Notices Before Drive

10

Notice

Children at the backseat may open the
back door unexpectedly.
1

 Move the children security lock pin

to the locking position.

2

 Do not pull the inner handle of the

door when the children security lock
has been locked so as to prevent any
damage to the handle.

Burglarproof No-Key
Entering System

No-Key Entering System can open the

door in a distance of 6 meters through a
sensor. The LBD on the sensor lights up
to indicate the sensor in operation.

1

LOCK button:Lock all doors. When

danger signal light has glittered 3 times,
the burglarproof system is in operation.

2

UNLOCK button: Open all doors.

When danger signal light glittered twice,
the burglarproof system is closed.

Notice

The effective range of the sensor will
change with environment.

Activating door Lock
and Burglarproof Mode

l

Close all the windows;

l

Turn ignition key to B, and pull out
the key;

l

Let all passengers get off the car.

l

Close all doors and hoods and trunk
lid.

l

Press down the LOCK button on
the sensor so as to lock all of the
doors. Those cars equipped with
power window lifting system will
automatically raise all windows,
and at the same time hazard
warning lamp glitters 3 times and
the burglarproof mode is started.

l

If the ignition switch is set on II,
the burglarproof mode does not
work but the function of locking
still work normally.

Notice

If you use key to lock the door, the
burglarproof mode can not be activated.
Please use sensor if you want to activate
that mode.

Lock

Unlock

Notices Before Drive

11

Relief of Door Lock and
Burglarproof Mode

Press UNLOCK button on the sensor to
unlock all doors and hazard warning lamp
glitters twice at the same time,
burglarproof mode is exited.
Normal status: If there is not interruption
and fault, hazard-warning lamp will
glitter twice, and the interval between
each glitter is 0.5 sec.

Replace Sensor Battery:

Sensor indicator lamp does not glitter,
which means that battery needs to be
replaced, but sensor can still be used for a
period of time.
Replace a Panasonic CR2032 battery ( or
other equivalent 3V battery) in following
process:
l

Insert a screwdriver into the gap
between the sensor cover and
separate the 2 covers of the sensor.

l

Insert a screwdriver into the gap
between the sensor covers and
separate them.

l

Pull the sensor power supply out of
the cover and disconnect the
attachments carefully and put it at a
clean place.

l

Install new battery, make sure that
the polarity is correctly
placed(cathode facing bottom)

l

Install the attachments and put the
sensor power supply into the cover.

l

Close the two covers of sensor.

l

Check whether the sensor can work
properly.

Notice

The waste Li-battery will do harm to the
environment:

l

Do not drop the waste battery as
living garbage;

l

Dispose the waste battery according
to the local reclaim regulations.

l    Sensor might be damaged

l   Do not reverse the polarity of the

sensor

l    Prevent falling

l   Do not lay anything heavy on the

sensor

l    Do not let the sensor touch water or

be exposed to straight sunlight

l

If the sensor get wet, clean it with a
soft piece of cloth

Power Window Switch

When the ignition switch is set to “II”,
we can operate power window through
power window switch on the inner handle.
Press down the top of switch, window
glass will fall. while pulling up the top of
switch, window glass will rise. Loose the
switch when window glass reaches to an

ideal position.

Accumu

lator

Notices Before Drive

12

Notice

l

Pull off the ignition key when
leaving the car so as to prevent any
unnecessary hurt to the children
caused by their operation when left
alone.

l

Do not spread hands, head or any
other thing out of the window.

l    The unexpected close of the window

will cause serious damage, so do
not let the children play with the
electric window switch.

Manual Sunshade-Roof

Operate with your hands to tilt sun shade
roof up.
Before doing this, check whether roof
antenna is at a proper position.
Pull forward to open it.
Press the button and raise

sunshade

roof

to an ideal position.

Press the button again and pull down

sunshade roof

 handle to close the

sunshade roof.

Notice

The sun shading top can not open when
there is sundries on it.
l

Clean the top before open it.

l

Eliminate the water drops, snow,
ice and sands before opening the
sun shading top.

l

Do not place anything heave on the
sun shading top or around. Please
close the sun shading when leaving
the car alone.

Outer Rearview Mirror

Adjust the outer rearview mirror to see
both sides of the road clearly and confirm
the position of the things you saw. Move
the outer rearview mirror to an ideal
position (for the movable lens) or use
adjustment button (for the joystick)
directly so as to adjust the angle of the
mirror.

Notices Before Drive

13

The outer rearview mirror at the
passenger side is a convex, so things you
see in it will be closer than what it is
actually. Use this mirror you can watch
much wide of the road behind you. When
entering a narrow roadway or washing
your cars, you can push back the mirror
which will properly collapse to the body.

Notice

The around line of sight might be
weakened which will increase the
possibility of accidents. Please adjust the
angle of the rearview mirror and check
whether there is any damage on the
mirror. Use defroster, atomizer and
blower to eliminate the ice and frost.
The outer rearview mirror shows thing

closer, so use inner rearview mirror to
clear the rear line of sight. Do not block
the rearview range from the driver seat.

Inner Rearview Mirror

The inner rearview mirror can be moved
up and down as well as left and right so
as to get the best line of sight.
There are 2 positions for the inner rear
view mirror which are daytime and night.
During daytime the high speed joystick
should be moved to daytime position. At
night the joystick should be adjusted to
“Night” position to weaken the beam of
the headlight of the cars behind.

Notice

To maintain the rearview range of the
driver, choose daytime and high speed for
the best line of sight. If you choose night
position, it will decrease the definition of
the rearview mirror.

Front Seat Slipping
Adjustment

Draw up the control joystick under the
front seat and slip it to an ideal position,
then loose the joystick.
