Chery QQ Maintenance Manual 372 EFI System
Yes Next
12 Shut off fuel gauge valve. Connect ignition key
again to run fuel pump for 3 seconds. Check if
fuel pressure can be set up.
No 14
Yes Replace
pressure
regulator
13 Open fuel gauge valve, use return fuel
blocker to clamp fuel pipe for no returning fuel.
Check if fuel pressure can be set up soon。
No
Repair and replace
injector or fuel pipe
Yes
Repair or replace fuel
inlet
14 Check if fuel pipe is leaked or blocked.
No
Replace fuel pump
Yes
Repair or replace
returning fuel pipe
15 Check returning fuel pipe is blocked or bend
No Replace
pressure
regulator
Yes Next
16 Check if the date of MAP or IAT are normal。
No Replace
sensor
Yes Next
17
Check if ignition coil,distrbutor,high voltage
wire and spark plug are normal
No
Replace or adjust
Yes
Check A/C system
18 Check if A/C system is malfunction.
No Replace
ECU
15）A/C system malfunction
Yes Next
1
Check if there is full coolant and check if A/C
belt,A/C clutch ,pressure switch are narmal
No Eliminate
malfunction
Yes Eliminate
malfunction
2
Turn on A/C switch in engine idle.Check if A/C
thermistor is malfunction
No Next
Yes Next
3
Turn on A/C switch. Connect adaptor between ECU
and harness.Check if output signal for ECU pin 50
and 58(A/C switch) is normal
No Check
harness
Yes
Replace bulb or
repair harness
4
If the vehicle is low-level contro, check if A/C can
working when turn off A/C.
No Next
Yes Repair
A/C
relay and
harness
5
Check if output low-level for ECU pin 68(connect
earthing terminal of A/C relay pull-in coil)
No Replace
ECU
