296

TECHNICAL SPECIFICATIONS

Wheel Mounting Surface

Tighten the lug nuts/bolts in a star pattern until

each nut/bolt has been tightened twice. Ensure

that the socket is fully engaged on the lug nut/bolt

(do not insert it halfway).

Torque Patterns

After 25 miles (40 km) check the lug nut/bolt

torque to be sure that all the lug nuts/bolts are

properly tightened.

FUEL REQUIREMENTS

While operating on gasoline with the required

octane number, hearing a light knocking sound

from the engine is not a cause for concern.

However, if the engine is heard making a heavy

knocking sound, see a dealer immediately. Use of

gasoline with a lower than recommended octane

number can cause engine failure and may void or

not be covered by the New Vehicle Limited

Warranty.
Poor quality gasoline can cause problems such as

hard starting, stalling, and hesitations. If you

experience these symptoms, try another brand of

gasoline before considering service for the vehicle.

3.6L E

NGINE

Do not use E-85 flex fuel or ethanol blends greater

than 15% in this engine.

This engine is designed to meet all

emissions regulations and provide

optimum fuel economy and performance

when using high quality unleaded regular

gasoline having a posted octane number of 87 as

specified by the (R+M)/2 method. The use of

higher octane premium gasoline is not required, as

it will not provide any benefit over regular gasoline

in these engines.

EFORMULATED

ASOLINE

Many areas of the country require the use of

cleaner burning gasoline referred to as

“reformulated gasoline”. Reformulated gasoline

contains oxygenates and are specifically blended

to reduce vehicle emissions and improve air

quality.
The use of reformulated gasoline is recommended.

Properly blended reformulated gasoline will

provide improved performance and durability of

engine and fuel system components.

WARNING!

To avoid the risk of forcing the vehicle off the

jack, do not tighten the lug nuts/bolts fully until

the vehicle has been lowered. Failure to follow

this warning may result in personal injury.

TECHNICAL SPECIFICATIONS

297

ASOLINE

XYGENATE

LENDS

Some fuel suppliers blend unleaded gasoline with

oxygenates such as ethanol.

Problems that result from using gasoline

containing more than 15% ethanol (E-15) or

gasoline containing methanol are not the

responsibility of the manufacturer and may void or

not be covered under New Vehicle Limited

Warranty.

E-85 I

-F

LEX

UEL

EHICLES

Non-Flex Fuel Vehicles (FFV) are compatible with

gasoline containing up to 15% ethanol (E-15). Use

of gasoline with higher ethanol content may void

the New Vehicle Limited Warranty.
If a Non-FFV vehicle is inadvertently fueled with

E-85 fuel, the engine will have some or all of these

symptoms:



Operate in a lean mode



OBD II Malfunction Indicator Light on



Poor engine performance



Poor cold start and cold drivability



Increased risk for fuel system component

corrosion

CNG A

LP F

UEL

YSTEM

ODIFICATIONS

Modifications that allow the engine to run on

Compressed Natural Gas (CNG) or Liquid Propane

(LP) may result in damage to the engine,

emissions, and fuel system components. Problems

that result from running CNG or LP are not the

responsibility of the manufacturer and may void or

not be covered under the New Vehicle Limited

Warranty.

ETHYLCYCLOPENTADIENYL

ANGANESE

RICARBONYL

(MMT) I

ASOLINE

MMT is a manganese-containing metallic additive

that is blended into some gasoline to increase

octane. Gasoline blended with MMT provides no

performance advantage beyond gasoline of the

same octane number without MMT. Gasoline

blended with MMT reduces spark plug life and

reduces emissions system performance in some

vehicles. The manufacturer recommends that

gasoline without MMT be used in your vehicle. The

MMT content of gasoline may not be indicated on

the gasoline pump; therefore, you should ask your

gasoline retailer whether the gasoline contains

MMT. MMT is prohibited in Federal and California

reformulated gasoline.

CAUTION!

DO NOT use E-85, gasoline containing methanol,

or gasoline containing more than 15% ethanol

(E-15). Use of these blends may result in starting

and drivability problems, damage critical fuel

system components, cause emissions to exceed

the applicable standard, and/or cause the

Malfunction Indicator Light to illuminate. Please

observe pump labels as they should clearly

communicate if a fuel contains greater than

15% ethanol (E-15).

298

TECHNICAL SPECIFICATIONS

(Continued)

ATERIALS

DDED

UEL

Besides using unleaded gasoline with the proper

octane rating, gasolines that contain detergents,

corrosion and stability additives are

recommended. Using gasolines that have these

additives will help improve fuel economy, reduce

emissions, and maintain vehicle performance.

Designated TOP TIER Detergent

Gasoline contains a higher level of

detergents to further aide in minimizing

engine and fuel system deposits. When

available, the usage of TOP TIER Detergent

gasoline is recommended. Visit

www.toptiergas.com

for a list of TOP TIER

Detergent Gasoline Retailers.
Indiscriminate use of fuel system cleaning agents

should be avoided. Many of these materials

intended for gum and varnish removal may contain

active solvents or similar ingredients. These can

harm fuel system gasket and diaphragm materials.

UEL

YSTEM

AUTIONS

NOTE:

Intentional tampering with the emissions control

system can result in civil penalties being assessed

against you.

CAUTION!

Follow these guidelines to maintain your

vehicle’s performance:



The use of leaded gasoline is prohibited by

Federal law. Using leaded gasoline can impair

engine performance and damage the emis

sions control system.



An out-of-tune engine or certain fuel or ignition

malfunctions can cause the catalytic

converter to overheat. If you notice a pungent

burning odor or some light smoke, your engine

may be out of tune or malfunctioning and may

require immediate service. Contact an autho

rized dealer for service assistance.



The use of fuel additives, which are now being

sold as octane enhancers, is not recom

mended. Most of these products contain high

concentrations of methanol. Fuel system

damage or vehicle performance problems

resulting from the use of such fuels or addi

tives is not the responsibility of the manufac

turer and may void or not be covered under

the New Vehicle Limited Warranty.

CAUTION!

TECHNICAL SPECIFICATIONS

299

FLUID CAPACITIES

ENGINE FLUIDS AND LUBRICANTS

Metric

Fuel (Approximate)
3.6L Engine

19 Gallons

71 Liters

Engine Oil With Filter
3.6L Engine

5 Quarts

4.7 Liters

Cooling System*

3.6L Engine

13.1 Quarts — Standard Duty Cooling

13.4 Quarts — Heavy Duty Cooling

12.4 Liters — Standard Duty Cooling

12.7 Liters — Heavy Duty Cooling

* Includes heater and coolant reservoir filled to MAX level.

Component

Fluid, Lubricant, or Genuine Part

Engine Coolant

We recommend you use Mopar® Antifreeze/Coolant 10 Year/150,000 Mile

(240,000 km) Formula OAT (Organic Additive Technology) or equivalent

meeting the requirements of the manufacturer Material Standard MS.90032.

Engine Oil – 3.6L Engine

We recommend you use Mopar® SAE 0W-20 Full Synthetic Engine Oil which

meets the requirements of the manufacturer Material Standard MS-6395.

Equivalent full synthetic SAE 0W-20 engine oil can be used but must have the

API Starburst trademark

page 249.

300

TECHNICAL SPECIFICATIONS

CHASSIS FLUIDS AND LUBRICANTS

Engine Oil Filter

We recommend you use a Mopar® Engine Oil Filter. If a Mopar® Engine Oil

Filter is unavailable only use filters that meet or exceed SAE/USCAR-36 Filter

Performance Requirements.

Fuel Selection – 3.6L Engine

87 Octane (R+M)/2 Method, 0-15% ethanol (Do not use E-85).

Component

Fluid, Lubricant, or Genuine Part

CAUTION!



Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and

may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Tech

nology (HOAT) engine coolant (antifreeze) or any “globally compatible” coolant (antifreeze). If a non-OAT engine coolant (antifreeze) is introduced into the

cooling system in an emergency, the cooling system will need to be drained, flushed, and refilled with fresh OAT coolant (conforming to MS.90032), by an

authorized dealer as soon as possible.



Do not use water alone or alcohol-based engine coolant (antifreeze) products. Do not use additional rust inhibitors or antirust products, as they may not be

compatible with the radiator engine coolant and may plug the radiator.



This vehicle has not been designed for use with propylene glycol-based engine coolant (antifreeze). Use of propylene glycol-based engine coolant (antifreeze)

is not recommended.

Component

Fluid, Lubricant, or Genuine Part

Automatic Transmission

Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid, or

equivalent.
Failure to use the correct fluid may affect the function or performance of your

transmission.

Brake Master Cylinder

We recommend you use Mopar® DOT 3 Brake Fluid, SAE J1703 should be

used.

301

CUSTOMER ASSISTANCE

SUGGESTIONS FOR OBTAINING SERVICE

FOR YOUR VEHICLE

REPARE

PPOINTMENT

All work to be performed may not be covered by the

warranty. Discuss additional charges with the

service manager. Keep a maintenance log of your

vehicle's service history. This can often provide a

clue to the current problem.

REPARE

A L

IST

Make a written list of your vehicle's problems or the

specific work you want done. If you've had an

accident or work done that is not on your

maintenance log, let the service advisor know.

EASONABLE

ITH

EQUESTS

If you list a number of items and you must have

your vehicle by the end of the day, discuss the

situation with the service advisor and list the items

in order of priority. At many authorized dealers, you

may obtain a rental vehicle (additional charges

may apply). If you need a rental, it is advisable to

make these arrangements when you call for an

appointment.

IF YOU NEED ASSISTANCE

FCA US LLC and its authorized dealers are vitally

interested in your satisfaction. We want you to be

happy with our products and services.
Warranty service must be done by an authorized

dealer. We strongly recommend that you take the

vehicle to an authorized dealer. They know your

vehicle the best, and are most concerned that you

get prompt and high quality service. FCA US LLC’s

authorized dealers have the facilities,

factory-trained technicians, special tools, and the

latest information to ensure the vehicle is fixed

correctly and in a timely manner.
This is why you should always talk to an authorized

dealer’s service manager first. If for some reason

you are still not satisfied, talk to the general

manager or owner of the authorized dealer. They

want to know if you need assistance. If an

authorized dealer is unable to resolve the concern,

you may contact FCA US LLC's Customer

Assistance center.

Any communication to FCA US LLC’s customer

center should include the following information:



Owner's name and address



Owner's telephone number (home, mobile, and

office)



Authorized dealer name



Vehicle Identification Number (VIN)



Vehicle delivery date and mileage

FCA US LLC C

USTOMER

ENTER

P.O. Box 21–8004
Auburn Hills, MI 48321–8004
Phone: (800) 247-9753

FCA C

ANADA

. C

USTOMER

ENTER

P.O. Box 1621
Windsor, Ontario N9A 4H6
Phone: (800) 465-2001 English / (800) 387-9983

French

302

CUSTOMER ASSISTANCE

EXICO

Av. Prolongacion Paseo de la Reforma, 1240
Sante Fe C.P. 05109
Mexico, D. F.
In Mexico City: 800-505-1300
Outside Mexico City: +(52)55 50817568

UERTO

ICO

US V

IRGIN

SLANDS

FCA Caribbean LLC
P.O. Box 191857
San Juan 00919-1857
Phone: (800) 247-9753
Fax: (787) 782-3345

USTOMER

SSISTANCE

EARING

PEECH

MPAIRED

(TDD/TTY)

To assist customers who have hearing difficulties,

FCA US LLC has installed special TDD (Telecommu

nication Devices for the Deaf) equipment at its

customer center. Any hearing or speech impaired

customer, who has access to a TDD or a

conventional teletypewriter (TTY) in the United

States, can communicate with FCA US LLC by

dialing 1-800-380-2479.

Canadian residents with hearing difficulties that

require assistance can use the special needs relay

service offered by Bell Canada. For TTY

teletypewriter users, dial 711 and for Voice callers,

dial 1-800-855-0511 to connect with a Bell Relay

Service operator.

ERVICE

ONTRACT

You may have purchased a service contract for a

vehicle to help protect you from the high cost of

unexpected repairs after FCA US LLC’s New Vehicle

Limited Warranty expires. The Mopar® Vehicle

Protection plans are the ONLY vehicle extended

protection plans authorized, endorsed and backed

by FCA US LLC to provide additional protection

beyond your vehicle’s warranty. If you purchased a

Mopar® Vehicle Protection Plan, you will receive

Plan Provisions and an Owner Identification Card in

the mail within three weeks of the vehicle delivery

date. If you have any questions about the service

contract, call FCA US LLC’s Service Contract

National Customer Hotline at 1-800-521-9922

(Canadian residents, call (800) 465-2001

English / (800) 387-9983 French).

FCA US LLC is not responsible for any service

contract you may have purchased from another

manufacturer. If you require service after the FCA

US LLC New Vehicle Limited Warranty expires,

please refer to the contract documents, and

contact the person listed in those documents.
We appreciate that you have made a major

investment when you purchased the vehicle. An

authorized dealer has also made a major

investment in facilities, tools, and training to

ensure that you are absolutely delighted with the

ownership experience.

WARNING!

Engine exhaust (internal combustion engines

only), some of its constituents, and certain

vehicle components contain, or emit, chemicals

known to the State of California to cause cancer

and birth defects, or other reproductive harm. In

addition, certain fluids contained in vehicles and

certain products of component wear contain, or

emit, chemicals known to the State of California

to cause cancer and birth defects, or other

reproductive harm.

CUSTOMER ASSISTANCE

303

WARRANTY INFORMATION

See the Warranty Information for the terms and

provisions of FCA US LLC warranties applicable to

this vehicle and market. Refer to

www.mopar.com/om

for further information.

See the Warranty Information for the terms and

provisions of FCA Canada Inc. warranties

applicable to this vehicle and market. Refer to

www.owners.mopar.ca/en

for further

information.
Use this QR code to access your

digital experience.

MOPAR® PARTS

Mopar® original equipment parts & accessories

and factory filled fluids are available from an

authorized dealer. They are recommended for your

vehicle to keep it operating at its best and maintain

its original condition.

REPORTING SAFETY DEFECTS

50 U

NITED

TATES

ASHINGTON

, D.C.

If you believe that your vehicle has a

defect that could cause a crash or cause

injury or death, you should immediately

inform the National Highway Traffic

Safety Administration (NHTSA) in

addition to notifying FCA US LLC.
If NHTSA receives similar complaints, it

may open an investigation, and if it finds

that a safety defect exists in a group of

vehicles, it may order a recall and

remedy campaign. However, NHTSA

cannot become involved in individual

problems between you, an authorized

dealer or FCA US LLC.

To contact NHTSA, you may call the

Vehicle Safety Hotline toll free at

1-888-327-4236 (TTY:

1-800-424-9153); or go to http://

www.safercar.gov; or write to:

Administrator, NHTSA, 1200 New Jersey

Avenue, SE., West Building, Washington,

D.C. 20590. You can also obtain other

information about motor vehicle safety

from http://www.safercar.gov.

ANADA

If you believe that your vehicle has a

safety defect, you should contact the

Customer Service Department

immediately. Canadian customers who

wish to report a safety defect to the

Canadian government should contact

Transport Canada, Motor Vehicle Defect

Investigations and Recalls at

1-800-333-0510 or go to

wwwapps.tc.gc.ca/Saf-Sec-Sur/7/

PCDB-BDPP.

304

CUSTOMER ASSISTANCE

PUBLICATION ORDER FORMS

To order the following manuals, you may use either

the website or the phone numbers listed below.
Service Manuals
These comprehensive Service Manuals provide a

complete working knowledge of the vehicle,

system, and/or components and is written in

straightforward language with illustrations,

diagrams, and charts.
Diagnostic Procedure Manuals
Diagnostic Procedure Manuals are filled with

diagrams, charts and detailed illustrations. These

manuals make it easy to find and fix problems on

computer-controlled vehicle systems and features.

They show exactly how to find and correct

problems, using step-by-step troubleshooting and

drivability procedures, proven diagnostic tests and

a complete list of all tools and equipment.
To order a hard copy of your Service or Diagnostic

Procedure manuals, visit:

www.techauthority.com

(US and Canada).

Owner's Manuals
These Owner's Manuals have been prepared with

the assistance of service and engineering

specialists to acquaint you with specific FCA

vehicles.

To access your Owner's Information online, visit

www.mopar.com/om

(US) or

www.owners.mopar.ca

(Canada).

Or
Call Tech Authority toll free at:



1-800-890-4038 (US)

Owner's Manuals, Radio Manuals and Warranty

Information Books can be ordered through

Archway at:



1-800-387-1143 (Canada)

GENERAL INFORMATION

The following regulatory statement applies to all

Radio Frequency (RF) devices equipped in this

vehicle:
This device complies with Part 15 of the FCC Rules

and with Innovation, Science and Economic

Development Canada license-exempt RSS

standard(s). Operation is subject to the following

two conditions:
1. This device may not cause harmful

interference, and

2. This device must accept any interference

received, including interference that may

cause undesired operation.

Le présent appareil est conforme aux CNR

d`Innovation, Science and Economic Development

applicables aux appareils radio exempts de

licence. L'exploitation est autorisée aux deux

conditions suivantes:
1. l'appareil ne doit pas produire de brouillage,

2. l'utilisateur de l'appareil doit accepter tout

brouillage radioélectrique subi, même si le

brouillage est susceptible d'en compromettre

le fonctionnement.

La operación de este equipo está sujeta a las

siguientes dos condiciones:
1. es posible que este equipo o dispositivo no

cause interferencia perjudicial y

2. este equipo o dispositivo debe aceptar

cualquier interferencia, incluyendo la que

pueda causar su operación no deseada.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void

the user’s authority to operate the equipment.

Content .. 17 18 19
