CONDITION
POSSIBLE CAUSE
CORRECTION
8. Other passengers
talking while customer is
attempting to use the
system
8. Although designed for primary use by the driver, the
microphone will pick up passengers in any seat of the vehicle.
System performance is increased in low noise environments.
Phonebook
names not
recognized
consistently
1. Phonebook names
recorded in high noise
conditions
1. For increased system performance, it is recommended that the
phone book entries are recorded in a low noise environment. That
is, vehicle in park, with windows up.
2. Phonebook name(s)
short
2. For increased performance it is recommended that the user
use both first and last name as a phonebook entry. Example
9
Daniel James
9
as opposed to
9
Dan
9
.
3. Phonebook names
recorded by another user
3. It is recommended that each user of the system record their
own phonebook entries. This will increase the recognition
performance.
4. Similar names in
phonebook
4. For increased system performance it is recommended that the
user do not enter similar sounding names in the phonebook.
5. Object interfering with
microphone input
5. Object interfering with microphone input.
Poor Phone
audio quality.
1. Microphone failure
1. Use a scan tool, and check for Microphone faults.
2. Rear view mirror not
properly fixed to
mounting button
2. Mirror must be firmly mounted to the mounting location. Tighten
mirror to the specified torque.
3. System being used in
high noise conditions
3. System performance is increased when noise conditions in the
vehicle are lowered. Ideal conditions include windows closed.
No Phone Audio
1. Phone setting cause
phone audio to be routed
to handset.
1. Route audio to
9
Hands free
9
device.
HANDS FREE MODULE
REMOVAL
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the instrument panel lower console
(Refer to 23 - BODY/INSTRUMENT PANEL/STOR-
AGE BIN - REMOVAL).
(3) Remove the mounting fasteners (Fig. 1).
(4) Disconnect the electrical harness connector and
remove module.
INSTALLATION
(1) Connect electrical harness connector and posi-
tion module.
(2) Install mounting fasteners.
(3) Install instrument panel lower console (Refer to
23 - BODY/INSTRUMENT PANEL/STORAGE BIN -
INSTALLATION).
(4) Connect battery negative cable.
Fig. 1 HANDS FREE MODULE
