保养手册



Distance reading（Km）

Maintenance item

7500 15000

30000

level

Hand brake: Check stroke, adjust if necessary



★



★



Brake friction disc: Check thickness

★



★



★



Vehicle bottom protector: Range estimate damage





★

Safety belt: Check to see if it is damaged.



★



★



Teo-in



value,Camber angle: Check, adjust if necessary



★



★



Rear wheel bearing: Check clearance and lubrication



★



★



Ball stud: Check clearance



★



★



Rear camshaft rubber hinge: Check to see if it is damaged



★



★



Engine oil pan bolt: Check to see if it is loose, tighten if necessary





★

Control arm rubber cap: Check to see if it is damaged



★



★



Braking hose: Check ageing or damage





★

Braking hard pipe: Check damage, corrosion and joint leakage





★



保养手册  Maintenance Manual



Distance reading（Km）

Maintenance item

7500 15000

30000

Joints for fuel system: Check ageing, damage or abnormal loose and abrasion





★



Tire(including spare tire): Check tread pattern depth, adjust tire pressure, check tire bolt full-load torque

★



★



Change of position for tires





★



Joint bolt for chassis and vehicle body: Check to see if it is    loose, tighten if necessary

★



★



★



Tire: Check to see if it is loose, oil leakage for rear wheel bolt bearing

★



★



★



CO content during slack drive: Check, adjust if necessary

★



★



★



Trial drive: Check function for all system



★

★

Besides above items, for manual transmission vehicle, replace brake fluid for every 2 years or 50000 km, replace transmission gear oil for

every 1 year or 50000 km. For automatic transmission vehicle, replace transmission gear oil for every 1 year or 30000 km, replace timing

chain for every 40000 km.











保养手册







    CHERY







Service Center

(stamp)

Vehicle data



Vehicle Owner:_____

Company (name):_

Address:_______________________

Tel:_______________________

E-MAIL：_____________________

Vehicle purchase date:_____

Use purpose:__________

Nameplate number:_____



Vehicle chassis
Number











Model











Vehicle

description























Engine number/
Transmission number











Paint number/Inner
parts











Optional

parts



First 2500 km Free

Maintenance Card


Date:____
Distance Reading:_
Use purpose:__
Nameplate Number:___


Service Station (stamp)

Vehicle owner (signature):_
