GETTING TO KNOW YOUR VEHICLE

To Unfold Third Row Seats

1. Pull up on the assist strap to lift the seat out

of the storage bin and push the seat forward

until the anchors latch.

Assist Straps

2. Pulling strap “2” releases the seatback to

return to its full upright position.

Strap “2”

3. Raise the head restraint to its upright position.

Stow 'n Go Seating

On vehicles equipped with Stow 'n Go seating, the

second and third row seats can be folded into the

floor for convenient storage.

AUTO ADVANCE ‘N RETURN — IF EQUIPPED

On vehicles equipped with the Auto Advance ‘n

Return feature, the front seat will move forward

automatically to a location that will allow the

second row Stow ‘n Go seat movement, without

interference by the front seat. After the second row

seat is stowed, the front seat will move back to the

previous location once the Auto Advance ‘n Return

button is pushed again.

The Auto Advance ‘n Return feature is available to

both the front driver and passenger power seats (if

equipped).

A one-touch Auto Advance ‘n Return button is

located on the B-pillar trim panel, just in front of

the power sliding door.

Auto Advance ‘n Return Button (Left Side Shown)

WARNING!



In a collision, you or others in your vehicle

could be injured if seats are not properly

latched to their floor attachments. Always be

sure the seats are fully latched.



Sitting in a seat with the head restraint in its

lowered position could result in serious injury

or death in a collision. Always make sure the

head restraints are in their upright positions

when the seat is to be occupied.

WARNING!

During power seat operation, personal injury or

cargo damage may occur. Ensure the front seat

is not occupied and the seat travel path is clear

when operating the power seat.

GETTING TO KNOW YOUR VEHICLE

Using the Auto Advance ‘n Return Feature
NOTE:



The button is only functional when the power

sliding door is open and the vehicle is in PARK.

If the door is not open or the vehicle is not in

PARK when the button is pushed, the front seat

will not move and a message will be displayed in

the instrument cluster display.



If the power sliding door is closing when the

button is pushed, the front seat will not move

and a message will be displayed in the instru

ment cluster display.



The Auto Advance ‘n Return feature will not

function if the front doors are open.

1. Push and release the Auto Advance ‘n Return

button.

2. Perform the second row Stow ‘n Go seat

movement

page 43.

3. Push and release the Auto Advance ‘n Return

button a second time. The front seat cushion

and seatback will return to the original starting

location.

NOTE:



To abort seat operation while seat is in motion,

push the Auto Advance ‘n Return button, or

push the front power seat button to stop the

seat movement. Pushing the Auto Advance ‘n

Return button again will return the front seat to

the original starting location.



The Auto Advance ‘n Return system includes

obstacle detection. When the system detects an

obstacle, the seat will stop, reverse direction,

and return to the previous location. A message

will be displayed in the instrument cluster indi

cating that an obstacle has been detected.



If the front seat is already in a location that will

allow space for Stow ‘n Go of the second row

seat, the front seat will not move and a message

will be displayed in the instrument cluster.



If calibration of the front seat is lost, the seat will

automatically recalibrate when the Auto

Advance ‘n Return button is pushed. This may

result in the seat cushion moving forward and

downward, before moving to the location that

will allow space for the second row Stow ‘n Go

seat movement.

SECOND ROW STOW 'N GO

For Manual Seats: To stow the seat in the floor, move

the front seat all the way forward using the manual

seat adjustment bar. Move the seatback all the way

forward using the recliner handle located on the

outboard side of the cushion. Move the seat height to

at least mid position using the height adjuster handle

in the outboard side of the cushion.

For Power Seats: Push the Auto Advance ‘n Return

button located on the B-pillar trim (if equipped)

page 42.

1. To access the storage area, remove the floor

mat (if equipped) and place the lock rod in the

locked position.

Lock Rod

NOTE:



Push the lock rod inward for the unlocked

position.



Pull outward on the lock rod for the locked

position.



For information on storage bin function with

the seats rearward

page 85.

GETTING TO KNOW YOUR VEHICLE

2. Pull the latch located near the second row seat

to open the floor panel.

Floor Latch

3. Pull the floor panel and position it toward the

front seats while folding the top half down and

rest it against the front seats.

Push Panel Forward

4. Remove the plastic storage bin (if equipped)

from the storage area, and store in a safe

location.

5. Fold the armrest upward and stow the seat by

grabbing the strap on the lower part of the

seatback, and guide the seat into the storage

area.

Pull Strap

6. Push down on the seatback to lock the seat

into the storage area.

Push To Lock

7. Close the floor by pulling the floor panel

backwards by the bottom corner edge of the

panel.

Extend Floor Panel

GETTING TO KNOW YOUR VEHICLE

8. Push down on floor panel to lock into place.

Push To Lock

9. Readjust the front seat as needed, and

replace the floor mat (if equipped).

TO UNSTOW SECOND ROW SEATS

For Manual Seats: To unstow the seat from the

floor, move the front seat all the way forward using

the manual seat adjustment bar.
For Power Seats: Push the Auto Advance ‘n Return

button located on the B-pillar trim (if equipped)

page 42.

1. To access the storage area, remove the floor

mat (if equipped) and place the lock rod in the

unlocked position.

Lock Rod

NOTE:



Push the lock rod inward for the unlocked

position.



Pull outward on the lock rod for the locked

position.

WARNING!

In a collision, serious injury could result if the

seat storage bin covers are not properly latched:



Do not drive the vehicle with the storage bin

covers open.



Keep the storage bin covers closed and

latched while the vehicle is in motion.



Do not use a storage bin latch as a tie down.

CAUTION!



The storage bin cover must be latched and flat

to avoid damage from contact with the front

seat tracks, which have minimal clearance to

the cover.



Do not sit on the second row seat when it is in

the stowed position with the seatback upright

otherwise damage to the seat may occur.

GETTING TO KNOW YOUR VEHICLE

2. Pull the latch located near the second row seat

to open the floor panel.

Floor Latch

3. Pull the floor panel and position it toward the

front seats while folding the top half down and

rest it against the front seats.

Push Panel Forward

4. Pull the strap located on the seat and pull the

seat out of the storage area. Push the seat

rearward making sure that it locks into the

floor. Fold the seatback into the upright

position and pull the headrest up.

NOTE:

The seatback may be locked, if it is, it will be

necessary to use the recliner handle to unlock the

back before folding into the upright position.

Pull Strap

5. Replace the plastic storage bin into the

storage area.

6. To position the floor panel back into its original

state, grab the bottom corner and extend it

outward.

Extend Panel

7. Lay the floor panel flat and push down until it

clicks into position.

Push Down To Lock

8. Readjust the front seat as needed, and

replace the floor mat (if equipped).

GETTING TO KNOW YOUR VEHICLE

(Continued)

OWER

DJUSTMENT

RONT

EATS

) —

QUIPPED

Some models may be equipped with eight-way

power seats for the driver and front passenger. The

power seat switches are located on the outboard

side of the seat. The switches control the

movement of the seat cushion and the seatback.

Driver Power Seat Switches

Adjusting The Seat Forward Or Rearward

The seat can be adjusted both forward and

rearward by using the seat switch. The seat will

move in the direction of the switch. Release the

switch when the desired position has been

reached.

Adjusting The Seat Up Or Down

The height of the seats can be adjusted up or

down. Pull upward or push downward on the rear of

seat switch, the seat will move in the direction of

the switch. Release the switch when the desired

position has been reached.

WARNING!



In a collision, you or others in your vehicle

could be injured if seats are not properly

latched to their floor attachments. Always be

sure the seats are fully latched.



Sitting in a seat with the head restraint in its

lowered position could result in serious injury

or death in a collision. Always make sure the

head restraints are in their upright positions

when the seat is to be occupied.

1 — Seat Switch
2 — Seatback Switch
3 — Lumbar Switch

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious

injury or death.

CAUTION!

Do not place any article under a power seat or

impede its ability to move as it may cause

damage to the seat controls. Seat travel may

become limited if movement is stopped by an

obstruction in the seat's path.

WARNING!

GETTING TO KNOW YOUR VEHICLE

Tilting The Seat Up Or Down

The angle of the seat cushion can be adjusted in

two directions. Pull upward or push downward on

the front of the seat switch, the front of the seat

cushion will move in the direction of the switch.

Release the switch when the desired position has

been reached.

Reclining The Seatback

The angle of the seatback can be adjusted forward

or rearward. Push the seatback switch forward or

rearward, the seat will move in the direction of the

switch. Release the switch when the desired

position is reached.

Power Lumbar — If Equipped

Power Lumbar Switch Location

The front driver’s and passenger’s seat may be

equipped with a four way lumbar adjustment. The

power lumbar switch is located on the outboard

side of the equipped power seat. Push the switch

forward or rearward to increase or decrease the

lumbar support. Push the switch upward or

downward to raise or lower the lumbar support.

Easy Entry/Exit Seat — If Equipped

This feature provides automatic driver seat

positioning to enhance driver mobility when

entering and exiting the vehicle.
The distance the driver seat moves depends on

where you have the driver seat positioned when

you place the vehicle’s ignition in the OFF position.



When the ignition is placed in the OFF position,

the driver seat will move about 2.4 inches

(60 mm) rearward if the driver seat position is

greater than or equal to 2.7 inches (67.7 mm)

forward of the rear stop. The seat will return to

its previously set position when the ignition is

cycled out of the OFF position.



When the ignition is placed in the OFF position,

the driver seat will move to a position 0.3 inches

(7.7 mm) forward of the rear stop if the driver

seat position is between 0.9 – 2.7 inches

(22.7 – 67.7 mm) forward of the rear stop.

The seat will return to its previously set position

when the ignition is cycled out of the OFF posi

tion.



The Easy Entry/Easy Exit feature is disabled

when the driver seat position is less than

0.9 inches (22.7 mm) forward of the rear stop.

At this position, there is no benefit to the driver

by moving the seat for Easy Exit or Easy Entry.

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious

injury or death.

CAUTION!

Do not place any article under a power seat or

impede its ability to move as it may cause

damage to the seat controls. Seat travel may

become limited if movement is stopped by an

obstruction in the seat's path.

GETTING TO KNOW YOUR VEHICLE

(Continued)

When enabled within Uconnect Settings, Easy

Entry and Easy Exit positions are stored in each

memory setting profile (if equipped)

page 32.

NOTE:

The Easy Entry/Exit feature is enabled or disabled

within the Uconnect system

page 188.

OWER

DJUSTMENT

EAR

EATS

) —

QUIPPED

Third Row Power Recline — If Equipped

The power recline feature, located on the trim

panel next to the seat, adjusts the seatback angle

forward/rearward for occupant comfort.

Reclining The Seatback
The angle of the seatback can be adjusted forward

or rearward. Push and hold the forward or rearward

button, the seat will move in the direction of the

button push. Release the button when the desired

position is reached.

Third Row Power Seat Switch

NOTE:

The third row power recline buttons can be locked

out using the Third Row Lockout setting within the

Uconnect system

page 188.

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious

injury or death.



Do not place the seat belt webbing behind the

third row stow clip when using the seat belt to

restrain an occupant. The seat belt will not be

positioned properly on the occupant and they

could be more seriously injured in an accident

as a result.

CAUTION!

Do not place any article under a power seat or

impede its ability to move as it may cause

damage to the seat controls. Seat travel may

become limited if movement is stopped by an

obstruction in the seat's path.

WARNING!

GETTING TO KNOW YOUR VEHICLE

Third Row Power Stow ‘n Go Seat —

If Equipped

A one-touch power folding seat switch is located in

the right rear trim panel as part of a switch bank.
NOTE:

The third row outboard seat belts may interfere

with the power folding of the seat. Place the seat

belt webbing behind the stow clip before stowing or

opening the seat. When the seat is in the desired

position, remove the webbing from the stow clip so

that it is ready for use. Never leave the seat belt in

the stow clip when it is used to restrain an

occupant.
NOTE:



The outer head restraints will lower automati

cally as necessary when the power seat begins

to move.



The center head restraint raises and lowers

manually but will not lower automatically.



The head restraint can also be lowered manu

ally using the pull strap located at the back of

the seat

page 55.

The switch is only functional when the liftgate is

open and the vehicle is in PARK.
The rear switch bank allows multiple power folding

and unfolding positions for the third row seats.

Left and right third row seats can be folded

individually or together. The third row power folding

seat adjusts to the following positions using the

switch bank located on the left rear trim panel:

Rear Panel Power Switch Bank

To move the selected seat(s) to the normal

(seated) position, push and release the “Normal”

button. The seat will automatically stop when the

Normal position is reached.
To move the selected seat(s) to the stow position,

push and release the “Stow” button. The seat will

automatically stop when the Stow position is

reached.

To move the selected seat(s) back in the forward or

reverse direction, push and hold the “Fold

Forward/Back” button. Release the button when

the desired position is reached.
1. Disconnect the center shoulder belt from the

mini-buckle before attempting to fold/stow

the power third row seats.

2. Before pushing the “Normal” or “Stow” button,

place the outboard seat belt webbing behind

the stow clips, located on the rear trim panel.

When the seat reaches the desired position,

remove the webbing from the clip so it is ready

for use to restrain an occupant.

Seat Belt Stowage Clip

3. To abort seat operation while seat is in motion,

push a different seat position selector switch

to stop the seat. Once the seat stops moving,

then the desired position can be selected.

1 — Open To Normal
2 — Stow
3 — Fold Forward/Rearward
4 — Right/Left Seats/Both Seats

GETTING TO KNOW YOUR VEHICLE

4. The third row power seat system includes

obstacle detection. When the system detects

an obstacle, the motors will stop and reverse

direction. Should this occur, remove the

obstacle before pushing the button again.

EATED

EATS

Front Heated Seats — If Equipped

The front heated seats control buttons

are located in the touchscreen.

You can choose from HI, LO or off heat settings.

The indicator lights in each switch indicate the

level of heat in use. Two indicator lights will

illuminate for HI, one for LO and none for off.



Press the heated seat button once to turn the

HI setting on.



Press the heated seat button a second time to

turn the LO setting on.



Press the heated seat button a third time to turn

the heating elements off.

The level of heat selected will stay on until the

operator changes it.
NOTE:



Once a heat setting is selected, heat will be felt

within two to five minutes.



The engine must be running for the heated

seats to operate.

For information on use with the Remote Start

system, see

page 21.

Rear Heated Seats — If Equipped

On some models, the second row seats are

equipped with heaters. There are two heated seat

switches that allow the second row passengers to

operate the seats independently. The heated seat

switches are located on the sliding side door

handle trim panels.

Second Row Heated Seat Switch (Left Side Shown)

You can choose from HI, LO or off heat settings.

Amber indicator lights in each switch indicate the

level of heat in use. Two indicator lights will

illuminate for HI, one for LO and none for off.
Push the switch once to select HI-level heating.

Push the switch a second time to select LO-level

heating. Push the switch a third time to shut the

heating elements off.
NOTE:

Once a heat setting is selected, heat will be felt

within two to five minutes.
When the HI-level setting is selected, the heater

will provide a boosted heat level during the initial

stages of operation. Then, the heat output will drop

to the normal HI-level. The level of heat selected

will stay on until the operator changes it.

WARNING!



Persons who are unable to feel pain to the

skin because of advanced age, chronic illness,

diabetes, spinal cord injury, medication,

alcohol use, exhaustion or other physical

condition must exercise care when using the

seat heater. It may cause burns even at low

temperatures, especially if used for long

periods of time.



Do not place anything on the seat or seatback

that insulates against heat, such as a blanket

or cushion. This may cause the seat heater to

overheat. Sitting in a seat that has been over

heated could cause serious burns due to the

increased surface temperature of the seat.

GETTING TO KNOW YOUR VEHICLE

ENTILATED

EATS

— I

QUIPPED

Located in the first row seat cushions are

small fans that draw the air from the

passenger compartment and move air

through fine perforations in the seat

cover to help keep the driver and front passenger

cooler in higher ambient temperatures.

The fans operate at two speeds, HI and LO.
The front ventilated seats control buttons are

located in the touchscreen.



Press the ventilated seat button once to

choose HI.



Press the ventilated seat button a second time

to choose LO.



Press the ventilated seat button a third time to

turn the ventilated seat off.

NOTE:

The engine must be running for the ventilated

seats to operate.
For information on use with the Remote Start

system, see

page 21.

DJUSTABLE

RMREST

RONT

EATS

) — I

QUIPPED

Your vehicle may be equipped with adjustable

armrests on the front seats. The armrest can be

adjusted up or down.
To adjust the armrest height, push and hold the

button while moving the armrest to the desired

position. Release the button to lock the armrest

into place.

Adjustable Armrest Adjustment Button

LASTIC

ROCERY

ETAINER

OOKS

Retainer hooks which will hold plastic grocery bag

handles are built into the seatbacks of the second

row rear seats, and if equipped, the backs of the

front row seats. The floor supports the partial

weight of the bagged goods.

EAD

ESTRAINTS

Head restraints are designed to reduce the risk of

injury by restricting head movement in the event of

a rear impact. Head restraints should be adjusted

so that the top of the head restraint is located

above the top of your ear.

WARNING!



All occupants, including the driver, should not

operate a vehicle or sit in a vehicle’s seat until

the head restraints are placed in their proper

positions in order to minimize the risk of neck

injury in the event of a crash.



Head restraints should never be adjusted

while the vehicle is in motion. Driving a vehicle

with the head restraints improperly adjusted

or removed could cause serious injury or

death in the event of a collision.

GETTING TO KNOW YOUR VEHICLE

Head Restraints — Front Seats

The front driver and passenger seats are equipped

with four-way head restraints.
To raise the head restraint, pull upward on the

head restraint. To lower the head restraint, push

the adjustment button, located at the base of the

head restraint, and push downward. The front

head restraints are also adjustable forward and

rearward. To tilt forward, pull the top of the head

restraint toward the front of the vehicle to the

desired position. To adjust the head restraint

rearward, continue pulling forward on the top of

the head restraint to the furthest forward position

and the head restraint will return to the upright

position.
NOTE:

To remove the head restraint, raise it as far as it

can go. Then, push the release button and the

adjustment button at the base of each post while

pulling the head restraint up. Seatback angle may

need to be adjusted to fully remove the head

restraint. To reinstall the head restraint, put the

head restraint posts into the holes and push

downward. Then, adjust the head restraint to the

appropriate height.

Front Head Restraint

Normal Position

Forward Adjustment

1 — Release Button
2 — Adjustment Button

WARNING!



A loose head restraint thrown forward in a

collision or hard stop could cause serious

injury or death to occupants of the vehicle.

Always securely stow removed head restraints

in a location outside the occupant compart

ment.



ALL the head restraints MUST be reinstalled in

the vehicle to properly protect the occupants.

Follow the re-installation instructions above

prior to operating the vehicle or occupying a

seat.

GETTING TO KNOW YOUR VEHICLE

Head Restraints — Second Row Quad

Seats

The second row outboard head restraints, as well

as the removable 8th passenger seat (if equipped),

may have adjustable head restraints.
NOTE:

If equipped with Stow ‘n Go seating, the head

restraints are non-adjustable and non-removable.

Do not pull on non-adjustable head restraints

when folding the seat.
To raise the head restraint, pull upward on the

head restraint. To lower the head restraint, push

the adjustment button, located at the base of the

head restraint, and push downward.
To remove the head restraint, raise it as far as it

can go. Then, push the release button and the

adjustment button at the base of each post while

pulling the head restraint up. Seatback angle may

need to be adjusted to fully remove the head

restraint. To reinstall the head restraint, put the

head restraint posts into the holes and push

downward. Then, adjust the head restraint to the

appropriate height.

Head Restraints — Second Row Bench

The second row bench seat is equipped with

adjustable head restraints.
To raise the head restraint, pull upward on the

head restraint. To lower the head restraint, push

the adjustment button, located at the base of the

head restraint, and push downward.

Bench Seat Head Restraint

To remove the head restraint, raise it as far as it

can go. Then, push the release button and the

adjustment button at the base of each post while

pulling the head restraint up. Seatback angle may

need to be adjusted to fully remove the head

restraint. To reinstall the head restraint, put the

head restraint posts into the holes and push

downward. Then, adjust the head restraint to the

appropriate height.

NOTE:

For information on child restraint tethering, see

page 239.

1 — Release Button
2 — Adjustment Button

WARNING!



A loose head restraint thrown forward in a

collision or hard stop could cause serious

injury or death to occupants of the vehicle.

Always securely stow removed head restraints

in a location outside the occupant compart

ment.



ALL the head restraints MUST be reinstalled in

the vehicle to properly protect the occupants.

Follow the re-installation instructions above

prior to operating the vehicle or occupying a

seat.

GETTING TO KNOW YOUR VEHICLE

Head Restraints — Third Row

The outboard head restraints can be manually

folded forward for improved rearward visibility. Pull

the release strap to fold them forward.

Release Straps

NOTE:



The head restraints must be raised manually

when occupying the third row.



Do not fold if there are passengers seated in the

third row seats.

The head restraint in the center position can be

raised and lowered for tether routing or height

adjustment

page 239.

NOTE:

To remove the center head restraint, raise it as far

as it can go. Then, push the release button and the

adjustment button at the base of each post while

pulling the head restraint up. To reinstall the head

restraint, put the head restraint posts into the

holes and push downward. Then, using the

adjustment button, adjust the head restraint to the

appropriate height.

Adjustment Button

POWER FOLDING THIRD ROW HEAD

RESTRAINTS — IF EQUIPPED

For improved visibility, the third row outboard head

restraints can be folded using the Uconnect

system.
Press Vehicle, then Controls located on the bottom

of the Uconnect display.

Press the Head Restraint Fold button to

power fold the third row head restraints.

NOTE:



The head restraints can be folded downward

using the Head Restraint button or using the

manual release strap. The head restraints must

be raised manually when occupying the third

row.



Do not fold if there are passengers seated in the

third row seats.

WARNING!

ALL the head restraints MUST be reinstalled in

the vehicle to properly protect the occupants.

Follow the re-installation instructions above prior

to operating the vehicle or occupying a seat.

GETTING TO KNOW YOUR VEHICLE

UCONNECT VOICE RECOGNITION —

IF EQUIPPED

NTRODUCING

OICE

ECOGNITION

Start using Uconnect Voice Recognition (VR) with

these helpful quick tips. It provides the key Voice

Commands and tips you need to know to control

your system.

ASIC

OICE

OMMANDS

The following basic Voice Commands can be given

at any point while using your Uconnect system.
Push the VR button on the steering wheel.

After the beep, say:



“Cancel” to stop a current voice session.



“Help” to hear a list of suggested Voice

Commands.



“Repeat” to listen to the system prompts again.

Notice the visual cues that inform you of your

Voice Recognition system’s status.

TARTED

The VR button is used to activate/deactivate

your Voice Recognition system.
Helpful hints for using Voice Recognition:



Reduce background noise. Wind noise and

passenger conversations are examples of noise

that may impact recognition.



Speak clearly at a normal pace and volume

while facing straight ahead.



Each time you give a Voice Command, first push

the VR button, wait until after the beep, then say

your Voice Command. You can also say the

vehicle “Wake Up” word and state your

command.

NOTE:

The factory default Wake Up word is set to

“Hey Uconnect” and can be reprogrammed

through the Uconnect Settings. After the beep, say:



A passenger can press the VR button shortcut

on the radio status bar to also issue a

command.



You can interrupt the help message or system

prompts by pushing the VR button and saying a

Voice Command or saying the vehicle’s “Wake

Up” word and saying a command from the

current category.

Uconnect Voice Command Buttons

1 — Push To Answer An Incoming Phone Call
2 — For Vehicles Equipped With Navigation:

Push The Voice Recognition Button To Begin

Radio, Media, Navigation, Climate, Start Or

Answer A Phone Call, And Send Or Receive A Text

2 — For Vehicles Not Equipped With Navigation:

Push The Phone Button To Answer An Incoming

Phone Call

GETTING TO KNOW YOUR VEHICLE

DDITIONAL

NFORMATION

Uconnect are registered trademarks and Mopar

Owner Connect is a trademark of FCA US LLC.

SiriusXM® and all related marks and logos are

trademarks of SiriusXM® Radio Inc.

page 370.

For Uconnect system support, call

1-877-855-8400 (24 hours a day 7 days a week)

or visit

DriveUconnect.com (US) or

DriveUconnect.ca (Canada).

MIRRORS

NSIDE

EARVIEW

IRROR

Manual Mirror — If Equipped

A single ball joint mirror is used to allow the driver

to adjust up, down and left, right. The mirror should

be adjusted to center on the view through the rear

window.

Headlight glare can be reduced by moving the

small control under the mirror to the night position

(toward the rear of the vehicle). The mirror should

be adjusted while set in the day position (toward

the windshield).

Manual Rearview Mirror

Automatic Dimming Mirror — If Equipped

This mirror automatically adjusts for headlight

glare from vehicles behind you. You can turn the

feature on or off by pushing the button at the base

of the mirror. A light to the left of the button will

illuminate to indicate when the dimming feature is

activated. The sensor to the right of the button

does not illuminate.

NOTE:

This feature is disabled when the vehicle is in

REVERSE. If your vehicle is not equipped with an

on/off button on the mirror, the mirror will default

to on and can be turned on/off through the touch

screen.

Automatic Dimming Mirror On/Off Button

CAUTION!

To avoid damage to the mirror during cleaning,

never spray any cleaning solution directly onto

the mirror. Apply the solution onto a clean cloth

and wipe the mirror clean.

Chrysler Pacifica (2022 year). Manual in english - page 3
