Citroen C-Elysee (2017 year). Instruction

VOL+

VOL-

207

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

AUDIO

Auxiliary socket (AUX)

Auxiliary JACK socket

Do not connect a device to the USB port and to the auxiliary Jack

socket at the same time.

The auxiliary Jack socket permits the connection of a

portable non-mass storage device or an Apple

player if

not recognised by the USB port.

Connect the portable device to the auxiliary Jack socket using a

suitable cable (not supplied).

Press the

SRC/TEL button several times

in succession and select "

AUX".

First adjust the volume on your portable device.

Then adjust the volume of the audio

system.

The display and management of controls is on the

portable device.

208

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

AUDIO

Streaming - Playing audio files via

Bluetooth

Depending on the compatibility of the phone

Pair/connect the telephone: see the "USING THE

TELEPHONE" section.

Streaming allows music files on a telephone to be heard via the

vehicle's speakers.

The telephone must support the appropriate bluetooth profiles

(Profiles A2DP / AVRCP).

Activate the streaming source by pressing

SRC/TEL.

Control of playback is via the audio system. The

contextual information can be displayed in the screen.

In certain cases, playing of the audio files must be initiated from

the telephone.

The audio quality depends on the quality of the transmission from

the telephone.

Play mode

The play modes available are:

- Normal: the tracks are played in order, depending on the

classification of the selected files.

- Random: the tracks in an album or folder are played in a random

order.

- Random all: all of the tracks saved in the media are played in

random order.

- Repeat: the tracks played are only those from the current album

or folder.

Press the control knob for access to

the contextual menu.
or
Press MENU

Select "

Multimedia" and confirm.

Select "

Media parameters" and

confirm.

Select "

Playback mode" and confirm.

Select the desired play mode then

press the control knob to confirm and

save the modifications.

209

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

Pairing a telephone

First connection

The services offered depend on the network, the SIM card and the compatibility of the Bluetooth telephone used.

Consult your telephone's manual and your operator to find out which services are available to you.

Activate the telephone's Bluetooth function and

ensure that it is "visible to all" (refer to the telephone

user guide).

Press MENU

A window is displayed "

Search in progress…".

Select the telephone to be connected

from the list. Only one telephone can

be connected at a time.

Select "

Search for a device".

For safety reasons and because they require prolonged attention on the part of the driver, the operations for pairing of the Bluetooth mobile

telephone with the Bluetooth hands-free system of your audio system must be carried out with the

vehicle stationary and the ignition on.

Visit www.citroen.co.uk for more information (compatibility, additional help, ...).

Select "

Bluetooth connection" and

confirm.

210

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

A virtual keypad is displayed on the

screen: enter a code of at least 4 digits

then press the control knob to confirm.

A message is displayed on the screen of the

telephone: enter the same code and confirm.

A message appears in the screen to confirm the result of the

connection.

Pairing can also be initiated from the telephone by searching for

detected Bluetooth devices.

Accept the connection to the telephone.

If pairing fails, try again; the number of attempts is not limited.

The directory and the calls list can be accessed after the

synchronisation period (if the telephone is compatible).

Automatic connection must be configured in the telephone to allow

the connection each time the vehicle is started.

In some cases, the reference number of the telephone or the

Bluetooth address may appear instead of the name of the telephone.

Pair/connect the telephone then listen: see the AUDIO section.

Streaming - Playing audio files via

Bluetooth

211

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

To see the telephone status,
press MENU

Select "Telephone

" and confirm.

Select "

Telephone management"

and confirm.

Select "

Telephone status" and confirm.

Telephone status

The screen displays: the name of the telephone, the name of the

network, network signal strength, confirmation of the Bluetooth

connection and the streaming connection.

212

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

The telephone connection automatically includes hands free operation

and audio streaming.

The ability of the system to connect to just one profile depends on the

telephone. Both profiles may connect by default.

Press MENU

Select "

Bluetooth connection" and

confirm.

Indicates connection of the audio steaming profile.

Managing connections

Select "

Connections management"

and confirm. The list of paired

telephones is displayed.

Select a telephone and confirm.

Indicates connection of the hands-free profile.

Then select and confirm:

- "

Connect telephone" / "Disconnect

telephone": to connect / disconnect

the telephone or the hands-free

connection only.

- "

Connect media player" /

Disconnect media player": to

connect / disconnect only streaming.

- "

Connect telephone + media

player

" / "

Disconnect telephone +

media player

": to connect /

disconnect the telephone (hands-free

and streaming).

- "

Delete connection": to delete the

pairing.

Indicates that a device is connected.

213

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

To display the "

TELEPHONE" menu:

- Make along press on

SRC/TEL.

- Or, press the control knob to

display the contextual menu. Select

Call" and confirm.

- Or, press MENU, select

"Telephone

" and confirm. Select

Call" and confirm.

Select "Dial

" to enter a number and

confirm.

To display the "

TELEPHONE" menu:

- Make a long press on

SRC/TEL.

- Or, press the dial to display the

contextual menu. Select "

Call" and

confirm.

- Or, press MENU, select

"Telephone

" and confirm. Select

Call" and confirm.

Press the control knob to confirm to

start the call.

Select "

Calls list" and confirm.

Making a call - Dialling

Select numbers one at a time using

the 7

and 8 buttons and confirm.

Making a call - Recently called numbers*

Select the number and confirm to start

the call.

The calls list includes calls sent and received in the vehicle using the

connected telephone.

* Depending on the compatibility of the telephone.

Correction allows numbers to be deleted one at a time.

It is possible to make a call directly from the telephone; park the

vehicle first as a safety measure.

BACK

214

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

To display the "

TELEPHONE" menu:

- Make a long press on

SRC/TEL.

- Or, press the dial to display the

contextual menu. Select "

Call" and

confirm.

- Or, press MENU, select

"Telephone

" and confirm. Select

Call" and confirm.

Select "

Directory" and confirm.

An incoming call is announced by a ring and a superimposed display

in the multifunction screen.

Mobile
(depending on the information

available in the contact records of

the telephone connected).

"YES

" to accept the call is selected by

default.

Press the control knob to accept the

call.
Select "NO

" and confirm to reject the

call.

Making a call - From the directory of contacts

Select a contact then confirm.

Receiving a call

Select the number and confirm.

A long press on

BACK or on SCR/TEL

also rejects an incoming call.

Business

Home

Press one of these buttons to accept

the call.

215

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

During a call, press the control knob to

display the contextual menu.

Hang up

In the contextual menu:

- select "

Micro OFF" to switch off the

microphone.

- deselect "

Micro OFF" to switch the

microphone on.

Managing calls

A long press on one of these buttons

also ends the call.

In the contextual menu, select "

Hang up"

to end the call.

Secret - Mute

(so that the caller cannot hear)

216

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

From the contextual menu, select

DTMF tones" and confirm to use

the digital keypad to navigate in the

interactive voice response menu.

From the contextual menu, select

Switch" and confirm to return to a call

left on hold.

Interactive voice response

Call on hold

In the contextual menu:

- select "Telephone mode" to

transfer the call to the telephone.

- deselect "Telephone mode" to

transfer the call to the vehicle.

In certain cases, the combined mode has to activated from the

telephone.

If the contact has been cut off, when you reconnect on returning to

the vehicle, the Bluetooth connection will be restored automatically

(depending on the compatibility of the telephone).

Combined mode

(to leave the vehicle without ending the call)

217

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

USING THE TELEPHONE

Directory

The telephone directory is sent to the system, depending on the

compatibility of the telephone.

The directory is temporary and depends on the Bluetooth

connection.

Contacts imported from the telephone to the audio system directory

are saved in a permanent directory visible to all, whatever the

telephone connected.

To modify the contacts saved in the

system, press MENU then select

"Telephone

" and confirm.

Select "

Directory management" and

confirm.

You can:

- "

Consult an entry",

- "

Delete an entry",

- "

Delete all entries".

Select "

Directory" to see the list of

contacts.

For access to the directory make a long

press on

SRC/TEL

Press the control knob then select

Call" and confirm.

218

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

Press ¯

to display the audio

settings menu.

The settings available are:

- Ambience,

- Bass,

- Treble,

- Loudness,

- Distribution: Personalised or Driver,

- Left / right balance,

- Fader (front / rear balance),

- Auto. volume.

Screen C

The distribution (or spatialisation using the Arkamys

system), is

an audio process which allows the sound quality to be improved

according to the setting chosen, corresponding to the position of

the listeners in the vehicle.

AUDIO SETTINGS

Select and confirm "

Other settings…"

to display the next setting in the list.

The Ambience, Treble and Bass audio settings are different and

independent for each sound source.

On-board audio: Arkamys

Sound Staging.

With Sound Staging, the driver and passengers are immersed in an

"audio scene" recreating the natural atmosphere of an auditorium:

truly a part of the scene and its surroundings.

This new sensation is made possible by software in the audio

system which processes the digital signals from the media players

(radio, CD, MP3…) without changing the audio settings. This

processing takes account of the characteristics of the passenger

compartment to produce optimum results.

The Arkamys

software installed in your audio system processes

the digital signal from the media players (radio, CD, MP3, ...) and

recreates a natural musical scene, with harmonious placement of

instruments and voices in the space in front of passengers, level

with the windscreen.

219

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

SCREEN MENU MAP(S)

SCREEN C

MEDIA

Media parameters

Choice of playback mode

Choice of track listing

TELEPHONE

Call

Dial

Directory

Calls list

Voice mail box

Directory management

Consult an entry

Delete an entry

Delete all entries

Telephone management

Telephone status

Hang up

BLUETOOTH CONNECTION

Normal

Random

Random all

Repeat

By folders

By artists

By genres

By playlists

Radio parameters

Connections management
Search for a device

MAIN FUNCTION

Option A1

Option A11

Option A

Option B...

220

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

SCREEN MENU MAP(S)

PERSONALISATION -

CONFIGURATION

Define the vehicle parameters

Driving assistance

Parking assistance

Vehicle lighting

Daytime lights

Interior lighting

Follow-me-home headlamps

Choice of language
Display configuration

Choice of units

Date and time adjustment

Display parameters

Brightness

221

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

FREqUENTLY ASKED qUESTIONS

The following tables contain answers to the most frequently asked questions.

qUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between

the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Fader, Left-Right Balance) to the middle position,

select the musical ambience "None" and set the

loudness correction to the "Active" position in CD

mode or to the "Inactive" position in radio mode.

When changing the

settings for treble and

bass, the ambience

setting is deselected.

When changing the

ambience setting, treble

and bass are reset

to zero.

Choosing an ambience imposes settings for treble and bass. Modifying

one without the other is not possible.

Modify the treble and bass settings or the

ambience setting to obtain the desired sound

quality.

When changing the

balance setting,

distribution is deselected.

Choosing a distribution setting imposes a balance setting. Modifying one

without the other is not possible.

Modify the balance setting or the distribution

setting to obtain the desired sound quality.

222

C-elysee_en_Chap12a_RD5(RD45)_ed01-2016

FREqUENTLY ASKED qUESTIONS

qUESTION

ANSWER

SOLUTION

The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 MHz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through an automatic car wash or in an underground car park).

Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for another frequency

giving better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

The traffic announcement

(TA) is displayed. I do

not receive any traffic

information.

The radio station does not broadcast traffic information.

Tune to a radio station which broadcasts traffic

information.

The stored stations are

not found (no sound,

87.5 MHz is displayed...).

An incorrect waveband is selected.

Press the BAND button to return to the waveband

on which the stations are stored.

Citroen C-Elysee (2017 year). Instruction - part 14
