Chery S11 / Chery QQ. Manual - part 284

Notices Before Drive

Notice

Do not adjust the driver seat during
driving so as to prevent the car to
be out of control.

The looseness of the seat belt will
reduce its protection function.

Adjust the front seats before tying
the seat belt.

Do not leave anything under the
seat which will disturb the seat
adjustment organ.

Front Seat Tilt
Adjustment

Pull up the
joystick at
the side of
the seat to
adjust the
backrest to
an ideal
angle, and
then loose
the
joystick.

Notice

Do not adjust the backrest when driving.
Do not tilt the seat too much to prevent
the seat belt slide. Adjust the backrest to a
vertical angle for max protection
functions.

Headrest

The headrest is designed to decrease the
danger of hurting the cervix. You can
adjust its altitude by pulling up or press
down it.

Notice

The headrest is to prevent any hurt. Do
not drive before adjusting it. Adjust its
altitude so that the back of the head can
touch the middle part of the headrest.
After the adjustment, fix the position of
the headrest. Please make sure the
headrest has been adjusted and fixed to
the right position before drive.

Notices Before Drive

Disassembly the headrest:
l

Pull the headrest up to the highest
position.

Insert a small screwdriver into the
notch of the left guide bushing.

Touch the head of the stop perch
with the screwdriver and pull the
headrest out from the bushing.

Folding Backseat
Backrest

Fold down the backrest to increase the
space of the trunk.
Folding process:
l

Lift the seat cushion to vertical.

Pull up the lock button on the seat
backrest, loose the backrest, and
fold in the direction of front and
down.

If you want the seat backrest get
back to the vertical position, just
pull up the backrest and pull the
backrest to the proper position.

If you want the cushion back to the
original position, just put it to a
proper position and pull and press
to the lock position.

Notice

Do not pile any goods on the back
seat because it may cause damage
when the goods moving.

Notice when the backseat get back
to the vertical position:

1. Checks whether the seat backrest

and seat cushion have been locked at
a firm position by pushing or
pulling.

2. Ensure that the seatbelt is not

twisted or stuck in the seat backrest,
and place it at a proper position.

Notices Before Drive

Seat Belt Precaution
Measure

To protect the passenger, the entire
passenger must correctly use seatbelt
during driving. One seatbelt for only one
person, and those children under 6 years
old are not suitable to use seatbelt, and
you should assembly proper child seat or
assistant cushion for your child.

Notice

Passengers may get hurt in a collision or
emergency stop, so they must use seatbelt
at anytime. Do not use one belt by several
people. Do not put anything hard or
fragile in the pocket or clothes clinging to
the seatbelt. Misusage of the seatbelt will
cause serious damage. Do not change the
seatbelt or attach any equipment which
will affect the employment of the seatbelt.
The worn seatbelt can not be used any
more which will probably affect the
safety of the people.

When using a seatbelt, please use it and
maintain the belt and child protection
system with correct method in order to
decrease the damage to the people in a
collision or emergency stop.

Notice

Misusage of the seatbelt may cause
damage or even death to people. The
seatbelt should be firm and the seat
backrest should be adjusted to vertical.
Do not lean on the backrest when driving
the car. Do not use it if the belt twisted.
Do not tie the belt cross down the arm
which should be at the middle of the
shoulder, and also do not wrap it around
the head or neck. Tie it clinging to the
buttocks but not waist. If the seatbelt tied
too loosely, it will increase the rate of
hurt to people because the body will slide
under a loose belt. The loose button of
the seat belt should face outside. Insert
the pin of the belt into the appointed
connection lock. Do not put anything at
the shield board hatch of the seatbelt to
prevent it from getting stuck. If it gets
stuck, the only way is to entangle the
entire belt into the reel and then pull the
ideal length out according to the need.

Maintenance of the Seat
Belt

The seat belt should be maintained clean
and dry, avoiding any pollution by
polishing composition, oil, chemical,
especially by the acid of the accumulator.
Please wash with litmusless soap. Do not
blanch or dye the belt which will
probably do harm to the belt. Prevent the
seat belt from any sharp-edged things.
Check the belt regularly for any damage
and replace those worn ones in time. The
over strained belt should be replaced after
an accident. Chery suggests replacing
all the components of the seatbelt after
a collision. But after a slight collision, if
the Chery Service Station does not check
out any damage, and all the components
can work normally, there is no need to
replace. If there is any damage or false
with the seat belt and its components
which has not been used in an accident,
they also need to be tested and replaced if
necessary.

Notice

The worn seat belt may cause serious
damage, so check the seat belt

components regularly. After a collision,
you must take all the seat belt
components to the Chery Service Station

for a check and replace them according to
the need. If the belt has been damaged or
polluted, it must be replaced. After a

Notices Before Drive

serious collision, the seat belt
components must be replaced no matter
there is evident damage or not. If the seat
belt is not suitable, it will arouse much
more serious damage. Do not change
seatbelt at will.

For pregnant woman
Suggest the pregnant woman to refer to
the doctors for the usage before using the
seatbelt.

Notice

In order to avoid any damage to the
pregnant woman and the infant during the
travel, please use “three points on the
cross” connected seatbelt if possible and
tie it as low as possible to cross the entire
pregnant position (refer to the doctor).

Children Protection
System

Be sure to use proper children protection

system when bringing any infants or
children.
The children protection system should be
assembled on the seat according to the
height and weight of the child.
Status shows that proper children
protection system will be safer if it is
assembled on the back seat rather than
the front seat.

Notice

Infants and children should be kept in the
children protection system. Do not
assembly the backward children
protection system on the front seat with
air bag.

If the children protection system is
assembled on the front seat, child will
probably be seriously hurt when the air
bag charged and inflated.
Please assembly the children protection
system on the back seat as possible as
you can. If it must be assembled on the
front passenger seat, the seat should be

adjusted back as possible.

Notice

Assembly the children protection
system according to the instruction
provided by the manufacturer.

Tie is firmly or remove it when
there is no use.

Do not hold your child in arm when
riding on the car.

If the children protection system is too
small for your child, just let him or her sit
on the back seat and tie up the seat belt. If
the child sit at the position with crossed
seat belt, and the belt is close to his or her
face or neck, you should move the child
to the middle, that is lean to the inner part
of the belt, and put your child at a place
without crossed seat belt if possible.

Three point seat belt

There is three points seat belt with brake
limit on every Chery car. Although the

spring-plugged seat belt is cooperated
well, the body is permitted to move freely
during a smooth running.

There is a sensitive reel on the seat belt
which is used to lock the seat belt in
violent acceleration and deceleration.
