Citroen C-Crosser (2012 year). Instruction - part 13

191

A U D I O a n d T E L E M A T I C S

Information displayed in Radio mode

A. A pre-set number is displayed when

a pre-set channel has been selected.

B. The name of the station is displayed

during the reception of RDS data. If

the name has not been transmitted,

the frequency is displayed.

C. Stereo is displayed when a stereo

transmission is received.

D. AF is displayed when the AF control

function is activated.

E. PTY (programme type) is displayed

if the RDS data received is dis-

played.

TRAFINF is displayed, during an

interruption, for traffi c information.

ALARM is displayed, during an

interruption, for urgent information.

F. Display of 6 pre-set stored stations.

G. To receive the stored station.

Press and hold to store a station.

H. To change the frequency step by

step.

Press and hold for scrolling of the

frequency.

I. To search for currently broadcasting

stations which can be received in

the current location, until a station is

found.

J. To display the programme types

pre-setting screen, e.g.: sport, rock,

classical, news, ... Press PTY again

to exit.

K. Press this button to display the

secondary menu.

L. REG is displayed during the recep-

tion of regional frequencies data.

M. RDS is displayed during the reception

of RDS data.

N. TP is displayed when the traffi c

information is in standby mode.

192

A U D I O a n d T E L E M A T I C S

Radio, selecting an FM station and storing

Press the MODE button.

Press

Explanations

Result

You can select [ Seek] or [Seek ] to start a continuous

search until the stations which can be received in the current

location are detected.

Press FM. By default the screen shows the FM1 stations.

Press [ Tune] to decrease the frequency or [Tune

] to increase the

frequency. The frequency is changed in steps of 0.1 MHz.
Continue to press to tune to a station automatically.

Once the frequency has been selected, a long press on the station (e.g. 3)

will store it.
The name of the station is displayed if it is available.

You can start automatic storing on FM3 for 6 stations, which

can be received in the current location, by pressing [^] then

[Auto-Store].

You can also start a search by type of programme by pressing

[PTY].

193

A U D I O a n d T E L E M A T I C S

Radio, RDS settings

Press

Explanations

Result

Press the MODE button.

Press FM. By default the screen shows the stations on FM1.

Press [^].

Press [RDS Settings].

Press [On] or [Off] to activate or deactivate the functions:
-

AF: automatic search for the best frequency,

REG: switch to the regional frequencies,

TP: automatic selection of stations broadcasting traffi c information.

194

A U D I O a n d T E L E M A T I C S

CD player

Your Audio-Telematic system allows

you to listen to audio CDs (CDDA, CD-

Text, CD-R/RW) or MP3 and WMA CDs.

Playing an audio CD

Switching off the engine or removing

the CD during recording will result in the

tracks being faulty.
The operation of the navigation system

may slow down during recording.
The recording speed may be slower

than 4x due to the processing load on

the equipment or the condition of the

audio CD.
If jumps or other errors occur, return to

the beginning of the track and start the

recording again.
Even if there is no gap between the

tracks on the CD, a brief silence be-

tween tracks is stored on the hard disk.

What is the Gracenote CDDB?

Copyright
Your Audio equipment may allow you

to listen to music which is usually pro-

tected by copyright in accordance with

current national and international stan-

dards. Please consult these standards

and comply with them.

Recording onto the music server

When the audio CD is

inserted in the player,

playing of the tracks is

automatic and they can

be recorded onto the

hard disk.

Simultaneous access to the music rec-

ognition service "Gracenote CDDB" on

the hard disk permits display of the title

information.

The tracks of audio CDs (not

MP3/WMA) can be recorded

onto the hard disk at approximately

4x speed (e.g.: 60 minutes converted

to 15 minutes) and stored on the music

server.
The sounds recorded may be altered

by the noise present and the quality of

the sound may differ from the original.
The tracks recorded on the music server

cannot be reproduced on another me-

dium (CD-R/RW, HDD, etc...).
Previously recorded tracks cannot be

recorded again from the same CD.

The title information for the

track currently being played

can be obtained from the

"Gracenote CDDB" database

stored on the hard disk.

The Gracenote company uses this

standard to identify the music and the

associated information such as:
-

the title of the album,

the name of the artist,

the title of the tracks,

the genre, ...

For further details, consult the site:

www.gracenote.com.
The Gracenote CDDB database incor-

porated in this equipment cannot guar-

antee the content of the data 100 %.

You can update this database using a

DVD sold separately.

195

A U D I O a n d T E L E M A T I C S

Information displayed in CD mode and recording a CD

A. The name of the album is displayed

for the track currently being played.

B. The name of the artist is displayed

for the album currently being played.

C. The playing time of the track currently

being played is displayed.

D. The playing mode currently selected

is displayed.

E. Position of the cursor and total number

of tracks on the album.

F. Displays the item currently selected.
G. To scroll up or down through the

tracks.

Press and hold for fast backwards

or forwards playing of a track.

H. Displays the number and the name of

the track. While driving, they are not

available and cannot be selected.

I. To display the secondary menu.
J. Move the cursor onto the track cur-

rently being played.

K. The number and the name of the

track currently being played are dis-

played.

L. During recording, this symbol is

displayed in red and it switches off

when all recording operations are

complete. The number indicates the

percentage of the total number of

tracks on the CD already recorded

onto the hard disc. 00 % when only

one track has been recorded.

M. The tracks which have not been

recorded are displayed in blue.

No symbol is displayed for tracks

which have been recorded.

The CD button is only active if the player

contains a CD.

Press Open to return the screen to the

vertical position.

196

A U D I O a n d T E L E M A T I C S

Playing a CD

Press the MODE button then CD, if the player already contains a CD.

Press

Explanations

Result

Otherwise, insert a CD in the player, play begins automatically.

Press [ Track] to select the previous track or return to the beginning of

the track currently being played.
Press and hold for fast backwards play.

Press [Track

] to select the next track.

Press and hold for fast forwards play.

Press [^] to access the secondary menu.

Press [Repeat] to play the track in a loop (repetition).
Press [^] then [Repeat] to stop.

Press [Scan] to play the beginning of each track for approximately

9 seconds (scan). Press [^] then [Scan] to stop or press the current track

(during the 9 seconds) and play begins.

Press [Random] to play the tracks in random order. Press [^] then

[Random] to stop.

Selecting a track

Changing the play mode

A U D I O a n d T E L E M A T I C S

Recording a CD onto the music server (1/3)

Press

Explanations

Result

All of the tracks are recorded automatically when a CD is inserted.
This automatic recording is programmed by default on leaving the factory.

Automatic recording of all of the tracks

If you have changed the recording mode (manual or fi rst track), while a

CD is being played press [^] to access to secondary menu.

Press [REC. Setting].

Press [Auto REC.] and confi rm by pressing [Back].

Next, eject the CD currently being played then insert a CD and the

recording of all of the tracks begins.

If you wish to record the CD which is currently being played, press [^] to

access the secondary menu and press [REC. Start].

If another track (already recorded) is selected during recording, the

recording continues and the new track selected is played.
If another track (not recorded) is selected, the recording which is in

progress stops and the recording of the new track selected begins. This

track is played during recording.

A U D I O a n d T E L E M A T I C S

Recording a CD onto the music server (2/3)

Press

Explanations

Result

Manual recording of individual tracks

You can record the tracks manually, one by one.
After inserting a CD and while it is being played, press [^] to access the

secondary menu.

Press [REC. Setting].

Press [Manual REC.] and confi rm by pressing [Back].

Once the manual programming has been carried out, select the track to

be recorded then press [^].

Press [REC. Start], the recording of the track selected begins.

If another track is selected during recording, the recording stops and the new

track selected is played.

199

A U D I O a n d T E L E M A T I C S

Recording a CD onto the music server (3/3)

Press

Explanations

Result

Automatic recording of the fi rst track

You can programme the automatic recording of the fi rst track when a CD

is inserted.
After inserting a CD and while it is being played, press [^] to access the

secondary menu.

Press [REC. Setting] then [Single REC.] and confi rm by pressing [Back].

Next, eject the CD which is currently being played then insert a CD and

the recording of the fi rst track begins.

If you wish to record the fi rst track of the CD which is currently being

played, press [^] to access the secondary menu and press [REC. Start].

If another track is selected during recording, the recording stops and the

track selected is played.

Stopping automatic or manual recording

During the recording of a CD or of a track on a CD, press [^] to access the

secondary menu.

Press [REC. Stop], the recording stops.

200

A U D I O a n d T E L E M A T I C S

General notes on the Music Server

What is the music server?
Your Audio-Telematic system allows

you to copy audio CDs onto a music

server, up to 2,500 songs on a 10 Gb

hard disk.
The tracks on audio CDs (not MP3 or

WMA) can be recorded onto the hard

disk at approximately 4x speed and

stored on the music server.
Refer to the "Recording a CD" section.
The music server then allows you to

manage groups and lists of tracks.

"Original" group, number 01:

"Original Playlist" lists:

"My Best" group, number 02:

"New Group" group for the user,

numbers 03 to 99:

"My Favorites" list:

"My Frequency" list:

"User Playlist" list:

This is the location of

the original playlist cre-

ated automatically (not manual) when a

track of an audio CD is recorded.
It is not possible to change its name or

delete it.
You can record up to 9999 playlists in

this group.

This is the location of the

playlists, etc... created

automatically from the information read

on the music server.
It is not possible to change its name or

delete it.
The groups "My Favorites" and "My

Frequency" are stored here.

This is the location of

the user's playlists.

You can record up to 9999 playlists in

this group.
The group can be created, renamed or

deleted.

These are original play

lists created automatical-

ly (not manual) when an

audio CD is recorded.

The lists and the artists can be renamed

or deleted. The genres can also be set.

This is the location of a

playlist of tracks selected

by the user from the original list.
If you delete a track from the original

list, it will be deleted from the user list.
The list and the artist can be renamed

or deleted.
It is possible to add tracks or change

their order.

This is the location of

the playlists used most

frequently from the original list.
It is not possible to add tracks or change

their order.

This is the location for

storing your favourite

tracks.

They can be deleted from the list and

the order in which they are played can

be changed.

201

A U D I O a n d T E L E M A T I C S

Information displayed in Music Server mode

A. The number and the name of the

track currently being played are dis-

played.

B. The number and the name of the

playlist currently being played are

displayed.

C. The name of the artist is displayed

for the playlist currently being played.

D. The playing time of the track cur-

rently being played is displayed.

E. The playing mode currently selected

is displayed.

F. Group lists: position of the cursor

and total number of groups.

Playlists: position of the cursor and

total number of playlists.

Track lists: position of the cursor

and total number of tracks.

G. To display the list of groups, the

playlist and the list of tracks.

H. To scroll up or down through the

tracks.

Press and hold for fast backwards

or forwards playing of a track.

I. To scroll up or down through the

playlists.

J. Group lists: number and name of

the group.

Playlists: number and name of the

playlist.

Track lists: number and name of the

track.

  K.   To display the secondary menu.
  L.   Displays the item currently selected.
  M.   Move the cursor onto the track cur-

rently being played.

202

A U D I O a n d T E L E M A T I C S

Explanations

Result

Playing a track or a playlist on the Music Server

Press

Press the MODE button then Music Server.

The playlists are played in a loop.
The server can play a track while recording another track from a CD. You

must wait until recording is complete before playing the recorded track.

Selecting a track

Press these buttons to switch between groups, playlists and

tracks.
You cannot switch directly from groups to tracks.

Press [ Track] to select the previous track or return to the beginning of

the track currently being played.
Press and hold for fast backwards play.

Press [Track

] to select the next track.

Press and hold for fast forwards play.

Selecting a playlist

Press [ Playlist] to select the previous playlist.

Press [Playlist ] to select the next playlist.

203

A U D I O a n d T E L E M A T I C S

Creating a group and a playlist on the Music Server

Explanations

Result

Press [^] to access the secondary menu.

Creating a group

Press [New Group], enter the name of the group and press [SET].
The group is stored on the server.

Creating a playlist

Press [^] to access the secondary menu then press [Function Settings].

Press [New Playlist].

Select the group to which the playlist is to be attached. The group must

be created fi rst.

Enter the name of the playlist and confi rm by pressing [SET].
Then select the search method attached to this new list (either from the

list or by conditions).
The list is stored on the server.

Press

A U D I O a n d T E L E M A T I C S

General notes on MP3/WMA CDs

Playing an MP3/WMA CD

When the MP3/WMA CD is

inserted in the player, play-

ing of the tracks is automatic.
The tracks cannot be recorded

onto the music server.

You can play CDs with up to 8 levels,

255 folders and 400 fi les maximum.

Copyright
Your Audio equipment may allow you

to listen to music which is usually pro-

tected by copyright in accordance with

current national and international stan-

dards. Please consult these standards

and comply with them.

Acceptance of the fi les
Some blank CDs may not be played

by your equipment (quality, recording

speed...).
When you burn a CD-R or CD-RW,

select the ISO 9660 level 1.2 or Joliet

burning standard.
To obtain the best acoustic quality pos-

sible, select the lowest burning speed.
The MPEG1 and MPEG2 standards

are accepted.
Transmission speeds between 32 and

320 kbits/s and scans between 16 kHz

and 48 kHz are accepted.
To display the title information (the name

of the artist, the title of the album, etc...),

the information contained in the ID3 Tags

or the WMA Tags must be included in the

MP3/WMA fi les burned onto the disc.

What is the MP3/WMA fi le format?
MP3 is the abbreviation of MPEG-1

Audio Layer 3 and MPG is the abbrevia-

tion of Motion Pictures Experts Group, a

digital video data compression standard

used on media such as video CDs.
The MP3 compression reduces the

number of bytes in a song by eliminating

the long sound waves in the range of fre-

quencies which are imperceptible to the

human ear, so producing high quality au-

dio fi les with a low volume of data.
This compression divides the size of

the content of a conventional audio CD

by approximately 10, which means that

the content of 10 audio CDs can be

recorded onto a single CD-R or CD-RW.

WMA is the abbreviation of Windows

Media Audio, another audio data com-

pression standard offered by Microsoft.
It can be used to create and save audio

fi les at a compression rate higher than

that of the MP3 format.
Windows Media and Microsoft Corpo-

ration are trademarks registered in the

United States and/or other countries.

205

A U D I O a n d T E L E M A T I C S

Information displayed in MP3/WMA CD mode

A. The number and the name of the track

currently being played are displayed.

B. The name of the album/folder is dis-

played for the track currently being

played.

C. The name of the artist is displayed

for the track currently being played.

D. The playing time of the current track

is displayed.

E. The playing mode currently selected

is displayed.

F. Position of the cursor and total num-

ber of folders or tracks on the current

level.

G. To display the list of folders of a higher

level.

H. Displays the item currently selected.

I. To scroll up or down through the

tracks.

Press and hold for fast backwards

or forwards playing of a track.

J. To scroll up or down through the

folders.

K. Displays the folder number and the

folder name. Plus the lists and num-

bers of tracks and the name of the

fi le (without extension).

L. To display the secondary menu.
M. Move the cursor onto the track cur-

rently being played.

N. Displays the type of medium, MP3

or WMA.

The CD button is only active if the player

contains a CD.

Press Open to return the screen to the

vertical position.

206

A U D I O a n d T E L E M A T I C S

Playing an MP3/WMA CD (1/2)

Press

Explanations

Result

Press the MODE button then CD, if the player already contains a CD.

Moving around the folders

Selecting a folder

Otherwise, insert a CD in the player, play begins automatically.

You can move by one level at a time.
Press on the name of a folder and at each press the list of folders of the

level below is displayed.

Press on the folder above to move up and/or select a level.

Press [ Folder] to select the previous folder.

Press [Folder ] to select the next folder.

These displays indicate the current level:
CD: level 0, folder below: level, folder below that, level 2, etc...
Up to 8 levels maximum.

Content .. 11 12 13 14 ..
