STARTING AND OPERATING

The Trailer Tow Package may include a four and

seven-pin wiring harness. Use a factory approved

trailer harness and connector.

NOTE:

Do not cut or splice wiring into the vehicle’s wiring

harness.
The electrical connections are all complete to the

vehicle but you must mate the harness to a trailer

connector. Refer to the following illustrations.

NOTE:



Disconnect trailer wiring connector from the

vehicle before launching a boat (or any other

device plugged into vehicle’s electrical connect)

into water.



Be sure to reconnect once clear from water

area.

Four-Pin Connector

Seven-Pin Connector

OWING

IPS

Before towing, practice turning, stopping, and

backing up the trailer in an area located away from

heavy traffic.

Automatic Transmission

Select the DRIVE range when towing. The

transmission controls include a drive strategy to

avoid frequent shifting when towing. For increased

engine braking on steep downhill grades, select

the LOW range.

Cruise Control — If Equipped



Do not use on hilly terrain or with heavy loads.



When using the Cruise Control, if you experience

speed drops greater than 10 mph (16 km/h),

disengage until you can get back to cruising

speed.



Use Cruise Control in flat terrain and with light

loads to maximize fuel efficiency.

1 — Ground
2 — Park
3 — Left Stop/Turn
4 — Right Stop/Turn

1 — Backup Lamps
2 — Running Lamps
3 — Left Stop/Turn
4 — Ground
5 — Battery
6 — Right Stop/Turn
7 — Electric Brakes

STARTING AND OPERATING

137

RECREATIONAL TOWING (BEHIND MOTORHOME)

OWING

HIS

EHICLE

EHIND

NOTHER

EHICLE

NOTE:



To avoid inadvertent Electric Park Brake (EPB)

engagement, you must ensure that the Auto

Park Brake feature is disabled before towing

this vehicle (if rear wheels are on the ground).

The Auto Park Brake feature is enabled or

disabled via the customer programmable

features

page 141.



When towing your vehicle, always follow appli

cable state and provincial laws. Contact state

and provincial Highway Safety offices for addi

tional details.



If your vehicle is disabled and in need of

commercial towing service, for further informa

tion

page 240.

DO NOT flat tow this vehicle. Damage to the

drivetrain will result.

Recreational Towing
Front-Wheel Drive (FWD) Models
Recreational towing is allowed ONLY if the front

wheels are OFF the ground. This may be

accomplished using a tow dolly (front wheels off

the ground) or vehicle trailer (all four wheels off the

ground). If using a tow dolly, follow this procedure:
1. Properly secure the dolly to the tow vehicle,

following the dolly manufacturer's

instructions.

2. Drive the front wheels onto the tow dolly.
3. Apply the parking brake.
4. Place the transmission in PARK.
5. Turn the ignition OFF.
6. Properly secure the front wheels to the dolly,

following the dolly manufacturer's instructions.

Towing Condition

Wheel OFF The Ground

FWD Models

Flat Tow

NONE

NOT ALLOWED

Dolly Tow

Front

Rear

NOT ALLOWED

On Trailer

ALL

CAUTION!



DO NOT flat tow this vehicle. Damage to the

drivetrain will result. If this vehicle requires

towing, make sure the drive wheels are OFF

the ground.



Ensure that the EPB is released, and remains

released, while being towed.



Towing this vehicle in violation of the above

requirements can cause severe transmission

damage. Damage from improper towing is not

covered under the New Vehicle Limited

Warranty.

138

STARTING AND OPERATING

7. Turn the ignition to the ON/RUN position, but

do not start the vehicle.

8. Press and hold the brake pedal.
9. Release the parking brake.
10. Turn the ignition OFF.
11. Release the brake pedal.

DRIVING TIPS

RIVING

LIPPERY

URFACES

Information in this section will aid in safe

controlled launches in adverse conditions.

Acceleration

Rapid acceleration on snow covered, wet, or other

slippery surfaces may cause the driving wheels to

pull erratically to the right or left. This phenomenon

occurs when there is a difference in the surface

traction under the front (driving) wheels.

Traction

When driving on wet or slushy roads, it is possible

for a wedge of water to build-up between the tire

and road surface. This is hydroplaning and may

cause partial or complete loss of vehicle control

and stopping ability. To reduce this possibility, the

following precautions should be observed:



Slow down during rainstorms or when the roads

are slushy.



Slow down if the road has standing water or

puddles.



Replace the tires when tread wear indicators

first become visible.



Keep tires properly inflated.



Maintain sufficient distance between your

vehicle and the vehicle in front of you to avoid a

collision in a sudden stop.

RIVING

HROUGH

ATER

Driving through water more than a few inches/

centimeters deep will require extra caution to

ensure safety and prevent damage to your vehicle.

Flowing/Rising Water

WARNING!

Rapid acceleration on slippery surfaces is

dangerous. Unequal traction can cause sudden

pulling of the front wheels. You could lose

control of the vehicle and possibly have a

collision. Accelerate slowly and carefully

whenever there is likely to be poor traction (ice,

snow, wet, mud, loose sand, etc.).

WARNING!

Do not drive on or across a road or path where

water is flowing and/or rising (as in storm

run-off). Flowing water can wear away the road

or path's surface and cause your vehicle to sink

into deeper water. Furthermore, flowing and/or

rising water can carry your vehicle away swiftly.

Failure to follow this warning may result in

injuries that are serious or fatal to you, your

passengers, and others around you.

STARTING AND OPERATING

139

(Continued)

Shallow Standing Water

Although your vehicle is capable of driving through

shallow standing water, consider the following

Warnings and Cautions before doing so.

WARNING!



Driving through standing water limits your

vehicle’s traction capabilities. Do not exceed

5 mph (8 km/h) when driving through

standing water.



Driving through standing water limits your

vehicle’s braking capabilities, which increases

stopping distances. Therefore, after driving

through standing water, drive slowly and

lightly press on the brake pedal several times

to dry the brakes.



Failure to follow these warnings may result in

injuries that are serious or fatal to you, your

passengers, and others around you.

CAUTION!



Always check the depth of the standing water

before driving through it. Never drive through

standing water that is deeper than the bottom

of the tire rims mounted on the vehicle.



Determine the condition of the road or the

path that is under water and if there are any

obstacles in the way before driving through

the standing water.



Do not exceed 5 mph (8 km/h) when driving

through standing water. This will minimize

wave effects.



Driving through standing water may cause

damage to your vehicle’s drivetrain compo

nents. Always inspect your vehicle’s fluids

(i.e., engine oil, transmission, axle, etc.) for

signs of contamination (i.e., fluid that is milky

or foamy in appearance) after driving through

standing water. Do not continue to operate

the vehicle if any fluid appears contaminated,

as this may result in further damage. Such

damage is not covered by the New Vehicle

Limited Warranty.



Getting water inside your vehicle’s engine can

cause it to lock up and stall out, and cause

serious internal damage to the engine. Such

damage is not covered by the New Vehicle

Limited Warranty.

CAUTION!

140

MULTIMEDIA

UCONNECT SYSTEMS

For detailed information about your Uconnect 5

With 7-inch Display or Uconnect 5/5 NAV With

10.1-inch Display system, refer to your Uconnect

Owner’s Manual Supplement.

NOTE:

Uconnect screen images are for illustration

purposes only and may not reflect exact software

for your vehicle.

CYBERSECURITY

Your vehicle may be a connected vehicle and may

be equipped with both wired and wireless

networks. These networks allow your vehicle to

send and receive information. This information

allows systems and features in your vehicle to

function properly.
Your vehicle may be equipped with certain security

features to reduce the risk of unauthorized and

unlawful access to vehicle systems and wireless

communications. Vehicle software technology

continues to evolve over time and FCA US LLC,

working with its suppliers, evaluates and takes

appropriate steps as needed. Similar to a

computer or other devices, your vehicle may

require software updates to improve the usability

and performance of your systems or to reduce the

potential risk of unauthorized and unlawful access

to your vehicle systems.
The risk of unauthorized and unlawful access to

your vehicle systems may still exist, even if the

most recent version of vehicle software (such as

Uconnect software) is installed.

NOTE:



FCA US LLC or your dealer may contact you

directly regarding software updates.



To help further improve vehicle security and

minimize the potential risk of a security breach,

vehicle owners should:



Routinely check

www.driveuconnect.com

(US Residents) or

www.driveuconnect.ca

(Canadian Residents) to learn about avail

able Uconnect software updates.



Only connect and use trusted media

devices (e.g. personal mobile phones,

USBs, CDs).

Privacy of any wireless and wired communications

cannot be assured. Third parties may unlawfully

intercept information and private communications

without your consent

page 102.

WARNING!



It is not possible to know or to predict all of the

possible outcomes if your vehicle’s systems

are breached. It may be possible that vehicle

systems, including safety related systems,

could be impaired or a loss of vehicle control

could occur that may result in an accident

involving serious injury or death.



ONLY insert trusted devices/components into

your vehicle. Media of unknown origin could

possibly contain malicious software, and if

installed in your vehicle, it may increase the

possibility for vehicle systems to be breached.



As always, if you experience unusual vehicle

behavior, take your vehicle to your nearest

authorized dealer immediately.

MULTIMEDIA

141

UCONNECT SETTINGS

The Uconnect system uses a combination of

buttons on the touchscreen and buttons on the

faceplate located on the center of the instrument

panel. These buttons allow you to access and

change the Customer Programmable Features.

Many features can vary by vehicle.
Buttons on the faceplate are located below and/or

beside the Uconnect system in the center of the

instrument panel. In addition, there is a Scroll/

Enter control knob located on the right side. Turn

the control knob to scroll through menus and

change settings. Push the center of the control

knob one or more times to select or change a

setting.
Your Uconnect system may also have Screen Off

and Mute buttons on the faceplate.
Push the Screen Off button on the faceplate to turn

off the Uconnect screen. Push the button again or

tap the screen to turn the screen on.
Press the Back Arrow button to exit out of a Menu

or certain option on the Uconnect system.
Push and hold the Power button on the radio’s

faceplate for a minimum of 15 seconds to reset

the radio.

USTOMER

ROGRAMMABLE

EATURES

Uconnect 5/5 NAV With 10.1-inch Display

For the Uconnect 5 With 7-inch Display and the

Uconnect 5/5 NAV With 10.1-inch Display
Press the Vehicle button, then press the Settings

tab on the top of the touchscreen. In this menu, the

Uconnect system allows you to access all of the

available programmable features.

NOTE:



Only one touchscreen area may be selected at a

time.



Depending on the vehicle’s options, feature

settings may vary.

When making a selection, press the button on the

touchscreen to enter the desired menu. Once in

the desired menu, press and release the preferred

setting option until a check mark appears next to

the setting, showing that setting has been

selected. Once the setting is complete, press the

Vehicle button to exit to the screen. Pressing the

Up or Down Arrow button on the right side of the

screen will allow you to toggle up or down through

the available settings.

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

142

MULTIMEDIA

KeySense

The vehicle’s KeySense settings are protected by a unique four-digit PIN, which the vehicle owner creates when accessing the specific settings for the first

time. This four-digit PIN can only be reset by an authorized dealer.
After pressing the KeySense button on the touchscreen, and entering the KeySense PIN, the following settings will be available:

Setting Name

Description

Forward Collision Warning Sensitivity — If Equipped

This setting will change the distance at which the Forward Collision Warning

(FCW) alert sounds. The “Medium” setting will have the FCW system signal

when an object is in view, and the possibility of a collision is detected. The

“Near” setting will have the FCW system signal when the object is closer to the

vehicle. The “Far” setting will have the FCW system signal when an object is at

a far distance from the vehicle.

Forward Collision Warning — If Equipped

This setting will turn the Forward Collision Warning (FCW) system on or off.

The “Warning Only” setting will provide only an audible chime when a collision

is detected. The “Warning + Active Braking” setting will provide an audible

chime and apply some brake pressure when a collision is detected.

ParkSense — If Equipped

This setting will change the type of ParkSense alert when a close object is

detected. The “Sound Only” setting will provide an audible chime when an

object is detected. The “Sound and Display” setting will provide both an

audible chime and a visual display when an object is detected.

Front ParkSense Volume — If Equipped

This setting adjusts the volume of the Front ParkSense system. The available

settings are “Low”, “Medium”, and “High”.

Rear ParkSense Volume — If Equipped

This setting adjusts the volume of the Rear ParkSense system. The available

settings are “Low”, “Medium”, and “High”.

Rear ParkSense Braking Assist — If Equipped

This setting will turn the Rear ParkSense Braking Assist on or off.

MULTIMEDIA

143

Display

Blind Spot Alert — If Equipped

This setting will change the type of alert provided when an object is detected

in a vehicle’s blind spot. The “Lights” setting will activate the Blind Spot Alert

lights on the outside mirrors. The “Lights & Chime” setting will activate both

the lights on the outside mirrors and an audible chime.

Maximum Vehicle Speed

This setting adjusts the Maximum Vehicle Speed. This feature can be set to

65, 70, 75, 80, or 85 mph (90, 95, 100, 105 or 110 km/h) by using the “-”

and “+” options.

Start Up Fuel Level Message

This setting will turn on the Start Up Fuel Level Message on or off.

Earlier Low Fuel Alert

This setting will turn on the Earlier Low Fuel Alert on or off.

Setting Name

Description

After pressing the Display button on the touchscreen, the following settings will be available:

Setting Name

Description

Language

This setting will change the language of the Uconnect system and Instrument

Cluster Display. The available languages are English, Français, and Español.

Display Mode

This setting will allow you to set the brightness manually or have the system

set it automatically. The “Auto” setting has the system automatically adjust

the display brightness. The “Manual” setting will allow the user to adjust the

brightness of the display.

Display Brightness With Headlights ON/Brightness

This setting will allow you to set the brightness when the headlights are on. To

access this setting, Display Mode must be set to Manual. The “+” setting will

increase the brightness; the “-” will decrease the brightness.

144

MULTIMEDIA

Display Brightness With Headlights OFF/Brightness

This setting will allow you to set the brightness when the headlights are off. To

access this setting, Display Mode must be set to Manual. The “+” setting will

increase the brightness; the “-” will decrease the brightness.

Set Theme

This setting will allow you to change the theme of the radio.

Units

This setting changes the “Speed” (MPH or km/h), “Distance” (mi or km), “Fuel

Consumption” (MPG [US], MPG [UK], L/100 km, or km/L), “Pressure” (psi,

kPa, or bar), “Temperature” (°C or °F), and “Current Consumption” (MPG

[US], MPG[UK], L/100 km, or km/L) units of measurement independently.

Touchscreen Beep

This setting will allow you to turn the touchscreen beep on or off.

Show Main Category Bar Labels

This setting will allow the main category bar labels to be shown on or off.

Control Screen Timeout — If Equipped

This setting allows you to set the Control Screen to turn off automatically after

five seconds or stay open until manually closed.

Navigation Next Turn Displayed in Cluster

This setting will display navigation prompts in the Instrument Cluster Display.

Phone Pop-Ups Displayed In Cluster

This setting will display smartphone notifications and messages in the

Instrument Cluster Display.

Ready To Drive Pop-Ups — If Equipped

This setting will enable the Ready To Drive Pop-Ups in the Instrument Cluster

Display.

Setting Name

Description

MULTIMEDIA

145

Safety & Driving Assistance

After pressing the Safety & Driving Assistance button on the touchscreen, the following settings will be available:

Setting Name

Description

Forward Collision Warning Sensitivity — Located In Automatic Emergency

Braking Submenu

This setting will change the distance at which the Forward Collision Warning

(FCW) alert sounds. The “Medium” setting will have the FCW system signal

when an object is in view, and the possibility of a collision is detected. The

“Near” setting will have the FCW system signal when the object is closer to the

vehicle. The “Far” setting will have the FCW system signal when an object is at

a far distance from the vehicle.

Forward Collision Warning — Located In Automatic Emergency Braking

Submenu

This setting will turn the Forward Collision Warning system on or off. The “Off”

setting will deactivate the FCW system. The “Warning Only” setting will provide

only an audible chime when a collision is detected. The “Warning + Active

Braking” setting will provide an audible chime and apply some brake pressure

when a collision is detected.

Pedestrian Emergency Braking — Located In Automatic Emergency Braking

Submenu

This setting will turn the Pedestrian Emergency Braking system “Off” or to

“Warning & Active Braking”.

ParkSense — If Equipped

This setting will change the type of ParkSense alert when a close object is

detected. The “Sound Only” setting will provide an audible chime when an

object is detected. The “Sound and Display” setting will provide both an

audible chime and a visual display when an object is detected.

Rear ParkSense Volume — If Equipped

This setting adjusts the volume of the Rear ParkSense system. The available

settings are “Low”, “Medium”, and “High”.

Rear ParkSense Braking Assist — If Equipped

This setting will turn the Rear ParkSense Braking Assist on or off.

Sliding Door Alert — If Equipped

This setting will turn the Sliding Door Alert on and off.

146

MULTIMEDIA

Clock & Date

Blind Spot Alert — If Equipped

This setting will change the type of alert provided when an object is detected

in a vehicle’s blind spot. The “Off” setting will turn off Blind Spot Alert. The

“Lights” setting will activate the Blind Spot Alert lights on the outside mirrors.

The “Lights & Chime” setting will activate both the lights on the outside

mirrors and an audible chime.

Hill Start Assist

This setting will turn the Hill Start Assist system on or off.

KeySense — If Equipped

This setting will access KeySense features.

Setting Name

Description

After pressing the Clock & Date button on the touchscreen, the following settings will be available:

Setting Name

Description

Sync Time With GPS

This setting will sync the time to the GPS receiver in the system. The system

will control the time via the GPS location.

Set Time

This setting will allow you to manually set the time of your clock.

Time Format

This setting will allow you to set the time format (AM/PM). Sync Time With GPS

must be off for this setting to be available. The “12 hrs” setting will set the

time to a 12-hour format. The “24 hrs” setting will set the time to a 24-hour

format.

Set Date

This setting will allow you to set the date by day, month, and year

(DD/MM/YY).

MULTIMEDIA

147

Phone/Bluetooth®

Set Time Hours — If Equipped

This setting will allow you to set the hours. Sync Time With GPS must be off for

this setting to be available. The “+” setting will increase the hours. The “-”

setting will decrease the hours.

Set Time Minutes — If Equipped

This setting will allow you to set the minutes. Sync Time With GPS must be off

for this setting to be available. The “+” setting will increase the minutes. The

“-” setting will decrease the minutes.

Show Time in Status Bar — If Equipped

This setting will place the time in the radio’s status bar.

Setting Name

Description

When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio

device or smartphone. The list of paired audio devices or smartphones can be accessed from this menu.

Setting Name

Description

Phone Pop-Ups Displayed In Cluster

This setting will activate phone message pop-ups in the Instrument Cluster

Display.

Do Not Disturb — If Equipped

This setting will open the Do Not Disturb settings menu. The settings are “Auto

Reply” (both, text, call), “Auto Reply Message” (custom, default), and “Custom

Auto Reply Message” (create message).

Device Manager

This setting will open the Device Manager main screen.

Do Not Disturb All

This setting will open the “Do Not Disturb All” settings menu. The available

options are “On” and “Off”.

Enable Two Active Phones — If Equipped

This setting will enable or disable two active phones with the vehicle. The

setting options are “On” and “Off”.

148

MULTIMEDIA

Voice — If Equipped

Navigation — If Equipped

After pressing the Voice button on the touchscreen, the following settings will be available:

Setting Name

Description

Voice Options

This setting will allow you to change the voice options for the radio to “Male”

or “Female”.

Show Command List

This setting will allow you to turn the Command List on or off. The “Always”

setting will always show the Command List. The “With Help” setting will show

the Command List and provide a brief description of what the command does.

The “Never” setting will turn the Command List off.

Wake Up Word

This setting will allow you to turn the voice recognition “Wake Up” word on or

off. The available options are “Off”, “Hey Uconnect”, and “Hey Chrysler”.

Voice Barge-In

This setting will allow you to turn the voice recognition barge-in feature

on or off.

When the Navigation button is pressed on the touchscreen, the system displays options related to the vehicle’s built-in Navigation system. These settings can

change which icons display on the map, how “time to arrival is calculated”, and route types.
For more information on Navigation and settings, refer to the Uconnect Owner’s Manual Supplement.

MULTIMEDIA

149

Camera

Mirrors & Wipers

When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features.

Setting Name

Description

ParkView Backup Camera Delay

This setting will add a timed delay to the ParkView Backup Camera when

shifting out of REVERSE.

ParkView Backup Camera Active Guidelines

This setting will turn the ParkView Backup Camera Active Guidelines on or off.

ParkView Backup Camera Fixed Guidelines

This setting will turn the ParkView Backup Camera Fixed Guidelines on or off.

When the Mirrors & Wipers button is pressed on the touchscreen, the system displays the options related to the vehicle’s mirrors and wipers.

Setting Name

Description

Rain Sensing Auto Wipers

This setting will turn the Rain Sensing Auto Wipers on or off.

Headlights With Wipers

This setting will turn the headlights on when the wipers are activated.

150

MULTIMEDIA

Lights

When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights.

NOTE:

When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of

the vehicle purchased.

Setting Name

Description

Headlight Off Delay

This setting will allow you to set the amount of time it takes for the headlights

to shut off after the vehicle is turned off. The available settings are “0 sec”,

“30 sec”, “60 sec”, and “90 sec”.

Headlight Illumination On Approach

This setting will allow you to set the amount of time it takes for the headlights

to shut off after the vehicle is unlocked. The available settings are “0 sec”,

“30 sec”, “60 sec”, and “90 sec”.

Headlights with Wipers

This setting will turn the headlights on when the wipers are activated.

Daytime Running Lights

This setting will allow you to turn the Daytime Running Lights on or off.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock

button is pushed on the key fob on or off.

Auto Dim High Beams

This setting will allow you to turn the Auto Dim High Beams on or off.

Flash Lights With Sliding Door

This setting will flash the lights when the sliding door reverses. The available

options are “On” and “Off”.

MULTIMEDIA

151

Brakes

Doors & Locks

After pressing the Brakes button on the touchscreen, the following settings will be available:

Setting Name

Description

Auto Park Brake

This setting will turn the Auto Park Brake on or off.

Brake Service

This setting will allow you to retract the brakes for servicing.

After pressing the Doors & Locks button on the touchscreen, the following settings will be available:

NOTE:

The Auto Door Locks feature default condition is enabled. When enabled, the door locks will lock automatically when the vehicle’s speed exceeds 12 mph

(20 km/h). The Auto Door Locks feature can be enabled or disabled by an authorized dealer per written request of the customer. Please see an authorized

dealer for service.

Setting Name

Description

Auto Door Locks — If Equipped

This setting will allow you to change if the doors lock automatically when the

vehicle reaches 12 mph (19 km/h).

Auto Unlock On Exit

This setting will unlock the doors when any of the doors are opened from

the inside.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock

button is pushed on the key fob on or off.

Chrysler Voyager (2022 year). Manual in english - page 9
