GETTING TO KNOW YOUR VEHICLE

NOTE:

On the third attempt ALL doors will lock and the key

fob can be locked in the vehicle.
To Lock The Vehicle’s Doors And Liftgate
With one of the vehicle’s key fobs within 5 ft

(1.5 m) of the driver or passenger front door

handle, push the door handle lock button to lock all

four doors and the liftgate.

Push The Door Handle Button To Lock

Do NOT grab the door handle when pushing the

door handle button. This could unlock the door(s).

Do NOT Grab The Door Handle When Locking

NOTE:



After pushing the door handle lock button, you

must wait two seconds before you can lock or

unlock the doors, using either Passive Entry

door handle. This is done to allow you to check

if the vehicle is locked by pulling the door

handle, without the vehicle unlocking.



If Passive Entry is disabled using the Uconnect

Settings, the key protection described in

"Frequency Operated Button Integrated Key

(FOBIK-Safe)" remains active/functional.



The Passive Entry system will not operate if the

key fob battery is depleted.

To Unlock/Enter The Liftgate
The liftgate Passive Entry unlock feature is built

into the electronic liftgate release button. With a

valid Passive Entry key fob within 5 ft (1.5 m) of the

liftgate, push the electronic liftgate release button

for a power open on vehicles equipped with Power

Liftgate. Pull the electronic liftgate handle and lift

for Manual Liftgate vehicles.

Electronic Liftgate

1 — Electronic Liftgate Release Handle
2 — Passive Entry Lock Button

GETTING TO KNOW YOUR VEHICLE

To Lock The Liftgate
With a valid Passive Entry key fob within 5 ft

(1.5 m) of the liftgate, push the Passive Entry lock

button located to the right of the liftgate release

handle.
The vehicle doors can also be locked by using the

key fob lock button, or the lock button located on

the vehicle’s interior door panel

page 370.

UTOMATIC

NLOCK

OORS

XIT

—

QUIPPED

The Unlock Doors Automatically On Exit feature

unlocks all of the vehicle doors when any door is

opened. This will occur only after the gear selector

has been placed into the PARK position, after the

vehicle has been driven (the gear selector has

been placed out of PARK and all doors closed).
The Unlock Doors Automatically On Exit feature will

not operate if there is any manual operation of the

door locks (lock or unlock).
This feature can be turned on or off in the

Uconnect system

page 188.

ANUAL

LIDING

IDE

OOR

The sliding door may be opened from the inside or

the outside. Pull outward on the exterior handle to

open the sliding door. The sliding door inside

handle functions by rocking forward and back.

Rocking the handle backwards opens the door and

rocking forward releases the hold open latch in

order to close the door.

Side Door Handle And Lock Functions

To keep your door operating properly, observe the

following guidelines:



Always open the door smoothly.



Avoid high impacts against the door stop when

opening the door. This is very important when

your vehicle is parked on an incline as the door

will slide faster in the downhill direction.



There is a hold-open latch that is activated when

the sliding door is fully opened. This latch will

keep your sliding door open on any incline. To

close the sliding door after the hold-open latch

is activated, you must rock the inside handle

forward or pull outward on the exterior handle.

Always make sure that the sliding door is fully

latched anytime the vehicle is in motion.

NOTE:

The left side sliding door cannot be opened while

the fuel door is open. If attempted, a message will

appear in the instrument cluster display, and the

door will automatically return to the closed

position.

1 — Door Handle
2 — Door Lock

GETTING TO KNOW YOUR VEHICLE

OWER

LIDING

IDE

OOR

—

QUIPPED

The power sliding door may be power opened or

closed in several ways:



Key fob



Inside or outside handles



Buttons located:



In the overhead console



Just inside the sliding door



On the outside handle

Push the button on the key fob twice

within five seconds to open, close, or

reverse a power sliding door.

The key fob and the overhead console button will

operate the door when the door is locked. All other

ways require the sliding door to be unlocked. If the

vehicle is equipped with Passive Entry, pushing the

button on the outside handle or Hands-Free

feature (if equipped) will unlock and open the

sliding door, with a valid Passive Entry key fob

within 5 ft (1.5 m) of the door handle.

Overhead Console Power Switches

There is a power sliding side door switch located on

the B-pillar trim panel on the driver’s and

passenger’s side, just in front of the power sliding

door for the rear seat passengers.
To operate the sliding door manually with the

handles or to avoid unintentional operation of the

power sliding doors from the rear seats, push the

power sliding door power off button, located in the

overhead console, to remove power to the handles

and buttons just inside the sliding doors.

The power off LED, in the overhead console, will be

lit when the handles are manual. When the LED is

lit, pushing the power sliding door power off button

will return the handles to power operation.

NOTE:



If anything obstructs the power sliding side door

while it is closing or opening, the door will auto

matically reverse to the closed or open position

and an audible tone will sound, provided it

meets sufficient resistance. The turn signals will

flash with sliding door movements.



If the power sliding door stops in the middle due

to obstacles, it will power open on the next

command.

Power Sliding Side Door Switch (Left Side Shown)

1 — Liftgate
2 — Left Sliding Door
3 — Sliding Door Power Off
4 — Right Sliding Door

GETTING TO KNOW YOUR VEHICLE

ANDS

-F

REE

LIDING

OORS

—

QUIPPED

To open the Hands-Free Sliding Doors, use a

straight in and out kicking motion under the

vehicle in the general location below the door

handle(s). Do not move your foot sideways or in

a sweeping motion or the sensors may not detect

the motion.

Activation Zone

When a valid kicking motion is completed, the

sliding door will chime, the hazard lights will

flash and the sliding door will open almost

instantaneously. This assumes all options are

enabled in the Uconnect Settings.

NOTE:



To open the Hands-Free Sliding Doors requires

a valid Passive Entry key fob within 5 ft (1.5 m)

of the door handle. If a valid Passive Entry key

fob is not within 5 ft (1.5 m), the door will not

respond to any kicks.



The Hands-Free Sliding Doors will only operate

when the gear selector is in PARK.



With every movement of the Hands-Free Sliding

Doors, an audible tone will sound and the turn

signals will flash. You can turn these alerts on or

off in the Uconnect system

page 188.



If anything obstructs the power sliding side door

while it is closing or opening, the door will auto

matically reverse to the closed or open position

and an audible tone will sound, provided it

meets sufficient resistance. The turn signals will

flash with sliding door movements.



If the power sliding doors encounter multiple

obstructions within the same cycle, the system

will automatically stop.

The Hands-Free Sliding Doors feature may be

turned off through Uconnect Settings

page 188.

NOTE:

The Hands-Free Sliding Doors feature should be

turned off during jacking, tire changing, and

vehicle service.

WARNING!



Personal injury or cargo damage may occur if

caught in the path of the sliding door. Make

sure the door path is clear before closing

the door.



Before driving off, check the instrument

cluster for a sliding door or door open

message or warning indicator. Failure to do

this could result in unintentionally leaving the

sliding door open while driving.

GETTING TO KNOW YOUR VEHICLE

HILD

ROTECTION

OOR

OCK

YSTEM

— R

EAR

OORS

To provide a safer environment for small children

riding in the rear seats, the sliding doors are

equipped with a Child Protection Door Lock

system.
To Engage The Child Protection Door Lock
1. Open the sliding side door.
2. On the rear of the sliding door, slide the

Child Protection Door Lock control inward

(toward the vehicle) to engage the Child

Protection Door Lock.

Child Protection Door Locks

3. Repeat Steps 1 and 2 on the opposite sliding

door.

NOTE:



After engaging the Child Protection Door Lock,

always test the inside door handle with the

sliding door closed to make certain the Child

Protection Door Lock is in the locked position.



After disengaging the Child Protection Door

Lock, always test the inside door handle with the

sliding door closed to make certain the Child

Protection Door Lock is in the unlocked position.



The inside door handle will not open the sliding

door when the Child Protection Door Lock is

engaged.



The power sliding door will operate from the

switch located just inside the sliding door,

regardless of the Child Protection Door Lock

lever position.



To avoid unintentional operation of the power

sliding door from the rear seats, push the

Sliding Door Power Off button, located in the

overhead console. When the overhead console

power OFF LED is illuminated, the sliding door

may not be power opened or closed by pushing

the buttons just inside the sliding doors or

pulling on the handles.

To Disengage The Child Protection Door Lock
1. Open the sliding side door.
2. Slide the Child Protection Door Lock control

outward (away from the vehicle) to disengage

the Child Protection Door Lock.

3. Repeat Steps 1 and 2 on the opposite sliding

door.

NOTE:

After disengaging (or engaging) the Child

Protection Door Lock, always test the inside door

handle with the sliding door closed to make certain

the Child Protection Door Lock is in the desired

position. The inside door handle will open the

sliding door when the Child Protection Door Lock is

disengaged.

WARNING!

Avoid trapping anyone in the vehicle in a

collision. Remember that the sliding doors

cannot be opened from the inside door handle

when the Child Protection Door Locks are

engaged.

GETTING TO KNOW YOUR VEHICLE

STEERING WHEEL

ILT

ELESCOPING

TEERING

OLUMN

This feature allows you to tilt the steering column

upward or downward. It also allows you to lengthen

or shorten the steering column. The tilt/

telescoping lever is located left of the steering

wheel at the end of the steering column.

Tilt/Telescoping Lever

To unlock the steering column, push the lever

downward (toward the floor). To tilt the steering

column, move the steering wheel upward or

downward as desired. To lengthen or shorten the

steering column, pull the steering wheel outward

or push it inward as desired. To lock the steering

column in position, push the lever upward until

fully engaged.

EATED

TEERING

HEEL

—

QUIPPED

The steering wheel contains a heating

element that helps warm your hands in

cold weather. The heated steering wheel

has only one temperature setting. Once

the heated steering wheel has been turned on, it

will stay on for an average of 80 minutes before

automatically shutting off. This time will vary based

on environmental temperatures. The heated

steering wheel can shut off early or may not turn on

when the steering wheel is already warm.

The heated steering wheel button is located within

the Uconnect system. You can access the button

through the Comfort screen.



Press the heated steering wheel button once to

turn the heating element on.



Press the heated steering wheel button a

second time to turn the heating element off.

NOTE:

The engine must be running for the heated

steering wheel to operate.
For information on use with the Remote Start

system, see

page 21.

WARNING!

Do not adjust the steering column while driving.

Adjusting the steering column while driving or

driving with the steering column unlocked, could

cause the driver to lose control of the vehicle.

Failure to follow this warning may result in

serious injury or death.

WARNING!



Persons who are unable to feel pain to the

skin because of advanced age, chronic illness,

diabetes, spinal cord injury, medication,

alcohol use, exhaustion, or other physical

conditions must exercise care when using the

steering wheel heater. It may cause burns

even at low temperatures, especially if used

for long periods.



Do not place anything on the steering wheel

that insulates against heat, such as a blanket

or steering wheel covers of any type and mate

rial. This may cause the steering wheel heater

to overheat.

GETTING TO KNOW YOUR VEHICLE

DRIVER MEMORY SETTINGS — IF EQUIPPED

This feature allows the driver to save up to two

different memory profiles for easy recall through a

memory switch. Each memory profile saves

desired position settings for the following features:



Driver’s seat



Easy Entry/Exit seat operation (if equipped)



Power steering wheel position (if equipped)



Side mirrors (if equipped)



A set of desired radio station presets

NOTE:



Your vehicle is equipped with two key fobs, each

can be linked to either memory position 1 or 2.



Memory settings will be linked to the driver

profiles in the Uconnect system, in addition to

several other features (radio presets, home

screens, settings, navigation, phone, etc.)

page 188.

The Driver Memory Settings switch is located on

the driver door, next to the door handle, and

consists of three buttons:



The set (S) button, which is used to activate the

memory save function.



The (1) and (2) buttons which are used to recall

either of two saved memory profiles.

Driver Memory Switch

ROGRAMMING

EMORY

EATURE

To create a new memory profile, perform the

following:

NOTE:

Saving a new memory profile will erase the

selected profile from memory.
1. Place the vehicle’s ignition in the ON/RUN

position (do not start the engine).

2. Adjust all memory profile settings to desired

preferences (i.e., driver’s seat, outside mirrors

and radio station presets).

3. Push the set (S) button on the memory switch,

and then push the desired memory button

(1 or 2) within five seconds. The instrument

cluster display will show which memory

position has been set.

NOTE:

Memory profiles can be set without the vehicle in

PARK.

INKING

NLINKING

EMORY

Your key fob can be programmed to recall one of

two saved memory profiles.

NOTE:

Before programming your key fob you must select

the “Personal Settings Linked to Key Fob” feature

through the Uconnect Settings

page 188.

To program your key fob, perform the following:
1. Place the vehicle’s ignition in the OFF

position.

2. Select a desired memory profile 1 or 2.
3. Once the profile has been recalled, push and

release the set (S) button on the memory

switch.

1 — Memory Profile Button 1
2 — Memory Profile Button 2
3 — Set Button

GETTING TO KNOW YOUR VEHICLE

4. Push and release button (1) or (2) accordingly.

“Memory Profile Set” (1 or 2) will display in the

instrument cluster.

5. Push and release the lock button on the

key fob within 10 seconds.

NOTE:

Your key fob can be unlinked from your memory

settings by pushing the set (S) button, and then,

within 10 seconds, pushing the unlock button on

the key fob.

EMORY

OSITION

ECALL

NOTE:



The vehicle speed must be less than or equal to

5 mph (8 km/h) to recall memory positions. If a

recall is attempted when the vehicle speed is

greater than 5 mph (8 km/h), a message will be

displayed in the instrument cluster display.



Memory settings can be linked to driver profiles

in the Uconnect system. Changing driver profiles

will also recall the linked memory settings if the

conditions are met

page 188.

To recall the memory settings for driver one or

two, push the desired memory button (1 or 2) on

the driver's door or the unlock button on the key

fob linked to the desired memory position.

A recall can be canceled by pushing any of the

memory buttons on the driver's door during a recall

(S, 1, or 2). When a recall is canceled, the driver's

seat stops moving. A delay of one second will occur

before another recall can be selected.

NOTE:

Pushing the mirror adjust switch will cancel the

memory mirror recall.

SEATS

Seats are a part of the Occupant Restraint system

of the vehicle.

ANUAL

DJUSTMENT

RONT

EATS

) —

QUIPPED

WARNING!



It is dangerous to ride in a cargo area, inside

or outside of a vehicle. In a collision, people

riding in these areas are more likely to be seri

ously injured or killed.



Do not allow people to ride in any area of your

vehicle that is not equipped with seats and

seat belts. In a collision, people riding in these

areas are more likely to be seriously injured or

killed.



Be sure everyone in your vehicle is in a seat

and using a seat belt properly.

WARNING!



Adjusting a seat while the vehicle is moving is

dangerous. The sudden movement of the seat

could cause you to lose control. The seat belt

might not be adjusted properly and you could

be injured. Adjust the seat only while the

vehicle is parked.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt and be seriously or even fatally

injured. Use the recliner only when the vehicle

is parked.

GETTING TO KNOW YOUR VEHICLE

Manual Front Adjuster

Both front seats are adjustable forward or

rearward. The manual seat adjustment handle is

located under the seat cushion at the front edge of

each seat.

Manual Seat Adjustment

While sitting in the seat, pull up on the handle and

slide the seat forward or rearward. Release the bar

once you have reached the desired position. Then,

using body pressure, move forward and rearward

on the seat to be sure that the seat adjusters have

latched.

Manual Seat Height Adjustment

The driver’s seat height can be raised or lowered

by using a lever, located on the outboard side of

the seat. Pump the lever upward to raise the seat

height or pump the lever downward to lower the

seat height.

Manual Front Seat Recline Adjustment

For models equipped with manual seats, the

recline lever is located on the outboard side of

the seat.
To recline, lean forward slightly, lift the lever and

push back to the desired position and release the

lever. Lean forward and lift the lever to return the

seatback to its normal position. Using body

pressure, lean forward and rearward on the seat to

be sure the seatback has latched.

ANUAL

DJUSTMENT

EAR

EATS

)

1 — Forward/Rearward Adjustment Bar
2 — Height Adjustment
3 — Recline Lever

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.

WARNING!

Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious injury

or death.

WARNING!



Adjusting a seat while the vehicle is moving is

dangerous. The sudden movement of the seat

could cause you to lose control. The seat belt

might not be adjusted properly and you could

be injured. Adjust the seat only while the

vehicle is parked.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt and be seriously or even fatally

injured. Use the recliner only when the vehicle

is parked.

GETTING TO KNOW YOUR VEHICLE

Manual Forward/Rearward Adjustment —

Quad Seats (If Equipped)

Both second row seats are adjustable forward or

rearward. The manual seat adjustment handle is

located under the seat cushion at the front edge of

each seat.

Manual Rear Seat Adjuster

While sitting in the seat, pull up on the handle and

slide the seat forward or rearward. Release the bar

once you have reached the desired position. Then,

using body pressure, move forward and rearward

on the seat to be sure that the seat adjusters have

latched.

Manual Recline — Quad Seats

Recline Lever

To recline, lean forward slightly, lift the lever, and

push back to the desired position and release the

lever. Lean forward and lift the lever to return the

seatback to its normal position. Using body

pressure, lean forward and rearward on the seat to

be sure the seatback has latched.

Second Row Bench Seat — If Equipped

The second row bench seat can accommodate two

passengers, while providing easy access to the

third row seats without any folding of the second

row seats.

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.

WARNING!

Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious injury

or death.

GETTING TO KNOW YOUR VEHICLE

To recline the seatback, lean forward slightly, lift

the recline lever located on the outboard side of

the seat cushion, and push back to the desired

position and release the lever. Lean forward and

lift the lever to return the seatback to its normal

position. Using body pressure, lean forward and

rearward on the seat to be sure the seatback has

latched.

Recline Lever

The bench seat does not stow in the floor, but is

removable for added cargo space.

Removing The Bench Seat
1. Adjust the driver and passenger seats

forward to allow room for the bench seat

removal.

2. Raise the armrest completely, then lift the

recline lever located on the outboard side of

the seat to fold the seatback flat against the

seat cushion.

Folded Position

3. Pull the release strap located behind the seat,

in the center near the floor to release the

latches.

Release Strap Location

4. Once the latches are released, tilt the entire

seat toward the front of the vehicle. The seat

can now be removed through either sliding

side door, or through the liftgate.

Tilt Bench Seat Forward

GETTING TO KNOW YOUR VEHICLE

NOTE:



Due to the weight of the bench seat, it is recom

mended that two people are utilized for its

removal.



When storing the removed bench seat, it is

important to keep the seatback in the folded

position.

Reinstalling The Bench Seat
1. To reinstall the bench seat, align the seats

front attachments into the detent positions

on the floor.

2. Tilt seat rearward to lock the seatback into its

original position.

NOTE:

Push downward to ensure the rear latches are in

the locked position.
3. Lift the recline handle and return the seatback

to the seating position.

Second Row Removable 8th Seat —

If Equipped

While the 8th seat does not stow in the floor, it is

foldable and removable for added cargo space.

Second Row 8th Seat Fold Flat Strap

The release strap is located on the front of the

seat, near the floor. To remove the seat, pull the

release strap to release the rear latches. The seat

assembly can now be removed from the vehicle by

moving it in a rearward direction from the detent

positions in the floor.

Release Strap

NOTE:

The seat can be removed easier with one outboard

seat stowed in the load floor.
To reinstall the seat, align the seat into the detent

positions on the floor. Tilt seat rearward to lock the

seatback into its original position.

In Floor Detent Guides

WARNING!

If not properly latched, the seat could become

loose. Personal injuries could result.

GETTING TO KNOW YOUR VEHICLE

Fold-Flat — Quad Seats

To fold the seat, lift the recliner lever to the full

upward position and push the seatback forward

until it rests on the seat cushion.

Fold-Flat Seat Recline Lever

NOTE:



The seatback may lock into the fold-flat position.

Use the recline lever to unlock the seatback.



If equipped with Stow ‘n Go seating: when

returning the seat to the original position, the

headrest must be folded back to the original

position.

Stow ‘n Go Seating Head Restraint

Easy Entry

Easy Tilt Seat — With Or Without Child Seat

Installed
The second row seats can be tilted forward for easy

entry into the third row with or without a child seat

installed.
1. Located in the seatback of the second row

seat is a lever (or handle for Stow ‘n Go seats)

that provides easier access to the third row by

tilting the seat forward.

2. Slide the lever upwards, or if equipped, pull the

handle forward, to unlock the seatback.

Lift Easy Tilt Seat Lever (If Equipped)

Pull Easy Tilt Seat Handle (If Equipped)

WARNING!

If not properly latched, the seat could become

loose. Personal injuries could result.

GETTING TO KNOW YOUR VEHICLE

3. Push on seatback to slide seat forward to

access the third row.

Easy Tilt Seat

Easy Tilt With Child Seat Installed

4. To put the seat back into original position, just

pull back on the seatback and lock the seat

into position.

Easy Entry — With The Seat Folded Flat
The seats can be folded and tilted for more

accessibility for passengers to enter and exit the

third row.
1. Without a child seat installed, you can fold the

seat by pulling the recliner handle on the

bottom part of the seat. Before pulling the

recliner lever, make sure the arm rests are

folded up.

Recliner Lever

2. To put it back into position, pull back on the

folded seat and make sure that it locks into

position. Then, pull the seatback toward the

back and fold down the arm rests.

Exit For Third Row Passengers — Stow ‘n Go Seats

Only
If the second row is equipped with Stow ‘n Go, third

row passengers can pull on the strap and push the

seat forward for folding the seatback down and

tilting the seat to the floor for an easy exit.

Pull Strap For Third Row Passengers

NOTE:

This process is for when there is no child seat

installed. Use the easy entry lever if a child seat is

installed.

WARNING!

Do not use this feature with a child in seat.

Serious injury or death may occur.

GETTING TO KNOW YOUR VEHICLE

Second Row Removable Quad Seat

The second row quad seats, not equipped with the

Stow ‘n Go feature, are removable for added cargo

space.
Removing Seat
1. Adjust seat to the full rearward position.
2. Lift the recline lever to fold the seatback flat

against the seat cushion.

Lift Recline Lever And Fold Seatback Flat

NOTE:

Push downward on the seatback to make sure it is

in the locked position.
3. The release strap is located on the front of the

seat, near the floor.

Seat Release Strap

4. To remove the seat, pull the release strap to

release the rear latches.

5. Tilt the back of the seat to the upward position.

Tilt Seat Forward

6. The seat assembly can now be removed from

the vehicle. Grab the front seatback edge

located near the head restraint and the grab

the bar on the rear side of the seat cushion for

easy removal.

Seat Removal

Reinstalling Seat
1. To reinstall the seat: With the seat tilted

forward, align the seat’s front attachments

into the detent positions on the floor.

In Floor Seat Detents

GETTING TO KNOW YOUR VEHICLE

Installing Seat

2. Tilt seat rearward to lock the seat back into its

original position.

NOTE:

Push downward to ensure the rear latches are in

the locked position.
3. Lift the recline handle and return the seat back

to the seating position.

Manually Folding Third Row Seats —

If Equipped

1. Lower the center head restraint down to the

seatback by pushing the button on the guide

and pushing the head restraint down.

2. Pull release strap marked “1” to release the

anchors.

Release Strap “1”

3. Pull release strap marked “2” and tumble the

seat rearward into the storage bin.

Strap “2”

Stowed Third Row Seat

WARNING!

If not properly latched, the seat could become

loose. Personal injuries could result.

Chrysler Pacifica Hybrid (2022 year). Manual in english - page 2
