61

uu

Airbags

u

Airbag Care

Safe

Driving

Airbag Care

You do not need to, and should not, perform any maintenance on or replace any
airbag system components yourself. However, you should have your vehicle
inspected by a dealer in the following situations:

■

When the airbags have deployed

If an airbag has inflated, the control unit and other related parts must be replaced.
Similarly, once an automatic seat belt tensioner has been activated, it must be
replaced.

■

When the vehicle has been in a moderate-to-severe collision

Even if the airbags did not inflate, have your dealer inspect the following: the driver’s
seat position sensor, weight sensors in the passenger’s seat, front seat belt
tensioners, and each seat belt that was worn during the crash.

■

Do not remove or modify a front seat without consulting a dealer

This would likely disable or affect the proper operation of the driver’s seat position
sensor or the weight sensors in the passenger’s seat. If it is necessary to remove or
modify a front seat to accommodate a person with disabilities, contact an Acura
dealer, or for U.S. vehicles, Acura Client Relations at 1-800-382-2238 and for
Canadian vehicles, Acura Client Services at 1-888-9-ACURA-9.

1

Airbag Care

We recommend against the use of salvaged airbag
system components, including the airbag, tensioners,
sensors, and control unit.

62

Safe

Driving

Child Safety

Protecting Child Passengers

Each year, many children are injured or killed in vehicle crashes because they are
either unrestrained or not properly restrained. In fact, vehicle crashes are the
number one cause of death of children ages 12 and under.

To reduce the number of child deaths and injuries, every state, Canadian province
and territory requires that infants and children be properly restrained when they ride
in a vehicle.

Children should sit properly restrained in a rear seat.

 This is because:

•

An inflating front or side airbag can injure
or kill a child sitting in the front seat.

•

A child in the front seat is more likely to
interfere with the driver’s ability to safely
control the vehicle.

•

Statistics show that children of all sizes and
ages are safer when they are properly
restrained in a rear seat.

1

Protecting Child Passengers

The National Highway Traffic Safety Administration
and Transport Canada recommend that all children
ages 12 and under be properly restrained in a rear
seat. Some states or provinces/territories have laws
restricting where children may ride.

3

WARNING

Children who are unrestrained or
improperly restrained can be seriously
injured or killed in a crash.

Any child too small for a seat belt should be
properly restrained in a child seat. A larger
child should be properly restrained with a
seat belt, using a booster seat if necessary.

63

uu

Child Safety

u

Protecting Child Passengers

Safe

Driving

•

Any child who is too small to wear a seat belt correctly must be restrained in an
approved child seat that is properly secured to the vehicle using either the seat
belt or the lower anchors of the LATCH system.

•

Never hold a child on your lap because it is impossible to protect them in the
event of a collision.

•

Never put a seat belt over yourself and a child. During a crash, the belt would
likely press deep into the child and cause serious or fatal injuries.

•

Never let two children use the same seat belt. Both children could be very
seriously injured in a crash.

•

Do not allow children to operate the doors, windows or seat adjustments.

•

Do not leave children in the vehicle unattended, especially in hot weather when
the inside of the vehicle can get hot enough to kill them. They could also activate
vehicle controls causing it to move unexpectedly.

1

Protecting Child Passengers

To deactivate a lockable retractor, release the buckle
and allow the seat belt to wind up all the way.

To remind you of the passenger’s front airbag
hazards and child safety, your vehicle has warning
labels on the dashboard (U.S. models) and on the
front visors. Please read and follow the instructions
on these labels.

2

Safety Labels

 P. 81

3

WARNING

Allowing a child to play with a seat belt or
wrap one around their neck can result in
serious injury or death.

Instruct children not to play with any seat
belt and make sure any unused seat belt a
child can reach is buckled, fully retracted,
and locked.

64

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

Safety of Infants and Small Children

An infant must be properly restrained in a rear-facing, reclining child seat until the
infant reaches the seat manufacturer’s weight or height limit for the seat, and the
infant is at least one year old.

■

Positioning a rear-facing child seat

Child seats must be placed and secured in a
rear seating position.

When properly installed, a rear-facing child seat may prevent the driver or a front
passenger from moving their seat all the way back, or from locking their seat-back
in the desired position. Make sure that there is no contact between the child seat
and the seat in front of it.

It can also interfere with proper operation of the passenger’s advanced front airbag
system.

2

Airbags

 P. 47

If this occurs, we recommend that you install the child seat directly behind the front
passenger’s seat, move the seat as far forward as needed, and leave it unoccupied.
Or, you may wish to get a smaller rear-facing child seat.

■

Protecting Infants

1

Protecting Infants

Many experts recommend use of a rear-facing seat
for a child up to two years old if the child’s height and
weight are appropriate for a rear-facing seat.

Rear-facing child seats should never be installed in a
forward-facing position.

Always refer to the child seat manufacturer’s
instructions before installation.

Do not allow a front seat to rest against a child seat
installed in a rear seating position:
The weight sensor in the front seat may not correctly
detect the actual weight of the occupant.

3

WARNING

Placing a rear-facing child seat in the front
seat can result in serious injury or death
during a crash.

Always place a rear-facing child seat in the
rear seat, not the front.

Continued

65

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

If a child is at least one year old and has exceeded the weight and height limitations
of a rearward-facing child seat, the child should be properly restrained in a firmly
secured forward-facing child seat until they exceed the weight and height
limitations for the forward-facing child seat.

■

Forward-facing child seat placement

We strongly recommend placing a forward-
facing child seat in a rear seating position.

Placing a forward-facing child seat in the front seat can be hazardous, even with
advanced front airbags that automatically turn the passenger’s front airbag off. A
rear seat is the safest place for a child.

■

Protecting Smaller Children

1

Protecting Smaller Children

Educate yourself about the laws and regulations
regarding child seat use where you are driving, and
follow the child seat manufacturer’s instructions.

3

WARNING

Placing a forward-facing child seat in the
front seat can result in serious injury or
death if the front airbag inflates.

If you must place a forward-facing child
seat in front, move the vehicle seat as far
back as possible, and properly restrain the
child.

uu

Child Safety

u

Safety of Infants and Small Children

66

Safe

Driving

Most child seats are LATCH-compatible (Lower Anchors and Tethers for CHildren).
Some have a rigid-type connector while others have a flexible-type connector. Both
are equally easy to use. Some existing and previously owned child seats can only be
installed using the seat belt. Whichever type you choose, follow the child seat
manufacturer’s use and care instructions including recommended expiration dates
as well as the instructions in this manual. Proper installation is key to maximizing
your child’s safety.

In seating positions and vehicles not equipped with LATCH, a LATCH-compatible
child seat can be installed using the seat belt and a top tether for added security.
This is because all child seats are required to be designed so that they can be secured
with a lap belt or the lap part of a lap/shoulder belt. In addition, the child seat
manufacturer may advise that a seat belt be used to attach a LATCH-compatible seat
once a child reaches a specified weight. Please read the child seat owner’s manual
for proper installation instructions.

■

Important consideration when selecting a child seat

Make sure the child seat meets the following three requirements:

•

The child seat is the correct type and size for the child.

•

The child seat is the correct type for the seating position.

•

The child seat is compliant with Federal Motor Vehicle Safety Standard 213 or
Canadian Motor Vehicle Safety Standard 213.

■

Selecting a Child Seat

1

Selecting a Child Seat

Installation of a LATCH-compatible child seat is
simple.

LATCH-compatible child seats have been developed
to simplify the installation process and reduce the
likelihood of injuries caused by incorrect installation.

Continued

67

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

A LATCH-compatible child seat can be installed in the second row seats. A child seat
is attached to the lower anchors with either the rigid or flexible type of connectors.

1.

Locate the lower anchors under the marks.

■

Installing a LATCH-Compatible Child Seat

1

Installing a LATCH-Compatible Child Seat

3

WARNING

Never attach two child seats to the same
anchor. In a collision, one anchor may not
be strong enough to hold two child seat
attachments and may break, causing
serious injury or death.

Models with second row captain seat

Marks

Marks

Models with second row bench seat

68

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

2.

Place the child seat on the vehicle seat, then
attach the child seat to the lower anchors
according to the instructions that came
with the child seat.

u

When installing the child seat, make sure
that the lower anchors are not
obstructed by the seat belt or any other
object.

Rigid Type

Lower Anchors

Flexible Type

Continued

69

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

Second row captain seat

3.

Put the outer head restraint to its upper-
most position, then route the tether strap
between the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

3.

Put the outer head restraint to its upper
most position, then route the tether strap
outside the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

4.

Tighten the tether strap as instructed by the
child seat manufacturer.

5.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; little movement should be felt.

6.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

2

Protecting Child Passengers

 P. 62

1

Installing a LATCH-Compatible Child Seat

For your child’s safety, when using a child seat
installed using the LATCH system, make sure that the
child seat is properly secured to the vehicle.
A child seat that is not properly secured will not
adequately protect a child in a crash and may cause
injury to the child or other vehicle occupants.

Straight Top Tether Type

Anchor

Other Top Tether Type

Anchor

Tether Strap Hook

Tether Strap Hook

Straight Top Tether Type

Other Top Tether Type

All Types

70

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

Second row bench seat

3.

Put the outer head restraint to its
uppermost position, then route the tether
strap between the head restraint legs, and
secure the tether strap hook to the anchor.
Make sure the strap is not twisted.

3.

Put the outer head restraint to its upper
most position, then route the tether strap
outside the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

3.

Put the center head restraint to its lowest
position, then route the tether strap over
the top of the head restraint and secure the
tether strap hook to the anchor. Make sure
the strap is not twisted.

Anchor

Straight Top Tether Type

Anchor

Other Top Tether Type

Tether Strap Hook

Tether Strap Hook

Outer position
Straight Top Tether Type

Outer position
Other Top Tether Type

Center position

71

uu

Child Safety

u

Safety of Infants and Small Children

Continued

Safe

Driving

4.

Tighten the tether strap as instructed by the
child seat manufacturer.

5.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; little movement should be felt.

6.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

2

Protecting Child Passengers

 P. 62

All positions

uu

Child Safety

u

Safety of Infants and Small Children

72

Safe

Driving

A child seat can be installed with a lap/shoulder belt in any rear seat or, if absolutely
necessary, the front passenger seat.

1.

Place the child seat on the vehicle seat.

2.

Route the seat belt through the child seat
according to the seat manufacturer’s
instructions, and insert the latch plate into
the buckle.

u

Insert the latch plate fully until it clicks.

3.

Slowly pull the shoulder part of the belt all
the way out until it stops. This activates the
lockable retractor.

4.

Let the seat belt retract a few inches and
check that the retractor has switched
modes by pulling on the webbing. It should
not pull out again until it is reset by
removing the latch plate from the buckle.

u

If you are able to pull the shoulder belt
out, the lockable retractor is not
activated. Slowly pull the seat belt all the
way out, and repeat steps 3 – 4.

■

Installing a Child Seat with a Lap/Shoulder Seat Belt

1

Installing a Child Seat with a Lap/Shoulder Seat Belt

A child seat that is not properly secured will not
adequately protect a child in a crash and may cause
injury to the child or other vehicle occupants.

Continued

73

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

5.

Grab the shoulder part of the seat belt near
the buckle, and pull up to remove any slack
from the lap part of the belt.

u

When doing this, place your weight on
the child seat and push it into the vehicle
seat.

6.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; less than one inch of movement
should occur near the seat belt.

7.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

1

Installing a Child Seat with a Lap/Shoulder Seat Belt

To deactivate a lockable retractor, release the buckle
and allow the seat belt to wind up all the way.

uu

Child Safety

u

Safety of Infants and Small Children

74

Safe

Driving

A tether anchorage point is provided behind
each second and third row seating position.
If you have a child seat that comes with a
tether but can be installed with a seat belt, the
tether may be used for additional security.

■

Adding Security with a Tether

1

Adding Security with a Tether

Always use a tether for forward-facing child seats
when using the seat belt or lower anchors.

Models with second row captain seat

Tether Anchorage Points

Tether Anchorage Points

Models with second row bench seat

Tether Anchorage Points

Third row seat

75

uu

Child Safety

u

Safety of Infants and Small Children

Continued

Safe

Driving

■

Using a second row anchor

1.

Put the outer head restraint to its upper-
most position, then route the tether strap
between the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

1.

Put the outer head restraint to its upper
most position, then route the tether strap
outside the head restraint legs, and secure
the tether strap hook to the anchor. Make
sure the strap is not twisted.

Models with second row captain seat

Anchor

Other Top Tether Type

Straight Top Tether Type

Anchor

Tether Strap Hook

Tether Strap Hook

Outer positions
Straight Top Tether Type

Outer positions
Other Top Tether Type

76

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

1.

Put the center head restraint to its lowest
position, then route the tether strap over
the top of the head restraint and secure the
tether strap hook to the anchor. Make sure
the strap is not twisted.

2.

Tighten the tether strap as instructed by the
child seat manufacturer.

Anchor

Models with second row bench seat

Other Top Tether Type

Straight Top Tether Type

Anchor

Tether Strap Hook

Tether Strap Hook

Center position of second row bench seat

All positions
