
list of recent destinations, personal
points of interest, contacts in the list.

Select " Calculator " to display a
calculator.

) In the secondary page, press on

" Time/Date ".

Choose the item then select " Delete ".

Select " Calendar " to display a
calendar.

) Modify the settings using the

number keypad, then confirm.

) Press

Confirm " to save and

quit.

) Select

Adjust time " or " Adjust

date ".

Select " Factory settings " to return
to the original settings.

Modifying system settings

Setting the date and time

When setting the time, you can select
" Satellite synchronisation ", so that the time is
adjusted automatically by satellite reception.

Connected services

Level 1

Level 2

Level 3

Content .. 21 22 23 24 ..
