uu

HomeLink

®

 Universal Transceiver

u

Training HomeLink

366

Features

■

Programming a Button

1

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from

orange to rapidly flashing green

.

This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simple press and release the
programmed HomeLink button. Activation will now
occur for the trained device.

Questions
For questions or comments, visit

www.HomeLink.com

,

www.youtube.com/

HomeLinkGentex

, or by calling the HomeLink Hotline

(North America only) at (800) 355-3515.

HomeLink

®

 is a registered trademark of Gentex

Corporation.

2.

1.

Press and hold the desired HomeLink button until
the HomeLink indicator begins to

slowly flash

orange

. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Training
Complete

HomeLink LED is

continuously on green

.

YES

YES

1.

Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the
HomeLink

®

 button you want to program.

3b.

Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from

slowly flashing orange to

rapidly flashing or continuously on
green

? The process should take less

than 60 seconds.

NO

2.

Press and hold the desired HomeLink button. Is the HomeLink indicator (LED)

slowly

flashing orange

?

NO

3a.

Hold the button on the remote
transmitter. Does HomeLink indicator
(LED) change from

slowly flashing

orange to rapidly flashing green or
continuously on green

? The process

should take less than 60 seconds.

5.

Press and hold the HomeLink button again.

HomeLink indicator

rapidly flashes

green

.

5a.

The remote has a rolling code. Press the
“learn” button on the remote-controlled
device (e.g. garage door opener).

6.

Press and hold the HomeLink button
again.
The remote-controlled device should
operate.

Training Complete

5b.

Within 30 secs, press and hold the
programmed HomeLink button for 2
secs.

4.

Press and hold the programmed HomeLink
button for about a second. Does the device
(garage door opener) work?

367

Continued

Features

Bluetooth

®

 HandsFreeLink

®

Bluetooth

®

 HandsFreeLink

®

 (HFL) allows you to place and receive phone calls using

your vehicle’s audio system, without handling your cell phone.

Using HFL

■

HFL Buttons

1

Bluetooth

®

 HandsFreeLink

®

Place your phone where you can get good reception.

To use HFL, you need a

Bluetooth

-compatible cell

phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

•

U.S.: Visit

www.handsfreelink.com/Acura

, or call 1-

888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-855-490-7351.

To use the system, the

Bluetooth

®

 setting must be

On

.

2

Phone Setup

 P. 373

Voice control tips

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphones.

•

Press the

 button when you want to call a

number using a phonebook name or a number.
Speak clearly and naturally after a beep.

•

If the microphone picks up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, use the audio system’s
volume or use the audio remote controls on the
steering wheel.

 (Talk) Button

Microphone

 (Back) Button

VOL

(

+

/

VOL

(

-

 (Volume) Switch

Left Selector Wheel

APPS

 Button

uu

Bluetooth

®

 HandsFreeLink

®

u

Using HFL

368

Features

Left Selector Wheel:

•

Incoming call:

Move the selector wheel to the right to answer the call. Move it

to the left to decline the call.

•

During a call:

Move the selector wheel to the right to display the call options

menu. Move it to the left to end the call.

•

 (back) button:

Press the button to go back to the previous screen or to

cancel a command.

•

 (talk) button:

Press the button to start voice recognition.

To go to the phone screen of the multi-information display or the head-up display

*

:

1.

Press the

APPS

 button on the steering wheel.

2.

Using the selector wheel, scroll to

Phone

 on the multi-information display or the

head-up display

*

, and then press the left selector wheel.

u

You can select

Favorites

 or

Recents

 by moving the selector wheel to the left

or the right.

1

Bluetooth

®

 HandsFreeLink

®

Bluetooth

®

 Wireless Technology

The

Bluetooth

®

 word mark and logos are registered

trademarks owned by

Bluetooth

 SIG, Inc., and any

use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

* Not available on all models

Continued

369

uu

Bluetooth

®

 HandsFreeLink

®

u

Using HFL

Features

The audio/information screen notifies you when there is an incoming call.

Bluetooth

®

 connection status is displayed in the B-zone.

■

HFL Status Display

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

HFL Mode

Caller’s Name (If registered)/
Caller’s Number (If not registered)

Bluetooth

 Indicator

Appears when your phone is connected to HFL.

Signal Strength

Battery Level Status

370

uu

Bluetooth

®

 HandsFreeLink

®

u

Using HFL

Features

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

■

Limitations for Manual Operation

*

* Not available on all models

371

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use the system.

■

Phone screen

1.

Press the

 (home) button.

2.

Select

Phone

.

1

HFL Menus

To use HFL, you must first pair your

Bluetooth

-

compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving.

Display the last outgoing, incoming and missed calls.

Recents

All

Dialed

Received

Display the last outgoing calls.

Display the last incoming calls.

Missed

Display the last missed calls.

Enter Number

Enter a phone number to dial.

Contacts

Display the phonebook of the paired phone.

Add Favorite

(Favorite Contact List)

MENU

From Recents

From Contacts

Using Enter Number

Dial the selected number in the favorite contact list.

Display the

Phone Menu

 screen.

Select a phone number from the call history to store as a
favorite contact number.
Select a phone number from the phonebook to store as a
favorite contact number.
Enter a phone number to store as a favorite contact number.

372

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

Phone Menu screen

1.

Press the

 (home) button.

2.

Select

Phone

.

3.

Select

MENU

.

Change Connected Phone

+ Connect New Device

Pair a new phone to the system.

Connect or disconnect a paired device.

Ringtone

Select the ring tone.

Auto Sync Phone

Set phonebook and call history data to be automatically imported when a phone is paired to HFL.

Auto Phone Call Transfer

Set calls to automatically transfer from your phone to HFL when you enter the vehicle.

AcuraLink Assist

Turn AcuraLink Assist on and off.

Options

Delete Device

Automatically

Download Updates

Delete a paired device.

Turn automatic download
function of the software
on and off.

Options

Turns the

Bluetooth

®

 on and off.

(Existing entry list)

Continued

373

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

Bluetooth

®

 setup

You can turn

Bluetooth

®

 function on and off.

1.

Press the

 (home) button.

2.

Select

Settings

.

3.

Select

Connections

.

4.

Select

Bluetooth

.

5.

Select

Options

.

6.

Select

On

.

■

Phone Setup

1

Bluetooth

®

 setup

If there is an active connection to Android Auto, this
setting is unavailable.

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

374

Features

■

To pair a cell phone (when there is no
phone paired to the system)

1.

Press the

 (home) button.

2.

Select

Phone

.

3.

Select

Connect Phone

.

4.

Make sure your phone is in search or
discoverable mode, then select

+ Connect

New Device

.

u

HFL automatically searches for a

Bluetooth

®

 device.

5.

Select your phone when it appears on the
list.

u

If your phone still does not appear,
search for

Bluetooth

®

 devices using your

phone.
From your phone, search for

HandsFreeLink

.

6.

The system gives you a pairing code on the
audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

7.

Select desired functions and then select

Connect

.

u

The pop-up menu appears on the screen,
if the internet wireless hotspot function
is selected.

1

Phone Setup

Your

Bluetooth

-compatible phone must be paired to

the system before you can make and receive hands-
free calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
paired to the system.

Once you have paired a phone, you can see it
displayed on the screen with one or more icons on
the right side.
These icons indicate the following:

: The phone is compatible with

Bluetooth

®

 Audio.

: The phone can be used with HFL.

: The phone can be used with internet wireless

hotspot.

If there is an active connection to Apple CarPlay or
Android Auto, pairing of additional

Bluetooth

®



compatible devices is unavailable.

Enable Smart Sharing pop-up

Smart Sharing to share phone data with Acura, you
can change the setting later by deleting the device in

Phone Menu

.

For detail information of all data shared visit

https://

acuralink.acura.com/#/acuralinkLegalTerms

Continued

375

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To change the currently paired phone

1.

Go to the

Phone Menu

 screen.

2

Phone Menu screen

 P. 372

2.

Select

Change Connected Phone

.

When connecting to other phone:

3.

Select a phone to connect.

4.

Select ,

or  .

5.

Select

Connect

.

When changing the currently paired phone
setting:

3.

Select a currently paired phone.

4.

Select ,

or  .

5.

Select

Apply Changes

.

1

To change the currently paired phone

If there is an active connection to Android Auto, this
setting is unavailable.

If no other phones are found or paired when trying to
switch to another phone, HFL will continue to
connect a original phone.

To pair other phones, select

+ Connect New Device



from the

Bluetooth

 screen.

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

376

Features

■

To delete a paired phone

1.

Go to the

Phone Menu

 screen.

2

Phone Menu screen

 P. 372

2.

Select

Change Connected Phone

.

3.

Select a phone you want to delete.

4.

Select

Options

.

5.

Select

Delete Device

.

6.

A confirmation message appears on the
screen. Select

Delete

.

1

To delete a paired phone

You can also delete a paired phone by the following
procedure.
1. Press the

 (home) button.

2. Select

Settings

.

3. Select

Connections

.

4. Select

Bluetooth

.

5. Select a phone you want to delete.
6. Select

Options

.

7. Select

Delete Device

.

8. A confirmation message appears on the screen.

Select

Delete

.

If there is an active connection to Android Auto, you
cannot delete a paired phone.

Continued

377

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

You can change the ring tone setting.

1.

Go to the

Phone Menu

 screen.

2

Phone Menu screen

 P. 372

2.

Select

Ringtone

.

3.

Select

Vehicle

 or

Phone

.

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1.

Go to the

Phone Menu

 screen.

2

Phone Menu screen

 P. 372

2.

Select

Auto Phone Call Transfer

.

3.

Select

On

 or

Off

.

■

Ring Tone

1

Ring Tone

Vehicle

: The fixed ring tone sounds from the

speakers.

Phone

: Depending on the make and model of the

cell phone, the ring tone stored in the phone will
sound if the phone is connected.

■

Automatic Transferring

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

378

Features

■

When Auto Sync Phone is set to On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to the system.

■

Changing the Auto Sync Phone setting

1.

Go to the

Phone Menu

 screen.

2

Phone Menu screen

 P. 372

2.

Select

Auto Sync Phone

.

3.

Select

On

 or

Off

.

■

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

On some phones, it is necessary to set up it enabled
to be imported the cellular phonebook.

When you select a name from the list in the cellular
phonebook, you can see a category icon. The icons
indicate what types of numbers are stored for that
name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Home

Mobile

Work

Other

Pager

Car

Preference

Fax

Voice

379

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Continued

Features

To store a favorite contact number:

1.

Go to the phone screen.

2

Phone screen

 P. 371

2.

Select

Add Favorite

.

3.

Select a place from where to choose a
number.

From Recents

:

u

Select a number from the call history.

From Contacts

:

u

Select a number from the phonebook of
a cellular phone connected to the
system.

Using Enter Number

:

u

Trace the number on A-zone touchpad,
then press it.
If the

KEYPAD

 icon located to the upper

right of the screen is selected, the
keyboard will appear.

4.

Select a number.

■

Favorite Contacts

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

380

Features

■

To edit a Favorite Contact

1.

Go to the phone screen.

2

Phone screen

 P. 371

2.

Select and hold a desired favorite contact.

3.

Select the following options:

•

Remove Favorite

: Delete the favorite

contact.

•

Add to Home Page

: Add a favorite

contact shortcut icon to the home
screen.

•

Add to Heads-Up Display

*

: Add a

favorite contact shortcut icon to the
head-up display menu.

4.

Press the

 (back) button on the True

Touchpad Interface.

u

The screen will return to the previous
screen.

You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, or Favorite Contact
entries.

■

Making a Call

1

Making a Call

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

While there is an active connection with Apple
CarPlay, phone calls cannot be made with
HandsFreeLink

®

 and are only made from Apple

CarPlay.

* Not available on all models

Continued

381

uu

Bluetooth

®

 HandsFreeLink

®

u

HFL Menus

Features

■

To make a call using the imported
phonebook

1.

Go to the phone screen.

2

Phone screen

 P. 371

2.

Select

Contacts

.

3.

Select a name.

u

You can sort by

First Name

 or

Last

Name

. Select the icon on the upper right

of the screen.

4.

Select a number.

u

Dialing starts automatically.

■

To make a call using a phone number

1.

Go to the phone screen.

2

Phone screen

 P. 371

2.

Select

Enter Number

.

3.

Trace the number on A-zone touchpad,
then press it.

u

You can enter the number using the on-
screen keyboard. Select

KEYPAD

 located

to the upper right of the screen.

4.

Press the A-zone touchpad.

u

Dialing starts automatically.

u

If the on screen keyboard is displayed,
select

Call

.

1

To make a call using the imported phonebook

You can send a message or set a navigation

*

 route to

contact address other than making a call on this
feature.

2

Text Message

 P. 385

2

Refer to Navigation System Manual

* Not available on all models
