uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

498

Main

tenan

ce

■

Maintenance Service Items

1

Maintenance Service Items

•

Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.

•

Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.

Maintenance Minder Message

System Message
Indicator

Main Item

Sub Items

499

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

*1: If a message

Maintenance Due Now

 does not appear more than 12 months after the display is

reset, change the engine oil every year.

# : See information on maintenance and emissions warranty.

CODE

Maintenance Main Items

A

•

Replace engine oil

*1

B

•

Replace engine oil

*1

 and oil filter

•

Inspect front and rear brakes

•

Check expiration date for temporary tire repair kit
bottle (if equipped)

•

Inspect tie rod ends, steering gearbox, and boots

•

Inspect suspension components

•

Inspect driveshaft boots

•

Inspect brake hoses and lines (Including ABS/VSA

®

)

•

Inspect all fluid levels and condition of fluids

•

Inspect exhaust system

#

•

Inspect fuel lines and connections

#

*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and

from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).

*4: Driving in mountainous areas at very low vehicle speeds results in higher transmission temperature.

This requires transmission fluid changes more frequently than recommended by the Maintenance
Minder. If you regularly drive your vehicle under this condition, have the transmission fluid changed at
30,000 miles (48,000 km), then every 25,000 miles (40,000 km).

*5: If you drive regularly in very high temperatures (over 110°F, 43°C), in very low temperatures (under

-20°F, -29°C), replace every 60,000 miles (100,000 km).

*6: Driving in mountainous areas at very low vehicle speeds results in higher level of mechanical (Shear)

stress to fluid. This requires Twin Motor Unit fluid changes more frequently than recommended by the
Maintenance Minder. If you regularly drive your vehicle under this condition, have the Twin Motor Unit
fluid changed at 7,500 miles (12,000 km), then every 15,000 miles (24,000 km).

CODE

Maintenance Sub Items

1

•

Rotate tires

2

•

Replace air cleaner element

*2

•

Replace dust and pollen filter

*3

•

Inspect drive belt

3

•

Replace transmission fluid

*4

4

•

Replace spark plugs

•

Replace timing belt and inspect water pump

*5

•

Inspect valve clearance

5

•

Replace engine coolant

6

•

Replace Twin Motor Unit fluid

*6

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

500

Main

tenan

ce

Reset the maintenance minder information display if you have performed the
maintenance service.

1.

Set the power mode to ON.

2.

Press the

SETTINGS

 button.

3.

Select

Vehicle Settings

 by rotating the interface dial, then press

ENTER

.

4.

Move the interface dial right or left to select

Maintenance Info.

 tab.

5.

Rotate the interface dial to select

Maintenance Reset

, then press

ENTER

.

6.

Move the interface dial down to select

RESET

, then press

ENTER

.

u

A confirmation message appears on the audio/information screen.

7.

Rotate the interface dial to select

Reset

, then press

ENTER

.

u

The displayed maintenance items disappear, and the engine oil life returns to
100%.

To cancel the maintenance reset mode, select

Cancel

, then press

ENTER

.

■

Resetting the Display

1

Resetting the Display

NOTICE

Failure to reset the Maintenance Minder

TM

 display

after a maintenance service results in the system
showing incorrect maintenance intervals, which can
lead to serious mechanical problems.

The dealer will reset the Maintenance Minder

TM



display after completing the required maintenance
service. If someone other than a dealer performs
maintenance service, reset the Maintenance
Minder

TM

 display yourself.

SETTINGS

 Button

Audio/Information Screen

501

Main

tenan

ce

Maintenance Under the Hood

Maintenance Items Under the Hood

Brake Fluid
(Black Cap)

Washer Fluid
(Black Cap)

Engine Oil Dipstick
(Orange)

Engine Oil Fill Cap

12-Volt Battery

Engine Coolant Reserve
Tank

Radiator Cap

Inverter Coolant
Filler Tank

502

uu

Maintenance Under the Hood

u

Opening the Hood

Main

tenan

ce

Opening the Hood

1.

Park the vehicle on a level surface, and set
the parking brake.

2.

Pull the hood release handle under the
driver’s side lower left corner of the
dashboard.

u

The hood will pop up slightly.

3.

Push the hood latch lever (located under
the front edge of the hood to the center) to
the side and raise the hood. Once you have
raised the hood slightly, you can release the
lever.

4.

Lift the hood up most of the way.

u

The hydraulic supports will lift it up the
rest of the way and hold it up.

When closing, lower it to approximately 12
inches (30 cm), then press down firmly with
your hands.

1

Opening the Hood

NOTICE

Do not open the hood when the wiper arms are
raised. The hood will strike the wipers, resulting in
damage to the hood and/or the wipers.

NOTICE

Do not press the engine cover forcibly. This may
damage the engine cover and component parts.

When closing the hood, check that the hood is
securely latched.

If the hood latch lever moves stiffly, or if you can
open the hood without lifting the lever, the latch
mechanism should be cleaned and lubricated.

Pull

Hood Release Handle

Lever

503

uu

Maintenance Under the Hood

u

Engine Compartment Cover

Main

tenan

ce

Engine Compartment Cover

The component parts in the engine compartment are protected by a cover.
You may need to remove the cover when you perform certain maintenance work.
To remove the cover:

1.

Remove the holding clips.

2.

Move the hood seal rubber back and forth to remove it from the fender garnish.

3.

Pull up on the engine compartment cover, remove it from the pins.

1

Engine Compartment Cover

Insert a flat-tip screwdriver, lift and remove the center
pin to remove the clip.

Insert the clip with the center pin raised, and push
until it is flat.

Holding clip

Push until the
pin is flat

Engine Compartment Cover

Clip

Fender Garnish

Hood Seal Rubber

504

uu

Maintenance Under the Hood

u

Recommended Engine Oil

Main

tenan

ce

Recommended Engine Oil

Use a genuine engine oil or another commercial engine oil of suitable type and
viscosity (for the ambient temperature) as shown in the image that follows.

Oil is a major contributor to your engine’s performance and longevity. If you drive
the vehicle with insufficient or deteriorated oil, the engine may fail or be damaged.

*1:Formulated to improve fuel economy.

■

Synthetic oil

You may also use synthetic motor oil if it is labeled with the API Certification Seal
and is the specified viscosity grade.

Genuine Engine Oil

Commercial Engine Oil

•

Genuine Acura Motor Oil

•

Premium-grade 0W-20 detergent oil
with an API Certification Seal on the
container

1

Recommended Engine Oil

Engine Oil Additives
Your vehicle does not require oil additives. In fact,
they may adversely affect the engine performance
and durability.

The following seal indicates the oil is energy
conserving and that it meets the American Petroleum
Institute’s latest requirements.

Ambient Temperature

0W-20

Ambient Temperature

505

uu

Maintenance Under the Hood

u

Oil Check

Main

tenan

ce

Oil Check

We recommend that you check the engine oil level every time you refuel.
Park the vehicle on level ground.
Turn off the power system. You can check the oil level without the engine having
run beforehand. If the engine has been running, wait approximately three minutes
before you check the oil.

1.

Remove the dipstick (orange).

2.

Wipe the dipstick with a clean cloth or
paper towel.

3.

Insert the dipstick back all the way into its
hole.

4.

Remove the dipstick again, and check the
level. It should be between the upper and
lower marks. Add oil if necessary.

1

Oil Check

If the oil level is near or below the lower mark, slowly
add oil being careful not to overfill.

Upper Mark
Lower Mark

506

uu

Maintenance Under the Hood

u

Adding Engine Oil

Main

tenan

ce

Adding Engine Oil

1.

Unscrew and remove the engine oil fill cap.

2.

Add oil slowly.

3.

Reinstall the engine oil fill cap, and tighten
it securely.

4.

Wait for three minutes and recheck the
engine oil dipstick.

1

Adding Engine Oil

NOTICE

Do not fill the engine oil above the upper mark.
Overfilling the engine oil may result in leaks and
engine damage.

If any oil spills, wipe it away immediately. Spilled oil
may damage the engine compartment components.

Engine Oil Fill Cap

507

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

Continued

Main

tenan

ce

Changing the Engine Oil and Oil Filter

You must change the engine oil and oil filter regularly in order to maintain the
engine’s lubrication. The engine may be damaged if they are not changed regularly.

Turning the power system on automatically starts the engine if the following
conditions are met:

•

The SPORT mode is on.

2

SPORT Mode

 P. 393

Change the oil and filter in accordance with the maintenance message on the multi-
information display.

1.

Run the engine until it reaches normal
operating temperature, and then turn the
engine off.

2.

Open the hood and remove the engine oil
fill cap.

3.

Remove the drain bolt and washer from
the bottom of the engine, and drain the
oil into a suitable container.

4.

Remove the oil filter and dispose of the
remaining oil.

5.

Check that the filter gasket is not stuck to
the engine contact surface.

u

If it is stuck, you must detach it.

6.

Wipe away dirt and dust adhering to the
contact surface of the engine block, and
install a new oil filter.

u

Apply a light coat of new engine oil to
the filter gasket.

1

Changing the Engine Oil and Oil Filter

NOTICE

You may damage the environment if you do not
dispose of the oil in a suitable way. If you are
changing the oil by yourself, appropriately dispose of
the used oil. Put the oil in a sealed container and take
it to a recycling center. Do not throw the oil away
into a garbage can or onto the ground.

You will need a special wrench to replace the oil
filter. You can buy this wrench from a dealer.

When installing the new oil filter, follow the
instructions supplied with the oil filter.

Reinstall the engine oil fill cap. Start the engine. The
low oil pressure indicator should go off within five
seconds. If it does not, turn off the engine, and check
your work.

Drain Bolt

Washer

Oil Filter

508

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

Main

tenan

ce

7.

Put a new washer on the drain bolt, then reinstall the drain bolt.

u

Tightening torque:
30 lbf∙ft (40 N∙m, 4.0 kgf∙m)

8.

Pour the recommended engine oil into the engine.

u

Engine oil change capacity (including filter):
4.5 US qt (4.3 L)

9.

Reinstall the engine oil fill cap securely and start the engine.

10.

Run the engine for a few minutes, and then check that there is no leak from the
drain bolt or oil filter.

11.

Stop the engine, wait for three minutes, and then check the oil level on the
dipstick.

u

If necessary, add more engine oil.

509

uu

Maintenance Under the Hood

u

Cooling System

Continued

Main

tenan

ce

Cooling System

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the engine coolant level every time you refuel. Check the
reserve tank first. If it is completely empty, also check the coolant level in the
radiator. Add the engine coolant accordingly.

1. Make sure the engine and radiator are

cool.

2.

Check the amount of coolant in the reserve
tank.

u

If the coolant level is below the

MIN



mark, add the specified coolant until it
reaches the

MAX

 mark.

3.

Inspect the cooling system for leaks.

Specified coolant: Acura Long Life Antifreeze/Coolant Type 2

■

Reserve Tank

1

Cooling System

NOTICE

Genuine Acura engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about -31°F (-35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Acura antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Acura coolant can result in
corrosion, causing the cooling system to malfunction
or fail. Have the cooling system flushed and refilled
with Acura antifreeze/coolant as soon as possible.

Do not add rust inhibitors or other additives to your
vehicle’s cooling system. They may not be compatible
with the coolant or with the engine components.

3

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

Reserve
Tank

MAX

MIN

uu

Maintenance Under the Hood

u

Cooling System

510

Main

tenan

ce

1. Make sure the engine and radiator are

cool.

2.

Remove the engine compartment cover.

2

Engine Compartment Cover

 P. 503

3.

Turn the radiator cap 1/8 turn counter-
clockwise and relieve any pressure in the
cooling system.

4.

Push down and turn the radiator cap
counter-clockwise to remove it.

5.

The coolant level should be up to the base
of the filler neck. Add coolant if it is low.

6.

Put the radiator cap back on, and tighten it
fully.

■

Radiator

1

Radiator

NOTICE

Pour the fluid slowly and carefully so you do not spill
any. Clean up any spills immediately; they can
damage components in the engine compartment.

Radiator Cap

511

uu

Maintenance Under the Hood

u

Inverter Coolant

Main

tenan

ce

Inverter Coolant

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the inverter coolant level every time you refuel.

Have a dealer replace the inverter coolant.

1.

Check the fluid level in the tank.

2.

If the coolant level has dropped below the

MIN

 level, have your vehicle serviced at a

dealer.

u

Only a properly trained technician can
refill the coolant and check the system
for leaks.

Specified coolant: Acura Long Life Antifreeze/Coolant Type 2

■

Checking the Coolant

1

Inverter Coolant

NOTICE

Genuine Acura engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about -31°F (-35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Acura antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Acura coolant can result in
corrosion, causing the cooling system to malfunction
or fail. Have the cooling system flushed and refilled
with Acura antifreeze/coolant as soon as possible.

Do not add rust inhibitors or other additives to your
vehicle’s cooling system. They may not be compatible
with the coolant or with the motor components.

MAX

MIN

Filler
Tank

512

uu

Maintenance Under the Hood

u

Transmission Fluid

Main

tenan

ce

Transmission Fluid

Have a dealer check the fluid level and replace if necessary.

Do not attempt to check or change the automatic transmission fluid yourself.

Brake Fluid

The fluid level should be between the

MIN



and

MAX

 marks on the side of the reserve

tank.

■

Dual Clutch Transmission Fluid

Specified fluid: Acura Automatic Transmission Fluid ATF DW-1

Specified fluid: Acura Heavy Duty Brake Fluid DOT 3

■

Checking the Brake Fluid

1

Dual Clutch Transmission Fluid

NOTICE

Acura ATF DW-1 must not be mixed with other
transmission fluids.

Using a transmission fluid other than Acura ATF
DW-1 may adversely affect the operation and
durability of your vehicle’s transmission, and damage
the transmission.
Any damage caused by using a transmission fluid that
is not equivalent to Acura ATF DW-1 is not covered
by Acura’s new vehicle limited warranty.

1

Brake Fluid

NOTICE

Brake fluid marked DOT 5 is not compatible with your
vehicle’s braking system and can cause extensive
damage.

If the specified brake fluid is not available, you should
use only DOT 3 or DOT 4 fluid from a sealed
container as a temporary replacement.

Using any non-Acura brake fluid can cause corrosion
and decrease the longevity of the system. Have the
brake system flushed and refilled with Acura Heavy
Duty Brake Fluid DOT 3 as soon as possible.

If the brake fluid level is at or below the

MIN

 mark,

have a dealer inspect the vehicle for leaks or worn
brake pads as soon as possible.

MIN

Reserve Tank

MAX

513

uu

Maintenance Under the Hood

u

Refilling Window Washer Fluid

Main

tenan

ce

Refilling Window Washer Fluid

If the washer fluid is low, a message appears on the multi-information display.
Pour the washer fluid carefully. Do not overflow the reservoir.

1

Refilling Window Washer Fluid

NOTICE

Do not use engine antifreeze or a vinegar/water
solution in the windshield washer reservoir.
Antifreeze can damage your vehicle’s paint. A
vinegar/water solution can damage the windshield
washer pump.
Use only commercially available windshield washer
fluid.
Avoid prolonged use of hard water to prevent lime
scale build up.
