Chrysler Pacifica (2022 year). Manual in english

GETTING TO KNOW YOUR VEHICLE

Blower Control

Blower Control regulates the amount of

air forced through the climate control

system. There are seven blower speeds

available. Adjusting the blower will cause

automatic mode to switch to manual operation.

The speeds can be selected using either the

blower control knob on the faceplate or the

buttons on the touchscreen.



Faceplate: The blower speed increases as you

turn the blower control knob clockwise from

the lowest blower setting. The blower speed

decreases as you turn the blower control knob

counterclockwise.



Touchscreen:Blower speed can be selected by

pressing the blower bar area between the icons.

Press the desired blower speed from 1-7.

Mode Control

The airflow distribution mode can be

adjusted so air comes from the

instrument panel outlets, floor outlets,

defrost outlets and demist outlets.

Faceplate: Push the button in the center of the

knob to change the airflow distribution mode.
Touchscreen: Select Mode by pressing one of the

Mode Buttons on the touchscreen.

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these outlets

can be individually adjusted to direct the

flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and

down or side to side to regulate airflow direction.

There is a shut-off wheel located below the air

vanes to shut off or adjust the amount of airflow

from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight

amount of air is directed through the

defrost and side window demister

outlets.

Mix Mode

Air is directed through the floor, defrost,

and side window demister outlets. This

setting works best in cold or snowy

conditions that require extra heat to the

windshield. This setting is good for maintaining

comfort while reducing moisture on the

windshield.

Climate Control OFF Button

Press and release this button on the

touchscreen or push and release the

button on the faceplate to turn the

Climate Control ON/OFF.

Controlling The Rear Climate Controls

From The Front ATC Panel—If Equipped

The Three-Zone Automatic Temperature Control

(ATC) system allows for adjustment of the rear

climate controls from the front ATC panel.
To change the rear system settings:



Press the Rear Climate button on the touch

screen to display the rear climate controls.

Control functions now operate the rear system.



To return to the Front screen on the Uconnect

system, press the Front Climate or Done button

on the touchscreen.

GETTING TO KNOW YOUR VEHICLE

Uconnect 5 With 10.1-in Display Rear Control Screen

REAR CLIMATE CONTROL BUTTON

Press and release the Rear button to

access the rear climate controls. The

indicator will illuminate when the rear

climate controls are on.

REAR AUTO BUTTON

Press and release the AUTO button on

the touchscreen, within the Rear screen,

to change the current setting. The REAR

AUTO indicator will illuminate when REAR

AUTO is on. This feature automatically controls the

rear interior cabin temperature by adjusting airflow

distribution and amount. Toggling this function will

cause the rear system to switch between manual

mode and automatic modes

page 82.

REAR LOCK BUTTON

Press and release this button to lock out

the rear manual temperature controls

from adjusting the rear temperature and

blower settings.

FRONT CLIMATE BUTTON

Press and release the Front button to

change the display on the Uconnect

system back to the Front Climate

Controls.

REAR TEMPERATURE CONTROL

These buttons provide the front occupants with the

ability to control the rear temperature.

Push the up arrow button on the

touchscreen to increase the

temperature.
Push the down arrow button on the

touchscreen to decrease the

temperature.

NOTE:

When the SYNC feature is active, the passenger’s

temperature will move up and down with the

driver’s temperature.

SYNC BUTTON

Press the SYNC To Driver button on the

touchscreen to toggle the SYNC feature

on/off. The SYNC indicator is illuminated

when this feature is enabled. SYNC is

used to synchronize the front and rear passenger

temperature settings with the driver temperature

setting. Changing the front or rear passenger

temperature/mode/blower settings while in

SYNC will automatically exit this feature.
NOTE:

The SYNC setting is only available on the touchscreen.

BLOWER CONTROL

Blower Control is used to regulate the

amount of air forced through the Climate

Control system. There are seven blower

speeds available. Adjusting the blower

causes automatic mode to switch to manual

operation. The speeds can be selected using the

buttons on the touchscreen.

PANEL MODE

Press this button on the touchscreen to

change the air distribution mode to Panel

Mode. In Panel Mode, air comes from the

outlets in the headliner. Each of these

outlets can be individually adjusted to direct the

flow of air. Moving the air vanes of the outlets to

one side will shut off the airflow.

GETTING TO KNOW YOUR VEHICLE

BI-LEVEL MODE

Press this button on the touchscreen to

change the air distribution mode to

Bi-Level Mode. In Bi-Level Mode, air

comes from both the headliner outlets

and the floor outlets.
NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

FLOOR MODE

Press this button on the touchscreen to

change the air distribution mode to Floor

Mode. In Floor Mode, air comes from the

floor outlets.

REAR PASSENGER CLIMATE CONTROL OFF

BUTTON

Press and release the OFF button to

turn the Rear Climate Controls off.

Rear Automatic Temperature

Control (ATC) — If Equipped

The rear Automatic Temperature Control (ATC)

system has floor air outlets underneath the

passengers’ seats, and overhead outlets at

each outboard rear seating position. The system

provides heated air through the floor outlets or

cool, dehumidified air through the headliner

outlets.
Rear second row occupants can only adjust the

rear ATC control when the Rear Temperature Lock

button is turned off.
The rear ATC system is located in the headliner, on

the passenger side of the vehicle.

Rear Automatic Climate Controls

1. Adjust the rear blower, rear temperature and

the rear modes to suit your comfort needs.

2. ATC is selected by pushing the AUTO button.

Once the desired temperature is displayed, the

ATC System will automatically achieve and

maintain that comfort level. When the system is

set up for your comfort level, it is not necessary to

change the settings. You will experience the

greatest efficiency by simply allowing the system to

function automatically.
NOTE:

It is not necessary to move the temperature

settings. The system automatically adjusts the

temperature, mode and fan speed to provide

comfort as quickly as possible.

AUTO BUTTON

The AUTO button automatically controls

the interior cabin temperature by

adjusting distribution and amount of

airflow. Performing this function will

cause the system to switch between manual mode

and automatic modes

page 82.

REAR TEMPERATURE CONTROL

To change the temperature in the rear of

the vehicle, push temperature control up

button to raise the temperature. The rear

temperature settings are displayed in

control head.

To change the temperature in the rear of

the vehicle, push temperature control

down button to lower the temperature.

The rear temperature settings are

displayed in control head.

GETTING TO KNOW YOUR VEHICLE

REAR BLOWER CONTROL

The rear blower control can be manually

set to off, or any fixed blower speed by

pushing the blower control buttons. This

allows the rear seat occupants to control

the volume of air circulated in the rear of the

vehicle. The larger of the two icons increases

blower speed, whereas the smaller of the two icons

decreases the blower speed.

REAR MODE CONTROL

Push this button on the Rear Climate

Controls to change the air distribution

mode for the rear passengers.

PANEL MODE

Air comes from the outlets in the

headliner. Each of these outlets can be

individually adjusted to direct the flow of

air. Moving the air vanes of the outlets to

one side will shut off the airflow.

BI-LEVEL MODE

Air comes from both the headliner outlets

and the floor outlets.

NOTE:

In many temperature positions, the Bi-Level mode

is designed to provide cooler air out of the head

liner outlets and warmer air from the floor outlets.

FLOOR MODE

Air comes from the floor outlets.

REAR CLIMATE CONTROL/BLOWER OFF

To manually set the rear blower controls

to off, press the Rear Climate Control/

Blower Off button.

ANUAL

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 5 With 7-inch Display

Manual Temperature Controls

MAX A/C Button

Press and release the MAX A/C button to

change the current setting. The indicator

illuminates when MAX A/C is on.

Performing this function again will cause

the MAX A/C operation to switch into manual mode

and the MAX A/C indicator will turn off.
NOTE:

The MAX A/C setting is only available on the touch

screen.

A/C Button

Press and release the A/C button to

change the current setting. The indicator

illuminates when A/C is on.

NOTE:



For Manual Climate Controls, if the system is in

Mix, Floor or Defrost Mode, the A/C can be

turned off, but the A/C system shall remain

active to prevent fogging of the windows.



If fog or mist appears on the windshield or side

glass, select Defrost mode, and increase blower

speed if needed.



If your air conditioning performance seems

lower than expected, check the front of the A/C

condenser (located in front of the radiator), for

an accumulation of dirt or insects. Clean with a

gentle water spray from the front of the radiator

and through the condenser.

GETTING TO KNOW YOUR VEHICLE

Recirculation Button

Press and release this button to change

the system between recirculation mode

and outside air mode. The Recirculation

indicator and the A/C indicator illuminate

when the Recirculation button is pressed.

Recirculation can be used when outside conditions

such as smoke, odors, dust, or high humidity are

present. Recirculation can be used in all modes

except for Defrost. Recirculation may be

unavailable (button on the touchscreen greyed

out) if conditions exist that could create fogging on

the inside of the windshield. The A/C (Air

Conditioning) can be deselected manually without

disturbing the mode control selection. Continuous

use of the Recirculation mode may make the

inside air stuffy and window fogging may occur.

Extended use of this mode is not recommended.

On systems with Manual Climate Controls, the

Recirculation mode (if equipped) is not allowed in

Defrost mode to improve window clearing

operation. Recirculation is disabled automatically

if this mode is selected. Attempting to use

Recirculation while in this mode causes the LED on

the control button to blink and then turn off.

Front Defrost Button

Press and release the Front Defrost

button to change the current airflow

setting to Defrost mode. The indicator

illuminates when this feature is on.

Air comes from the windshield and side window

demist outlets. When the defrost button is

selected, the blower level may increase. Use

Defrost mode with maximum temperature settings

for best windshield and side window defrosting

and defogging. Performing this function will cause

the Automatic Temperature Control (ATC) to switch

into manual mode. If the Front Defrost mode is

turned off the climate system will return the

previous setting.

Rear Defrost Button

Push and release the Rear Defrost

Control button to turn on the rear window

defroster and the heated outside mirrors

(if equipped). An indicator will illuminate

when the rear window defroster is on. The rear

window defroster automatically turns off after

15 minutes.

Front Temperature Control

These buttons provide the driver and passenger

with independent temperature control.

Push the red button on the faceplate or

touchscreen or press and slide the

temperature bar towards the red arrow

button on the touchscreen for warmer

temperature settings.

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

GETTING TO KNOW YOUR VEHICLE

Push the blue button on the faceplate or

touchscreen or press and slide the

temperature bar towards the blue arrow

button on the touchscreen for cooler

temperature settings.

SYNC Button

Press the SYNC button on the

touchscreen to toggle the Sync feature

on/off. The SYNC indicator is illuminated

when this feature is enabled. SYNC is

used to synchronize the front and rear passenger

temperature settings with the driver temperature

setting. Changing the front or rear passenger

temperature setting while in SYNC will

automatically exit this feature. Pressing SYNC on

the touchscreen while in the Front Climate screen

synchronizes the driver and passenger

temperatures only. In order to SYNC rear

temperature to driver temperature, the

touchscreen must be on the Rear Climate screen.
NOTE:

The SYNC setting is only available on the touch

screen.

Blower Control

Blower Control is used to regulate the

amount of air forced through the Climate

Control system. There are seven blower

speeds available. The speeds can be

selected using either the blower control knob on

the faceplate or the buttons on the touchscreen.



Faceplate: The blower speed increases as you

turn the blower control knob clockwise from the

lowest blower setting. The blower speed

decreases as you turn the blower control knob

counterclockwise.



Touchscreen: Use the small blower icon to

reduce the blower setting and the large blower

icon to increase the blower setting. Blower

speed can also be selected by pressing the

blower bar area between the icons.

Mode Control

The airflow distribution mode can be

adjusted so air comes from the

instrument panel outlets, floor outlets,

defrost outlets and demist outlets.

Faceplate: Push the button in the center of the

knob to change the airflow distribution mode.
Touchscreen: Select Mode by pressing one of the

Mode Buttons on the touchscreen.

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these outlets

can be individually adjusted to direct the

flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and

down or side to side to regulate airflow direction.

There is a shut-off wheel located below the air

vanes to shut off or adjust the amount of airflow

from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight

amount of air is directed through the

defrost and side window demister

outlets.

GETTING TO KNOW YOUR VEHICLE

Mix Mode

Air is directed through the floor, defrost,

and side window demister outlets. This

setting works best in cold or snowy

conditions that require extra heat to the

windshield. This setting is good for maintaining

comfort while reducing moisture on the

windshield.

Climate Control OFF Button

Press and release this button to turn the

Climate Control ON/OFF.

Controlling The Rear Climate Controls

From The Front MTC Display/Touchscreen

The Three-Zone Manual Temperature Control

(MTC) system allows for adjustment of the rear

climate controls from the front MTC display/

touchscreen.
To change the rear system settings:



Press the Rear Climate button on the touch

screen to display the rear climate controls. The

control functions now operate the rear system.



Press the Front Climate button on the touch

screen to return to the front climate controls.

REAR CLIMATE CONTROL BUTTON

Press and release this button to access

the rear climate controls. The indicator

will illuminate when the rear climate

controls are on.

REAR LOCK BUTTON

Press and release this button to lock out

the rear manual temperature controls

from adjusting the rear temperature and

blower settings.

FRONT CLIMATE BUTTON

Press and release this button to change

the display on the Uconnect system back

to the Front Climate Controls.

REAR TEMPERATURE CONTROL

These buttons provide the rear passengers with

independent temperature control.

Push the up arrow button on the

touchscreen to increase the

temperature.

Push the down arrow button on the

touchscreen to decrease the

temperature.

NOTE:

When the SYNC feature is active, the passenger’s

temperature moves up and down with the driver’s

temperature.

SYNC BUTTON

Press the SYNC To Driver button on the

touchscreen to toggle the SYNC feature

on/off. The SYNC indicator is illuminated

when this feature is enabled. SYNC is

used to synchronize the front and rear passenger

temperature settings with the driver temperature

setting. Changing the front or rear passenger

temperature setting while in SYNC exits this

feature.
NOTE:

The SYNC setting is only available on the touchscreen.

BLOWER CONTROL

Blower Control is used to regulate the

amount of air forced through the Climate

Control system. There are seven blower

speeds available. Adjusting the blower

causes automatic mode to switch to manual

operation. The speeds can be selected using the

buttons on the touchscreen.

GETTING TO KNOW YOUR VEHICLE

PANEL MODE

Press this button on the touchscreen to

change the air distribution mode to Panel

Mode. In Panel Mode, air comes from the

outlets in the headliner. Each of these

outlets can be individually adjusted to direct the

flow of air. Moving the air vanes of the outlets to

one side will shut off the airflow.

BI-LEVEL MODE

Press this button on the touchscreen to

change the air distribution mode to

Bi-Level Mode. In Bi-Level Mode, air comes

from the headliner and floor outlets.

NOTE:

Bi-Level Mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

FLOOR MODE

Press this button on the touchscreen to

change the air distribution mode to Floor

Mode. In Floor Mode, air comes from the

floor outlets.

REAR PASSENGER CLIMATE CONTROL OFF

BUTTON

Press and release this button to turn the

Rear Climate Controls off.

Rear Manual Temperature Control (MTC)

The rear Manual Temperature Control (MTC)

system has floor air outlets at the rear right side of

the third row seats and overhead outlets at each

outboard rear seating position. The system

provides heated air through the floor outlets or

cool, dehumidified air through the headliner

outlets.
The rear system temperature control buttons are

located on the headliner on the passenger side of

the vehicle.

Rear Manual Climate Controls

REAR TEMPERATURE CONTROL

To change the temperature in the rear of

the vehicle, push temperature control up

button to raise the temperature. The rear

temperature settings are displayed in

control head.

To change the temperature in the rear of

the vehicle, push temperature control

down button to lower the temperature.

The rear temperature settings are

displayed in control head.

CAUTION!

Interior air enters the Rear Automatic

Temperature Control system through an intake

grille, located in the floor under the passengers’

seats. Do not block or place objects directly in

front of the inlet grille or heater outlets. The

electrical system could overload causing

damage to the blower motor.

GETTING TO KNOW YOUR VEHICLE

REAR BLOWER CONTROL

The rear blower control can be manually

set to off, or any fixed blower speed by

pushing the blower control buttons. This

allows the rear seat occupants to control

the volume of air circulated in the rear of the

vehicle. The larger of the two icons increases

blower speed, whereas the smaller of the two icons

decreases the blower speed.

REAR MODE CONTROL

Push this button on the Rear Climate

Controls to change the air distribution

mode for the rear passengers.

PANEL MODE

Air comes from the outlets in the

headliner. Each of these outlets can be

individually adjusted to direct the flow of

air. Moving the air vanes of the outlets to

one side will shut off the airflow.

BI-LEVEL MODE

Air comes from both the headliner outlets

and the floor outlets.

NOTE:

In many temperature positions, the Bi-Level mode

is designed to provide cooler air out of the head

liner outlets and warmer air from the floor outlets.

FLOOR MODE

Air comes from the floor outlets.

REAR CLIMATE CONTROL/BLOWER OFF

To manually set the rear blower controls

to off, press the Rear Climate Control/

Blower Off button.

UTOMATIC

EMPERATURE

ONTROL

(ATC) — I

QUIPPED

Automatic Operation

1. Push the AUTO button on the faceplate, or the

AUTO button on the touchscreen on the

Automatic Temperature Control (ATC) Panel.

2. Next, adjust the temperature you would like

the system to maintain by adjusting the driver

and passenger temperature control buttons.

Once the desired temperature is displayed, the

system will achieve and automatically

maintain that comfort level.

3. When the system is set up for your comfort

level, it is not necessary to change the

settings. You will experience the greatest

efficiency by simply allowing the system to

function automatically.

NOTE:



It is not necessary to move the temperature

settings for cold or hot vehicles. The system

automatically adjusts the temperature, mode,

and blower speed to provide comfort as quickly

as possible.



The temperature can be displayed in U.S. or

Metric units by selecting the U.S./Metric

customer-programmable feature within the

Uconnect system

page 188.

To provide you with maximum comfort in the

Automatic mode during cold start-ups, the blower

fan will remain on low until the engine warms up.

The blower will increase in speed and transition

into Auto mode.

Manual Operation Override

This system offers a full complement of manual

override features. The AUTO symbol in the front

Automatic Temperature Control (ATC) display will

be turned off when the system is being used in the

manual mode.

GETTING TO KNOW YOUR VEHICLE

LIMATE

OICE

OMMANDS

Adjust vehicle temperatures hands-free and keep

everyone comfortable while you keep moving

ahead. (If vehicle is equipped with climate control.)
Push the VR button on the steering wheel. After the

beep, say one of the following commands:



“Set driver temperature to 70 degrees”



“Set passenger temperature to 70 degrees”

Did you know: Voice Command for Climate may only

be used to adjust the interior temperature of your

vehicle. Voice Command will not work to adjust the

heated seats or steering wheel if equipped.

PERATING

IPS

Refer to the chart at the end of this section for

suggested control settings for various weather

conditions.

Summer Operation

The engine cooling system must be protected with

a high-quality antifreeze coolant to provide proper

corrosion protection and to protect against engine

overheating. OAT coolant (conforming to

MS.90032) is recommended.

Winter Operation

To ensure the best possible heater and defroster

performance, make sure the engine cooling

system is functioning properly and the proper

amount, type, and concentration of coolant is

used. Use of the Air Recirculation mode during

Winter months is not recommended, because it

may cause window fogging.

Vacation/Storage

For information on maintaining the Climate Control

system when the vehicle is being stored for an

extended period of time, see

page 357.

Window Fogging

Vehicle windows tend to fog on the inside in mild,

rainy, and/or humid weather. To clear the

windows, select Defrost or Mix mode and increase

the front blower speed. Do not use the

Recirculation mode without A/C for long periods,

as fogging may occur.

Outside Air Intake

Make sure the air intake, located directly in front of

the windshield, is free of obstructions, such as

leaves. Leaves collected in the air intake may

reduce airflow, and if they enter the air distribution

box, they could plug the water drains. In Winter

months, make sure the air intake is clear of ice,

slush, and snow.

Cabin Air Filter

The Climate Control system filters out dust and

pollen from the air. Contact an authorized dealer to

service your cabin air filter, and to have it replaced

when needed.

Stop/Start System — If Equipped

While in an Autostop, the Climate Control system

may automatically adjust airflow to maintain cabin

comfort. Customer settings will be maintained

upon return to an engine running condition.

Operating Tips Chart

WEATHER

CONTROL SETTINGS

Hot Weather

And Vehicle

Interior Is

Very Hot

Set the mode control to

(Panel Mode), (A/C) on, and

blower on high. Roll down the

windows for a minute to flush out

the hot air. Adjust the controls as

needed to achieve comfort.

Warm

Weather

Turn (A/C) on and set the

mode control to (Panel

Mode).

Cool Sunny

Operate in (Bi-Level Mode).

Cool &

Humid

Conditions

Set the mode control to (Floor

Mode) and turn (A/C) on to

keep windows clear.

Cold

Weather

Set the mode control to (Floor

Mode). If windshield fogging

starts to occur, move the control

to (Mix Mode).

GETTING TO KNOW YOUR VEHICLE

INTERIOR STORAGE AND EQUIPMENT

TORAGE

Glove Compartment

The glove compartment is located on the

passenger side of the instrument panel.
To open the glove compartment, pull the release

handle.

Release Handle

Front Door Storage

Both interior front door panels have multiple

pockets for storage.

Overhead Sunglass Storage

At the front of the overhead console, a

compartment is provided for the storage of one

pair of sunglasses.
From the closed position, push the indentation to

open the compartment.

Overhead Sunglass Door Latch

The door will slowly rotate to the full open position.

Instrument Panel Drawer

There is a storage drawer located in the lower

center of the instrument panel. It can be released

by pushing the access button above it. The drawer

is actuator assisted once the access button is

pushed. Pull drawer outward to the fully open

position.

Drawer Access Button

WARNING!

If containers of hot liquid are placed in the bottle

holder, they can spill when the door is closed,

burning the occupants. Be careful when closing

the doors to avoid injury.

CAUTION!

The storage drawer must be closed while driving.

If left open during a collision, additional damage

may occur to property or the drawer mechanism.

GETTING TO KNOW YOUR VEHICLE

Front Seatback Storage — If Equipped

The front seatbacks have a storage pocket on

some models.

Front Seatback Storage

Second Row Floor Storage Bins

There are removable storage bins (if equipped)

located in the areas below the load floor, located in

front of the second row seats.

In Floor Storage Bin

1. To access the storage bins with front seats in

the rearward position, place the lock rod in

the unlocked position so the load floor can

fold upwards towards the seatback.

Lock Rod

NOTE:



Push the lock rod inward for the locked

position.



Pull outward on the lock rod for the

unlocked position.

2. Pull the latch located near the second row seat

to open the floor panel.

Floor Latch

GETTING TO KNOW YOUR VEHICLE

STORAGE BIN SAFETY WARNING

Carefully follow these warnings to help prevent

personal injury or damage to your vehicle:

SEAT STORAGE BIN COVER EMERGENCY

RELEASE LEVER

As a security measure, the Seat Storage Bin Cover

has an Emergency Release Lever built into the

latching mechanism.

Storage Bin Cover Emergency Release Lever

NOTE:

In the event of an individual being locked inside

the storage bin, the storage bin cover can be

opened from inside of the bin by pushing on the

glow-in-the-dark lever attached to the storage bin

cover latching mechanism.

WARNING!

In a collision, serious injury could result if the

seat storage bin covers are not properly latched.



Do not drive the vehicle with the storage bin

covers open.



Keep the storage bin covers closed and

latched while the vehicle is in motion.



Do not operate the storage bin covers while

the vehicle is in motion.



Do not use a storage bin latch as a tie down.

CAUTION!

The storage bin cover must lay flat and be

latched to avoid damage from contact with the

front seat tracks, which have minimal clearance

to the cover. If the storage bin cover is left in the

open position, front seat adjustment may

damage the cover.

WARNING!



Always close the storage bin covers when your

vehicle is unattended.



Do not allow children to have access to the

second row seat storage bins. Once in the

storage bin, young children may not be able to

escape. If trapped in the storage bin, children

can die from suffocation or heat stroke.



In a collision, serious injury could result if the

seat storage bin covers are not properly latched.



Do not drive the vehicle with the storage bin

covers open. Keep the storage bin covers

closed and latched while the vehicle is in

motion.



Do not operate the storage bin covers while

the vehicle is in motion.



Do not use a storage bin latch as a tie down.

CAUTION!

The storage bin cover must lay flat and be

latched to avoid damage from contact with the

front seat tracks, which have minimal clearance

to the cover. If the storage bin cover is left in the

open position, front seat adjustment may

damage the cover.

GETTING TO KNOW YOUR VEHICLE

CREENS

— I

QUIPPED

Sun screens are available for second and third row

seating windows. The screens store in the sill trim

panels, and the tops of the windows are equipped

with hooks that the sun screens attach to when

pulled out.
Gently pull up on the tab to raise the sun screen.

Continue pulling the sun screen until the tab is

near the top of the window.
Once the screen is completely to the top of the

window, extend the top bar of the sun screen over

the two hooks attached to the top of the window.

Sun Screen Extended

To lower the sun screen, gently lift the tab upward

to disengage the hooks, and feed the screen back

into the base sill.

USB/AUX C

ONTROL

There are numerous USB ports located throughout

the vehicle that allow an external USB device to be

plugged into the USB port.
NOTE:



If a smartphone is plugged into a video USB

port, the device will only have charging capa

bility and allow for files/media to be stored, if

equipped with Uconnect Theater.



Once a device is connected to the USB port, it

will begin charging and is ready for use with the

system. Type C and Type A charge-only USB

ports can be used at the same time but cannot

be used simultaneously while playing media.

When both Type C and Type A charge-only USB

ports are in use they will be charged at a

reduced rate.

For example, if a device is plugged into the Type A

USB port and another device is plugged into the

Type C USB port, a message will appear and allow

you to select which device to use.

Front Center Stack AUX Jack And USB Ports

1 — Type C And Type A USB Ports 1
2 — Type C And Type A USB Ports 2
3 — AUX Port

GETTING TO KNOW YOUR VEHICLE

There are multiple USB “Charge Only” ports in this

vehicle.



In the center console



On the instrument panel



On the back of the front row seats in the Ucon

nect Theater Media Hubs (if equipped)



On the back of the front row seats



Above the rear cup holder in the third row of

seats

Charge Only USB In The Center Console

NOTE:

The USB outlet in the bottom of the instrument

panel can be switched from ignition only to

constant battery powered all the time. See an

authorized dealer for details.

Rear Seat USB Charging Port Without Uconnect Theater

Rear Seat USB Media Hub With Uconnect Theater

3rd Row USB Charging Port

NOTE:

The USB “Charge Only” ports will recharge battery

operated USB devices when connected.
Different scenarios are listed below when a

non-phone device is plugged into the smaller and

larger USB ports, and when a phone device is

plugged into the smaller and larger USB ports:



“A new device is now connected. Previous

connection was lost”.



“(Phone Name) now connected. Previous

connection was lost”.



“Another device is in use through the same USB

port. Please disconnect the first device to use

the second device”.

1 — Headphone Jack (Headphone Output Only)
2 — HDMI Port
3 — USB Port (Charge Only)

GETTING TO KNOW YOUR VEHICLE

Plugging in a phone or another USB device may

cause the connection to a previous device to be

lost.
NOTE:

Charge unsupported devices with the Charge Only

USB ports. If an unsupported device is plugged into

a Media USB port, a message will display on the

touchscreen that the device is not supported by

the system.

OWER

UTLETS

Your vehicle is equipped with 12 Volt (15 Amp)

power outlets, and 5 Volt (2.5 Amp) USB ports, that

can be used to power cellular phones, small

electronics and other low powered electrical

accessories. The power outlets can be labeled with

either a “key” or a “battery” symbol to indicate how

the outlet is powered. Power outlets labeled with a

key symbol are powered when the ignition is in the

ACC or ON/RUN position, while the outlets labeled

with a battery symbol are connected directly to the

battery and powered at all times.
NOTE:

All accessories connected to the battery powered

outlets should be removed or turned off when the

vehicle is not in use to protect the battery against

discharge.

Depending on the type of center console your

vehicle is equipped with, there is a front power

outlet located either on the center stack, bottom of

the instrument panel, or inside the center console.

12 Volt Front Power Outlet (On Center Stack) - If Equipped

12 Volt Front Power Outlet (In Floor Tray) - If Equipped

12 Volt Front Power Outlet (In Center Console)

CAUTION!

Power outlets are designed for accessory plugs

only. Do not insert any other object in the power

outlets as this will damage the outlet and blow

the fuse. Improper use of the power outlet can

cause damage not covered by your New Vehicle

Limited Warranty.

Chrysler Pacifica (2022 year). Manual in english - page 5
