control operation. The incoming voice is broadcast
through the vehicle’s radio speakers, automatically
overriding any other audio signals on the front
speakers when the hands-free system is in use. A
microphone in the rearview mirror picks up vehicle
occupant’s voices.

The system will communicate with a telephone

that is anywhere within the vehicle. However, cover-
ing the hand held phone or the hands-free phone
module with a metal object may block the signal. The
system will recognize up to seven telephones, each of
which is given a spoken identification by the user
during the setup process. The system includes Span-
ish voice recognition in addition to English.

Two buttons on the rearview mirror, identified with

ISO icons, control the system: A

9phone9 button turns

the system on and off; a

9voice recognition9 (or voice

command) button prompts the hands-free system to
listen for a voice command.

OPERATION

TELECOMMUNICATION

Two buttons on the rearview mirror, identified with

ISO icons, control the system: A

9phone9 button turns

the system on and off; a

9voice recognition9 (or voice

command) button prompts the hands-free system to
listen for a voice command. The system includes the
following features:

• Phone book - Stores telephone numbers for later

recall by name or other verbal identification, called a
voice tag, and memory location.

• Four memory locations - Home, Work, Cellular

and Pager. A maximum of 32 unique names or voice
tags may be stored at the same time, with a different
number in each of the four memory locations.

• Voice tag dialing - Dials the number associated

with a voice tag and memory location.

• Digit dialing - Dials the telephone number by

recognizing the names of the digits as they are spo-
ken.

• Receiving calls - A voice prompt notifies the user

of an incoming call. A voice response accepts or
rejects the call without manual intervention.

• Privacy Mode - Switches the call to the hand-

held telephone and the hands-free system and back
again using the “voice recognition” (or “voice com-
mand”) button and a voice command, if desired.

NAVIGATION/TELECOMMUNICATION

8T - 1

HANDS FREE MODULE

REMOVAL

(1) Disconnect and isolate the battery negative

cable.

(2) Remove the radio (Refer to 8 - ELECTRICAL/

AUDIO/RADIO - REMOVAL).

(3) Remove the mounting fasteners (Fig. 1).
(4) Disconnect the electrical harness connector and

remove module.

INSTALLATION

(1) Connect electrical harness connector and posi-

tion module.

(2) Install mounting fasteners.
(3) Install radio (Refer to 8 - ELECTRICAL/AU-

DIO/RADIO - INSTALLATION).

(4) Connect battery negative cable.

Fig. 1 HANDS FREE MODULE

8T - 2

NAVIGATION/TELECOMMUNICATION

WIRING

TABLE OF CONTENTS

page

LOCATION . . . . . . . . . . . . . . . . . . . . . . . . 8W-91-1

POWER DISTRIBUTION . . . . . . . . . . . . . . . 8W-97-1

WIRING

8W - 1
