GETTING TO KNOW YOUR INSTRUMENT PANEL

For Screen Setup:



OK button allows user to enter menu and

submenus.



Within each submenu layer, the up and
down arrow buttons will allow the user to

select the item of interest.



Pushing the OK button makes the selection. A

confirmation screen will appear, returning the

user to the first page of the submenu.



Pushing the left arrow button will exit each

submenu layer and return to the main menu.

For the Trip and Fuel Economy menus:



Information is reset by pushing and holding the

OK button.

NGINE

IFE

ESET

Oil Change Required
Your vehicle is equipped with an engine oil change

indicator system. The “Oil Change Required”

message will display in the instrument cluster

display for five seconds after a single chime has

sounded, to indicate the next scheduled oil change

interval. The engine oil change indicator system is

duty cycle based, which means the engine oil

change interval may fluctuate, dependent upon

your personal driving style.

Unless reset, this message will continue to display

each time you place the ignition in the ON/RUN

position. To turn off the message temporarily, push

and release the OK or arrow buttons. To reset the

oil change indicator system (after performing the

scheduled maintenance), refer to the following

procedure.
Vehicles Equipped With Keyless Enter ‘n Go™ —

Ignition
Use the steering wheel instrument cluster display

controls for the following procedure(s):
1. Without pressing the brake pedal, push the

ENGINE START/STOP button and place the

ignition in the ON/RUN position (do not start

the engine).

2. Push and release the down arrow button to

scroll downward through the main menu to

“Vehicle Info.”

3. Push and release the right arrow button to

access the ”Oil Life” screen.

4. Push and hold the OK button to reset oil life. If

conditions are met, the gauge and numeric

display will update to show 100%. If conditions

are not met a pop-up message of "To reset oil

life engine must be off with ignition in run" will

be displayed (for five seconds), and the user

will remain at the Oil Life screen.

5. Push and release the up or down arrow

button to exit the submenu screen.

NOTE:

If the indicator message illuminates when you start

the vehicle, the oil change indicator system did not

reset. If necessary, repeat this procedure.
Secondary Method Of Resetting Engine Oil Life
1. Without pressing the brake pedal, push the

ENGINE START/STOP button and place the

ignition to the ON/RUN position (do not start

the engine).

2. Fully press the accelerator pedal, slowly, three

times within ten seconds.

3. Without pushing the brake pedal, push the

ENGINE START/STOP button once to return the

ignition to the OFF position.

NOTE:

If the indicator message illuminates when you start

the vehicle, the oil change indicator system did not

reset. If necessary, repeat this procedure.

GETTING TO KNOW YOUR INSTRUMENT PANEL

NSTRUMENT

LUSTER

ISPLAY

ELECTABLE

ENU

TEMS

Push and release the up or down arrow

button until the desired Selectable Menu item is

displayed in the instrument cluster display.
Follow the Menu or submenu prompts as desired.

Speedometer

Push and release the OK button to toggle between

mph and km/h.

Vehicle Info

The Vehicle Info consists of the following submenu
(pushing the left or right arrow button will

allow you to scroll through the submenu):



Tire Pressure Monitor



Coolant Temperature



Transmission Temperature



Oil Temperature



Oil Pressure



Oil Life



AWD Status — If Equipped



Battery Voltage

Driver Assist — If Equipped

The Driver Assist menu provides the status and a

visual about the Adaptive Cruise Control and

LaneSense features. When they are both off the

screen, the display will read "Adaptive Cruise

Control (ACC) and LaneSense Off."
Adaptive Cruise Control (ACC) Feature —

If Equipped
The instrument cluster display displays the current

ACC system settings

page 100. The information

displayed depends on ACC system status.
Push the ACC ON/OFF button (located on the

steering wheel) until one of the following displays

in the instrument cluster display:
Adaptive Cruise Control Off
When ACC is deactivated, the display will read

“Adaptive Cruise Control Off.”
Adaptive Cruise Control Ready
When ACC is activated but the vehicle speed

setting has not been selected, the display will read

“Adaptive Cruise Control Ready.”
Push the SET + or the SET- button (located on the

steering wheel) and the following will display in the

instrument cluster display:

ACC Set
When ACC is set, the set speed will display in the

instrument cluster.
The ACC screen may display once again if any ACC

activity occurs, which may include any of the

following:



Distance Setting Change



System Cancel



Driver Override



System Off



ACC Proximity Warning



ACC Unavailable Warning

LaneSense — If Equipped
The instrument cluster display displays the current

LaneSense system settings

page 114. The

information displayed depends on LaneSense

system status. Push the LaneSense button

(located on the center stack below the Uconnect

display) until one of the following displays in the

instrument cluster display:



LaneSense Off
When LaneSense is deactivated, the display will

read “LaneSense Off.”



LaneSense On
When LaneSense is activated, the display will

read “LaneSense On.”

GETTING TO KNOW YOUR INSTRUMENT PANEL

Fuel Economy

The Fuel Economy Menu has two submenu pages;

one with Current Value (instantaneous calculation

of the fuel economy) displayed and one without the
Current Value displayed (toggle the left or
right arrow button to select one):



Current Fuel Economy (MPG, L/100 km, or km/L).



Range To Empty (miles or km).



Average Fuel Economy (MPG, L/100 km, or km/L).



Lower end of gauge will be displayed in an

amber color and turn green as Fuel Economy

improves.



Hold the OK button to reset average fuel

economy information.

Trip Info

Push and release the up or down arrow

button until the Trip Menu item is displayed in the
instrument cluster display. Toggle the left or
right arrow button to select Trip A or Trip B. The

Trip information will display the following:



Distance – Shows the total distance (mi or km)

traveled for Trip A or Trip B since the last reset.



Average Fuel Economy – Shows the average

fuel economy (MPG, L/100km or km/L) of Trip A

or Trip B since the last reset.



Elapsed Time – Shows the total elapsed time of

travel since the last reset.

Hold the OK button to reset feature information.

Audio

This menu displays the Audio information of the

currently playing audio source (e.g. FM radio).

Messages

This feature shows the number of stored warning
messages, if any. Pushing the left or right

arrow button will allow you to scroll through the

stored messages.

Screen Setup

Push and release the up or down arrow

button until the Screen Setup Menu displays in the

instrument cluster display. Push and release the

OK button to enter the submenus. The Screen

Setup feature allows you to change what

information is displayed in the instrument cluster

as well as the location that information is

displayed.
NOTE:

Screen Setup is available only when the vehicle is

not in motion.

Upper Left

None

Range to

Empty

Trip A Distance

Outside Temp

Average (MPG,

L/100 km, or

km/L)

Trip B Distance

Time

Current (MPG,

L/100 km, or

km/L)

Compass

Upper Right

None

Range to

Empty

Trip A Distance

Outside Temp

Average (MPG,

L/100 km, or

km/L)

Trip B Distance

Time

Current (MPG,

L/100 km, or

km/L)

Compass

GETTING TO KNOW YOUR INSTRUMENT PANEL

Restore Default



Cancel

Current Gear



Off

Odometer



Show



Hide

Fuel Gauge



Standard



Detailed

ATTERY

AVER

ATTERY

AVER

ODE

ESSAGE

— E

LECTRICAL

OAD

EDUCTION

CTIONS

— I

QUIPPED

This vehicle is equipped with an Intelligent Battery

Sensor (IBS) to perform additional monitoring of

the electrical system and status of the vehicle

battery.
In cases when the IBS detects charging system

failure, or the vehicle battery conditions are

deteriorating, electrical load reduction actions will

take place to extend the driving time and distance

of the vehicle. This is done by reducing power to or

turning off non-essential electrical loads.
Load reduction is only active when the engine is

running. It will display a message if there is a risk

of battery depletion to the point where the vehicle

may stall due to lack of electrical supply, or will not

restart after the current drive cycle.
When load reduction is activated, the message

“Battery Saver On” or “Battery Saver Mode” will

appear in the instrument cluster.

These messages indicate the vehicle battery has a

low state of charge and continues to lose electrical

charge at a rate that the charging system cannot

sustain.
NOTE:



The charging system is independent from load

reduction. The charging system performs a diag

nostic on the charging system continuously.



If the Battery Charge Warning Light is on it may

indicate a problem with the charging system

page 78.

The electrical loads that may be switched off (if

equipped), and vehicle functions which can be

affected by load reduction:



Heated Seat/Vented Seats/Heated Wheel —

If Equipped



Heated/Cooled Cup Holders — If Equipped



Rear Defroster And Heated Mirrors



HVAC System



115 Volts AC Power Inverter System



Audio and Telematics System

Center

Compass

Outside Temp Time

Range to

Empty

Average (MPG,

L/100 km, or

km/L)

Current (MPG,

L/100 km, or

km/L)

Trip A Distance Trip B Distance Audio

Information

Menu Title

Digital Speed

None

GETTING TO KNOW YOUR INSTRUMENT PANEL

Loss of the battery charge may indicate one or

more of the following conditions:



The charging system cannot deliver enough

electrical power to the vehicle system because

the electrical loads are larger than the capability

of the charging system. The charging system is

still functioning properly.



Turning on all possible vehicle electrical loads

(e.g. HVAC to max settings, exterior and interior

lights, overloaded power outlets +12 Volts, 115

Volts AC, USB ports) during certain driving condi

tions (city driving, towing, frequent stopping).



Installing options like additional lights, upfitter

electrical accessories, audio systems, alarms

and similar devices.



Unusual driving cycles (short trips separated by

long parking periods).



The vehicle was parked for an extended period

of time (weeks, months).



The battery was recently replaced and was not

charged completely.



The battery was discharged by an electrical load

left on when the vehicle was parked.



The battery was used for an extended period

with the engine not running to supply radio,

lights, chargers, +12 Volt portable appliances

like vacuum cleaners, game consoles and

similar devices.

What to do when an electrical load reduction

action message is present (“Battery Saver On” or

“Battery Saver Mode”)
During a trip:



Reduce power to unnecessary loads if possible:



Turn off redundant lights (interior or exte

rior)



Check what may be plugged in to power

outlets +12 Volts, 115 Volts AC, USB ports



Check HVAC settings (blower, temperature)



Check the audio settings (volume)

After a trip:



Check if any aftermarket equipment was

installed (additional lights, upfitter electrical

accessories, audio systems, alarms) and review

specifications if any (load and Ignition Off Draw

currents).



Evaluate the latest driving cycles (distance,

driving time and parking time).



The vehicle should have service performed if

the message is still present during consecutive

trips and the evaluation of the vehicle and

driving pattern did not help to identify the cause.

ROGRAMMABLE

EATURES

The instrument cluster display can be used to view
or change the following settings. Push the up   or
down   arrow button to scroll through the main
menus, then push the right   arrow button to

scroll through the submenus of each menu item.
Push the left arrow button to scroll back to a

previous menu or submenu.

WARNING LIGHTS AND MESSAGES

The warning/indicator lights will illuminate in the

instrument panel together with a dedicated

message and/or acoustic signal when applicable.

These indications are indicative and precautionary

and as such must not be considered as exhaustive

and/or alternative to the information contained in

the Owner’s Manual, which you are advised to read

carefully in all cases. Always refer to the

information in this chapter in the event of a failure

indication. All active warning lights will display first

if applicable. The system check menu may appear

different based upon equipment options and

current vehicle status. Some warning lights are

optional and may not appear.

GETTING TO KNOW YOUR INSTRUMENT PANEL

ARNING

IGHTS

Air Bag Warning Light

This warning light will illuminate to

indicate a fault with the air bag, and will

turn on for four to eight seconds as a

bulb check when the ignition is placed in

the ON/RUN or ACC/ON/RUN position. This light

will illuminate with a single chime when a fault with

the air bag has been detected, it will stay on until

the fault is cleared. If the light is either not on

during startup, stays on, or turns on while driving,

have the system inspected at an authorized dealer

as soon as possible.

Brake Warning Light

This warning light monitors various

brake functions, including brake fluid

level and parking brake application. If

the brake light turns on it may indicate

that the parking brake is applied, that the brake

fluid level is low, or that there is a problem with the

Anti-Lock Brake System reservoir.
If the light remains on when the parking brake has

been disengaged, and the fluid level is at the full

mark on the master cylinder reservoir, it indicates

a possible brake hydraulic system malfunction or

that a problem with the Brake Booster has been

detected by the Anti-Lock Brake System (ABS) /

Electronic Stability Control (ESC) system. In this

case, the light will remain on until the condition has

been corrected. If the problem is related to the

brake booster, the ABS pump will run when

applying the brake, and a brake pedal pulsation

may be felt during each stop.
The dual brake system provides a reserve braking

capacity in the event of a failure to a portion of the

hydraulic system. A leak in either half of the dual

brake system is indicated by the Brake Warning

Light, which will turn on when the brake fluid level

in the master cylinder has dropped below a

specified level.
The light will remain on until the cause is corrected.
NOTE:

The light may flash momentarily during sharp

cornering maneuvers, which change fluid level

conditions. The vehicle should have service

performed, and the brake fluid level checked.
If brake failure is indicated, immediate repair is

necessary.

Vehicles equipped with the Anti-Lock Brake System

(ABS) are also equipped with Electronic Brake

Force Distribution (EBD). In the event of an EBD

failure, the Brake Warning Light will turn on along

with the ABS Light. Immediate repair to the ABS

system is required.
Operation of the Brake Warning Light can be

checked by turning the ignition switch from the OFF

position to the ON/RUN position. The light should

illuminate for approximately two seconds. The light

should then turn off unless the parking brake is

applied or a brake fault is detected. If the light does

not illuminate, have the light inspected by an

authorized dealer.
The light also will turn on when the parking brake

is applied with the ignition switch in the ON/RUN

position.
NOTE:

This light shows only that the parking brake is

applied. It does not show the degree of brake appli

cation.

WARNING!

Driving a vehicle with the red brake light on is

dangerous. Part of the brake system may have

failed. It will take longer to stop the vehicle. You

could have a collision. Have the vehicle checked

immediately.

GETTING TO KNOW YOUR INSTRUMENT PANEL

Seat Belt Reminder Warning Light

This warning light indicates when the

driver or passenger seat belt is

unbuckled. When the ignition is first

placed in the ON/RUN or ACC/ON/RUN

position and if the driver’s seat belt is unbuckled,

a chime will sound and the light will turn on. When

driving, if the driver or front passenger seat belt

remains unbuckled, the Seat Belt Reminder Light

will flash or remain on continuously and a chime

will sound

page 160.

Battery Charge Warning Light

This warning light will illuminate when

the battery is not charging properly. If it

stays on while the engine is running,

there may be a malfunction with the

charging system. Contact an authorized dealer as

soon as possible.
This indicates a possible problem with the

electrical system or a related component.

Door Open Warning Light

This indicator will illuminate when a

door is ajar/open and not fully closed.

NOTE:

If the vehicle is moving, there will also be a single

chime.

Electric Power Steering Fault Warning

Light

This warning light will turn on when

there's a fault with the Electric Power

Steering (EPS) system

page 97.

Electronic Throttle Control (ETC) Warning

Light

This warning light will illuminate to

indicate a problem with the ETC system.

If a problem is detected while the

vehicle is running, the light will either

stay on or flash depending on the nature of the

problem. Cycle the ignition when the vehicle is

safely and completely stopped and the

transmission is placed in the PARK position. The

light should turn off. If the light remains on with the

vehicle running, your vehicle will usually be

drivable; however, see an authorized dealer for

service as soon as possible.

NOTE:

This light may turn on if the accelerator and brake

pedals are pressed at the same time.
If the light continues to flash when the vehicle is

running, immediate service is required and you

may experience reduced performance, an

elevated/rough idle, or engine stall and your

vehicle may require towing. The light will come on

when the ignition is placed in the ON/RUN or ACC/

ON/RUN position and remain on briefly as a bulb

check. If the light does not come on during starting,

have the system checked by an authorized dealer.

Engine Coolant Temperature Warning

Light

This warning light warns of an

overheated engine condition. If the

engine coolant temperature is too high,

this indicator will illuminate and a single

chime will sound. If the temperature reaches the

upper limit, a continuous chime will sound for four

minutes or until the engine is able to cool,

whichever comes first.
If the light turns on while driving, safely pull over

and stop the vehicle. If the Air Conditioning (A/C)

system is on, turn it off. Also, shift the transmission

into NEUTRAL and idle the vehicle. If the

temperature reading does not return to normal,

turn the engine off immediately and call for service

page 204.

WARNING!

Continued operation with reduced assist could

pose a safety risk to yourself and others. Service

should be obtained as soon as possible.

GETTING TO KNOW YOUR INSTRUMENT PANEL

Trunk Open Warning Light

This indicator will illuminate when the

trunk is open and not fully closed.

NOTE:

If the vehicle is moving, there will also be a single

chime.

Oil Pressure Warning Light

This warning light will illuminate to

indicate low engine oil pressure. If the

light turns on while driving, stop the

vehicle, shut off the engine as soon as

possible, and contact an authorized dealer. A

chime will sound when this light turns on.
Do not operate the vehicle until the cause is

corrected. This light does not indicate how much oil

is in the engine. The engine oil level must be

checked under the hood.

Oil Temperature Warning Light

This warning light will illuminate to

indicate the engine oil temperature is

high. If the light turns on while driving,

stop the vehicle and shut off the engine

as soon as possible. Wait for oil temperature to

return to normal levels.

Transmission Temperature Warning Light —

If Equipped

This warning light will illuminate to warn

of a high transmission fluid

temperature. This may occur with

strenuous usage such as trailer towing.

If this light turns on, stop the vehicle and run the

engine at idle or slightly faster, with the

transmission in PARK or NEUTRAL, until the light

turns off. Once the light turns off, you may continue

to drive normally.

Vehicle Security Warning Light —

If Equipped

This light will flash at a fast rate for

approximately 15 seconds when the

Vehicle Security system is arming, and

then will flash slowly until the vehicle is

disarmed.

ELLOW

ARNING

IGHTS

Service Adaptive Cruise Control Warning

Light — If Equipped

This light will turn on when a ACC is not

operating and needs service

page 100.

Anti-Lock Brake System (ABS) Warning

Light

This warning light monitors the ABS. The

light will turn on when the ignition is

placed in the ON/RUN or ACC/ON/RUN

position and may stay on for as long as

four seconds.
If the ABS light remains on or turns on while

driving, then the Anti-Lock portion of the brake

system is not functioning and service is required as

soon as possible. However, the conventional brake

system will continue to operate normally,

assuming the Brake Warning Light is not also on.

WARNING!

If you continue operating the vehicle when the

Transmission Temperature Warning Light is

illuminated you could cause the fluid to boil over,

come in contact with hot engine or exhaust

components and cause a fire.

CAUTION!

Continuous driving with the Transmission

Temperature Warning Light illuminated will

eventually cause severe transmission damage

or transmission failure.

GETTING TO KNOW YOUR INSTRUMENT PANEL

If the ABS light does not turn on when the ignition

is placed in the ON/RUN or ACC/ON/RUN position,

have the brake system inspected by an authorized

dealer.

Electronic Stability Control (ESC) Active

Warning Light — If Equipped

This warning light will indicate when the

Electronic Stability Control system is

Active. The ESC Indicator Light in the

instrument cluster will come on when

the ignition is placed in the ON/RUN or ACC/ON/

RUN position, and when ESC is activated. It should

go out with the engine running. If the ESC Indicator

Light comes on continuously with the engine

running, a malfunction has been detected in the

ESC system. If this warning light remains on after

several ignition cycles, and the vehicle has been

driven several miles (kilometers) at speeds greater

than 30 mph (48 km/h), see an authorized dealer

as soon as possible to have the problem

diagnosed and corrected.



The ESC OFF Indicator Light and the ESC Indi

cator Light come on momentarily each time the

ignition is placed in the ON/RUN or ACC/ON/

RUN position.



The ESC system will make buzzing or clicking

sounds when it is active. This is normal; the

sounds will stop when ESC becomes inactive.



This light will come on when the vehicle is in an

ESC event.

Electronic Stability Control (ESC) OFF

Warning Light — If Equipped

This warning light indicates the ESC is

off.
Each time the ignition is turned to ON/

RUN or ACC/ON/RUN, the ESC system

will be on, even if it was turned off previously.

Service LaneSense Warning Light —

If Equipped

This warning light will illuminate when

the LaneSense system is not operating

and requires service. Please see an

authorized dealer.

LaneSense Warning Light — If Equipped

The LaneSense system provides the

driver with visual and steering torque

warnings when the vehicle starts to drift

out of its lane unintentionally without

the use of a turn signal.



When the LaneSense system senses a lane drift

situation, the LaneSense indicator changes

from solid green to solid yellow.



When the LaneSense system senses the lane

has been approached and is in a lane departure

situation, the LaneSense indicator changes

from solid white/green to flashing yellow

page 114.

Low Fuel Warning Light

When the fuel level reaches

approximately 1.9 gal (7.13 L), this light

will turn on and a single chime will

sound.

Low Washer Fluid Warning Light —

If Equipped

This warning light will illuminate when

the windshield washer fluid is low

page 216.

Engine Check/Malfunction Indicator

Warning Light (MIL)

The Engine Check/Malfunction

Indicator Light (MIL) is a part of an

Onboard Diagnostic System called OBD

II that monitors engine and automatic

transmission control systems. This warning light

will illuminate when the ignition is in the ON/RUN

position before engine start. If the bulb does not

come on when turning the ignition switch from OFF

to ON/RUN, have the condition checked promptly.

GETTING TO KNOW YOUR INSTRUMENT PANEL

Certain conditions, such as a loose or missing gas

cap, poor quality fuel, etc., may illuminate the light

after engine start. The vehicle should be serviced if

the light stays on through several typical driving

styles. In most situations, the vehicle will drive

normally and will not require towing.
When the engine is running, the MIL may flash to

alert serious conditions that could lead to immediate

loss of power or severe catalytic converter damage.

The vehicle should be serviced by an authorized

dealer as soon as possible if this occurs.

Service AWD Warning Light — If Equipped

This warning light will turn on to indicate

the All Wheel Drive (AWD) system is not

functioning properly and that service is

required. Contact an authorized dealer.

Service Forward Collision Warning (FCW)

Light — If Equipped

This warning light will illuminate to

indicate a fault in the Forward Collision

Warning System. Contact an authorized

dealer for service

page 155.

Tire Pressure Monitoring System (TPMS)

Warning Light

The warning light switches on and a

message is displayed to indicate that

the tire pressure is lower than the

recommended value and/or that slow

pressure loss is occurring. In these cases, optimal

tire duration and fuel consumption may not be

guaranteed.
Should one or more tires be in the condition

mentioned above, the display will show the

indications corresponding to each tire.

Each tire, including the spare (if provided), should

be checked monthly when cold and inflated to the

inflation pressure recommended by the vehicle

manufacturer on the vehicle placard or tire

inflation pressure label. If your vehicle has tires of

a different size than the size indicated on the

vehicle placard or tire inflation pressure label, you

should determine the proper tire inflation pressure

for those tires.
As an added safety feature, your vehicle has been

equipped with a TPMS that illuminates a low tire

pressure warning light when one or more of your

tires is significantly underinflated. Accordingly,

when the low tire pressure warning light

illuminates, you should stop and check your tires

as soon as possible, and inflate them to the proper

pressure. Driving on a significantly underinflated

tire causes the tire to overheat and can lead to tire

failure. Underinflation also reduces fuel efficiency

and tire tread life, and may affect the vehicle’s

handling and stopping ability.

WARNING!

A malfunctioning catalytic converter, as referenced

above, can reach higher temperatures than in

normal operating conditions. This can cause a fire

if you drive slowly or park over flammable

substances such as dry plants, wood, cardboard,

etc. This could result in death or serious injury to

the driver, occupants or others.

CAUTION!

Prolonged driving with the Malfunction Indicator

Light (MIL) on could cause damage to the

vehicle control system. It also could affect fuel

economy and driveability. If the MIL is flashing,

severe catalytic converter damage and power

loss will soon occur. Immediate service is

required.

CAUTION!

Do not continue driving with one or more flat

tires as handling may be compromised. Stop the

vehicle, avoiding sharp braking and steering. If a

tire puncture occurs, repair immediately using

the dedicated tire repair kit and contact an

authorized dealer as soon as possible.

GETTING TO KNOW YOUR INSTRUMENT PANEL

Please note that the TPMS is not a substitute for

proper tire maintenance, and it is the driver’s

responsibility to maintain correct tire pressure,

even if underinflation has not reached the level to

trigger illumination of the TPMS low tire pressure

warning light.
Your vehicle has also been equipped with a TPMS

malfunction indicator to indicate when the system

is not operating properly. The TPMS malfunction

indicator is combined with the low tire pressure

warning light. When the system detects a

malfunction, the warning light will flash for

approximately one minute and then remain

continuously illuminated. This sequence will

continue upon subsequent vehicle start-ups as

long as the malfunction exists. When the

malfunction indicator is illuminated, the system

may not be able to detect or signal low tire

pressure as intended. TPMS malfunctions may

occur for a variety of reasons, including the

installation of replacement or alternate tires or

wheels on the vehicle that prevent the TPMS from

functioning properly. Always check the TPMS

malfunction warning light after replacing one or

more tires or wheels on your vehicle to ensure that

the replacement or alternate tires and wheels

allow the TPMS to continue to function properly.

ELLOW

NDICATOR

IGHTS

Forward Collision Warning Off Indicator

Light — If Equipped

This indicator light illuminates to

indicate that Forward Collision Warning

is off

page 155.

REEN

NDICATOR

IGHTS

Adaptive Cruise Control (ACC) Set Without

Target Vehicle Light — If Equipped

This will display the distance setting for

the ACC system when the system is

engaged

page 100.

Adaptive Cruise Control (ACC) Set With

Target Vehicle Light — If Equipped

This will display when the ACC is set and

a vehicle in front is detected

page 100.

Cruise Control Set Indicator Light —

If Equipped

This indicator light will illuminate when

the cruise control is set to the desired

speed

page 98.

Front Fog Indicator Light — If Equipped

This indicator light will illuminate when

the front fog lights are on

page 44.

CAUTION!

The TPMS has been optimized for the original

equipment tires and wheels. TPMS pressures

and warning have been established for the tire

size equipped on your vehicle. Undesirable

system operation or sensor damage may result

when using replacement equipment that is not

of the same size, type, and/or style. Aftermarket

wheels can cause sensor damage. Using

aftermarket tire sealants may cause the Tire

Pressure Monitoring System (TPMS) sensor to

become inoperable. After using an aftermarket

tire sealant it is recommended that you take

your vehicle to an authorized dealer to have your

sensor function checked.

GETTING TO KNOW YOUR INSTRUMENT PANEL

LaneSense Indicator Light — If Equipped

The LaneSense indicator light

illuminates solid green when both lane

markings have been detected and the

system is “armed” and ready to provide

visual and torque warnings if an unintentional lane

departure occurs

page 114.

Parking/Headlights On Indicator Light

This indicator light will illuminate when

the parking lights or headlights are

turned on

page 44.

Sport Mode Indicator Light

This light will turn on when Sport Mode is

active.

Turn Signal Indicator Lights

When the left or right turn signal is

activated, the turn signal indicator will

flash independently and the

corresponding exterior turn signal lamps

will flash. Turn signals can be activated when the

multifunction lever is moved down (left) or up

(right).

NOTE:



A continuous chime will sound if the vehicle is

driven more than 1 mile (1.6 km) with either

turn signal on.



Check for an inoperative outside light bulb if

either indicator flashes at a rapid rate.

ECO Mode Indicator Light — If Equipped

This light will turn on when ECO mode is

active.

HITE

NDICATOR

IGHTS

Adaptive Cruise Control (ACC) Ready Light —

If Equipped

This light will turn on when ACC has

been turned on, but is not set

page 100.

Cruise Control Ready Indicator Light

This indicator light will illuminate when

the cruise control is ready, but not set

page 98.

LaneSense Indicator Light — If Equipped

When the LaneSense system is ON, but

not armed, the LaneSense indicator

light illuminates solid white. This occurs

when only left, right, or neither lane line

has been detected. If a single lane line is detected,

the system is ready to provide only visual warnings

if an unintentional lane departure occurs on the

detected lane line

page 114.

LUE

NDICATOR

IGHTS

High Beam Indicator Light

This indicator light will illuminate to

indicate that the high beam headlights

are on. With the low beams activated,

push the multifunction lever forward

(toward the front of the vehicle) to turn on the high

beams. Pull the multifunction lever rearward

(toward the rear of the vehicle) to turn off the high

beams. If the high beams are off, pull the lever

toward you for a temporary high beam on, "flash to

pass" scenario.

GETTING TO KNOW YOUR INSTRUMENT PANEL

ONBOARD DIAGNOSTIC SYSTEM — OBD II

Your vehicle is equipped with a sophisticated

Onboard Diagnostic system called OBD II. This

system monitors the performance of the

emissions, engine, and transmission control

systems. When these systems are operating

properly, your vehicle will provide excellent

performance and fuel economy, as well as engine

emissions well within current government

regulations.
If any of these systems require service, the OBD II

system will turn on the Malfunction Indicator Light

(MIL). It will also store diagnostic codes and other

information to assist your service technician in

making repairs. Although your vehicle will usually

be drivable and not need towing, see an authorized

dealer for service as soon as possible.

NBOARD

IAGNOSTIC

YSTEM

(OBD II) C

YBERSECURITY

Your vehicle is required to have an OBD II and a

connection port to allow access to information

related to the performance of your emissions

controls. Authorized service technicians may need

to access this information to assist with the

diagnosis and service of your vehicle and

emissions system

page 128.

CAUTION!



Prolonged driving with the MIL on could cause

further damage to the emission control

system. It could also affect fuel economy and

driveability. The vehicle must be serviced

before any emissions tests can be performed.



If the MIL is flashing while the vehicle is

running, severe catalytic converter damage

and power loss will soon occur. Immediate

service is required.

WARNING!



ONLY an authorized service technician should

connect equipment to the OBD II connection

port in order to read the VIN, diagnose, or

service your vehicle.



If unauthorized equipment is connected to the

OBD II connection port, such as a

driver-behavior tracking device, it may:



Be possible that vehicle systems,

including safety related systems, could be

impaired or a loss of vehicle control could

occur that may result in an accident

involving serious injury or death.



Access, or allow others to access, infor

mation stored in your vehicle systems,

including personal information.

GETTING TO KNOW YOUR INSTRUMENT PANEL

EMISSIONS INSPECTION AND

MAINTENANCE PROGRAMS

In some localities, it may be a legal requirement to

pass an inspection of your vehicle's emissions

control system. Failure to pass could prevent

vehicle registration.

For states that require an Inspection

and Maintenance (I/M), this check

verifies the Malfunction Indicator Light

(MIL) is functioning and is not on when

the engine is running, and that the OBD II system

is ready for testing.
Normally, the OBD II system will be ready. The

OBD II system may not be ready if your vehicle

was recently serviced, recently had a dead battery

or a battery replacement. If the OBD II system

should be determined not ready for the I/M test,

your vehicle may fail the test.
Your vehicle has a simple ignition actuated test,

which you can use prior to going to the test station.

To check if your vehicle's OBD II system is ready,

you must do the following:

1. Cycle the ignition switch to the ON position,

but do not crank or start the engine.

NOTE:

If you crank or start the engine, you will have to

start this test over.
2. As soon as you cycle the ignition switch to the

ON position, you will see the Malfunction

Indicator Light (MIL) symbol come on as part of

a normal bulb check.

3. Approximately 15 seconds later, one of two

things will happen:



The MIL will flash for about 10 seconds and

then return to being fully illuminated until

you turn OFF the ignition or start the engine.

This means that your vehicle's OBD II

system is not ready and you should not

proceed to the I/M station.



The MIL will not flash at all and will remain

fully illuminated until you place the ignition

in the off position or start the engine. This

means that your vehicle's OBD II system is

ready and you can proceed to the I/M

station.

If your OBD II system is not ready, you should see

an authorized dealer or repair facility. If your

vehicle was recently serviced or had a battery

failure or replacement, you may need to do nothing

more than drive your vehicle as you normally would

in order for your OBD II system to update. A

recheck with the above test routine may then

indicate that the system is now ready.
Regardless of whether your vehicle's OBD II system

is ready or not, if the MIL is illuminated during

normal vehicle operation you should have your

vehicle serviced before going to the I/M station.

The I/M station can fail your vehicle because the

MIL is on with the engine running.

(Continued)

STARTING AND OPERATING

STARTING THE ENGINE

Before starting your vehicle, adjust your seat,

adjust the inside and outside mirrors, fasten your

seat belt, and if present, instruct all other

occupants to buckle their seat belts.

UTOMATIC

RANSMISSION

The gear selector must be in the PARK position

before you can start the engine. Apply the brakes

before shifting into any driving gear.

EYLESS

NTER

‘

™ — I

GNITION

This feature allows the driver to operate the

ignition switch with the push of a button, as long as

the Remote Start/Keyless Enter ‘n Go™ key fob is

in the passenger compartment.

ORMAL

TARTING

To Turn On The Engine Using The ENGINE START/

STOP Button
1. The transmission must be in PARK.
2. Press and hold the brake pedal while pushing

the ENGINE START/STOP button once.

3. The system takes over and attempts to start

the vehicle. If the vehicle fails to start, the

starter will disengage automatically after 10

seconds.

4. If you wish to stop the cranking of the engine

prior to the engine starting, push the ENGINE

START/STOP button again.

NOTE:

Normal starting of either a cold or a warm engine is

obtained without pumping or pressing the accel

erator pedal.

WARNING!



When exiting the vehicle, always make sure

the ignition is in OFF position, remove the key

fob from the vehicle and lock the vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Leaving chil

dren in a vehicle unattended is dangerous for

a number of reasons. A child or others could

be seriously or fatally injured. Children should

be warned not to touch the parking brake,

brake pedal or the transmission gear selector.



Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and do

not leave the ignition (of a vehicle equipped

with Keyless Enter ‘n Go™) in the ACC or ON/

RUN position. A child could operate power

windows, other controls, or move the vehicle.



Do not leave children or animals inside parked

vehicles in hot weather. Interior heat build-up

may cause serious injury or death.

CAUTION!



Shift into or out of PARK or REVERSE only after

the vehicle has come to a complete stop.



Do not shift between PARK, REVERSE,

NEUTRAL, or DRIVE when the engine is above

idle speed.



Before shifting into any gear, make sure your

foot is firmly pressing the brake pedal.

WARNING!

STARTING AND OPERATING

To Turn Off The Engine Using The ENGINE START/

STOP Button
1. Place the gear selector in PARK, then push

and release the ENGINE START/STOP button.

2. The ignition will return to the OFF position.
3. If the gear selector is not in PARK, the ENGINE

START/STOP button must be held for two

seconds or three short pushes in a row with

the vehicle speed above 5 mph (8 km/h)

before the engine will shut off. The ignition will

remain in the ACC position until the gear

selector is in PARK and the button is pushed

twice to the OFF position.

4. If the gear selector is not in PARK and the

ENGINE START/STOP button is pushed once

with the vehicle speed above 5 mph (8 km/h),

the instrument cluster will display a “Vehicle

Not In Park” message and the engine will

remain running. Never leave a vehicle out of

the PARK position, or it could roll.

NOTE:

If the gear selector is not in PARK, and the ENGINE

START/STOP button is pushed once with the

vehicle speed below 5 mph (8 km/h), the engine

will shut off and the ignition will remain in the ACC

position. If vehicle speed drops below 1.2 mph

(1.9 km/h), the vehicle will AutoPark

page 87.

ENGINE START/STOP Button Functions — With

Driver’s Foot OFF The Brake Pedal (In PARK Or

NEUTRAL Position)
The ENGINE START/STOP button operates similar

to an ignition switch. It has three positions: OFF,

ACC, and ON/RUN. To change the ignition modes

without starting the vehicle and use the

accessories, follow these directions:
1. Start with the ignition in the OFF position.
2. Push the ENGINE START/STOP button once to

place the ignition to the ACC position.

3. Push the ENGINE START/STOP button a

second time to place the ignition to the ON/

RUN position.

4. Push the ENGINE START/STOP button a third

time to return the ignition to the OFF position.

UTO

ARK

AutoPark is a supplemental feature to assist in

placing the vehicle in PARK should the situations

on the following pages occur. It is a back up system

and should not be relied upon as the primary

method by which the driver shifts the vehicle into

PARK.
The conditions under which AutoPark will engage

are outlined on the following pages.

If the vehicle is not in PARK and the driver turns off

the engine, the vehicle may AutoPark.
AutoPark will engage when all of these conditions

are met:



Vehicle is equipped with a rotary selector and an

8-speed transmission



Vehicle is not in PARK



Vehicle speed is 1.2 mph (1.9 km/h) or less



Ignition switched from RUN to ACC

WARNING!



Driver inattention could lead to failure to place

the vehicle in PARK. ALWAYS DO A VISUAL

CHECK that your vehicle is in PARK by verifying

that a solid (not blinking) “P” is indicated in

the instrument cluster display and near the

gear selector. If the “P” indicator is blinking,

your vehicle is not in PARK. As an added

precaution, always apply the parking brake

when exiting the vehicle.



AutoPark is a supplemental feature. It is not

designed to replace the need to shift your

vehicle into PARK. It is a back up system and

should not be relied upon as the primary

method by which the driver shifts the vehicle

into PARK.

Chrysler 300 (2022 year). Manual in english - page 5
