(12) Remove low/reverse accumulator plug (Fig. 24). (13) Remove low/reverse accumulator piston using suitable pliers (Fig. 25). Remove piston and springs (14) Measure input shaft end play. Place transaxle so input shaft is vertical. Set up end play set and Fig. 23 Remove Low/Reverse Accumulator Snap Ring 1 - SNAP RING Fig. 24 Remove Low/Reverse Accumulator Plug 1 - ADJUSTABLE PLIERS Fig. 25 Low/Reverse Accumulator Piston 1 - ACCUMULATOR PISTON Fig. 26 Low/Reverse Accumulator 1 - PISTON RS 40TE AUTOMATIC TRANSAXLE 21 - 133 40TE AUTOMATIC TRANSAXLE (Continued) |
