Chrysler Pacifica Hybrid (2022 year). Manual in english

GETTING TO KNOW YOUR VEHICLE

LLUMINATED

ANITY

IRRORS

—

QUIPPED

To access an illuminated vanity mirror, flip down

one of the visors and lift the cover.

Illuminated Mirror

UTSIDE

IRRORS

The outside mirror(s) can be adjusted to the center

of the adjacent lane of traffic to achieve the

optimal view.

RIVER

UTSIDE

UTOMATIC

IMMING

IRROR

— I

QUIPPED

The driver’s outside mirror will automatically adjust

for glare from vehicles behind you. This feature is

controlled by the inside automatic dimming mirror

and will automatically adjust for headlight glare

when the inside mirror adjusts.

ONVERSATION

IRROR

Located in the overhead console there is a

conversation mirror to view all the passengers in

the vehicle. Push the panel to release the drop

down mirror. Raise the mirror and push to latch it

back in the stowed position.

Conversation Mirror

WARNING!

Vehicles and other objects seen in an outside

convex mirror will look smaller and farther away

than they really are. Relying too much on side

convex mirrors could cause you to collide with

another vehicle or other object. Use your inside

mirror when judging the size or distance of a

vehicle seen in a side convex mirror.

GETTING TO KNOW YOUR VEHICLE

OWER

IRRORS

— I

QUIPPED

The power mirror controls are located on the

driver-side door trim panel.

Power Mirror Controls

The power mirror controls consist of mirror select

buttons and a four-way mirror control switch. To

adjust a mirror, push either the L (left) or R (right)

to select the mirror that you want to adjust.

NOTE:

A light in the selected button will illuminate indi

cating the mirror is activated and can be adjusted.

Using the mirror control switch, push on any of the

four arrows for the direction that you want the

mirror to move.
Left and Right side power mirror positions can be

saved as part of the driver memory profile

(if equipped)

page 32.

OWER

OLDING

UTSIDE

IRRORS

—

QUIPPED

The switch for the power folding mirrors is located

between the power mirror switches L (left) and

R (right). Push the switch once and the mirrors will

fold in, pushing the switch a second time will return

the mirrors to the normal driving position.

Power Folding Mirror Switch

NOTE:

If the vehicle speed is greater than 10 mph

(16 km/h), the folding feature will be disabled.
If the mirrors are in the folded position, and vehicle

speed is equal or greater than 10 mph (16 km/h),

they will automatically unfold.
Resetting The Power Folding Outside Mirrors
You may need to reset the power folding mirrors if

the following occurs:



The mirrors are accidentally blocked while

folding



The mirrors are accidentally manually folded/

unfolded (by hand or by pushing the power

folding mirror switch).



The mirrors come out of the unfolded position



The mirrors shake and vibrate at normal driving

speeds

To reset the power folding mirrors: fold and unfold

them by pushing the button (this may require

multiple button pushes). This resets them to their

normal position.

1 — Left Mirror Select
2 — Mirror Control Switch
3 — Right Mirror Select

GETTING TO KNOW YOUR VEHICLE

UTOMATIC

OWER

OLDING

IRRORS

— I

QUIPPED

When enabled within Uconnect Settings

page 188, the exterior mirrors will automatically

fold when the vehicle’s ignition is placed in the

OFF position, and after the doors are locked and

closed.
The exterior mirrors will auto-fold in the following

situations after the ignition is placed in the OFF

position:



Pushing the lock button on the door panel

before the door is opened.

NOTE:

If the doors are already locked, push the lock

button again.



Opening the door, then pushing the lock button

on the door panel, followed by closing the door.



After exiting the vehicle, close the doors then

push the lock button on the key fob.



After exiting the vehicle, close the doors then

touch the lock icon on the Passive Entry door

handle.

If the exterior mirrors were folded automatically,

they will unfold when the ignition is placed in the

ON/RUN position.

NOTE:

If the mirrors were folded manually, by using the

power folding mirror switch on the driver’s door

panel, they will not automatically unfold.

UTSIDE

IRRORS

OLDING

EATURE

All outside mirrors are hinged and may be moved

either forward or rearward to resist damage. The

hinges have three detent positions:



Full forward position



Full rearward position



Normal position

EATED

IRRORS

— I

QUIPPED

These mirrors are heated to melt frost or

ice. This feature will be activated

whenever you turn on the rear window

defroster (if equipped)

page 72.

ILT

IDE

IRRORS

EVERSE

—

QUIPPED

Tilt Side Mirrors In Reverse provides automatic

outside mirror positioning which will aid the

driver’s view of the ground rearward of the front

doors. The driver's outside mirror will move slightly

downward from the present position when the

vehicle is shifted into REVERSE. The driver's

outside mirror will then return to the original

position when the vehicle is shifted out of the

REVERSE position. Each stored memory setting will

have an associated Tilt Side Mirrors In Reverse

position.

NOTE:

The Tilt Side Mirrors In Reverse feature can be

enabled or disabled through the Uconnect system

page 188.

GETTING TO KNOW YOUR VEHICLE

UNIVERSAL GARAGE DOOR OPENER

(HOMELINK®)

HomeLink® Buttons And Indicator Light

Use this QR code to access your

digital experience.



HomeLink® replaces up to

three hand-held transmitters

that operate devices such as

garage door openers, motor

ized gates, lighting, or home

security systems. The HomeLink® unit is



The HomeLink® buttons that are located in the

overhead console or sun visor designate the

three different HomeLink® channels.



To operate HomeLink®, push and release any

of the programmed HomeLink® buttons. These

buttons will activate the devices they are

programmed to with each press of the corre

sponding HomeLink® button.



The HomeLink® indicator light is located above

the center button.

NOTE:

HomeLink® is disabled when the Vehicle Security

system is active

page 370.

EFORE

EGIN

ROGRAMMING

OME

INK

For efficient programming and accurate

transmission of the Radio Frequency (RF) signal, it

is recommended that a new battery be placed in

the hand-held transmitter of the device that is

being programmed to the HomeLink® system.

Make sure your hand-held transmitter is

programmed to activate the device you are trying

to program your HomeLink® button to.

Ensure that your vehicle is parked outside of the

garage before you begin programming.
It is recommended that you erase all the channels

of your HomeLink® before you use it for the first

time.

RASING

OME

INK

HANNELS

To erase the channels, follow this procedure:
1. Place the ignition switch into the ON/RUN

position.

2. Push and hold the two outside HomeLink®

buttons (I and III) for up to 20 seconds, or until

the HomeLink® indicator light flashes.

NOTE:

Erasing all channels should only be performed

when programming HomeLink® for the first time.

Do not erase channels when programming addi

tional buttons.

GETTING TO KNOW YOUR VEHICLE

DENTIFYING

HETHER

AVE

OLLING

ODE

-R

OLLING

ODE

EVICE

Before programming a device to one of your

HomeLink® buttons, you must determine whether

the device has a rolling code or non-rolling code.
Rolling Code Devices
To determine if your device has a rolling code, a

good indicator is its manufacturing date. Typically,

devices manufactured after 1995 have rolling

codes. A device with a rolling code will also have a

“LEARN” or “TRAIN” button located where the

antenna is attached to the device. The button may

not be immediately visible when looking at the

device. The name and color of the button may vary

slightly by manufacturer.

NOTE:

The “LEARN” or “TRAIN” button is not the button

you normally use to operate the device.
Non-rolling Code Devices
Most devices manufactured before 1995 will not

have a rolling code. These devices will also not

have a “LEARN” or “TRAIN” button.

ROGRAMMING

OME

INK

® T

ARAGE

OOR

PENER

To program any of the HomeLink® buttons to

activate your garage door opener motor, proceed

as follows:

NOTE:

All HomeLink® buttons are programmed using this

procedure. You do not need to erase all channels

when programming additional buttons.
1. Place the ignition switch into the ON/RUN

position.

2. Place the garage door opener transmitter 1 to

3 inches (3 to 8 cm) away from the

HomeLink® button you wish to program, while

keeping the HomeLink® indicator light in view.

3. Push and hold the HomeLink® button you

want to program while you push and hold the

garage door opener transmitter button you are

trying to replicate.

4. Continue to hold both buttons and observe the

HomeLink® indicator light. The HomeLink®

indicator light will flash slowly and then rapidly.

Once this happens, release both buttons.

NOTE:

Make sure the garage door opener motor is

plugged in before moving on to the rolling code/

non-rolling code final steps.

Rolling Code Garage Door Opener Final Steps

NOTE:

You have 30 seconds in which to initiate rolling

code final step 2, after completing rolling code

final step 1.
1. At the garage door opener motor (in the

garage), locate the “LEARN” or “TRAIN”

button. This can usually be found where the

hanging antenna wire is attached to the

garage door opener motor. Firmly push and

release the “LEARN” or “TRAIN” button.

2. Return to the vehicle and push the

programmed HomeLink® button three times

(holding the button for two seconds each

time). If the garage door opener motor

operates, programming is complete.

3. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the final steps for the

rolling code procedure.

Non-Rolling Code Garage Door Opener Final Steps
1. Push and hold the programmed HomeLink®

button and observe the HomeLink® indicator

light. If the HomeLink® indicator light stays

on constantly, programming is complete.

GETTING TO KNOW YOUR VEHICLE

2. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the steps from the

beginning.

ROGRAMMING

OME

INK

® T

ISCELLANEOUS

EVICE

The procedure on how to program HomeLink® to a

miscellaneous device follows the same procedure

as programming to a garage door opener

page 62. Be sure to determine if the device has

a rolling code, or non-rolling code before beginning

the programming process.

NOTE:

Canadian Radio Frequency (RF) laws require trans

mitter signals to time-out (or quit) after several

seconds of transmission, which may not be long

enough for HomeLink® to pick up the signal during

programming. Similar to this Canadian law, some

U.S. gate operators are designed to time-out in the

same manner. The procedure may need to be

performed multiple times to successfully pair the

device to your HomeLink® buttons.

EPROGRAMMING

A S

INGLE

OME

INK

® B

UTTON

To reprogram a single HomeLink® button that has

been previously trained, without erasing all the

channels, proceed as follows. Be sure to

determine whether the new device you want to

program the HomeLink® button to has a rolling

code, or non-rolling code.
1. Place the ignition in the ON/RUN position,

without starting the engine.

2. Push and hold the desired HomeLink® button

until the HomeLink® indicator light begins to

flash after 20 seconds. Do not release the

button.

3. Without releasing the button, proceed with

Step 2 in “Programming HomeLink® To A

Garage Door Opener” and follow all remaining

steps.

ANADIAN

ATE

PERATOR

ROGRAMMING

For programming transmitters in Canada/United

States that require the transmitter signals to

“time-out” after several seconds of transmission:
Canadian Radio Frequency (RF) laws require

transmitter signals to time-out (or quit) after

several seconds of transmission, which may not be

long enough for HomeLink® to pick up the signal

during programming. Similar to this Canadian law,

some U.S. gate operators are designed to time-out

in the same manner.
It may be helpful to unplug the device during the

cycling process to prevent possible overheating of

the garage door or gate motor.
1. Place the ignition in the ON/RUN position.

NOTE:

For vehicles equipped with Keyless Enter ‘n Go™,

place the ignition in the RUN position. Make sure

while programming HomeLink® with the engine on

that your vehicle is outside of your garage, or that

the garage door remains open at all times.
2. Place the hand-held transmitter 1 to 3 inches

(3 to 8 cm) away from the HomeLink® button

you wish to program while keeping the

HomeLink® indicator light in view.

WARNING!



Your motorized door or gate will open and

close while you are programming the universal

transmitter. Do not program the transmitter if

people or pets are in the path of the door or

gate.



Do not run your vehicle in a closed garage or

confined area while programming the trans

mitter. Exhaust gas from your vehicle contains

Carbon Monoxide (CO) which is odorless and

colorless. Carbon Monoxide is poisonous

when inhaled and can cause you and others to

be severely injured or killed.

GETTING TO KNOW YOUR VEHICLE

3. Continue to push and hold the HomeLink®

button while you push and release (cycle) your

hand-held transmitter every two seconds until

HomeLink® has successfully accepted the

frequency signal. The indicator light will flash

slowly and then rapidly when fully trained.

4. Watch for the HomeLink® indicator to change

flash rates. When it changes, it is

programmed. It may take up to 30 seconds or

longer in rare cases. The garage door may

open and close while you are programming.

5. Push and hold the programmed HomeLink®

button and observe the indicator light.

NOTE:



If the indicator light stays on constantly,

programming is complete and the garage

door/device should activate when the

HomeLink® button is pushed.



To program the two remaining HomeLink®

buttons, repeat each step for each

remaining button. DO NOT erase the

channels.

If you unplugged the garage door opener/device

for programming, plug it back in at this time.

Reprogramming A Single HomeLink® Button

(Canadian/Gate Operator)
To reprogram a channel that has been previously

trained, follow these steps:
1. Place the ignition in the ON/RUN position.
2. Press and hold the desired HomeLink® button

until the indicator light begins to flash after

20 seconds. Do not release the button.

3. Without releasing the button, proceed with

“Canadian/Gate Operator Programming”

Step 2 and follow all remaining steps.

ECURITY

It is advised to erase all channels before you sell or

turn in your vehicle.
To do this, push and hold the two outside buttons

for 20 seconds until the indicator flashes. Note

that all channels will be erased. Individual

channels cannot be erased.
The HomeLink® Universal Transceiver is disabled

when the Vehicle Security system is active.

ROUBLESHOOTING

IPS

If you are having trouble programming

HomeLink®, here are some of the most common

solutions:



Replace the battery in the garage door opener

hand-held transmitter.



Push the LEARN button on the garage door

opener to complete the training for a rolling

code.



Did you unplug the device for programming and

remember to plug it back in?

If you have any problems, or require assistance,

please call toll-free 1-800-355-3515 or, on the

Internet at

HomeLink.com

for information or

assistance.

WARNING!



Vehicle exhaust contains carbon monoxide, a

dangerous gas. Do not run your vehicle in the

garage while programming the transceiver.

Exhaust gas can cause serious injury or death.



Your motorized door or gate will open and close

while you are programming the universal trans

ceiver. Do not program the transceiver if

people, pets or other objects are in the path of

the door or gate. Only use this transceiver with

a garage door opener that has a “stop and

reverse” feature as required by Federal safety

standards. This includes most garage door

opener models manufactured after 1982.

Do not use a garage door opener without these

safety features.

GETTING TO KNOW YOUR VEHICLE

EXTERIOR LIGHTS

ULTIFUNCTION

EVER

The multifunction lever is located on the left side of

the steering column. The multifunction lever

controls the turn signals, headlight high/low

beams, and flash-to-pass functions.

Multifunction Lever

EADLIGHT

WITCH

The headlight switch is located on the left side of

the instrument panel. The switch controls the

operation of the headlights, parking lights,

instrument panel lights, interior lights, and the

fog lights.

Headlight Switch

Headlight Switch (Vehicles Sold In Canada Only)

NOTE:

Vehicles sold in Canada are equipped with a head

light switch with an AUTO and ON detent but

without an OFF detent. Headlights will be deacti

vated when the headlight switch is placed in the

parking lights position. However, the Daytime

Running Lights (DRLs) will be activated along with

the front and rear marker lights. The DRLs may be

deactivated when the parking brake is engaged.

1 — Rotate Headlight Control
2 — Push Fog Light Control
3 — Ambient Light Dimmer Control
4 — Instrument Panel Dimmer Control

GETTING TO KNOW YOUR VEHICLE

From the O (off) position, rotate the headlight switch

clockwise to the first detent for parking light and

instrument panel light operation. Rotate the

headlight switch to the second detent for headlight,

parking light and instrument panel operation.

NOTE:

For vehicles sold in Canada, rotate the headlight

switch clockwise from the parking light and

instrument panel light position to the first detent to

turn on the headlights also. Rotate to the second

detent, AUTO position, to turn on automatic head

lights, parking lights, and instrument panel lights.

AYTIME

UNNING

IGHTS

(DRL

) —

QUIPPED

The headlights or LED light bars on your vehicle will

illuminate when the engine is started. This

provides a constant lights on condition until the

ignition is placed in the OFF position. If the parking

brake is applied, the Daytime Running Lights

(DRLs) will turn off.

NOTE:



For vehicles sold in Canada, the Daytime

Running Lights will automatically deactivate

when the front fog lights are turned on.



If allowed by law in the country in which the

vehicle was purchased, the Daytime Running

Lights can be turned on and off using the Ucon

nect system

page 188.



On some vehicles, the Daytime Running Lights

may deactivate, or reduce intensity, on one side

of the vehicle (when a turn signal is activated on

that side), or on both sides of the vehicle (when

the hazard warning lights are activated).

IGH

EAM

WITCH

Push the multifunction lever toward the instrument

panel to switch the headlights to high beams.

Pulling the multifunction lever back will turn the

low beams on.

UTOMATIC

IGH

EAM

— I

QUIPPED

The Automatic High Beam system provides

increased forward lighting at night by automatically

controlling the high beams through the use of a

camera mounted on the windshield. This camera

detects vehicle specific light and automatically

switches from high beams to low beams until the

approaching vehicle is out of view.

NOTE:

Broken, muddy, or obstructed headlights and tail

lights of vehicles in the field of view will cause

headlights to remain on longer (closer to the

vehicle). Also, dirt, film and other obstructions on

the windshield or camera lens will cause the

system to function improperly.

To Activate

1. Select “Auto Dim High Beams” through the

Uconnect system to enable the feature

page 188.

2. Rotate the headlight switch clockwise to the

AUTO position.

3. Push the multifunction lever away from you to

switch the headlights to the high beam

position. Refer to “Multifunction Lever” in this

section for further information.

NOTE:

This system will not activate until the vehicle is at,

or above 16 mph (25 km/h).

To Deactivate

Perform either of the following steps to deactivate

the Automatic High Beam system.
1. Deselect “Auto Dim High Beams” through the

Uconnect system

page 188.

2. Pull the multifunction lever toward you to

switch the headlights from the high beam to

the low beam position.

3. Rotate the headlight switch counterclockwise

from the AUTO to the on position.

NOTE:

Once active, the Automatic High Beam system will

stop functioning below 12 mph (20 km/h).

GETTING TO KNOW YOUR VEHICLE

LASH

-T

-P

ASS

You can signal another vehicle with your headlights

by lightly pulling the multifunction lever toward you.

This will cause the high beam headlights to turn on,

and remain on, until the lever is released.

UTOMATIC

EADLIGHTS

— I

QUIPPED

This system automatically turns your headlights on

or off based on ambient light levels. To turn the

system on, turn the headlight switch to the extreme

clockwise position aligning the indicator with the

AUTO on the headlight switch. When the system is

on, the Headlight Time Delay feature is also on.

This means your headlights will stay on for up to

90 seconds after the ignition is placed in the OFF

position. To turn the automatic system off, move

the headlight switch out of the AUTO position.

NOTE:

The engine must be running before the headlights

will come on in the Automatic mode.

EADLIGHTS

ITH

IPERS

—

QUIPPED

When your headlights are in the AUTO mode and

the engine is running, the headlights will

automatically turn on when the wiper system is

also turned on. Headlights on when windshield

wipers are on may be found on vehicles equipped

with an automatic headlight system.

NOTE:

The Headlights with Wipers feature can be turned

on or off through the Uconnect system

page 188.

EADLIGHT

IME

ELAY

— I

QUIPPED

This feature provides the safety of headlight

illumination for up to 90 seconds after exiting your

vehicle.
To activate the delay feature, place the ignition in

the OFF position while the headlights are still on.

The 90 second delay interval begins when

headlight switch is turned off. If the headlights or

parking lights are turned back on or the ignition is

placed in the ON position, the delay will be

cancelled.

When exiting the vehicle the driver can choose to

have the headlights remain on for 30, 60, or

90 seconds or not remain on. You can change

the timer setting through the Uconnect system

page 188.

If the headlights are turned off before the ignition,

they will turn off in the normal manner.

NOTE:

The headlights must be turned off within

45 seconds of placing the ignition in the OFF

position to activate this feature.

IGHTS

-O

EMINDER

If the headlights or the parking lights are left on

after the ignition is placed in the OFF position, the

vehicle will chime when the driver's door is opened.

GETTING TO KNOW YOUR VEHICLE

RONT

IGHTS

— I

QUIPPED

To activate the front fog lights, turn on the parking

lights or the low beam headlights and push the

headlight switch control knob. Pushing the

headlight switch control knob a second time will

turn the front fog lights off.

Fog Light Switch

Fog Light Switch (Vehicles Sold In Canada Only)

URN

IGNALS

Move the multifunction lever up or down to

activate the turn signals. The arrows on each side

of the instrument cluster flash to show proper

operation.

NOTE:

If either light remains on and does not flash, or

there is a very fast flash rate, check for a defective

outside light bulb.

Turn Signal Warning

If the vehicle electronics sense that the vehicle has

traveled for about 1 mile (1.6 km) with the turn

signals on, a chime will sound and a message will

display in the cluster to alert the driver.

ANE

HANGE

SSIST

— I

QUIPPED

Tap the multifunction lever up or down once,

without moving beyond the detent, and the turn

signal (right or left) will flash three times then

automatically turn off.

ATTERY

AVER

Timers are set to both the interior and exterior

lights to protect the life of your vehicle’s battery.
After 10 minutes, if the ignition is in the OFF

position, and any door is left open or the dimmer

control is rotated all the way up to the dome light

on position, the interior lights will automatically

turn off.

NOTE:

Battery saver mode is canceled if the ignition is

placed in the ON position.
If the headlights remain on while the ignition is

placed in the OFF position, the exterior lights will

automatically turn off after eight minutes. If the

headlights are turned on and left on for eight

minutes while the ignition is OFF, the exterior lights

will automatically turn off.

GETTING TO KNOW YOUR VEHICLE

INTERIOR LIGHTS

NTERIOR

OURTESY

IGHTS

The courtesy light switches are used to turn the

courtesy lights on/off.

Courtesy Light Switches

To operate the courtesy lights, push either the

driver or passenger light switch.

NOTE:



Before exiting the vehicle, make sure that the

interior lights are turned off. This will prevent the

battery from discharging once the doors are

closed.



If a light is left on, it will automatically be turned

off approximately 10 minutes after the ignition

is placed in the OFF position.

Rear Courtesy/Reading Lights —

If Equipped

Located above the rear passengers are courtesy/

reading lights. The lights turn on when a front door,

a sliding door or the liftgate is opened. If your

vehicle is equipped with Remote Keyless Entry

(RKE) the lights will also turn on when the unlock

button on the key fob is pushed.
The courtesy lights also function as reading lights.

Push the lens to turn these lights on while inside

the vehicle. Push the lens a second time to turn

each light off.

Dimmer Controls

The dimmer controls are part of the headlight

switch, and are located on the driver’s side of the

instrument panel.
With the parking lights or headlights on, rotating

the right dimmer control upward will increase the

brightness of the instrument cluster lights.

Rotating the left dimmer control will adjust the

interior light levels of the ambient lighting on the

instrument panel and doors.

Dimmer Controls

Dimmer Controls (Vehicles Sold In Canada Only)

1 — Ambient Light Dimmer Control
2 — Instrument Panel Dimmer Control

GETTING TO KNOW YOUR VEHICLE

At the top detent of the instrument panel dimmer,

all the interior lights will illuminate. At the bottom

most setting (extreme bottom) interior lights are

turned off (dome off), and the cluster, radio and

instrument lighting go to their lowest dimmable

setting.

WINDSHIELD WIPER AND WASHERS

The windshield wiper/washer controls are located

on the right side of the steering column. The front

wipers are operated by rotating a switch, located

on the end of the lever.

INDSHIELD

IPER

PERATION

The wipers and washers are operated by a switch

within the wiper lever. Rotate the switch at the end

of the lever upward, to the first detent past the

intermittent settings for low-speed wiper

operation. Rotate the switch at the end of the lever

upward to the second detent past the intermittent

settings for high-speed wiper operation. To turn the

windshield wipers off, rotate the switch within the

lever all the way down to OFF.

Windshield Wiper Operation

Intermittent Wipers
Use the intermittent wiper when weather

conditions make a single wiping cycle with a

variable pause between cycles desirable. Rotate

the switch at the end of the wiper lever to the first

detent position, and then turn the switch at the end

of the lever to select the desired delay interval.

There are four delay settings, which allow you to

regulate the wipe interval from a minimum of one

cycle every second to a maximum of approximately

36 seconds between cycles. The delay intervals

will double in duration when the vehicle speed is

10 mph (16 km/h) or less.
Windshield Washers
To use the washer, pull the lever rearward toward

you and hold. If the lever is pulled while on the

intermittent setting, the wipers will turn on and

operate for several wipe cycles after the lever is

released, and then resume the intermittent

interval previously selected. If the lever is pulled

while the wipers are in the off position, the wipers

will operate several cycles, then turn off.

1 — Pull For Front Washer
2 — Rotate For Rear Wiper Operation
3 — Rotate For Front Wiper Operation
4 — Push Forward For Rear Washer
5 — Push Up For Mist

CAUTION!

Always remove any buildup of snow that

prevents the windshield wiper blades from

returning to the “park” position. If the windshield

wiper switch is turned off, and the blades cannot

return to the “park” position, damage to the

wiper motor may occur.

WARNING!

Sudden loss of visibility through the windshield

could lead to a collision. You might not see other

vehicles or other obstacles. To avoid sudden

icing of the windshield during freezing weather,

warm the windshield with the defroster before

and during windshield washer use.

GETTING TO KNOW YOUR VEHICLE

Mist
Push the lever upward to the MIST position and

release for a single wiping cycle.

NOTE:

The Mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed on

the windshield. The wash function must be used in

order to spray the windshield with washer fluid.
For information on wiper care and replacement,

see

page 320.

AIN

ENSING

IPERS

— I

QUIPPED

This feature senses rain or snowfall on the

windshield and automatically activates the wipers.

Rotate the end of the windshield wiper lever to one

of the four detent positions to activate this feature.
The sensitivity of the system is adjustable from the

windshield wiper lever. Wiper sensitivity position 1

is the least sensitive, and wiper sensitivity position

4 is the most sensitive.

NOTE:



The Rain Sensing feature will not operate when

the wiper switch is in the low or high position.



The Rain Sensing feature may not function prop

erly when ice or dried saltwater is present on the

windshield.



Use of Rain-X or products containing wax or sili

cone may reduce rain sensor performance.



The Rain Sensing feature can be turned on and

off through the Uconnect system

page 188.

The Rain Sensing system has protective features

for the wiper blades and arms. It will not operate

under the following conditions:



Low Temperature Wipe Inhibit — The Rain

Sensing feature will not operate when the igni

tion is first placed in the ON position, when the

vehicle is stationary and the outside tempera

ture is below 32°F (0°C), unless the wiper

control on the windshield wiper lever is moved,

the vehicle speed becomes greater than 3 mph

(5 km/h) or the outside temperature rises

above freezing.



Neutral Wipe Inhibit — The Rain Sensing feature

will not operate when the ignition is ON, when

the transmission gear selector is in the

NEUTRAL position and the vehicle speed is less

than 3 mph (5 km/h), unless the wiper control

on the windshield wiper lever is moved, the

vehicle speed is greater than 3 mph (5 km/h) or

the gear selector is moved out of the NEUTRAL

position.



Remote Start Mode Inhibit — On vehicles

equipped with the Remote Start system, Rain

Sensing wipers are not operational when the

vehicle is in the Remote Start mode. Once the

operator is in the vehicle and has placed the

ignition switch in the ON/RUN position, rain

sensing wiper operation can resume, if it has

been selected, and no other inhibit conditions

(mentioned previously) exist.

EAR

IPER

ASHER

The rear wiper/washer is operated by rotating a

switch, located at the middle of the lever.

Rotate the center portion of the lever

upward to the first detent for intermittent

operation and to the second detent for

continuous rear wiper operation.

Rear Window Washer Operation

Pushing the windshield wiper lever

forward activates the rear window

washer. If the lever is pushed while on

the intermittent setting, the wipers will

turn on and operate for several wipe cycles after

the lever is released, and then resume the

intermittent interval previously selected. If the

lever is pushed while the wipers are in the off

position, the wipers will operate several wipe

cycles, then turn off.

GETTING TO KNOW YOUR VEHICLE

CLIMATE CONTROLS

UTOMATIC

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 5 With 7-inch Display

Automatic Temperature Controls

Uconnect 5/5 NAV With 10.1-inch Display

Automatic Temperature Controls

Max A/C Button

Press and release the MAX A/C button on

the touchscreen to change the current

setting to the coldest output of air.

The MAX A/C indicator illuminates when

MAX A/C is on. Pressing the button again will cause

the MAX A/C operation to exit.

NOTE:

The MAX A/C setting is only available on the touch

screen.

A/C Button

Press and release the button on the

touchscreen, or push the button on the

faceplate to change the current setting.

The indicator illuminates when A/C is on.

NOTE:



If the system is in Mix or Defrost Mode, the A/C

can be turned off, but the A/C system shall

remain active to prevent fogging of the windows.



If not operating in AUTO mode, the system will

not automatically sense the presence of fog,

mist or ice on the windshield. Defrost Mode

must be manually selected to clear the wind

shield and side glass.



If fog or mist appears on the windshield or side

glass, select Defrost Mode and adjust blower

speed if needed.

Recirculation Button

Press and release the Recirculation

button on the touchscreen, or press the

button on the faceplate, to change the

system between recirculation mode and

outside air. The Recirculation indicator and the

A/C indicator illuminate when the Recirculation

button is pressed. Recirculation can be used when

outside conditions such as smoke, odors, dust, or

high humidity are present. Recirculation can be

used in all modes. Recirculation may be

unavailable (button on the touchscreen greyed

out) if conditions exist that could create fogging on

the inside of the windshield. The A/C can be

deselected manually without disturbing the mode

control selection. Continuous use of Recirculation

mode may make the inside air stuffy and window

fogging may occur. Extended use of this mode is

not recommended. Recirculation mode may

automatically adjust to optimize customer

experience for warming, cooling,

dehumidification, etc.

GETTING TO KNOW YOUR VEHICLE

AUTO Button

Set your desired temperature and press

the AUTO button on the touchscreen, or

push the button on the faceplate. AUTO

will achieve and maintain your desired

temperature by automatically adjusting the blower

speed and air distribution. Air Conditioning (A/C)

may be active during AUTO operation to improve

performance. AUTO mode is highly recommended

for efficiency. You can turn AUTO on in one of two

ways:



Press and release this button on the touch

screen



Push the button on the faceplate

Toggling this function will cause the system to

switch between manual mode and automatic

mode

page 82.

Front Defrost Button

Press and release the Front Defrost

button on the touchscreen, or push the

button on the faceplate to change the

current airflow setting to Defrost mode.

The indicator illuminates when this feature is on.

Air comes from the windshield and side window

demist outlets. When the defrost button is

selected, the blower level may increase. Use

Defrost mode with maximum temperature settings

for best windshield and side window defrosting

and defogging. Performing this function will cause

the Automatic Temperature Control (ATC) to switch

into manual mode. If the Front Defrost mode is

turned off the climate system will return to the

previous setting.

Rear Defrost Button

Press and release the Rear Defrost

Control button on the touchscreen or

push and release the button on the

faceplate to turn on the rear window

defroster and the heated outside mirrors (if

equipped). An indicator will illuminate when the

rear window defroster is on. The rear window

defroster automatically turns off after 15 minutes.

Front Temperature Control

These buttons provide the driver and passenger

with independent temperature control.

Push the red button on the faceplate or

touchscreen or press and slide the

temperature bar towards the red arrow

button on the touchscreen for warmer

temperature settings.

Push the blue button on the faceplate or

touchscreen or press and slide the

temperature bar towards the blue arrow

button on the touchscreen for cooler

temperature settings.

NOTE:

The temperature can also be adjusted by pressing

the Temperature readout on the top left and right

corners of the status bar.

SYNC Button

Press the SYNC button on the

touchscreen to toggle the SYNC feature

on/off. The SYNC indicator is illuminated

when this feature is enabled. SYNC is

used to synchronize the front and rear passenger

temperature settings with the driver temperature

setting. Changing the front or rear passenger

temperature setting while in SYNC will

automatically exit this feature.

NOTE:

The SYNC setting is only available on the touchscreen.

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

Chrysler Pacifica Hybrid (2022 year). Manual in english - page 4
