Citroen DS4 (2017 year). Instruction

335

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Comments

Radio Media

Secondary page

Radio list

Save

Press a radio station to select it.

Update list

Update the list of stations received.

Frequency

Enter the desired radio frequency.

Confirm

Save the settings.

Radio Media

Secondary page

Photos

Home screen

Display the selected photo in the home page.

Rotate

Rotate the photo 90°.

Select all

Select all the photos in the list.
Press again to deselect.

Slideshow

Previous photo.

Display the photos in sequence, full-screen.
The system supports the following image formats:
.gif, .jpg, .bmp, .png.

Pause / Play.

Next photo.

Full screen

Display the selected photo full-screen.

336

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Media

Settings

337

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Comments

Radio Media

Secondary page

Media list

Presentation of the last media used.

Radio Media

Secondary page

Settings

Media

Settings

Shuffle (all tracks)

Choose the play settings.

Shuffle (current album)

Repeat

Aux. amplification

Radio

Settings

RDS options

Activate or deactivate the settings.

DAB/FM station tracking

Display Radio Text

Digital radio slideshow
display

Announcements

Settings

Traffic announcements (TA)

Activate or deactivate the settings.

News - Weather

Sport - Programm info

Flash - Unforeseen
events

Confirm

Save the settings.

338

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Press on Radio Media

to display the

primary page.

Press on Radio Media

to display the

primary page.

Select "Save

If necessary, select change of
source.

Press on Radio Media

to display the

primary page.

Select change source.

"AM Radio

By automatic frequency search

Select "FM Radio

"AM Radio

Press on the secondary page.

Select a preset radio station
in the list.

Select "FM Radio

Select a radio station from
the list offered.

Select "Update list" to refresh the
list.

Select "List

" in the primary page.

Press on Radio Media

to display the

primary page.

Radio

Changing a radio frequency

Selecting a station

To select a preset radio station.

THEN

Radio reception may be affected by
the use of electrical equipment not
approved by CITROËN, such as a USB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.

Select "Radio list

" in the secondary

page.

Press 3 or 4

to move the cursor for an

automatic search down or up for a radio
frequency.

339

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Select a radio station or frequency (refer to the
corresponding section).

Press on Radio Media

to display the

primary page.

Press on the secondary page.

Select "Settings

Select "Radio

Activate/deactivate "RDS
options

Press on Radio Media

to display the

primary page.

Press on the secondary page.

Press on "Save

" (preset).

Select a number in the list to preset the
previously chosen radio station.
A long press on a number saves (presets) the
station.

Press on Frequency

Enter the frequency in full (e.g.:
92.10 MHz) using the keypad then
"Confirm

Changing radio station
Pressing the name of the current radio station
brings up a list.
To change radio station press the name of the
desired station.

Press on Radio Media

to display the

primary page.

Select "Save

" (preset).

Presetting a station

Activating / Deactivating RDS

THEN

A press on this button presets all of
the stations one after the other.

Recalling preset stations

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100 % of the
territory. This explains the loss of
reception of the station during a journey.

340

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Display of options:
if active but not available, the display will be greyed out,
if active and available, the display will be blank.

Display of "Radiotext" for
the current station.

Select the audio source.
Display the "DAB" band.

Display of the name of the
current station.

Short-cut: access to the choice of audio
source and the list of stations (or titles,
depending on the source).

Select the radio station.

Any thumbnail broadcast by
the station.

Preset stations, buttons 1
to 15.
Short press: select the
preset radio station.
Long press: preset a radio
station.

Next "Multiplex".
Next radio station.

Secondary page.

Display the name and
number of the "multiplex"
service being used.

Previous "Multiplex".
Previous radio station.

DAB (Digital Audio Broadcasting) radio

If the "DAB" radio station being listened to is not
available on "FM", the "DAB FM" option is greyed out.

Journaline

is a text-based information service designed for digital radio systems.

It provides text-based information structured around topics and sub-topics.
This service is available from the "LIST OF DAB STATIONS" page.

341

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Select change of source.

Press on Radio Media

to display the

primary page.

Select "DAB Radio

Select "List

" in the primary page.

Select the radio station from the list offered.

Press on Radio Media

to display the

primary page.

Press on the secondary page.

Select "Settings

Select "Radio

Select "Digital/FM auto
tracking" then "Confirm

DAB / FM auto tracking

Digital radio

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB/FM station tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

Digital radio provides higher quality
reception and also the graphical display
of current information on the radio
station being listened to. Select "List" in
the primary page.
The range of multiplexes available is
displayed in alphabetical order.

If the "DAB" station being listened to
is not available on "FM" ("DAB/FM"
option greyed out), or "DAB/FM station
tracking" is not activated, the sound
will cut out while the digital signal is too
weak.

If "DAB/FM station tracking" is
activated, there is a difference of a few
seconds when the system switches to
"FM" analogue radio with sometimes a
variation in volume.
When the digital signal is restored, the
system automatically changes back to
"DAB".

Select "Radio list

" in the secondary

page.

342

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Media

USB port

Selecting the source

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

The steering mounted SRC (source)
button can be used to go to the next
media source, available if the source
is active.

Press on OK

to confirm the selection.

Select change of source.

Press on Radio Media

to display the

primary page.

To protect the system, do not use a USB
hub.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

Auxiliary socket (AUX)

CD player

Insert the CD in the player.

This source is only available if the "Auxiliary
socket" option has been activated in the
"Media" settings.

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

Choose the source.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or on connection of a
USB memory stick. The lists are memorised: if
they are not modified, the subsequent loading
time will be shorter.

343

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

The audio system will only play audio files
with ".wma, .aac, .flac, .ogg and .mp3" file
extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, etc.) can be played.
".wma" files must be of the standard wma 9
type.
The sampling rates supported are 32, 44 and
48 KHz.

In order to be able to play a recorded CDR or
CDRW, when recording it is preferable to select
the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it may
not be played correctly.
It is recommended that the same recording
standard is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g. " " ? ; ù) to avoid any playing
and displaying problems.

Information and advice

Use only USB memory sticks formatted FAT 32
(file allocation table).

The system supports USB mass
storage devices, BlackBerry

devices

or Apple

players via USB ports. The

adaptor cable is not supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied).

It is recommended that the USB cable
for the portable device is used.

To protect the system, do not use a
USB hub.

345

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Bluetooth

audio streaming

Streaming allows audio files on your telephone
to be played through the vehicle's speakers.

Connect the telephone: see the "Telephone"
section, then "Bluetooth

Choose the "Audio" or "All

" profile.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the peripheral device or by
using the audio system buttons.

Once connected in streaming mode,
the telephone is considered to be a
media source.
It is recommended that you activate
"Repeat

" on the Bluetooth

peripheral.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts).
The default classification used is by
artist. To modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

346

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Level 1

Settings

Level 2

Audio settings

Choice of color scheme

347

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Level 1

Level 2

Comments

Settings

Audio settings

Ambience

Choose the sound ambience.

Balance

Sound distribution using the Arkamys

system.

Sound effects

Set the volume or activate the link to vehicle
speed.

Ringtones

Set the telephone ringtone and volume.

Voice

Set the volume and voice for speaking street
names

Confirm

Save your settings.

Settings

Turn off screen

Function that turns off the display.
Pressing the screen reactivates it.

Settings

Color schemes

Confirm

Choose the color scheme, then confirm to save
the setting.

348

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Units

Display screen

Configuration

Adjust date and time

Factory settings

Level 1

Level 2

349

Audio and Telematics

DS4_en_Chap10b_SMEGplus_ed01-2016

Level 1

Level 2

Comments

Settings

Secondary page

System Settings

Units

Set the units used to display distance, fuel
consumption and temperature.

Delete data

Select the desired data in the list then press
Delete.

Factory settings

Return to factory settings.

Confirm

Save the settings.

Settings

Secondary page

Time/Date

Confirm

Set the date and time then confirm.

Settings

Secondary page

Screen settings

Activate automatic text scrolling

Activate or deactivate the setting then confirm.

Activate animations

Confirm

Citroen DS4 (2017 year). Instruction - part 22
