205

uu

Audio System

u

Audio System Theft Protection

Features

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead. In certain conditions, the system
may display a code entry screen. If this occurs, reactivate the audio system.

■

Reactivating the audio system

1.

Set the power mode to ON.

2.

Turn on the audio system.

3.

Press and hold the audio system power knob for more than two seconds.

u

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognize
the audio unit, you must go to a dealer and have the audio unit checked.

206

uu

Audio System

u

Audio Remote Controls

Features

Audio Remote Controls

Allow you to operate the audio system while driving. The information is shown on
the multi-information display or head-up display

*

.

VOL

(

+

/VOL

(

-

 (Volume) Switch

Press Up:

To increase the volume.

Press Down:

To decrease the volume.

 (Power) Button

Press to turn the audio system on and off.

Left Selector Wheel

•

When selecting the audio mode
Press the

APPS

 button, then roll up or down to select an item on the multi-

information display or head-up display

*

, and then press the left selector wheel.

Move the left selector wheel to the right to display the

Recents

 list, then scroll to

an item selected in the past and press the wheel.

1

Audio Remote Controls

Some modes appear only when an appropriate
device or medium is used.

Depending on the

Bluetooth

®

 device you connect,

some functions may not be available.

Press the

 (back) button for the multi-

information display or head-up display

*

 to go back to

the previous screen or cancel a command.

Press the

APPS

 button to go back to the menu screen

of the multi-information display or head-up display

*

.

Recents

 list is available when the following audio

mode is selected.

•

FM Radio

•

AM Radio

•

SiriusXM

•

USB Audio

Models with head-up display

 (Power) Button

VOL

(

+

/

VOL

(

-



(Volume) Switch

 (back) Button

Left Selector

Wheel

APPS

 Button

Models with head-up display

* Not available on all models

207

uu

Audio System

u

Audio Remote Controls

Features

Roll up or down:

To cycle through each modes, roll up or down and then press the left selector
wheel:

After an audio mode is selected, the left selector wheel can be operated for the
following functions.

•

When listening to the radio

Move to the right:

To select the next favorite radio station or channel.

Move to the left:

To select the previous favorite radio station or channel.

•

When listening to an iPod, USB flash drive,

Bluetooth

®

 Audio, or Smartphone

Connection

Move to the right:

To skip to the next song.

Move to the left:

To go back to the beginning of the current or previous song.

1

Audio Remote Controls

You can customize the items on multi-information
display or the head-up display

*

.

2

Customizing the Meter or Head-Up
Display

*

 P. 223

You cannot operate the audio functions while the
following functions are being operated on the multi-
information display or head-up display

*

.

•

Mode selection by pressing

APPS

 button

•

Navigation

*

•

Phone

•

Select Driving View

*

•

Customize Apps

Navigation

*

Phone

Select Driving View

*

Customize Apps

Audio Modes

(

FM Radio

,

USB Audio

, etc)

* Not available on all models

208

Features

Audio System Basic Operation

You can use the audio system for 30 minutes when the power mode to VEHICLE OFF
(LOCK) with the driver’s door closed, the system will then turn off automatically.
If you want to keep using it, we recommend that you turn the power mode to
ACCESSORY or ON.

VOL

 (Volume/Power) Knob:

Push to turn the audio system on and off. Turn to

adjust the volume when audio system is on.

/

 (Seek/Skip) Button:

Press to change station, channel, song or file.

 (Back) Button:

Press to go back to the previous display when it is displayed.

 (Home) Button:

Press to go to the home screen.

 (Cards List) Button:

Press to display the cards list of the B-zone on the audio/

information screen.

2

B-Zone

 P. 214

A-Zone Touchpad:

Click or swipe the pad with your finger, or move your finger

along the pad to operate the A-zone on the audio/information screen.

B-Zone Touchpad:

Click or swipe the pad with your finger to operate the B-zone

on the audio/information screen.

1

Audio System Basic Operation

True Touchpad Interface

2

True Touchpad Interface

 P. 209

A-Zone

2

A-Zone

 P. 212

B-Zone

2

B-Zone

 P. 214

/

 (Seek/

Skip) Button

VOL





(Volume/Power)

Knob

 (Home) Button

 (Back) Button

 (Cards List)

Button

A-Zone Touchpad

B-Zone Touchpad

209

uu

Audio System Basic Operation

u

True Touchpad Interface

Continued

Features

True Touchpad Interface

You can operate the system using True Touchpad Interface.

■

Click

Lightly press A-zone touchpad to select an
item.

■

Press and hold

Press and hold to initiate edit mode
throughout the system.

■

Swipe

Swipe or drag your finger in various directions
to operate each screen.

■

A-Zone Touchpad Operation

1

True Touchpad Interface

True Touchpad Interface

•

Some items may be grayed out during driving to
reduce the potential for distraction.

•

You can select them when the vehicle is stopped or
use voice commands.

•

Wearing gloves may limit or prevent True
Touchpad Interface response.

•

Some electronics like inverters may cause slow
response while using the True Touchpad Interface.

You can operate the True Touchpad Interface using
gloves when you set the

Touchpad Sensitivity



setting to

High

. However, the True Touchpad

Interface cannot be operated with insulated gloves.

2

Customized Features

 P. 300

210

uu

Audio System Basic Operation

u

True Touchpad Interface

Features

■

Flick

Flick (or drag) your finger up/down or left/
right to scroll in lists or change pages
throughout the system.

■

Hand-writing a character

Move your finger quickly to trace a character
on the A-zone touchpad.

■

Swipe with two fingers

Swipe (or drag) two fingers across the screen
to move the map.

Models with navigation system

211

uu

Audio System Basic Operation

u

True Touchpad Interface

Features

■

Click

Lightly press (click) the B-zone touchpad to
select a card.

■

Swipe

Swipe or drag your finger up or down to select
an item.

■

Flick

Flick up or down to cycle through card
displayed in the B-zone.

■

B-Zone Touchpad Operation

212

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Audio/Information Screen

Displays each mode status. From this display, you can go to various setup options.

■

Switching the display

Press the

 (home) button to go to the home screen.

Select the following icons on the home screen or

All Apps

 list.

■

Navigation

*

Displays the navigation screen.

2

Refer to the Navigation System Manual

■

Phone

Displays the HFL information.

2

Bluetooth

®

 HandsFreeLink

®

 P. 327

■

FM Radio/AM Radio/SiriusXM/USB Audio/Bluetooth Audio/AUX Input

Displays the audio information for each.

■

A-Zone

1

Audio/Information Screen

All Apps

 list

You can select any of the apps from the

All Apps

 list.

To display the

All Apps

 list, place your finger on the

True Touchpad Interface and swipe right.

2

Home Screen

 P. 216

You can add or remove any of the apps in the home
screen through the

All Apps

 list.

2

To add app icons to the home screen and
the head-up display

*

 P. 217

Home Screen

A-Zone

* Not available on all models

213

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

■

Settings

Enters the customizing menu screen.

2

Customized Features

 P. 300

■

Apple CarPlay

Displays the

Apple CarPlay

 screen.

2

Apple CarPlay

 P. 266

■

Android Auto

Displays the

Android Auto

 screen.

2

Android Auto

 P. 270

■

System Updates

Updates the software version of the audio system.

2

System Updates

 P. 225

■

Messages

Displays the text message screen.

2

Text Message

 P. 345

■

AT&T HotSpot

Displays the AT&T Hotspot screen.

2

AT&T Hotspot

 P. 264

■

AcuraLink

Displays the AcuraLink screen.

2

AcuraLink

®

 P. 356

uu

Audio System Basic Operation

u

Audio/Information Screen

214

Features

You can see the audio, HFL information, navigation mini map

*

, and clock

information on the B-zone using the B-zone touchpad.

■

Switching the card

Swipe up or down the B-zone touchpad to cycle through the following screen.

■

B-Zone

1

B-Zone

SiriusXM

®

 radio service notifications are displayed in

the B-zone.

B-Zone

1

Switching the card

The card in the B-zone will change depending on the
screen displayed in the A-zone.

*1: Appears only when you set a destination on the
Apple CarPlay or Android Auto navigation function.

2

Apple CarPlay

 P. 266

2

Android Auto

 P. 270

Models without navigation system

Now Playing Audio

Navigation

*1

Clock

* Not available on all models

215

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

You can also switching the screen by following procedure.

1.

Press the

 (cards list) button.

2.

Select an item then press the B-zone
touchpad.

uu

Audio System Basic Operation

u

Audio/Information Screen

216

Features

■

To change to a next screen

Swiping A-zone touchpad left or right takes you to the next screen.

■

Home Screen

1

Home Screen

The home screen has 2 pages. You can add up to 8
pages.

Press the

 (home) button to go directly back to

the first page of the home screen from any page.

Current Page Position

A-Zone Touchpad

Swipe left to go to

the additional pages

of the home screen.

Swipe right to

display the

All Apps



screen.

Continued

217

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To add app icons to the home screen and the head-up display

*

You can add app icons to the home screen and the head-up display.

1.

Press the

 (home) button.

2.

Swipe right to display the

All Apps

 screen.

3.

Go to an app on the list, then press and
hold A-zone touchpad.

4.

From the pop-up menu, select

Add to

Home Page

 or

Add to Heads-Up

Display

*

.

u

The

icon

or

HUD

*

 appears next to

the app on the list when the
corresponding icon has been added to
the home screen or head-up display.

1

To add app icons to the home screen and the head-up display

*

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

2

Defaulting All the Settings

 P. 323

If you perform

Factory Data Reset

, it may reset all

the settings to their factory default.

2

Defaulting All the Settings

 P. 323

In case those apps still do not startup normally, even
after

Factory Data Reset

, contact your dealer.

Each item with

HUD

 is listed on the head-up display

menu.

If you want to hide the item from the head-up display
menu, select

Remove from Heads-Up Display

.

Models with head-up display

* Not available on all models

uu

Audio System Basic Operation

u

Audio/Information Screen

218

Features

■

To add shortcut icons to the home screen and the head-up display

*

Shortcut icons for items stored in Favorite can be added to the home screen and the
head-up display.

1.

Select a favorite item, then press and hold
A-zone touchpad.

u

A pop-up menu will appear on the
screen.

2.

Select

Add to Home Page

 or

Add to

Heads-Up Display

*

.

u

A short cut icon will be added to the
home screen or the head-up display.

1

To add shortcut icons to the home screen and the head-up
display

*

You can add an icon to the head-up display directly
from the home screen. Select an icon on the home
screen, then press and hold the A-zone touchpad.
After that, select

Add to Heads-Up Display

, and

then press the

 (back) button or the

 (home)

button to confirm the change.
Note that icons for

Messages

,

Settings

, and

System Update

 cannot be added to the head-up

display.

Models with head-up display

* Not available on all models

Continued

219

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To move icons on the home screen

You can change the location of the icons on the home screen.

1.

Select the icon you want to move, then
press and hold A-zone touchpad.

u

The screen will change to the
customization screen.

2.

Drag the icon to where you want it to be
and then press and hold the A-zone
touchpad.

u

The icon will be repositioned and the
screen will remain in the customization
mode.

u

After you drag the icon, keep your finger
on the A-zone touchpad and then press
down. If you release your finger before
pressing the A-zone touchpad, the icon
will remain in its original place.

u

If you want to reposition the icon on
another page of the home screen, swipe
the A-zone touchpad.

3.

Press the

 (back) button or the



(home) button to confirm the change.

1

To move icons on the home screen

Press and hold

 (home) button to switch to the

customization screen.

Select and hold.

Drag and drop.

uu

Audio System Basic Operation

u

Audio/Information Screen

220

Features

■

To remove icons from the home screen and the head-up display

*

You can remove icons from the home screen and the head-up display.

1.

From the home screen, select the icon that
you want to remove, then press and hold
A-zone touchpad.

u

The screen will switch to the
customization screen.

2.

Go to

Remove from Home Page

 or

Remove from Heads-Up Display

*

 and

press the A-zone touchpad.

u

The icon will be removed from the home
screen or the head-up display, and the
screen will remain in the customization
mode.

3.

Press the

 (back) button or the



(home) button to confirm the change.

You can also remove an icon from the home
screen or head-up display directly from the

All

Apps

 list.

1.

Go to an item you want to remove, then
press and hold the A-zone touchpad.

2.

Go to

Remove from Home Page

 or

Remove from Heads-Up Display

*

 and

press the A-zone touchpad.

u

The icon will be removed from the home
screen or the head-up display.

3.

Press the

 (back) button or the



(home) button to confirm the change.

1

To remove icons from the home screen and the head-up display

*

Removing an icon from the home screen does not
result in the deletion of the corresponding app.

Press and hold

 (home) button to switch to the

customization screen.

If you remove a shortcut icon from the home screen,
the function of selected icon also remove from the
head-up display.

Models with head-up display

Select and hold.

* Not available on all models
