RAM Cargo Van (2015 year). Manual - part 26





Product Agreement

Software

This product contains software licensed under GNU
General Public License (GPL) or GNU Lesser General
Public License (LGPL), etc. You have the right of acqui-
sition, modification, and distribution of the source code
of the GPL/LGPL software. You may download Source
Code from the following website at no charge.

http://www.embedded-carmultimedia.jp/linux/oss/
download/MP_632_34W821

The website provides the Source Code

⬙As Is⬙ and

without warranty of any kind. By downloading Source
Code, you expressly assume all risk and liability associ-
ated with downloading and using the Source Code and
complying with the user agreements that accompany
each Source Code. Please note that we cannot respond to
any inquiries regarding the source code.

• THIS PRODUCT IS LICENSED UNDER THE AVC

PATENT PORTFOLIO LICENSE FOR THE PER-
SONAL AND NON-COMMERCIAL USE OF A CON-
SUMER TO (i) ENCODE VIDEO IN COMPLIANCE
WITH THE AVC STANDARD (

⬙AVC VIDEO⬙)

AND/OR (ii) DECODE AVC VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PRO-
VIDER LICENSED TO PROVIDE AVC VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR
ANY OTHER USE. ADDITIONAL INFORMATION
MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM.

• THIS PRODUCT IS LICENSED UNDER THE VC-1

PATENT PORTFOLIO LICENSE FOR THE PER-
SONAL AND NON-COMMERCIAL USE OF A CON-
SUMER TO (i) ENCODE VIDEO IN COMPLIANCE

406

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WITH THE VC-1 STANDARD (

⬙VC-1 VIDEO⬙)

AND/OR (ii) DECODE VC-1 VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PRO-
VIDER LICENSED TO PROVIDE VC-1 VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR
ANY OTHER USE. ADDITIONAL INFORMATION
MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM.

Patents

Cinavia Notice

This product uses Cinavia technology to limit the use of
unauthorized copies of some commercially-produced
film and videos and their soundtracks. When a prohib-
ited use of an unauthorized copy is detected, a message

will be displayed and playback or copying will be
interrupted. More information about Cinavia technology
is provided at the Cinavia Online Consumer Information
Center at http://www.cinavia.com. To request additional
information about Cinavia by mail, send a postcard with
your mailing address to: Cinavia Consumer Information
Center, P.O. Box 86851, San Diego, CA, 92138, USA.

This product incorporates proprietary technology under
license from Verance Corporation and is protected by
U.S. Patent 7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright and
trade secret protection for certain aspects of such tech-
nology. Cinavia is a trademark of Verance Corporation.
Copyright 2004-2010 Verance Corporation. All rights
reserved by Verance. Reverse engineering or disassembly
is prohibited.

4

UNDERSTANDING YOUR INSTRUMENT PANEL

407

-------------------------------------------------------------------------------------------------------------------------------------------------------------

• This product incorporates copyright protection tech-

nology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright pro-
tection technology must be authorized by Macrovi-
sion, and is intended for home and other limited
viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is
prohibited.

• Manufactured under license under U.S. Patent #’s:

5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents issued & pending.
DTS is a registered trademark and the DTS logos,
Symbol and DTS 2.0 Channel are trademarks of DTS,
Inc. © 1996-2007 DTS, Inc. All Rights Reserved.

• Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of
Dolby Laboratories.

ABOUT DIVX VIDEO: DivX is a digital video format
created by DivX, LLC, a subsidiary of Rovi Corporation.
This is an official DivX Certified® device that plays DivX
video. Visit divx.com for more information and software
tools to convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certi-
fied® device must be registered in order to play pur-
chased DivX Video-on-Demand (VOD) movies. To obtain
your registration code, locate the DivX VOD section in
your device setup menu. Go to vod.divx.com for more
information on how to complete your registration.

DivX®, DivX Certified® and associated logos are trade-
marks of Rovi Corporation or its subsidiaries and are
used under license.

408

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Trademark

• Blu-ray Disc™, Blu-ray™ and the logos are trademarks

of the Blu-ray Disc Association.

• Java is a registered trademark of Oracle and/or its

affiliates.

CAUTION!

Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.

STEERING WHEEL AUDIO CONTROLS —
IF EQUIPPED

The remote sound system controls are located on the rear
surface of the steering wheel, at the three and nine
o’clock positions.

Remote Sound System Controls (Back View Of

Steering Wheel)

4

UNDERSTANDING YOUR INSTRUMENT PANEL

409

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The right-hand rocker switch has a push-button in the
center, and controls the volume and mode of the sound
system. Pushing the top of the rocker switch will increase
the volume. Pushing the bottom of the rocker switch will
decrease the volume. Pushing the center button changes
the operation of the radio from AM to FM, or to CD
mode, depending on which radio is in the vehicle.

The left-hand rocker switch has a push-button in the
center. The function of the left-hand switch is different,
depending on which mode you are in.

The following describes the left-hand rocker switch op-
eration in each mode.

Radio Operation

Pushing the top of the switch will SEEK up for the next
listenable station, and pushing the bottom of the switch
will SEEK down for the next listenable station.

The button located in the center of the left-hand switch
will tune to the next preset station that you have pro-
grammed in the radio preset push-button.

CD Player

Pushing the top of the switch once will go to the next
track on the CD. Pushing the bottom of the switch once
will go to the beginning of the current track, or to the
beginning of the previous track if it is within one second
after the current track begins to play.

If you push the switch up or down twice it plays the
second track; three times, it will play the third, etc.

The button in the center of the left-hand switch has no
function in this mode.

410

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CD/DVD/Blu-ray™ Disc MAINTENANCE

To keep a CD/DVD/Blu-ray™ Disc in good condition,
take the following precautions:

1. Handle the disc by its edge; avoid touching the surface.

2. If the disc is stained, clean the surface with a soft cloth,

wiping from center to edge.

3. Do not apply paper or tape to the disc; avoid scratch-

ing the disc.

4. Do not use solvents such as benzene, thinner, cleaners,

or anti-static sprays.

5. Store the disc in its case after playing.

6. Do not expose the disc to direct sunlight.

7. Do not store the disc where temperatures may become

too high.

NOTE:

If you experience difficulty in playing a particular

disc, it may be damaged (i.e., scratched, reflective coating
removed, a hair, moisture or dew on the disc) oversized,
or have protection encoding. Try a known good disc
before considering disc player service.

RADIO OPERATION AND MOBILE PHONES

Under certain conditions, the mobile phone being on in
your vehicle can cause erratic or noisy performance from
your radio. This condition may be lessened or eliminated
by relocating the mobile phone antenna. This condition is
not harmful to the radio. If your radio performance does
not satisfactorily “clear” by the repositioning of the
antenna, it is recommended that the radio volume be
turned down or off during mobile phone operation when
not using Uconnect® (if equipped).

4

UNDERSTANDING YOUR INSTRUMENT PANEL

411

-------------------------------------------------------------------------------------------------------------------------------------------------------------

General Information

This device complies with Part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:

• Changes or modifications not expressly approved by

the party responsible for compliance could void the
user’s authority to operate the equipment.

• This device may not cause harmful interference.
• This device must accept any interference received,

including interference that may cause undesired op-
eration.

CLIMATE CONTROLS

The Climate Control system allows you to regulate the
temperature, amount, and direction of air circulating
throughout the vehicle. The controls are located on the
instrument panel, below the radio.

Manual Heating And Air Conditioning System —
If Equipped

The controls for the manual system in this vehicle contain
a series of outer rotary dials and inner push knobs. These
comfort controls can be set to obtain desired interior
conditions.

With the Three-Zone Temperature Control system, each
front seat occupant can independently control the Heat-
ing, Ventilation and Air Conditioning operations coming
from the outlets on their side of the vehicle.

The primary control for the rear blower is on the front
climate control unit located on the instrument panel.
When the front control is in any position other than rear,
the front control operates all the rear functions.

The rear airflow modes will mirror the front unit opera-
tion. Rear Panel mode is automatically selected when the
front control is in the Panel mode. When the front unit is
in Bi-Level mode, airflow will be emitted from both the

412

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

upper and lower rear outlets. When the front control is in
Floor, Defrost, or Mix modes, airflow will be directed out
of the rear floor outlets.

1. Left Front Temperature Control

Provides left front seat occupant with independent tem-
perature control. Turn left for cooler or right for warmer
temperature settings.

2. Rear Blower Control — If Equipped

Use this control to regulate the amount of air forced
through the rear system in any mode you select. The rear
blower speed increases as you move the control to the
right from the “O” (Off) position. There are seven blower
speeds. To allow the rear overhead control, turn blower
knob fully to the left, past The

⬙O⬙ off position into the

“REAR” control position.

3. Front Blower Control

Use this control to regulate the amount of air forced
through the system in any mode you select. The blower
speed increases as you move the control to the right from
the “O” (Off) position. There are seven blower speeds.

Manual Temperature Control

4

UNDERSTANDING YOUR INSTRUMENT PANEL

413

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4. Rear Temperature Control — If Equipped

Provides temperature control for the rear cabin. Turn left
for cooler or right for warmer temperature settings in the
rear cabin.

5. Right Front Temperature Control

Provides right front seat occupant with independent
temperature control. Turn left for cooler or right for
warmer temperature settings.

6. Mix Mode

Air is directed through the floor, defrost and side
window demist outlets. This setting works best in

cold or snowy conditions that require extra heat at the
windshield. This setting is good for maintaining comfort,
while reducing moisture on the windshield.

7. Front Defrost Mode

Air is directed through the windshield and side
window demist outlets. Use Defrost mode with

maximum blower and temperature settings for best
windshield and side window defrosting.

NOTE:

The air conditioning compressor may operate in

Mix and Defrost, even if the A/C button is not pushed.
This dehumidifies the air to help dry the windshield.
To improve fuel economy, use these modes only when
necessary.

8. Electronic Rear Window Defrost

Push this button to turn on the rear window
defroster and the heated outside mirrors (if

equipped). An indicator in the button will illuminate
when the rear window defroster is on. The rear window
defroster automatically turns off after approximately
10 minutes.

414

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

NOTE:

• You can turn off the heated mirror feature at anytime

by pushing the rear window defroster switch a
second time.

• To prevent excessive battery drain, use the rear win-

dow defroster only when the engine is operating.

CAUTION!

Failure to follow these cautions can cause damage to
the heating elements:
• Use care when washing the inside of the rear

window. Do not use abrasive window cleaners on
the interior surface of the window. Use a soft cloth
and a mild washing solution, wiping parallel to the
heating elements. Labels can be peeled off after
soaking with warm water.

(Continued)

CAUTION! (Continued)

• Do not use scrapers, sharp instruments, or abrasive

window cleaners on the interior surface of the
window.

• Keep all objects a safe distance from the window.

9. Recirculation Control Button

Push this button to choose between outside air
intake or recirculation of the air inside the
vehicle. An indicator light will illuminate when
you are in Recirculation mode. Only use the

Recirculation mode to temporarily block out any outside
odors, smoke, or dust, and to cool the interior rapidly
upon initial start-up in very hot or humid weather.

4

UNDERSTANDING YOUR INSTRUMENT PANEL

415

-------------------------------------------------------------------------------------------------------------------------------------------------------------

NOTE:

• If the Recirculation button is pushed when the

system is in Defrost mode the Recirculation LED
indicator will flash three times to indicate Recircula-
tion mode is not allowed.

• Continuous use of the Recirculation mode may make

the inside air stuffy and window fogging may occur.
Extended use of this mode is not recommended.

• In cold or damp weather, the use of the Recirculation

mode will cause windows to fog on the inside
because of moisture buildup inside the vehicle. For
maximum defogging, select the outside air position.

• In order to prevent fogging, when the Recirculation

button is pushed and the mode control is set to
Panel, the A/C will engage automatically.

• The A/C can be deselected manually without dis-

turbing the mode control selection.

10. Air Conditioning (A/C) Button

Push and release to change the current setting.
The indicator illuminates when ON.

NOTE:

If your air conditioning performance seems

lower than expected, check the front of the A/C con-
denser (located in front of the radiator), for an accumu-
lation of dirt or insects. Clean with a gentle water spray
from behind the radiator and through the condenser.
Fabric front fascia protectors may reduce airflow to the
condenser, reducing air conditioning performance.

11. Floor Mode Button

Air is directed through the floor outlets with a
small amount through the defrost and side win-

dow demist outlets.

416

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

12. Bi-Level Mode Button

Air is directed through the panel and floor outlets.

NOTE:

There is a difference in temperature (in

any conditions other than full cold or full hot), between
the upper and lower outlets for added comfort. The
warmer air goes to the floor outlets. This feature gives
improved comfort during sunny but cool conditions.

13. Panel Mode Button

Air is directed through the outlets in the instru-
ment panel. These outlets can be adjusted for

direction, and turned on or off to control airflow.

NOTE:

For maximum airflow to the rear, the center

instrument panel outlets can be directed toward the rear
seat passengers.

Economy Mode

If ECONOMY mode is desired, push the A/C button to
turn off the indicator light and the A/C compressor.
Rotate the temperature control knob to the desired tem-
perature. Also, make sure to select only Panel, Bi-Level or
Floor modes.

Max A/C

For maximum cooling use the A/C and Recirculation
mode buttons at the same time.

Rear Manual Climate Control — If Equipped

The Rear Manual Climate Control system has floor air
outlets at the rear of the right side sliding door, and
overhead outlets at each outboard rear seating position.
The unit provides warm or cool air through the floor and
upper outlets.

4

UNDERSTANDING YOUR INSTRUMENT PANEL

417

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The rear blower and temperature controls for the rear
seat passengers are located in the headliner, near the
center of the vehicle.

Rear Blower Control

The primary control for the rear blower is on the front
climate control unit, located on the instrument panel.

Only when the front control for the rear blower is in the
REAR

position do the second row seat occupants have

control of the rear blower speed.

The rear blower control, located in the rear overhead
console, has an off position and a range of blower speeds.
This allows the second row seat occupants to control the
volume of air circulated in the rear of the vehicle.

CAUTION!

Interior air enters the Rear Manual Climate Control
system through an intake grille, located in the right
side trim panel behind the third row seats. The
heater outlets are located in the right side trim panel,

(Continued)

Rear Manual Climate Controls

1 — Rear Blower

3 — Rear Mode

2 — Rear Temperature

4 — Rear Climate Control Lock

418

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION! (Continued)

just behind the sliding door. Do not block or place
objects directly in front of the inlet grille or heater
outlets. The electrical system could overload, causing
damage to the blower motor.

Rear Temperature Control

The rear mode selection REAR, allows the settings to be
controlled by the rear mode control knob.

To change the temperature in the rear of the vehicle,
rotate the temperature control knob counterclockwise for
cold air, and clockwise for heated air.

When rear controls are locked by the front system, the
lock symbol on the temperature knob is illuminated, and
the rear overhead adjustments are inoperable.

Rear Mode Control

Headliner Mode

Air comes from the outlets in the headliner. Each
of these outlets can be individually adjusted to

direct the flow of air. Moving the air vanes of the outlets
to one side will shut off the airflow.

Bi-Level Mode

Air comes from both the headliner outlets and the
floor outlets.

NOTE:

In many temperature positions, the Bi-Level

mode is designed to provide cooler air out of the head-
liner outlets and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets.

4

UNDERSTANDING YOUR INSTRUMENT PANEL

419

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Automatic Temperature Control (ATC) —
If Equipped

• Front Three-Zone ATC allows both driver and front

passenger seat occupant, and rear seat occupants to
select individual comfort settings.

• When occupants in the vehicle select the AUTO mode

operation, a comfort temperature can be set by using
the temperature up and down buttons, and the auto
blower operation will be set automatically.

• The system can be controlled manually, if desired.
• SYNC feature links the controls for all three zones,

allowing one comfort setting (driver setting) for the
cabin, if desired.

The Three-Zone ATC system automatically maintains the
interior comfort level desired by the driver and all
passengers. The system automatically adjusts the air
temperature, the airflow volume, amount of outside air

recirculation and the airflow direction. This maintains a
comfortable temperature, even under changing condi-
tions.

Front ATC Panel

420

UNDERSTANDING YOUR INSTRUMENT PANEL

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1. Air Conditioning (A/C) Button

Push and release to change the current Air Conditioning
(A/C) setting, the indicator illuminates when A/C is ON.
Performing this function will cause the ATC to switch
into manual mode.

2. Blower Control Display

This display shows the current Blower speed selection.

3. Left Front Seat Occupant Temperature Display

This display shows the temperature setting for the left
front seat occupant.

4. Mode Display

This display shows the current Mode selection (Panel,
Bi-Level, Floor, Mix).

5. Rear Temperature Control Display

This display shows the current Rear Temperature Control
settings.

6. Front Auto Indicator

This indicates when the system is in Front Auto mode.

7. Auto Indicator

This indicates when the system is in Auto mode.

8. Right Front Seat Occupant Temperature Display

This display shows the temperature setting for the right
front seat occupant.

9. Front Defrost Button

Push and release to change the current setting, the indicator
illuminates when ON. Performing this function will cause
the ATC to switch into manual mode. The blower will
engage immediately if the Defrost mode is selected.

4

UNDERSTANDING YOUR INSTRUMENT PANEL

421

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     24      25      26      27     ..
