Instrument Panel
25
Attention:
The size of tires will affect the
speedometer. Please use the approved tires
by Cherry Special Service Center.
Otherwise, the speedometer may not show
the accurate speed.
Odometer, Digital Clock
Actual gear is showed in the left part of
the odometer. Total mileage is showed in
the lower right part. Time and trip meter
are showed in the upper right area.
Time can be displayed in two different
formats: clock and digital
The switch between time and trip meter
display and adjustment:
To switch time to trip meter display, press
reset button in panel.
Ÿ
To reset the trip meter to zero, you
can press the reset button for long
period of time when trip meter
displays.
Ÿ
To reset time, you can press the reset
button for long period of time when
time displays.
Tachometer
It indicates engine’s rotational speed
(RPM)
The red area shown in gauge is the highest
speed the engine can reach in short time
under operating temperature after break-in
period.
However, it is recommended that shifting
into the next gear or releasing gas pedal
